UCOM COCOON 500 User manual

COCOON 500 / 600
HANDLEIDING
MODE D’EMPLOI
USER GUIDE
BEDIENUNGSANLEITUNG
V.1
Cocoon500_eur.book Page 1 Friday, June 20, 2003 2:49 PM

!! Important !!
To use ‘Caller ID’ (display caller), this service has to be activated on your phone line. Normally you need a separate subscription from your
telephone company to activate this function. If you don’t have the Caller ID function on your phone line, the incoming telephone numbers
will NOT be shown on the display of your telephone.
!! Belangrijk !!
Om de ‘Nummerweergave’ te kunnen gebruiken, moet deze dienst geactiveerd zijn op uw telefoonlijn. Om deze dienst te activeren, hebt U
hiervoor meestal een apart abonnement van uw telefoonmaatschappij nodig. Indien U geen nummerweergavefunctie hebt op uw
telefoonlijn, zullen de inkomende telefoonnummers NIET op de display van uw toestel verschijnen.
!! Important !!
Pour utiliser la fonction ‘Caller ID/Clip’ (affichage de l’appelant), ce service doit être activé sur votre ligne téléphonique. Généralement, vous
avez besoin d’un abonnement séparé de votre compagnie de téléphone pour activer cette fonction. Si vous n’avez pas la fonction ‘Caller
ID - Affichage Appelant’ sur votre ligne téléphonique, les numéros de téléphone entrants n’apparaîtront PAS sur l’écran de votre téléphone.
!! Wichtig!!
Zur Verwendung der ‘Rufnummernanzeige’ muss dieser Dienst erst für Ihre Telefonleitung freigegeben werden. Zur Aktivierung dieser
Dienstleistung benötigen Sie meistens ein separates Abonnement Ihrer Telefongesellschaft.Wenn Sie für Ihre Telefonleitung keine
Rufnummernanzeigefunktion haben, erscheinen die eingehenden Telefonnummern NICHT im Display Ihres Gerätes.
GB The features described in this manual are published with reservation to modifications.
NL De in deze handleiding beschreven mogelijkheden worden gepubliceerd onder voorbehoud
van wijzigingen.
FLes possibilités décrites dans ce manuel sont publiées sous réserve de modifications.
DDie in dieser Bedienungsanleitung umschriebenen Möglichkeiten, werden vorbehaltlich
Änderungen publiziert.
Cocoon500_eur.book Page 2 Friday, June 20, 2003 2:49 PM

Cocoon 500 / 600 3
ENGLISH
SAFETY INSTRUCTIONS 5
CLEANING 5
1. DESCRIPTION OF TELEPHONE 6
1.1 HANDSET/BASE COCOON 500 6
1.2 HANDSET/BASE COCOON 600 7
1.3 DISPLAY 8
1.3.1 Standby display 8
1.4 HANDSET INDICATOR (LED) 8
2. TELEPHONE INSTALLATION 9
2.1 CONNECTIONS 9
2.2 RECHARGABLE BATTERIES 9
3. USING THE TELEPHONE 10
3.1 CHOOSING MENU LANGUAGE 10
3.2 HANDSET ON/OFF 10
3.3 RECEIVING A CALL 10
3.4 MAKING AN EXTERNAL CALL 10
3.5 MAKING AN INTERNAL CALL 10
3.6 HANDSFREE MODE 10
3.7 INTERNAL CALL TRANSFER 10
3.8 CONFERENCE CALL 11
3.9 DISPLAY OF CALL DURATION 11
3.10 MICROPHONE MUTE 11
3.11 PAUSE KEY 11
3.12 CALLER IDENTIFICATION 11
3.12.1 List of calls 11
3.12.2 Delete all entries in the call list 12
3.13 REDIAL MEMORY 12
3.14 CALLING FROM THE PHONEBOOK 12
3.15 Using the alphanumerical keypad 12
3.16 USING THE MENU 12
4. PERSONALISATION 13
4.1 ADJUSTING SPEAKER VOLUME 13
4.1.1 Speaker volume during call 13
4.1.2 Set the default speaker volume 13
4.2 ADJUSTING THE RING VOLUME 13
4.2.1 Handset ring 13
4.2.2 Base ring 13
4.3 CHOOSING THE RING MELODY 13
4.3.1 Base melody 13
4.3.2 Handset melody, external call 14
4.3.3 Handset melody, internal call 14
4.4 ACTIVATION / DEACTIVATION OF BEEPS 14
4.4.1 Key pressed beeptone on/off 14
4.4.2 Low battery 14
4.4.3 Handset out of range 14
4.5 HANDSET NAME 14
4.6 CHANGING THE PIN CODE 14
4.7 SETTING THE DIALLING MODE 15
4.8 FLASH TIME DURATION 15
Cocoon500_eur.book Page 3 Friday, June 20, 2003 2:49 PM

