TypeS BT57799 Guide

1080P Solar Powered App View Backup Camera

TABLE OF CONTENTS
1. Introduction ..........................................................................................................................................................................1
2. Package Contents ...............................................................................................................................................................2
3. Product Specications ......................................................................................................................................................3
4. Product Overview ................................................................................................................................................................3
5. Camera Status & LED Indicators......................................................................................................................................4
6. Before You Install..................................................................................................................................................................4
7. APP Installation......................................................................................................................................................................5
8. Pairing the camera...............................................................................................................................................................6
9. Installation Guide ................................................................................................................................................................8
10. Settings and Operation ................................................................................................................................................12
11. Safety Information ..........................................................................................................................................................14
12. Maintenance & Warranty .............................................................................................................................................17
13. General Information ..................................................................................................................................................... 20

1
Please read all of the installation instructions carefully before installing the product. Improper
installation will void manufacturer’s warranty. The installation instructions do not apply to all types of
vehicles, and are written as guidelines to assist in installing the system.
Consult an experienced technician if you are not comfortable installing the product. You can also
contact TYPE S at 866.294.9244 to speak to one of our installation specialists if you have any specic
questions regarding the Wireless Backup Camera.
BEFORE using the Wireless Backup Camera - Solar Powered 1080P App View, please read the
safety information provided in this user manual. ALWAYS use the product as outlined in this
user manual.
Please make sure to read and understand all local laws and regulations regarding cameras and their
use in a vehicle. Laws vary by state.
1. INTRODUCTION

3
3. PRODUCT SPECIFICATIONS
4. PRODUCT OVERVIEW
Frequency: 2.4 GHz
Operating Voltage: DC 5V
Operating Temperature: 14ºF~122ºF (-10ºC~50ºC)
Camera Water Resistance: IP67 Rating
Battery Capacity: 2500mAh (Minimum Capacity 2400mAh)
Maximum Signal Range: 33 Feet / 10 Meters
(without interference or obstruction)
Power Button
USB Charging Port
LED Light
Camera Lens Solar Panel

4
5. CAMERA STATUS & LED INDICATORS
Power / Mode Status LED Indicators
Power On
Press and hold the power button until you see the blue LED light
ashes and then release.
Blue LED light ashes twice.
Power O
Press and hold the power button for more than 2 seconds and then
release.
Red LED light ashes once.
Reset password
While the Backup Camera is on, press and hold the power button for
more than 5 seconds and then release.
Blue LED light ashes 5 times.
Low Voltage Protection Red LED ashes continuously.
Please charge, pair, and test the Wireless Backup Camera with the TYPE S Drive App before you install
on your vehicle.
NOTE: The camera should come with at least 90% battery charge. We recommend to charge for 5-6
hours prior to use to ensure maximum performance.
6. BEFORE YOU INSTALL
CHARGING THE WIRELESS BACKUP CAMERA
Fold back camera power port plug and insert
included charging cable. Most AC USB wall
adapters will work with the USB charging cable.

7
5
67
98
5. Tap Pair Camera.
6. Tap the Connect icon to pair with the
camera.
7. Follow the on-screen instructions and
assign a new password for the camera.
8. Tap Join when the APP prompts you to
join the Backup Camera’s WiFi network.
9. You should see the live view.
NOTE: No matter you close or push the APP to the
background, the APP will switch back to live view
automatically everytime you open the APP again.

9
OPTION B  MOUNT ONTO EXISTING LICENSE PLATE WITH DOUBLESIDED TAPE
2. Secure with screws provided. 3. Unscrew and remove the license plate from your vehicle.
OR
1. Attach the International
Mounting Plate to the back of
the Wireless Backup Camera.
4. Peel o the cover of
the double-sided tape
from the International
Mounting Plate, and
attach the license plate
to the Wireless Backup
Camera.
RECOMMENDATION
Thoroughly clean & dry
the mounting surface area
of the license plate before
attaching.
OR

10
5. Secure the license plate with
the attached Wireless Backup
Camera to the vehicle.
OR

11
OPTION C  LOWERING INSTALLATION  FOR VEHICLES WITH TRUNK OR HATCH DOOR RELEASE
1. Unscrew and remove the license plate
from your vehicle.
2. Place the Two Way Mounting Tabs behind
the license plate. Insert the Mounting nuts
through the Wireless Backup Camera mount
holes and tighten with a wrench. Reference
the Assembly Reference Example.
3. Secure the Two Way Mounting Tabs to the
vehicle using the vehicle’s license plate screws.
(This allows more clearance for nger tips to release door latch)
US Mounting PlateMounting
Screw
Two Way
Mounting Tab
Mounting
Nut
Assembly Reference:

12
10. SETTINGS AND OPERATION
ROTATE CAMERA
Tap on the setting to reverse the camera view.
BRIGHTNESS
Swipe to adjust screen brightness.
CHROMA
Swipe to adjust screen chroma.
CONTRAST
Swipe to adjust screen contrast.
SATURATION
Swipe to adjust screen saturation.
OPERATION TIME
Tap to choose a dierent operation time.
The Wireless Backup Camera’s parking view
operation time will start to count down when
you wake up the Wireless Backup Camera.
When the timer runs out, the parking view will
automatically switch to stand-by mode.

