Tyco DSC WK141 User manual

D-306041 WK141 Installation Instructions 1
WK141
Portable Remote Wireless 2-Way Keypad
User’s Guide
1. INTRODUCTION
WK141 is a 2-way PowerG wireless keypads for the PowerMaster family control
panels. The WK141 also includes a built-in proximity RFID tag reader. The keypad
enables most common everyday user functions:
Arm and Disarm the alarm system.
Initiate Emergency, Fire and Panic alarms.
Control X-10 devices and PGM output (not to be enabled in UL Listed product).
Perform one of the AUX (auxiliary) predefined functions.
Review system Status.
When authorization is required, for example, to arm or disarm the system, the user
can enter his PIN Code via the built-in numerical keypad or alternatively present a
valid proximity tag to the built-in tag reader located at "N" in Figure 1.
In addition, the WK141 keypad supports panels featuring Partitions. Partitioning
allows you to have up to three controllable areas; each partition can be armed and
disarmed independently regardless of the status of the other two partitions by the
same or different users (see buttons marked "E" in Figure 1).
The keypads can be wall mounted using the supplied bracket or be used as
portable units. For compliance with various international standards, the keypads
are equipped with two tamper switches that can be configured to detect when the
cover of the battery compartment is removed or when the unit is removed from its
mounting bracket.
Note: For UL Listed Product, unit is not intended to be portable.
Other features of the WK141 keypad include:
Status, alarm memory, trouble and Ready / Not-Ready indications.
Automatic reporting of low battery voltage.
Keypad back lighting.
Exit/entry beeps
Tag reader can also be used to enroll proximity tags into the panel.
Long-life 4-5 years battery life expectancy (for typical use), 3 VDC lithium battery.
Note: For UL Listed product, the proximity feature may only be used to arm or
disarm the system.
Note: For UL Listed product, Model WK141 is for Supplemental Use only.
A. ARM HOME H. AUX / ENROLLMENT
B. ARM AWAY I. EMERGENCY ALARM
C. DISARM J. FIRE ALARM
D. X-10 / PGM K. PANIC ALARM
E. PARTITION SELECTION L. BUZZER INDICATOR
F. ARM INSTANT M. LED INDICATOR
G. STATUS / ESCAPE N. TAG READER
Figure 1 - External View
2. INSTALLATION
2.1 Mounting and Battery Replacement
1. Drill 2 holes in mounting surface, insert wall anchors and fasten the bracket with 2 screws.
2. Place the "Visual Indications" sticker within the frame.
3. Slide the keypad into the bracket.
A. Magnet (activates back tamper when bracket is removed from the wall).
Figure 2 - Mounting
1. Slide out the cover.
2. Replace the battery (verifyproper polarity) and close the cover.
A. Battery compartment tamper switch
Caution!
Risk of explosion if battery is replaced by an incorrect type. Dispose of
used battery according to manufacturer's instructions.
Figure 3 - Battery Replacement
2.2. ENROLLMENT
Refer to the PowerMaster panel's Installer Guide and follow the procedure under the "02:ZONES/DEVICES"option of the Installer Menu a general description of
which is provided in the following flow chart.
Step 1
Step 2
Step 3
Step 4
Enter the Installer menu and select
“02:ZONES/DEVICES”
Select "ADD NEW DEVICE"
See Note 1
Enroll the keypad by holding the
button and release it as soon as the
yellow LED lights. Alternatively, enter
the device ID (printed on the back of
the keypad)
Select the desired keypad
Number for the new keypad
See Note 2





B
A
C
D
E
F
G
H
IJ
K
L
M
N
3
A
1
2
21
A
02:ZONES/DEVICES
ADD NEW DEVICES
ENTR ID:XXX-XXXX
ENROLL NOW or
ID No. 370-XXXX
K06:Keypad
MODIFY DEVICES

