Tyco DSC WK160 User manual

D-306042 WK160 User’s Guide 1
WK160
Touch Screen Keyprox
User’s Guide
Table of Contents
1. INTRODUCTION.............................................................................................................2
2. INSTALLATION...............................................................................................................3
2.1 Inserting Battery.....................................................................................................3
2.2 Closing Battery Compartment Cover.....................................................................3
2.3 Wall Mounting Options...........................................................................................4
2.4 Enrolling the WK160..............................................................................................6
2.5 Configuring the WK160 Parameters......................................................................6
2.6 Enrolling Proximity Tags........................................................................................8
3. USING THE TOUCH SCREEN KEYPROX .....................................................................9
3.1 Arming and Disarming the System ........................................................................9
3.2 Initiating Alarms ...................................................................................................10
3.3 System Status and Indications.............................................................................10
3.4 Bypassing Zones.................................................................................................14
3.5 Controlling Home Automation Devices ................................................................14
3.6 Other Functions...................................................................................................15
APPENDIX A: SPECIFICATIONS.....................................................................................15
APPENDIX B: COMPLIANCE WITH STANDARDS..........................................................15

2 D-306042 WK160 User’s Guide
1. INTRODUCTION
WK160 is a 2-way wireless PowerG touch screen keyprox for the WP8010/30 family control
panels. The WK160 enables most common everyday user functions:
Arm and Disarm the alarm system.
Initiate Emergency, Fire and Panic alarms.
Control home automation devices.
Review system status.
Perform programmable predefined functions.
WK160 is operated by proximity tags. When authorization is required the user presents a
valid proximity tag to the built-in tag reader
In addition, the WK160 supports panels featuring Partitions. Partitioning allows you to select
up to three controllable areas; each partition can be armed and disarmed independently
regardless of the status of the other two partitions by the same or different users (see keys
marked "7" in the "Icon and Key Indications" Figure).
The WK160 can be wall-mounted using the supplied bracket or be used as a portable unit.
For compliance with various international standards, the WK160 is equipped with two tamper
switches that can be defined to detect when the cover of the battery compartment is removed
or when the unit is removed from its mounting bracket.
Note: For UL Listed Product, unit is not intended to be portable.
Other features of the WK160 include:
Easy-to-use intuitive graphical touch user interface
Proximity-tag operated, no need for user to remember codes
Allows all users' every day actions
Panel can be installed in hidden location
8 or 32 per system (depending on the control panel), suitable for any installation
Status, Alarm, Memory, Trouble and Ready indications.
Automatic reporting of low battery.
Back lighting.
Exit/entry beeps
Enrollment of proximity tags directly into control panel or via tag reader.
Long battery life expectancy (for typical use).
Note: For UL Listed product, the proximity feature may only be used to arm or disarm the
system.

D-306042 WK160 User’s Guide 3
2. INSTALLATION
2.1 Inserting Battery
CAUTION!
Risk of explosion if
battery is replaced
by an incorrect type.
Dispose of used
battery according to
manufacturer's
instructions.
Figure 1 –Battery Insertion
Insert two 1.5V batteries in each slot while ensuring battery polarity.
2.2 Closing Battery Compartment Cover
Portable Installation (Using Battery Cover without Tamper Hole)
Figure 2 - Battery Cover Mounting (part a)
1
2

4 D-306042 WK160 User’s Guide
Wall-mounted Installation (Using Battery Cover without Tamper Hole –
see "A")
Figure 3 - Battery Cover Mounting (part b)
A. Tamper
B. DC Power Connection
2.3 Wall Mounting Options
The WK160 unit mounting options are illustrated in the following drawings.
Wall Mounting
Figure 4a –Wall Mounting
1. Drill 3 mounting holes
3. Attach the unit to the bracket
2. Position the bracket and secure with 3 screws
4. Secure the unit with the screw

D-306042 WK160 User’s Guide 5
Wall Mounting with External Electrical Connector
Figure 4b –Wall Mounting with External Electrical Connector
1. Secure bracket with 2 screws as shown in the two drawings above.
2. Attach the unit to the bracket.
3. Secure the unit with the screw