13
FIRMWARE VERSION
Tap to check the Backup Camera’s rmware version.
UPGRADE
Tap to upgrade the Backup Camera’s rmware to
the latest version through the APP:
NOTE: - Keep your smart device connected to WiFi
in order to download the rmware.
- Make sure the APP is paired and connected
to the camera prior the upgrade.
1. Tap Start update to begin.
2. After the upgrade is done, the APP will switch
back to the live view.
RESET DEFAULT
Tap to clear all the camera settings.
CHANGE PASSWORD
Tap to change the Backup Camera’s pairing
password.
1 2

14
WARNING: A failure to read and follow these warnings and instructions may result in a serious
accident, including damaged property or a serious injury, including loss of life.
• The Wireless Backup Camera is designed as an aid to the driver in detecting large stationary
objects to help avoid damaging the vehicle. However, you, the driver, must use it safely and
properly. Use of the Wireless Backup Camera is not a substitute for safe, proper and legal driving.
• Never back up while looking only at the screen. You should always check behind and around
the vehicle when backing up just as you would if the vehicle did not have the Wireless Backup
Camera. Always make sure your intended path is clear. If you back up while looking only at the
APP screen, you may hit a vehicle, pedestrian, bicyclist, child, pet or other object resulting in injury
or death. Always back up slowly.
• Never depend on the Wireless Backup Camera entirely when backing up. The image on the screen
is dierent from actual conditions. Objects viewed in the APP screen dier from actual distance
because a wide-angle lens is used. Objects in the APP screen will appear visually opposite than
when viewed in the rear view and outside mirrors. Use the inside mirror or glance over your
shoulder to properly judge distances to other objects.
• The area displayed by the Wireless Backup Camera is limited. The Wireless Backup Camera does
not display objects that are close to or below the bumper, underneath the vehicle, or objects
out of the Camera’s eld of view. The area displayed on the screen may vary according to vehicle
orientation or road conditions.
• Be sure to check the Camera’s position and mounting angle before each use.
• Make sure the trunk, hatch, or backdoor is completely and securely closed when backing up.
• If the back of the vehicle is hit, the position and mounting angle of the Wireless Backup Camera
IMPORTANT SAFETY INSTRUCTIONS
1. SAVE THESE INSTRUCTIONS– This manual contains important safety and operating instructions of
Model BT57799.
2. Before using the product, read all instructions and cautionary markings.
3. Use of an attachment not recommended or sold by the product manufacturer may result in a risk
of re, electric shock, or injury to persons.
4. Do not disassemble the Wireless Backup Camera; take it to a qualied serviceperson when service
or repair is required. Incorrect reassembly may result in a risk of electric shock or re.
11. SAFETY INFORMATION

15
may change.
• When washing the vehicle with high pressure water, be sure not to spray it around the Wireless
Backup Camera. Otherwise, water may enter the Camera unit causing water condensation on the
lens, a malfunction, re or an electric shock.
• Do not strike the Wireless Backup Camera. It is a precision instrument. Otherwise, it may
malfunction or cause damage resulting in a re or an electric shock.
• This product will only provide images of items that are within the eld of view of the Wireless
Backup Camera. Thus, it is imperative that the Wireless Backup Camera should be kept clean and
unobstructed, and should be mounted so that its eld of view includes the entire area behind
your vehicle.
• Adhere to all applicable trac laws and motor vehicle regulations applicable to the device.
• Consult local laws and regulations for any restrictions on installation or use.
• Never allow children to play with the device. Small parts may be a choking hazard.
• There is a plastic cover over the Wireless Backup Camera. Do not scratch the cover when cleaning
dirt or snow from the cover.
• The Wireless Backup Camera has a water resistant construction. Do not detach, disassemble or
modify it. This may cause incorrect operation. Wireless Backup Camera is waterproof.
• Do not submerge Wireless Backup Camera in water, which can cause internal damage to the
Camera.
• If the temperature changes rapidly, such as when hot water is poured on the vehicle in cold
weather, the system may not operate normally. The Digital Camera can withstand the eects of
rain, snow, and inclement weather.
• When strong light directly enters a camera, objects may not be displayed clearly.
• The screen may icker under uorescent light.
• The colors of objects on the APP screen may dier somewhat from those of the actual object.
• If dirt, rain or snow attaches to the Camera, the APP screen may not clearly display objects. If
water droplets, snow or mud adhere to the Camera lens, rinse with water and wipe with a dry
cloth.
• Do not use alcohol, benzene or thinner to clean the Camera. This will cause discoloration. To clean
the Camera, wipe with a clean cloth dampened with mild cleaner diluted with water and then
wipe with a dry cloth.