2 D-306041 WK141 Installation Instructions
Step 5
Step 6
Step 7
Step 8
Configure Location parameter
Enter PARTITIONS.
See Note 3
Assign partitions to the keypad by
pressing the , and
buttons on the panel
Continue to section 2.3



means scroll and select
Notes:
1. If the keypad is already enrolled, you can configure the keypad parameters and assign partitions via the “Modify Devices” option –see Step 2.
2. The first three digits of the Device ID No. "371-XXXX" refer to WK141.
3. PARTITIONS will appear only if PARTITIONING was previously enabled in the panel (for further details, see "Partitioning" in the PowerMaster Installer Guide).
2.3. Configuring the Keypad Parameters
Enter the menu and follow the configuration instructions for the WK141 keypad as described in the following table.
Option
Configuration Instructions
Here you determine which of the two tampers (i.e. battery compartment cover or all of the tampers) will be active.
Optional settings: Disabled (default); all tampers; Battery cover.
Note: For UL Listed product, set to “all tampers”.
Here you determine whether or not the control panel will monitor supervision messages sent by the keypad or not (see Note).
Optional settings: ON (default) or OFF.
Notes:
1. Every 5 minutes the keypad performs a communication test session with the control panel (i.e. "Supervision signal) to check the
integrity and quality of the Radio link. If the keypad does not report a supervision signal at least once within a predefined time
window, a “MISSING” trouble alert is initiated. Therefore, if you intend to take the keypad out of the protected premises you must
switch the Supervision OFF to avoid the trouble alert.
2. For UL Listed product, set to “ON”.
Here you determine whether the keypad will sound the exit and entry beeps, or not, or whether the keypad will sound the beeps only
when the system is armed AWAY and not when it is armed HOME.
Optional settings: ON; OFF (default) and OFF @ Home.
Note: For UL Listed product, the sounder cannot be used as the only annunciator for the system.
Here you select the function of the (AUX) button . Four options are offered:
Status: Control panel displays and announces (applies only to control panels that support voice) the system status.
Stop Beeps: Pressing the AUX button will cause the control panel and other devices in the system (such as keypads, sirens etc.) to
stop beeping (for example during exit or entry delays).
Skip exit delay: Pressing the AUX button will immediately stop the exit delay.
PGM: Pressing the AUX button will activate the PGM output. The functions of the PGM output is configured at the corresponding
sections of the control panel’s Installer Guide (see “OUTPUTS” menu) and User Guide (see “SCHEDULER ” menu).
Not used: No function assigned to AUX button.
Optional settings: Status (default); Stop Beeps; Skip exit delay; PGM; and Not Used.
Note: PGM not to be enabled in UL Listed Product.
2.4 Enrollment of Proximity Tags
The built-in proximity tag reader of the WK141 can be also used to enroll proximity tags into the PowerMaster panel via the keypad as described in the corresponding
section of the control panel's User or Installer Guide, or as explained in the general description provided below.
Each proximity tag corresponds to its User Code. Therefore, be sure that a corresponding User Code is programmed for each enrolled proximity tag (code "0000" is
not allowed). For example, "T02:Tag <Prox>" must be assigned to User Code 2 and "T14:Tag <Prox>" must be assigned to User Code 14. Partition authorization of
each proximity tag is identical to that of the corresponding User Code. For example, if User Code 3 is set to Partitions 1 and 3, "T03:Tag <Prox>" will also be set to
Partitions 1 and 3. Means scroll and select
Step 1
Step 2
Step 3
Step 4
Enter the Installer menu of the control
panel and select the
“02:ZONES/DEVICES”
Select the "ADD NEW DEVICES" option
When "ENROLL NOW"is displayed,
press the AWAY button ( ) on
the WK141 keypad - the AWAY button
begins to blink
Present the proximity tag tothe WK141
keypad within the timeout period. If the
enrollment is successful the display
reads "DEVICE ENROLLED"and then
shows the device details