6 D-306042 WK160 User’s Guide
2.4 Enrolling the WK160
Refer to the WP8010/30 panel's Installer Guide and follow the procedure under the
"02:ZONES/DEVICES" option of the Installer Menu. A flowchart of the procedure is provided
below.
Step
Action
LCD Display
1
Enter the Installer menu and select
“02:ZONES/DEVICES”

2
Select "ADD NEW DEVICE" Option
See Note


3
Enroll the device or enter the 7-digit
code that appears on the device's
sticker.

4
Select the desired keyprox Number

5
Configure the settings of the device
6
Configure the Keyprox
See section 2.5
means scroll and select
Note: If the WK160 is already enrolled, you can configure the WK160 parameters via the
“Modify Devices” option – see Step 2.
2.5 Configuring the WK160 Parameters
Enter the main menu in the WP8010/30 control panel, choose the
number of the touch screen keyprox device to configure and follow the configuration
instructions for the WK160 touch screen keyprox.
Option
Configuration Instructions
Define the active tamper.
Option settings:Disabled (default); All Tampers and Battery
Cover.
Note: For UL Listed product, set to “All Tampers”.
Define whether or not the control panel will monitor supervision
messages sent by the keyprox (see Note).
Option settings:ON (default) or OFF.
02.ZONES/DEVICES
MODIFY
DEVICES
ADD NEW
DEVICES
ENTR ID:XXX-XXXX
ENROLL NOW
or
ID No. 374-XXXX
K07: LCD Keypad
K07.DEV SETTINGS
K07.DEV SETTINGS
TAMPERS
SUPERVISION

D-306042 WK160 User’s Guide 7
Notes:
1. Every 5 minutes the keyprox performs a communication test
session with the control panel (i.e. "Supervision signal) to check
the integrity and quality of the Radio link. If the keyprox does
not report a supervision signal at least once within a predefined
time, a “MISSING” trouble alert is initiated. Therefore, if you
take the keyprox out of the protected premises, switch the
Supervision OFF to avoid the trouble alert.
2. For UL Listed product, set to “ON”.
Define whether or not the keyprox will sound the exit and entry
beeps or whether the keyprox will sound the beeps only when the
system is armed AWAY and not when it is armed HOME.
Option settings: ON; OFF (default) and OFF @ Home.
Under trouble conditions, the panel sounder emits a series of 3
short reminder beeps once per minute. Here you determine
whether to enable or disable this reminder beeping or just disable
it at night. The “night” hours are defined in the factory but are
usually from 8 PM (20:00) until 7:00 AM.
Option settings: ON; OFF (default) and OFF @ night.
Note: For UL Listed product, set to “ON”.
Define the volume level of the sounder.
Option settings: Medium (default); Maximum and Minimum
Note: For UL Listed product, the sounder cannot be used as the
only annunciator for the system.
Enabling the function will turn off the display if no key is pressed
for more than several seconds.
Options settings: Disabled (default) and Enabled.
Notes:
1) When the "SCREEN SAVER" menu on the WP8010/30
control panel is configured as "refresh by key", touching the
right side of the screen on the WK160 device will return the
device to normal display (refer to the WP8010/30 Installer
Guide, section 3.5.6).
2) When the "SCREEN SAVER" menu on the WP8010/30
control panel is configured as "refresh by code", touching the
right side of the screen on the WK160 device and then
presenting the proximity tag to the tag reader will return the
device to normal display (refer to the WP8010/30 Installer
Guide, section 3.5.6).
Note: For UL Listed product, set to “Disabled”.
Select the function of the (AUX) key when pressed:
Not used: No function assigned to AUX key.
Status: Control panel displays and announces* the system status.
Stop Beeps: Control panel and other devices in the system (such
EXIT-ENTRY Beeps
Trouble Beeps
Sounder Volume
Screen Saver
BUTTON ()

