TYAN S5550 User manual

http://www.tyan.com
1
S5550
Version 1.0
Copyright
Copyright © 2018 MITAC COMPUTING TECHNOLOGY CORPORATION. All rights
reserved. No part of this manual may be reproduced or translated without prior
written consent from MITAC COMPUTING TECHNOLOGY CORPORATION.
Trademark
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following.
TYAN® is a trademark of MITAC COMPUTING TECHNOLOGY CORPORATION.
Intel® is a trademark of Intel® Corporation.
AMI, AMI BIOS are trademarks of AMI Technologies.
Microsoft®, Windows® are trademarks of Microsoft Corporation.
Nuvoton® is a trademark of Nuvoton Technology Corporation.
Notice
Information contained in this document is furnished by MITAC COMPUTING
TECHNOLOGY CORPORATION and has been reviewed for accuracy and reliability
prior to printing. MITAC assumes no liability whatsoever, and disclaims any express
or implied warranty, relating to sale and/or use of TYAN® products including liability
or warranties relating to fitness for a particular purpose or merchantability. MITAC
retains the right to make changes to product descriptions and/or specifications at
any time, without notice. In no event will MITAC be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.

http://www.tyan.com
2

http://www.tyan.com
3
Contents
Before you begin… .................................................................................... 4
Chapter 1: Instruction ................................................................................ 5
1.1 Congratulations ................................................................................. 5
1.2 Hardware Specifications .................................................................... 5
1.3 Software Specifications ................................................................... 15
Chapter 2: Board Installation ................................................................... 17
2.1 Board Image .................................................................................... 18
2.2 Block Diagram ................................................................................. 22
2.3 Mainboard Mechanical Drawing ...................................................... 23
2.4 Board Parts, Jumpers and Connectors ........................................... 24
2.5 Installing the Processor and Heat sink ............................................ 31
2.6 Thermal Interface Material .............................................................. 35
2.7 Tips on Installing Motherboard in Chassis ...................................... 36
2.8 Installing the Memory ...................................................................... 38
2.9 Attaching Drive Cables .................................................................... 41
2.10 Installing Add-In Cards .................................................................. 42
2.11 Connecting External Devices ........................................................ 43
2.12 Installing the Power Supply ........................................................... 45
2.13 Finishing Up ................................................................................... 46
Chapter 3: BIOS Setup ............................................................................. 47
3.1 About the BIOS ................................................................................ 47
3.2 Main Menu ....................................................................................... 49
3.3 Advanced Menu ............................................................................... 50
3.4 Chipset Menu .................................................................................. 90
3.5 Server Management ...................................................................... 102
3.6 Security .......................................................................................... 107
3.7 Boot ............................................................................................... 114
3.8 Save & Exit .................................................................................... 121
Chapter 4: Diagnostics ........................................................................... 123
4.1 Flash Utility .................................................................................... 123
4.2 AMIBIOS Post Code (Aptio) .......................................................... 124
Appendix: Fan and Temp Sensors........................................................ 131
Glossary ................................................................................................... 135
Technical Support .................................................................................. 141

http://www.tyan.com
4
Before you begin…
Check the box contents!
The retail motherboard package should contain the following:
1 x S5550 Motherboard
2 x SATA Cable
1 x Rear IO Shield
1 x S5550 Quick reference guide
IMPORTANT NOTE:
Sales sample may not come with the accessory listed above.
Please contact your sales representative to help order accessory for your
evaluation.

