Ubiquiti UniFi AP AC EDU User manual

UniFi AP AC EDU Mounting Template Gigabit PoE* (48V, 0.5A) with
Mounting Bracket
Power Cord*
Package Contents
* Included only in the single-pack of the UAP-AC-EDU.
Installation Requirements
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Phillips screwdriver
Drill and drill bit (6 mm for wall-mounting or 3 mm for ceiling-mounting)
Optional: Drywall or keyhole saw (to cut 18 mm hole for Ethernet cable feed)
Cat5/6 UTP cable for indoor installations
System Requirements
Linux, Mac OS X, or Microsoft Windows 7/8/10
Java Runtime Environment 1.8 or above recommended
Web Browser: Google Chrome (Other browsers may have limited functionality.)
UniFi Controller software v5.4 or newer (available at: ui.com/download/unifi)
Hardware Overview
LED
UniFi AP Ports
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Secondary
Reset
Reserved for future use.
The Reset button serves two functions for the UniFi AP:
Restart Press and release the Reset button quickly.
Restore to Factory Default Settings Press and hold the Reset button for more than
five seconds.
Note: You must remove the UniFi AP from the Speaker Assembly before
you can access the Reset button.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Cable Feed Opening
USB
Main
The USB and Ethernet cables feed through this opening.
The USB 2.0 port is used to support the Speaker Assembly.
This Gigabit Ethernet port is used to carry power and data.
Back of the Speaker Assembly
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Main Port
Clamp Bracket
This Gigabit Ethernet port is used to connect the power and should be connected to
the LAN and DHCP server.
The four Clamp Brackets are used to secure the UniFi AP AC EDU to the ceiling tile.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Hardware Installation
1.
2.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

3.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

4.
5.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

6. We strongly recommend that you attach the Safety Wire (length: 430 mm) to a
secure structural point using its clasp (inside diameter: 14 mm). Do NOT attach the
Safety Wire to a T-bar in the ceiling grid.
Note: It is the installer’s responsibility to verify that installation complies with
local construction and safety codes.
Two examples are shown below.
7.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

8.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

9.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

10.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

11.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Connecting Power
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

OR
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Note: The Gigabit PoE adapter is included only in the single-pack of the UAP-
AC-EDU.
Optional
Software Installation
Download and install the latest version of the UniFi Controller software. Launch it and
follow the on-screen instructions. The software and step-by-step instructions in the User
Guide are available at: ui.com/download/unifi
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

After you have installed the software and run the UniFi Installation Wizard, a login
screen will appear for the UniFi Controller management interface. Enter the username
and password that you created and click Sign In.
You can manage your wireless network and view network statistics using the UniFi
Controller management interface. For information on configuring and using the UniFi
Controller software, refer to the User Guide.
Mobile App Installation
Ubiquiti also offers the UniFi app, which is available from the App Store® (iOS) or
Google Play™ Store (Android). You can use it to provision a UniFi AP for basic
functionality without configuring a UniFi Controller. It also allows seamless provisioning
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

of APs for remote controllers (controllers not on the same Layer 2 network) and easy
access to local controllers and those monitored on unifi.ui.com
UniFi EDU App
Ubiquiti Networks offers the UniFi EDU app so you can broadcast announcements with
clarity from your mobile device.
1.
2. Follow the on-screen instructions.
The UniFi EDU app includes five tabs:
Broadcast Create broadcast groups and make an immediate announcement.
Schedule Schedule announcements.
Recordings Create recordings for later use.
Volume Adjust the volume for each UniFi AP AC EDU.
Settings Switch to a different site.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Note: For details, refer to the User Guide, which is available at:
ui.com/download/unifi
Specifications
UAP-AC-EDU
Dimensions 287.5 x 287.5 x 125.9 mm
(11.32 x 11.32 x 4.96")
Weight 1.820 kg (4.012 lb)
Networking Interface (2) 10/100/1000 Ethernet Ports
Port (1) USB Port
Buttons Reset
Power Method 802.3at PoE+
Power Supply 48V, 0.5A PoE Gigabit Adapter
Supported Voltage Range 44VDC to 57VDC
Max. Power Consumption 20W
Operating Frequency 2.4 GHz
5 GHz
Max. TX Power
2.4 GHz 22 dBm
5 GHz 22 dBm
MIMO
2.4 GHz 3 x 3
5 GHz 3 x 3
Throughput Speeds
1
2