8 D-306042 WK160 User’s Guide
as keyproxs, sirens etc.) will stop beeping during the exit delay.
Skip exit delay: Stop the exit delay immediately.
X-10 (PGM): Activate the appliance controlled by the chosen X-10
unit(s) or the device wired to the PGM output. For more details on
configuring the X-10/PGM output functions, see the corresponding
sections of the control panel’s Installer Guide (“OUTPUTS” menu)
and User Guide (“SCHEDULER” menu).
Option settings: Not Used, Status (default); Stop Beeps, Skip
exit delay; and X-10 (PGM).
* Applicable only to control panels that support the voice option.
Note: X-10/PGM not to be enabled in UL Listed Product.
Define whether or not to report power failure.
Option settings: NOT Connected (default) and Connected to AC.
Note: For UL Listed product, set to “NOT Connected”.
2.6 Enrolling Proximity Tags
You can enroll proximity tags in the WP8010/30 panel either via the WK160 touch screen
keyprox, as described below, or through the WP8010/30 control panel, as described in the
corresponding section of the control panel's User or Installer Guide.
Each proximity tag corresponds to its User Code. Therefore, be sure that a corresponding
User Code is programmed for each enrolled proximity tag (code "0000" is not allowed). For
example, "T02:Tag <Prox>" must be assigned to User Code 2 and "T14:Tag <Prox>" must
be assigned to User Code 14. Partition authorization of each proximity tag is identical to that
of the corresponding User Code. For example, if User Code 3 is set to Partitions 1 and 3,
"T03:Tag <Prox>" will also be set to Partitions 1 and 3.
Step
Action
LCD Display
1
Enter the Installer menu of the control panel and
go to “02:ZONES/DEVICES”

2
Select "ADD NEW DEVICE" Option


3
When "ENROLL NOW"is displayed, press the
AWAY key ( ) on the WK160. The AWAY
key and the Present Prox Tag key ( ) begin
to blink

4
Present the proximity tag to the WK160 within the
timeout period. If the enrollment is successful the
display reads "DEVICE ENROLLED"and then
shows the device details
AC POWER Connect
02.ZONES/DEVICES
MODIFY
DEVICES
ADD NEW
DEVICES
ENROLL NOW
or
T01:Tag (Prox)
DEVICE
ENROLLED

D-306042 WK160 User’s Guide 9
3. USING THE TOUCH SCREEN KEYPROX
3.1 Arming and Disarming the System
Step
Operation
User Actions
Keyboard &
Panel Response
Optional
1
Select a PARTITION (1)
(if Partition is enabled)
Any combination of
The selected key
blinks.
2
Arm AWAY
+ [] (4)
The selected key
and the "Present
Prox Tag" icon
( ) begin to
blink and prompt you
to present your Tag.
The keyprox's LED
blinks red once to
indicate transmission
of the arming
command to the
control panel.
The LED and the
buzzer then indicate
the control panel's
response –see
“System Status
and Indications”
section 3.3.
Arm HOME
+ [] (4)
Disarm (OFF)
+ [ ] (4)
Optional
3
Quick arm AWAY (3) (If
Quick Arm is enabled)
(2 sec.)
Quick arm HOME (3) (If
Quick Arm is enabled)
(2 sec.)
Optional
4
INSTANT
(After arming HOME/
AWAY) (5) (7)
LATCHKEY
(After arming AWAY)
(6) (7)
Notes:
1. If Partition is disabled at the control panel, skip Step 1.
2. If Partition is enabled at the control panel and a partition was not selected in Step 1, Step
2 will activate all of the partitions assigned to the user.
3. The Quick arm functions only if enabled at the control panel.
4. If the action is not completed while the selected arming key is blinking, the desired
function will not be executed.
5. Press the INSTANT key within maximum 8 seconds timeout period after completing the
previous step. This will delete the entry delay for the current arming session.
INSTANT is available only if supported in the WP8010/30 control panel (refer to the
WP8010/30 Installer Guide).
6. For LATCHKEY activation, press the LATCHKEY key within maximum 8 seconds
timeout period after completing the previous step.