http://www.tyan.com
5
Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN® S5550 motherboard, based on the
Intel® C240 Series Chipsets. The S5550 is designed to support single Intel®
Xeon E-2100, 8th Gen. Core i3, Celeron G4900 and Pentium G5000 Series
Processor, and up to 64GB of UDIMM ECC DDR4 2666/2400 memory.
Leveraging advanced technology from Intel®, the S5550 is capable of offering
scalable 32 and 64-bit computing, high-bandwidth memory design, and lightning-
fast PCI-E bus implementation.
The S5550 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provides the S5550 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN® website at http://www.tyan.com. There you can
find all the information on all TYAN® products as well as all the supporting
documentation, FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
TYAN S5550 (S5550GM2NR)
Processor
Q'ty / Socket Type (1) LGA1151
Supported CPU
Series
Intel Xeon E-2100 series
processors, 8th Gen. Intel Core i3
processors, Intel Celeron G4900
Series Processors and Intel
Pentium Processor G5000 Series
Thermal Design
Power (TDP) Wattage Max up to 95W
Chipset PCH Intel C242
Memory
Supported DIMM Qty (4) DIMM slots
DIMM Type / Speed UDIMM ECC DDR4 2666/2400
Capacity Up to 64GB
Memory channel 2 Channels
Memory voltage 1.2V
Expansion Slots PCI-E
(1) PCI-E Gen3 x16 slot (w/ x16 or
x8 link),
(1) PCI-E Gen3 x8 slot (w/ x8 or x0

http://www.tyan.com
6
link),
(1) PCI-E Gen3 x8 slot (w/ x2 link)
LAN
Q'ty / Port (2) GbE ports,
(1) PHY dedicated for IPMI
Controller Intel I210
PHY Realtek RTL8211E
Storage
SATA
Connector (4) SATA
Controller Intel C242
Speed 6.0 Gb/s
RAID RAID 0/1/10/5
(Intel RSTe)
sSATA
Connector (2) SATA-DOM
Controller Intel C242
Speed 6.0 Gb/s
RAID RAID 0/1/10/5
(Intel RSTe)
Graphic
Connector type D-Sub 15-pin
Resolution Up to 1920x1200 @60Hz
Chipset Aspeed AST2500
Input /Output
USB
(2) USB3.1 Gen2 ports (at rear),
(2) USB3.1 Gen1 ports (at rear),
(2) USB3.1 Gen1 ports (via Cable)
COM (2) headers
VGA (1) D-Sub 15-pin VGA port (at rear)
RJ-45 (2) GbE ports, (1) Dedicated for IPMI
SATA (6) SATA-III connectors
TPM (Optional) TPM Support Please refer to our TPM supported
list.
System Monitoring
Chipset Aspeed AST2500
Fan Total (6) 4-pin headers
Temperature Monitors temperature for CPU &
system environment
Voltage Monitors voltage for CPU, memory,
chipset & power supply
Others Watchdog timer support
Server Management
Onboard Chipset Onboard Aspeed AST2500
AST2500 iKVM 24-bit high quality video

http://www.tyan.com
7
Feature compression, Supports storage over
IP and remote platform-flash, USB
2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size AMI, 32MB
Feature
Hardware Monitor, PXE boot
support, ACPI sleeping states
S3,S4,S5, User Configurable FAN
PWM Duty Cycle, Console
Redirection, ACPI 6.1, SMBIOS
3.1/PnP/Wake on LAN
Physical Dimension
Form Factor Micro ATX
Board Dimension 9.6"x9.6" (243.8x243.8mm)
Regulation
FCC (SDoC) Class A
CE (DoC) Class A
Operating Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Operating System OS supported list Please refer to our AVL support
lists.
Package Contains
Motherboard (1) S5550 Motherboard
Manual (1) Quick Installation Guide
I/O Shield (1) I/O Shield
Cable SATA (2) SATA signal cables
TYAN S5550 (S5550GM4NR)
Processor
Q'ty / Socket Type (1) LGA1151
Supported CPU
Series
Intel Xeon E-2100 series
processors, 8th Gen. Intel Core i3
processors, Intel Celeron G4900
Series Processors and Intel
Pentium Processor G5000 Series
Thermal Design
Power (TDP) Wattage Max up to 95W