K06.LOCATION
K06.PARTITIONS
K06:P1P2 P3
K06.DEV SETTINGS
DEVICE SETTINGS
TAMPERS
SUPERVISION
EXIT-ENTRY Beeps
BUTTON ()
02.ZONES/DEVICES
MODIFY DEVICES
ADD NEW DEVICES
ENROLL NOW
T01:Tag (Prox)
DEVICE ENROLLED

D-306041 WK141 Installation Instructions 3
3. USING THE KEYPAD
3.1 Arming and Disarming the System
Step
Basic Arming
User Actions
Keypad & Panel Response
1
Select a PARTITION (1)
(when Partition is enabled)
or or
The selected button lights.
2
Arm AWAY
The selected button starts blinking and prompts you
to enter your "User Code" or present your Tag. See
step 3.
Arm HOME
Disarm (OFF)
Quick arm AWAY (2)
(2 sec.)
The keypad's LED blinks red once to indicate
transmission of the arming command to the control
panel. The control panel's response is then
indicated on the keypad via the LED and the buzzer
–see “Panel Response to Keypad Commands”
section 3.5 below.
Quick arm HOME (2)
(2 sec.)
3
Enter USER CODE or present
Proximity TAG. (3) (4)
[USER CODE] or [present TAG]
[DURESS CODE] (2580 by default) (5)
4
INSTANT
(After arming HOME/ AWAY) (6) (8)
The keypad's LED blinks red once to indicate
transmission of the command to the control panel.
The control panel's response is then indicated on
the keypad via the LED and the buzzer –see
“Panel Response to Keypad Commands”in
section 3.5 below.
LATCHKEY
(After arming AWAY) (7) (8)
Notes:
1. If Partition is disabled at the control panel, skip Step 1.
2. The Quick arm functions only if enabled at the control panel.
3. If Quick arm is selected in Step 2, skip Step 3.
4. (a) Pressing a non-valid code causes the control panel to reject the transmission.
(b) If the action is not completed while the selected arming button is blinking, the desired function will not be executed.
5. To use the Duress Code refer to the respective section in the control panel’s User Guide.
6. Press the INSTANT button within maximum 8 seconds timeout period after completing the previous step. This will delete the entry delay forthe current arming session.
7. Press the AWAY button TWICE within maximum 8 seconds timeout period after completing the previous step. To use the LATCHKEY arming refer to the
respective section in the control panel’s User Guide.
8. You can perform the LATCHKEY and INSTANT functions, one after the other. The order is not important.
9. Latchkey Arming is supplemental in UL installations.
3.2 Automation
The functions of the PGM and X-10 outputs is configured at the corresponding sections of the control panel’s Installer Guide (see “OUTPUTS” menu) and User Guide
(see “SCHEDULER ” menu).
Note: Automation not to be enabled in UL Listed Product.
Output Function
Actions
Response
X-10 or PGM device ON
[PGM 00]or [X-1001 to 15]
The keypad's LED blinks red once to
indicate transmission of the command to
the control panel. The control panel's
response is indicated on the keypad via
the LED and the buzzer –see “Panel
Response to Keypad Commands”in
section 3.5 below.
X-10 or PGM device OFF
[PGM 00]or [X-1001 to 15]
X-10 or PGM device TOGGLE
[PGM 00]or [X-1001 to 15]
Note: Long press (more than 2 sec.) of the button initiates the X-10 function. Short press of the button initiates the PGM function.
3.3 Initiating Alarms
Alarm
Actions
Response
Emergency alarm
(2 sec.)
See section 3.5.
Fire alarm
(2 sec.)
See section 3.5.
Panic alarm
(2 sec.)
See section 3.5.
Notes:
1. For SIA CP01 compliance, the Emergency and Fire buttons are disabled. In case of Emergency or Fire, the two Panic alarm buttons should be used.
2. For UL Listed product, Emergency is for ancillary use only.
3.4 Other Functions
Function
User Actions
Response
AUX Function (1)
See section 3.5.
STATUS indication
See section 3.6
Note: The function of the AUX button is configured in section 2.3 above
3.5 Panel Response to Keypad Commands
When executing a command, the keypad's LED ("M" in Figure 1) blinks red once to indicate transmission of the command to the control panel. If the operation is
successfully completed, the green LED lights momentarily and a "happy tune" is heard. If the operation fails or cannot be completed, for example, when the
system is "not ready", the red LED lights steadily and a "sad tune" is heard. If a trouble or alarm memory condition exists in the system, or when the system is not-
ready to arm, the Status button (G in Figure 1) flashes for several seconds prompting you to press it to retrieve the status information from the control panel.