10 D-306042 WK160 User’s Guide
7. LATCHKEY is available only if the LATCHKEY feature is enabled in the WP8010/30
control panel (see WP8010/30 Installer Guide).You can perform the LATCHKEY and
INSTANT functions, one after the other. The order is not important.
LATCHKEY and INSTANT functions can be operated only during exit delay.
While in INSTANT / LATCHKEY, the small circle icon on the upper right side of the
INSTANT / LATCHKEY icon lights.
Notes:
1. Latchkey Arming is supplemental in UL installations.
2. For UL Listed product, Emergency is for ancillary use only.
3.2 Initiating Alarms
Alarms
Actions
Response
Notes
Emergency
alarm
(2 sec.)
See section
3.3.
When pressing the Fire or Emergency
icons, the WK160 starts beeping. After
pressing the button for approx. 2
seconds, the WK160 sends the
command.
Fire alarm
(2 sec.)
See section
3.3.
Panic alarm
(2 sec.)
See section
3.3.
When pressing the Fire and Emergency
icons together, the WK160 starts
beeping. After pressing the button for
approx. 2 seconds, the WK160 sends
the Panic command.
3.3 System Status and Indications
When executing a command, the keyprox's LED ("30" in the "Icon and Key Indications"
Figure) blinks red once to indicate transmission of the command to the control panel. If the
operation is successfully completed, the green LED lights momentarily and a "happy
tune" sounds. If the operation fails or cannot be completed, for example, when the system
is "Not Ready", the red LED lights steadily and a "sad tune" sounds.
Buzzer Indication
LED Indication
Panel Response
Happy
(success) tune
Momentary GREEN
Success: Operation is
successfully completed
Sad (failure) tune
Momentary RED
Fail: Operation failed or
invalid key press
None
None
No communication:
Control panel does not
respond.

D-306042 WK160 User’s Guide 11
Arming Indications
The table below lists the Arming indication keys and their definition.
Icon/Key Indications
Arming Indication
ARM AWAY
ARM HOME
DISARM
Each icon appears one after the other
EXIT DELAY
+ The "Present Prox Tag" icon and DISARM
key blink simultaneously
ENTRY DELAY
If Partition is enabled, the arming indication of the first partition is displayed concurrently with
the corresponding first partition key LED , then the second partition indication is
displayed concurrently with the second partition key LED and then the third partition
indication is similarly displayed.
General Indications
The Ready/Not Ready, Alarm Memory, Trouble and Low Battery indications are provided via
the indications in the following table:
Number
Indication [1]
What it Means
Instructs the user to display the RFID proximity
tag in order to initiate a command.
Volume control mode.
System is NOT READY; one of the zonesis not
secured. You cannot arm the system before the
zone is secured or bypassed.
System is READY but one or more zones are
bypassed.
No indication
System is READY and all zones are secured.
+
Bypassed ( ) or Open ( ) Zone number

12 D-306042 WK160 User’s Guide
Number
Indication [1]
What it Means
+
Selected PGM or X-10 unit number.
+
Volume level
PGM/X-10 control mode.
System is armed in LATCHKEY mode.
Exit beeps are shut off. This mode disables when
the exit delay is over. [2]
System is armed in the INSTANT mode.
A message is waiting in the system.
The control panel is presently in "INSTALLER
MODE" or "USER SETTINGS".
Memory / Alarm in partition or system.
The partition / system has an active trouble
status that needs to be reviewed and cleared. [3]
AC failure.
Communication failure: WK160 is out of range of
the control panel or did not get an acknowledge
signal of a command from the control panel.
Indicates that the WK160 device's battery is low
and must be replaced (see section 2.1).
[1] The key indication is displayed after the first red LED blinks indicating the status request.
[2] Operates only during Exit Delay.
[3] See respective sections in the control panel's User and Installer's Guides.
[4] If there is more than one status indication at a single time, the keys are displayed
simultaneously.

