TYM TX1500 User manual

NOTE
CAUTION
WARNING
DANGER
WE GREATLY APPRECIATE YOUR PURCHASING OF TONGYANG EQUIPMENT
PREFACE
■
This operator’s manual describes how to operate the machine and precautions for your safety.
■
Please read this manual carefully before use and keep this manual handy and near the machine after reading.
■
Disassembling, repairing or modifying the equipment without understanding how to operate the equipment may be
the reason for accident or breakdown.
■
When lease or transfer this machine to another, be sure to hand over this manual to the user. In case the manual is
lost or damaged, contact your local authorized dealer or distributor immediately to ask for a new manual.
■
Any component or specification of the machine can be subject to change or modification in accordance with the de-
sign change. Therefore, if there is any ambiguous part, contact a Tongyang distributor or an authorized dealer near-
by.
Warning symbols are particularly important for safety so follow the instructions with special attention.
Meaning of each sign is shown as the following.
This symbol indicates an urgent condition that may result in harm, fatal injury or even death if this
instruction is ignored.
This symbol indicates a potential condition that may result in harm, fatal injury or even death if this
instruction is ignored.
This symbol indicates a condition that may result in a minor injury if the instruction is ignored.
This symbol indicates information of working procedures, and information about maintenance, re-
garding this equipment.
※ 
This manual includes
「
For the safe operation
」
chapter for the safety of user. Be sure to read this chapter be-
fore operation.
TX1500-영문-00(안).indd 1 2012-12-17 오후 2:22:03

SAFETY INSTRUCTION
■ Our company strives to achieve the level of safety required by national or
international standards on all our products.
■ All employees of our company work hard to understand and to attain the
safety goal of the equipment.
■ For doing so, we develop and perform the product safety program system-
atically in all the processes from procuring raw materials to design, manu-
facturing, and distribution.
■ Our company set up and run PL management system in order to provide
customers with fast and professional service after product sales.
TX1500-영문-00(안).indd 2 2012-12-17 오후 2:22:03

■SYMBOL MARK
The following symbol marks in control device are used for operation and maintenance. Keep in mind the meaning of
the following symbol marks so as to operate correctly.
DESCRIPTION OF SYMBOLS AND TECHNICAL TERMS
Engine speed “High speed”
Engine speed “Low speed”
Hazardasher
Headlamp "high beam"
Headlamp "low beam"
Horn
Turn indicator
Parking brake
A/C activation
Cruise control
Lift arm "lifting"
Lift arm "lowering"
Differential lock "engaging"
Differential lock "disengaging"
PTO "engaging"
PTO "disengaging"
Wiper
Blower speed
4WD suspension
TX1500-영문-00(안).indd 3 2012-12-17 오후 2:22:03

DESCRIPTION OF SYMBOLS AND TECHNICAL TERMS
■TECHNICAL TERMS

Shuttle shift lever Lever to shift between forward driving and reverse driving

Accelerator pedal Pedal to control engine RPM and/or driving speed with foot

Driving speed control wheel Wheel to control engine RPM and driving speed with hand

Throttle wheel Wheel to control engine RPM with hand

Control monitor Device to display tractor conditions and set driving and operation settings

Multifunction lever Device to control driving direction, cruise control activation and cruise control speed

PTO lever Lever to engage PTO (Power Take-Off) to use implement

Tilt lever Lever to adjust steering wheel angle for driver's comfort

Control panel Device to control lifting and lowering operation of implement

Joystick lever Lever to control loader (If equipped with loader)

External lifting /
lowering control switch Switch to lift and lower implement from out of cabin

Cruise control Device to maintain constant driving speed

Finger wheel Wheel to control external hydraulic pressure

Front axle suspension Device to absorb shock delivered from road surface for front axle
TX1500-영문-00(안).indd 4 2012-12-17 오후 2:22:04

FOR SAFE OPERATION
1. GENERAL PRECAUTIONS..................................... 1 -2
2. DURING MAINTENANCE AND CLEANING .......... 1 -6
3. WHEN STARTING ENGINE .................................. 1 -11
4. WHEN DRIVING.................................................... 1 -13
5. DRIVING ON NARROW FARM ROAD, BUMPY
ROAD, OR SLOPE ............................................... 1 -16
6. WHEN GETTING ON/OFF THE TRUCK ............... 1 -18
7. WHEN WORKING IN PADDY FIELD .................... 1 -20
8. AFTER DAILY WORK IS COMPLETED............. .. 1 -23
9. FOR LONG-TERM STORAGE .............................. 1 -24