16
• Will work up to 33 feet.
• ALWAYS engage Parking/Emergency/Hand Brakes of the vehicle when testing the system.
SAFETY AROUND AND BEHIND OTHER VEHICLES
Using a Wireless Backup Camera is not enough to completely overcome a vehicle’s blind spot. Many
preventable injuries and deaths occur in driveways or parking lots when drivers do not see children,
pets, or others near their vehicles. Here are a few safety tips that will help you to avoid a back-over
accident:
• Walk completely around your vehicle before getting in. Check for kids, toys, and pets before
entering the vehicle and starting the engine.
• Know where children are. Have children stand in a place where they are in full view.
• Be aware of young children. Young children are small and hard to see.
• Parents, caregivers and all adults need to be vigilant in supervising children, especially when
children are in the yard, driveway or parking lot playing near parked cars.
• Roll down your window so you will be able to hear what is happening outside your vehicle.
• Owners of SUVs, trucks, and vans need to take extra care to avoid hitting or running over a child.
• Teach children to move away from a vehicle whenever it is started.

17
12. MAINTENANCE & WARRANTY
CLEANING
• If dirt, rain or snow attaches to the Camera, the APP screen may not clearly display objects. If
water droplets, snow or mud adhere to the Camera lens, rinse with water and wipe with a dry
cloth.
• Do not use alcohol, benzene or thinner to clean the Camera. This will cause discoloration. To clean
the Camera, wipe with a clean cloth dampened with mild cleaner diluted with water and then
wipe with a dry cloth.
WARRANTY
• TYPE S
LIMITED WARRANTY
TYPE S warrants, to the original purchaser, that its products are free from defects in material
and workmanship for 1 year from the date of original purchase. Where permitted by law, TYPE
S liability shall be limited to that set forth in this limited express warranty. This limited express
warranty shall be the exclusive remedy of the purchaser and TYPE S makes no other warranty of
any kind aside from the limited express warranty stated above.
NOTE: Warranty only applies for North American customers of purchases made in North America.
CONDITIONS OF WARRANTY
If during the 1 year warranty period your new product is found to be defective, TYPE S will repair
such defect, or replace the product, without charge for parts or labor subject to the following
conditions:
1. All repairs must be performed by TYPE S.
2. All warranty claims must be accompanied by a copy of the sales receipt or bill of sale.
3. The equipment must not have been altered or damaged through negligence, accident,
improper operation, or failure to follow the product instructions for installation, use, or
care.
4. The replacement of parts is excluded from the warranty when replacement is necessary
due to normal wear and tear.

18
5. Repair or replacement parts supplied by TYPE S under this warranty are protected only for
the unexpired portion of the original warranty.
6. This is a “repair or replace” warranty only, and does not cover the costs incurred for the
installation, removal or reinstallation of the product, or damage to any mobile phone
device or vehicle.
OWNER’S RESPONSIBILITIES:
TYPE S will make every eort to provide warranty service within a reasonable period of time.
SHOULD YOU HAVE ANY QUESTIONS ABOUT SERVICE RECEIVED OR IF YOU WOULD LIKE
ASSISTANCE IN OBTAINING SERVICE, PLEASE CALL TOLL FREE 1.866.294.9244 DURING REGULAR
BUSINESS HOURS MONDAY THROUGH FRIDAY 8:00 AM TO 5:00 PM.
NOTE: Toll Free # is for North America Customers ONLY. See Customer service section for
customer contact numbers for other regions/oces.
For customer service and technical support, please call us at 1.866.294.9244. If at that time it is
determined that a replacement unit is needed, the support representative will issue a Return
Authorization and instruct on how to get a new unit.
TYPE S makes no other warranty of any kind aside from the limited express warranty stated herein.
DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY OF MERCHANTABILITY AND WARRANTY OF
FITNESS FOR PARTICULAR PURPOSE: EXCEPT AS SPECIFICALLY SET FORTH HEREIN, NO WARRANTY
OR REPRESENTATION, EXPRESS OR IMPLIES, IS MADE AS TO THE WIRELESS BACKUP CAMERA.
EXCEPT AS EXPRESSLY SET FORTH HEREIN, TYPE S AND/OR ITS AFFILIATES EXPRESSLY DISCLAIMS,
WITHOUT LIMITATION, ANY STATUTORY WARRANTIES AND ALL IMPLIED WARRANTIES, INCLUDING
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TYPE S and/or its aliates do not guarantee or promise that the user of Wireless Backup Camera
will not be in an accident or otherwise not collide with an object and/or person. Our Wireless
Backup Camera is not intended in any way to be a substitute for careful and cautious driving or for
