Ubiquiti UniFi UVP4Gon User manual

Enterprise VoIP Phone with
5"Touchscreen, Bluetooth,
WiFi, and Built-In Camera
Model: UVP-Pro
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Introduction
Thank you for purchasing the Ubiquiti Networks®UniFi®VoIP
Phone Professional, model UVP-Pro. The phone interface
is based on the popular Android™platform for ease of use.
This Quick Start Guide is designed to guide you through
installation and also includes warranty terms.
Package Contents
EnterpriseVoIP Phone with
5"Touchscreen,Bluetooth,
WiFi,and Built-In Camera
Model:UVP-Pro
UniFi VoIP Phone
Professional Micro Cloth Quick Start Guide
Installation Requirements
• UniFi Switch or PoE+ (802.3at-compliant) switch
• UniFi Controller
• Third-Party SIP/PBX Provider
TERMS OF USE: All Ethernet cabling runs must use CAT5 (or above). It is the customer’s
responsibility to follow local country regulations and indoor cabling requirements.
Before You Begin
Remove the protective
covering from the handset.
Remove the protective film
from the touchscreen.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Hardware Overview
Front
Camera
LED
Touchscreen
Volume
Camera Built-in camera can be used for snapping photos for
avatars or videoconferencing applications.
Touchscreen The 5" (diagonal) touchscreen display is used for
all interface navigation and dialing.
Volume Use the volume arrows to adjust audio levels.
LED The LED will illuminate when the device is first connected
to a 48V power source. Once the phone has started up, the
LED will turn off.
IMPORTANT: The LED will flash when a firmware update
is occurring. Do not disconnect power/Ethernet from the
device during this time.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Back Ports
PoE/LAN PC
PoE/LAN PC
PoE/LAN The PoE/LAN Ethernet port is 802.3at-compliant
and is used to connect data and power to the phone. Connect
this port to the same network as the UniFi Security Gateway
VOIP port.
PC The Ethernet port labeled PC is used for bridging.
WARNING: Do not connect a powered Ethernet
connection to the port labeled PC.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Side Ports
Micro-USB Port The Micro-USB port is only
intended for advanced users connecting the phone
to a computer.
Headset Jack 3.5 mm jack for optional wired stereo
and microphone headsets.
Handset
Mute button
Mute Press the Mute button to mute the microphone on the
handset.