http://www.tyan.com
8
Chipset PCH Intel C242
Memory
Supported DIMM Qty (4) DIMM slots
DIMM Type / Speed UDIMM ECC DDR4 2666/2400
Capacity Up to 64GB
Memory channel 2 Channels
Memory voltage 1.2V
Expansion Slots PCI-E
(1) PCI-E Gen3 x16 slot (w/ x16 or
x8 link),
(1) PCI-E Gen3 x8 slot (w/ x8 or x0
link),
(1) PCI-E Gen3 x8 slot (w/ x2 link)
LAN
Q'ty / Port (4) GbE ports +
(1) PHY dedicated for IPMI
Controller Intel I210
PHY Realtek RTL8211E
Storage
SATA
Connector (4) SATA
Controller Intel C242
Speed 6.0 Gb/s
RAID RAID 0/1/10/5
(Intel RSTe)
sSATA
Connector (2) SATA-DOM
Controller Intel C242
Speed 6.0 Gb/s
RAID RAID 0/1/10/5
(Intel RSTe)
Graphic
Connector type D-Sub 15-pin
Resolution Up to 1920x1200 @60Hz
Chipset Aspeed AST2500
Input /Output
USB
(2) USB3.1 Gen2 ports (at rear),
(2) USB3.1 Gen1 ports (at rear),
(2) USB3.1 Gen1 ports (via Cable)
COM (2) headers
VGA (1) D-Sub 15-pin VGA port (at rear)
RJ-45 (4) GbE ports, (1) Dedicated for IPMI
SATA (6) SATA-III connectors
TPM (Optional) TPM Support Please refer to our TPM supported
list.

http://www.tyan.com
9
System Monitoring
Chipset Aspeed AST2500
Fan Total (6) 4-pin headers
Temperature Monitors temperature for CPU &
system environment
Voltage Monitors voltage for CPU, memory,
chipset & power supply
Others Watchdog timer support
Server Management
Onboard Chipset Onboard Aspeed AST2500
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage over
IP and remote platform-flash, USB
2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size AMI, 32MB
Feature
Hardware Monitor, PXE boot
support, ACPI sleeping states
S3,S4,S5, User Configurable FAN
PWM Duty Cycle, Console
Redirection, ACPI 6.1, SMBIOS
3.1/PnP/Wake on LAN
Physical Dimension
Form Factor Micro ATX
Board Dimension 9.6"x9.6" (243.8x243.8mm)
Regulation
FCC (SDoC) Class A
CE (DoC) Class A
Operating Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Operating System OS supported list Please refer to our AVL support
lists.
Package Contains
Motherboard (1) S5550 Motherboard
Manual (1) Quick Installation Guide
I/O Shield (1) I/O Shield
Cable SATA (2) SATA signal cables

http://www.tyan.com
10
TYAN S5550 (S5550AGM2NR-EX)
Processor
Q'ty / Socket Type (1) LGA1151
Supported CPU
Series
Intel Xeon E-2100 series
processors, 8th Gen. Intel Core i3
processors, Intel Celeron G4900
Series Processors and Intel
Pentium Processor G5000 Series
Thermal Design
Power (TDP) Wattage Max up to 95W
Chipset PCH Intel C246
Memory
Supported DIMM Qty (4) DIMM slots
DIMM Type / Speed UDIMM ECC DDR4 2666/2400
Capacity Up to 64GB
Memory channel 2 Channels
Memory voltage 1.2V
Expansion Slots PCI-E
(1)PCI-E Gen3 x16 slot (w/ x16 or x8
link),
(1) PCI-E Gen3 x8 slot (w/ x8 or x0
link)
(1) PCI-E Gen3 x8 slot ( w/ x4 link),
LAN
Q'ty / Port (2) GbE ports,
(1) PHY dedicated for IPMI
Controller Intel I210
PHY Realtek RTL8211E
Storage
SATA
Connector (6) SATA
Controller Intel C246
Speed 6.0 Gb/s
RAID RAID 0/1/10/5
(Intel RSTe)
sSATA
Connector (2) SATA-DOM
Controller Intel C246
Speed 6.0 Gb/s
RAID RAID 0/1/10/5
(Intel RSTe)
Graphic VGA
Connector type (1) D-Sub 15-pin
Resolution Up to 1920x1200
@60Hz