D-306042 WK160 User’s Guide 13
Zone Status Indications
To view the zone numbers of enrolled detectors that are in NOT READY ( ) or
BYPASSED state ( ), repeatedly press the key. Upon each press of the key,
the next zone number appears on the Zone # display (marked "4" in the "Icon and Key
Indications" Figure).
To view the zone numbers that are assigned to a Partition, press the desired Partition
number ( / / ) followed by the key. Upon each press of the key, the
next zone number assigned to the pressed Partition number appears on the Zone # display.
Notes:
A zone which is BYPASSED and NOT READY is shown as BYPASSED ( ).
When "00" appears on the Zone # display, this indicates a NOT READY state in the alarm
system that is not related to any detector, for example, "tamper open" in a keypad or control
panel.
If all zones are READY and "not bypassed", the button is disabled.

14 D-306042 WK160 User’s Guide
3.4 Bypassing Zones
A zone can by bypassed by pressing the key until the zone number is shown on the zone #
display (marked "4" in the "Icon and Key Indications" Figure) followed by the key.
Notes:
1. Zone bypassing on the WK160 unit can be operated only if Bypass was enabled via the
control panel (see WP8010/30 Installer Guide, section 3.5.2 "Configuring
Arming/Disarming and Exit/Entry Procedures").
2. For UL Listed product, manual bypass must be enabled.
3.5 Controlling Home Automation Devices
To configure the PGM and X-10 output functions, see the corresponding sections of the
control panel’s Installer Guide (“OUTPUTS” menu) and User Guide (“SCHEDULER” menu).
Step
X-10 device ON
PGM device ON
X-10 or PGM
device OFF
X-10 or PGM
device TOGGLE
1
(~2sec)
2
…
[P0 to P9]
…
[00 to 99]
[PGM P0 to
P9] or [X-1001
to 99]
[PGM P0 to
P9] or [X-1001
to 99]
3
Notes:
1. Long press (more than 2 sec.) of the button initiates the X-10 function and the
PGM/X-10 display (marked "4" in the "Icon and Key Indications" Figure) will read "01".
Short press of the button initiates the PGM function and the PGM/X-10 display will
read "P0" with the key. This number is incremented by 1 upon each press of the
key.
2. X-10/PGM not to be enabled in UL Listed Product..
3. Automation not to be enabled in UL Listed Product.

D-306042 WK160 User’s Guide 15
3.6 Other Functions
Output Function
Actions
Response
AUX Function
Enrollment: Long key press (more than 5 sec.)
until green LED lights and then release key.
Back to Factory: Long key press (more than 7
sec.) to reset the WK160 device to factory default
settings.
Cancels current operation: Short key press
Volume control
Changes the volume level upon each key press.
Volume level alternates between 1, 2, 3, 0
Mute exit beeps
Mutes the exit beeps; small circle key will appear
above the key. Press button again to cancel mute.
Note: Operates only per Exit Delay duration. Upon
next Exit Delay, the exit beeps will not be muted.
APPENDIX A: SPECIFICATIONS
Frequency Band (MHz)
Europe and rest of world: 433-434, 868-869 USA: 912-919*
*Note: For UL Listed product, enable this frequency band.
Communication Protocol
PowerG
Battery type
Four 1.5V AA Alkaline batteries (GP)
Battery Life Expectancy
4 years (for typical use).
Low Battery Threshold
3.8 V
Power source (optional)
5-12VDC
Back light
Blue/white or black/white
Operating Temperature
0C to 55C (32F to 131F)
Note: For UL Listed product, the ambient temperature is
32°F to 120°F (0°C to 49°C)
Humidity
Average relative humidity of approx. 75% non-condensing.
For 30 days per year, relative humidity may vary from 85% to
95% non-condensing.
Note: For UL Listed product, Relative Humidity is 93%.
Dimensions (WxLxD)
150x100x20mm (5-7/8 x 3-7/8 x 13/16 in)
Weight (including battery and
bracket)
379 g (13 oz).
Mounting
Wall-mounted or portable
Color
Black or White-Silver
APPENDIX B: COMPLIANCE WITH STANDARDS
Compliance with Standards
Europe: EN 300220-1, EN 300220-2, EN300330,
EN301489, EN60950, EN50131-1, EN50131-3, EN50131-6.
The WK160 is compatible with the RTTE requirements -
Directive 1999/5/EC of the European Parliament and of the
Council of 9 March 1999 and EN50131-1 Grade 2 Class II.
Certified by Norwegian accredited certification body Applica
Test & Certification AS in accordance with EN 50131-3, EN
50131-6, EN 50131-5-3, EN 50130-4, and EN 50130-5.
Applica T&C has certified only the 868 MHz variant of this