4 D-306041 WK141 Installation Instructions
Panel Response
Buzzer Indication
LED Indication
Problem Indication
Success: Operation is
successfully completed
Happy (success) beep
Momentary GREEN
If the panel is Not-Ready or if a Trouble or Alarm
Memory conditions exit, the Status button (G in Fig.1)
flashes for few seconds. To identify the reason, press
the button to retrieve the Status indication - refer to
section 3.6 for further information.
Fail: Operation failed
Sad (failure) beep
Momentary RED
No communication: Control
panel does not respond.
None
None
3.6 Retrieving and Displaying System Status
Step
Status Request
User Actions
Keypad & Panel Response
1
Request Status
The keypad's LED blinks red once to indicate transmission of the status
request to the control panel.
2
Look at status
/ /
The panel's status is indicated on the keypad via the LED and the Arming
Keys and Partition Keys –see below
Arming Status
The system Arming Status is indicated via the respective arming/disarming buttons' LED that light for several seconds. For example, if the system is
armed AWAY, the button will light and if the system is disarmed, the button will also light.
If Partition is enabled, the arming Status of the first partition is displayed concurrently with the corresponding first partition button LED ,then the second
partition Status is displayed concurrently with the second partition button LED and then the third partition Status is similarly displayed.
Indication of Ready/Not Ready & Trouble Status
The Ready/Not Ready, Alarm Memory and Trouble indications are provided via the keypad LED (see "M" in Figure 1) as follows:
LED Indication [1]
System Status [2]
What it Means
Green
System READY
You can arm the system
Red
System NOT- READY
One of the zones is not secured. You can not arm the system before the zone is secured or bypassed. [3]
Yellow
Trouble or Alarm Memory
There was an alarm or there is trouble situation that need to be reviewed and cleared. [3]
Yellow blinking
Keypad Low-Battery
The battery of the keypad must be replaced as shown in section 2.1.
[1] The LED indication is displayed after the first red blink indicating the status request.
[2] If there is more than one status indication, the LED will display them consecutively.
[3] See respective sections in the control panel's User and Installer's Guides.
APPENDIX A: SPECIFICATIONS
Frequency Band (MHz)
Europe and rest of world: 433-434, 868-869 USA: 912-919**
**Note: For UL Listed product, enable this frequency band.
Operating Temperature
0C to 49C (32F to 120F)
Dimensions (LxWxD)
127x70x24mm (5 x 2-3/4 x 31/32 in)
Communication Protocol
PowerG
Relative humidity
93%
Battery type
Battery Life Expectancy
3V, CR123A type. (GP)
4-5 years* (for typical use).
Weight (including
battery)
107g (3.4 oz)
Low Battery Threshold
2.1 V
Color
White
* 3 years+, if used with a proximity tag
APPENDIX B: COMPLIANCE WITH STANDARDS
Compliance with Standards
Europe: EN 300220-1, EN 50130-4, EN 50131-1 Grade 2 Class II, EN 50131-3, EN 301489.
The WK141 is compatible with the RTTE requirements - Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999
and EN50131-1 Grade 2 Class II.
Certified by Norwegian accredited certification body Applica Test & Certification AS in accordance with EN 50131-3, EN 50131-6, EN
50131-5-3, EN 50130-4, and EN 50130-5.
Applica T&C has certified only the 868 MHz variant of this product.
USA: CFR 47 part 15. Canada: RSS 210. RFID Tags: ISO-18000-2 (125 kHz)
UK: This product is suitable for use in systems installed to conform to PD6662:2010 at Grade 2 and environmental class 2. DD243
and BS8243
ThePower G peripheral devices have two- way communication functionality, providing additional benefits as described in the technical
brochure. This functionality has not been tested to comply with the respective technical requirements and should therefore be considered
outside the scope of the product’s certification.
EN 50131-1 Security Grade
According to EN 50131-1:2006 and A1:2009, this equipment can be applied in installed systems up to and including Security Grade 2.
EN 50131-1 Environmental Class
Class II
This device complies with FCC Rules Part 15 and with Industry Canada licence-exempt RSS standard(s).
This equipment complies with FCC and IC RF radiation exposure limits set forth for an uncontrolled environment.
RFID Tags: ISO-18000-2 (125 kHz)
Operation is subject to two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference that may be received or that may cause undesired operation.
The digital circuit of this device has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in residential installations. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio and
television reception. However, there is no guarantee that interference will not occur in a particular installation. If this
device does cause such interference, which can be verified by turning the device off and on, the user is
encouraged to eliminate the interference by one or more of the following measures:
–Re-orient or re-locate the receiving antenna.
–Increase the distance between the device and the receiver.
–Connect the device to an outlet on a circuit different from the one which supplies power to the receiver.
–Consult the dealer or an experienced radio/TV technician.
Changes or modifications not expressly approved by Visonic Ltd. could void the user's authority to operate the
equipment.
WARNING! To comply with FCC and IC RF exposure compliance requirements,
the device should be located at a distance of at least 20 cm from all persons
during normal operation. The antennas used for this product must not be co-
located or operated in conjunction with any other antenna or transmitter.
This device complies with FCC Rules Part 15 and with Industry Canada
license-exempt RSS standard(s). Operation is subject to two conditions: (1)
This device may not cause harmful interference, and (2) this device must
accept any interference that may be received or that may cause undesired
operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
W.E.E.E. Product Recycling Declaration
For information regarding the recycling of this product you must contact the company from which you orignially purchased it. If you are discarding this product and not
returning it for repair then you must ensure that it is returned as identified by your supplier. This product is not to be thrown away with everyday waste.
Directive 2002/96/EC Waste Electrical and Electronic Equipment.