http://www.tyan.com
11
Chipset Aspeed AST2500
Display Port
Connector type (2) Display ports 1.2
Resolution Up to 4096X2304
@60Hz
Chipset Intel Processor
Graphics (pGFX)
Audio
Chipset Realtek ALC892-CG
Feature 2.1 ch
Input /Output
USB (4) USB3.1 Gen2 ports (at rear),
(2) USB3.1 Gen1 ports (via Cable)
COM (2) headers
VGA (1) D-Sub 15-pin VGA port (at rear)
RJ-45 (2) GbE ports,
(1) Dedicated for IPMI
Audio (1) 2x5-pin header,
(1) 3 holes Audio Jack connector
SATA (8) SATA-III connectors
Display port (2) Display ports 1.2
TPM (Optional) TPM Support Please refer to our TPM supported
list.
System Monitoring
Chipset Aspeed AST2500
Fan Total (6) 4-pin headers
Temperature Monitors temperature for CPU &
system environment
Voltage Monitors voltage for CPU, memory,
chipset & power supply
Others Watchdog timer support
Server Management
Onboard Chipset Onboard Aspeed AST2500
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage over
IP and remote platform-flash, USB
2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size AMI, 32MB
Feature
Hardware Monitor, PXE boot
support, ACPI sleeping states
S3,S4,S5, User Configurable FAN

http://www.tyan.com
12
PWM Duty Cycle, Console
Redirection, ACPI 6.1, SMBIOS
3.1/PnP/Wake on LAN
Physical Dimension
Form Factor Micro ATX
Board Dimension 9.6"x9.6" (243.8x243.8mm)
Operating Environment
Operating Temp. 0° C ~ 55° C (32° F~ 131° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Regulation
FCC (SDoC) Class A
CE (DoC) Class A
Operating System OS supported list Please refer to our AVL support
lists.
Package Contains
Motherboard (1) S5550 Motherboard
Manual (1) Quick Installation Guide
I/O Shield (1) I/O Shield
Cable SATA (2) SATA signal cables
TYAN S5550 (S5550AGM4NR-EX)
Processor
Q'ty / Socket Type (1) LGA1151
Supported CPU
Series
Intel Xeon E-2100 series
processors, 8th Gen. Intel Core i3
processors, Intel Celeron G4900
Series Processors and Intel
Pentium Processor G5000 Series
Thermal Design
Power (TDP) Wattage Max up to 95W
Chipset PCH Intel C246
Memory
Supported DIMM Qty (4) DIMM slots
DIMM Type / Speed UDIMM ECC DDR4 2666/2400
Capacity Up to 64GB
Memory channel 2 Channels
Memory voltage 1.2V
Expansion Slots PCI-E (1) PCI-E Gen3 x16 slot (w/ x16 or
x8 link),

http://www.tyan.com
13
(1) PCI-E Gen3 x8 slot (w/ x8 or x0
link),
(1) PCI-E Gen3 x8 slot ( w/ x4 link)
LAN
Q'ty / Port (4) GbE ports +
(1) PHY dedicated for IPMI
Controller Intel I210
PHY Realtek RTL8211E
Storage
SATA
Connector (6) SATA
Controller Intel C246
Speed 6.0 Gb/s
RAID RAID 0/1/10/5
(Intel RSTe)
sSATA
Connector (2) SATA-DOM
Controller Intel C246
Speed 6.0 Gb/s
RAID RAID 0/1/10/5
(Intel RSTe)
Graphic
VGA
Connector type (1) D-Sub 15-pin
Resolution Up to 1920x1200
@60Hz
Chipset Aspeed AST2500
Display Port
Connector type (2) Display ports 1.2
Resolution Up to 4096X2304
@60Hz
Chipset Intel Processor
Graphics (pGFX)
Audio
Chipset Realtek ALC892-CG
Feature 2.1 ch
Input /Output
USB (4) USB3.1 Gen2 ports (at rear),
(2) USB3.1 Gen1 ports (via Cable)
COM (2) headers
VGA (1) D-Sub 15-pin VGA port (at rear)
RJ-45 (4) GbE ports,
(1) Dedicated for IPMI
Audio (1) 2x5-pin header,
(1) 3 holes Audio Jack connector
SATA (8) SATA-III connectors
Display port (2) Display ports 1.2