16 D-306042 WK160 User’s Guide
product.
UK: This product is suitable for use in systems installed to
conform to PD6662:2010 at Grade 2 and environmental
class 2. DD243 and BS8243
USA: CFR 47 part 15
Canada: RSS 210
RFID Tags: ISO-18000-2 (125 kHz)
The Power G peripheral devices have two- way communication functionality, providing additional benefits as
described in the technical brochure. This functionality has not been tested to complywith the respective
technical requirements and should therefore be considered outside the scope of the product’s certification
EN 50131-1 Security Grade
According to EN 50131-1:2006 and A1:2009, this equipment
can be applied in installed systems up to and including
Security Grade 2
EN 50131-1 Environmental Class
Class II
This device complies with FCC Rules Part 15 and Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference,including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
WARNING! To comply with FCC and IC RF exposure compliance requirements, the mobile version of this
device should be located at a distance of at least 20 cm from all persons during normal operation. The antennas
used for this product must not be co-located or operated in conjunction with any other antenna or transmitter.
The portable device version complies with FCC and IC RF radiation exposure limits set forth for an uncontrolled
environment.
The digital circuit of this device has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in residential installations. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio and television reception. However, there is no guarantee that interference will not occur in
a particular installation. If this device does cause such interference, which can be verified by turning the device
off and on, the user is encouraged to eliminate the interference by one or more of the following measures:
–Re-orient or re-locate the receiving antenna.
–Increase the distance between the device and the receiver.
–Connect the device to an outlet on a circuit different from the one which supplies power to the receiver.
–Consult the dealer or an experienced radio/TV technician.
Changes or modifications not expressly approved by Visonic Ltd. could void the user's authority to operate the
equipment.
W.E.E.E. Product Recycling Declaration
For information regarding the recycling of this product you must contact the company from
which you orignially purchased it. If you are discarding this product and not returning it for
repair then you must ensure that it is returned as identified by your supplier. This product is
not to be thrown away with everyday waste.
Directive 2002/96/ECWaste Electrical and Electronic Equipment.

D-306042 WK160 User’s Guide 17
LIMITED WARRANTY
Digital Security Controls (DSC) warrants that for a
period of 12 months from the the product shall be
free of defects in materials and workmanship under
normal use and that in fulfillment of any breach of
such warranty, DSC shall, at its option, repair or
replace the defective equipment upon return of the
equipment to its repair depot. This warranty applies
only to defects in parts and workmanship and not to
damage incurred in shipping or handling, or damage
due to causes beyond the control of Digital Security
Controls such as lightning, excessive voltage,
mechanical shock, water damage, or damage arising
out of abuse, alteration or improper application of the
equipment.
Digital Security Controls (DSC) warrants that for a
period of 12 months from the date of purchase, the
product shall be free of defects in materials and
workmanship under normal use and that in fulfillment
of any breach of such warranty, DSC shall, at its
option, repair or replace the defective equipment
upon return of the equipment to its repair depot. This
warranty applies only to defects in parts and
workmanship and not to damage incurred in shipping
or handling, or damage due to causes beyond the
control of Digital Security Controls such as lightning,
excessive voltage, mechanical shock, water damage,
or damage arising out of abuse, alteration or
improper application of the equipment.

18 D-306042 WK160 User’s Guide
©2016 Tyco International Ltd. and its Respective Companies. All Rights Reserved.
Toronto, Canada www.dsc.com
Printed in Israel
D-306042 Rev 01 (02/16)