D-306041 WK141 Installation Instructions 5
LIMITED WARRANTY
Digital Security Controls (DSC) warrants that for a period of 12 months from the
date of purchase, the product shall be free of defects in materials and
workmanship under normal use and that in fulfillment of any breach of such
warranty, DSC shall, at its option, repair or replace the defective equipment upon
return of the equipment to its repair depot. This warranty applies only to defects
in parts and workmanship and not to damage incurred in shipping or handling, or
damage due to causes beyond the control of Digital Security Controls such as
lightning, excessive voltage, mechanical shock, water damage, or damage
arising out of abuse, alteration or improper application of the equipment.
Digital Security Controls (DSC) warrants that for a period of 12 months from
the date of purchase, the product shall be free of defects in materials and
workmanship under normal use and that in fulfillment of any breach of such
warranty, DSC shall, at its option, repair or replace the defective equipment
upon return of the equipment to its repair depot. This warranty applies only to
defects in parts and workmanship and not to damage incurred in shipping or
handling, or damage due to causes beyond the control of Digital Security
Controls such as lightning, excessive voltage, mechanical shock, water
damage, or damage arising out of abuse, alteration or improper application of
the equipment.

6 D-306041 WK141 Installation Instructions
©2016 Tyco International Ltd. and its Respective Companies. All Rights Reserved.
Toronto, Canada www.dsc.com
Printedin Israel
D-306041 Rev 01 (02/16)