http://www.tyan.com
14
TPM (Optional) TPM Support Please refer to our TPM supported
list.
System Monitoring
Chipset Aspeed AST2500
Fan Total (6) 4-pin headers
Temperature Monitors temperature for CPU &
system environment
Voltage Monitors voltage for CPU, memory,
chipset & power supply
Others Watchdog timer support
Server Management
Onboard Chipset Onboard Aspeed AST2500
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage over
IP and remote platform-flash, USB
2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size AMI, 32MB
Feature
Hardware Monitor, PXE boot
support, ACPI sleeping states
S3,S4,S5, User Configurable FAN
PWM Duty Cycle, Console
Redirection, ACPI 6.1, SMBIOS
3.1/PnP/Wake on LAN
Physical Dimension
Form Factor Micro ATX
Board Dimension 9.6"x9.6" (243.8x243.8mm)
Regulation
FCC (SDoC) Class A
CE (DoC) Class A
Operating Environment
Operating Temp. 0° C ~ 55° C (32° F~ 131° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Operating System OS supported list Please refer to our AVL support
lists.
Package Contains
Motherboard (1) S5550 Motherboard
Manual (1) Quick Installation Guide
I/O Shield (1) I/O Shield

http://www.tyan.com
15
Cable SATA (2) SATA signal cables
S5550 SKU Differences
SKU Name S5550AGM4NR-EX S5550AGM2NR-EX S5550GM4NR S5550GM2NR
SATA 8 8 6 6
Display Port 2 2 0 0
I210 LAN 4 2 4 2
Audio Yes Yes No No
1.3 Software Specifications
For OS (operation system) support, please check with TYAN® support for latest
information.

http://www.tyan.com
16
NOTE

http://www.tyan.com
17
Chapter 2: Board Installation
You are now ready to install your motherboard.
How to install our products right… the first time
The first thing you should do is reading this user’s manual. It contains important
information that will make configuration and setup much easier. Here are some
precautions you should take when installing your motherboard:
(1) Ground yourself properly before removing your motherboard from the
antistatic bag. Unplug the power from your computer power supply and
then touch a safely grounded object to release static charge (i.e. power
supply case). For the safest conditions, MITAC recommends wearing a
static safety wrist strap.
(2) Hold the motherboard by its edges and do not touch the bottom of the
board, or flex the board in any way.
(3) Avoid touching the motherboard components, IC chips, connectors,
memory modules, and leads.
(4) Place the motherboard on a grounded antistatic surface or on the antistatic
bag that the board was shipped in.
(5) Inspect the board for damage.
The following pages include details on how to install your motherboard into your
chassis, as well as installing the processor, memory, disk drives and cables.
Caution!
1. To avoid damaging the motherboard and associated
components, use torque force within the range 5~7
kgf/cm (4.35 ~ 6.09 lb/in) on each mounting screw
for motherboard installation.
2. Do not apply power to the board if it has been
damaged.

http://www.tyan.com
18
2.1 Board Image
S5550AGM4NR-EX
This picture is representative of the latest board revision available at the time of
publishing. The board you receive may not look exactly like the above picture.

http://www.tyan.com
19
S5550AGM2NR-EX

http://www.tyan.com
20
S5550GM4NR