4 Cocoon 500 / 600
ENGLISH
4.9 AUTOMATIC ANSWER 15
4.10 RESET 15
5. ADVANCED FUNCTIONS 16
5.1 PHONEBOOK 16
5.1.1 Add an entry into the phonebook 16
5.1.2 Modify a name or number 16
5.1.3 Deleting an entry 16
5.2 SEARCHING A HANDSET FROM THE BASE 16
5.3 CHOOSING PRIORITY RINGING 16
5.4 USING YOUR TELEPHONE WITH A PABX 17
6. MANAGING MULTIPLE HANDSETS 18
6.1 SETTING UP AN ADDITIONAL HANDSET 18
6.2 REMOVING A HANDSET 18
6.3 SETTING UP A HANDSET ON ANOTHER BASE 18
6.4 SELECTING A BASE 19
7. TROUBLE SHOOTING 19
8. WARRANTY 19
9. TECHNICAL CHARACTERISTICS 20
Cocoon500_eur.book Page 4 Friday, June 20, 2003 2:49 PM

Cocoon 500 / 600 5
ENGLISH
SAFETY INSTRUCTIONS
• Only use the charger plug supplied. Do not use other chargers, as this may damage the battery cells.
• Only insert rechargeable batteries of the same type. Never use ordinary, non-rechargeable batteries. Insert
rechargeable batteries so they connect to the right poles (indicated in the battery compartment of the handset).
• Do not touch the charger and plug contacts with sharp or metal objects.
• The operation of some medical devices may be affected.
• The handset may cause an unpleasant buzzing sound in hearing aids.
• Do not place the basic unit in a damp room or at a distance of less than 1.5 m away from a water source. Keep
water away from the handset.
• Do not use the telephone in environments where there is a risk of explosions.
• Dispose of the batteries and maintain the telephone in an environment-friendly manner.
• As this telephone cannot be used in case of a power cut, you should use a mains-independent telephone for
emergency calls, e.g. a mobile phone.
CLEANING
Clean the telephone with a slightly damp cloth or with an anti-static cloth. Never use cleaning agents or abrasive
solvents.
The CE symbol indicates that the unit complies with the essential requirements of the R&TTE directive.
Cocoon500_eur.book Page 5 Friday, June 20, 2003 2:49 PM

6 Cocoon 500 / 600
ENGLISH
1. DESCRIPTION OF TELEPHONE
1.1 HANDSET/BASE COCOON 500
Mute/Escape key
Up Key
Flash key
Power ON/OFF
Display
Phonebook
Charge indicator Power indicator
Incoming call LED
Cocoon 500
7PQRS
4GHI
2ABC
5JKL
8TUV
0
3DEF
6MNO
9WXYZ
1
RINT
Cocoon 500
Handset
indicator LED
Earpiece
Redial/pause key
Menu/OK
Line-key
Down Key
Call log Key
3 way Conversation
Internal call
Microphone
Paging Key
Set-up subscription
(press and hold )
Handfree
Cocoon500_eur.book Page 6 Friday, June 20, 2003 2:49 PM

Cocoon 500 / 600 7
ENGLISH
1.2 HANDSET/BASE COCOON 600
Cocoon 600
7PQRS
4GHI
2ABC
5JKL
8TUV
0
3DEF
6MNO
9WXYZ
1
RINT
Cocoon 600
Charge indicator Power indicator
Incoming call LED
Internal call
Mute/Escape key
Up Key
Redial/pause key
Paging Key
Set-up subscription
(press and hold )
Flash key
Power ON/OFF
Down Key
Call log Key
3 way Conversation
Display
Phonebook
Microphone
Line-key
Handfree
Handset
indicator LED
Earpiece
Menu/OK
Cocoon500_eur.book Page 7 Friday, June 20, 2003 2:49 PM

8 Cocoon 500 / 600
ENGLISH
1.3 DISPLAY
Icon line Character display line.
(12 characters maximum)
Each operation has an associated icon
Icon: Meaning:
You are online
EXT You are in external communication
INT You are in internal communication
You are in 3 way conversation
New numbers in call list
Hands free mode activated
You are opening your address book.
You are in the menu.
rechargeable battery level indicator
1 segment: weak, 2 segments: medium, 3 segments:
full. The segments scroll during battery recharging
The antenna indicates the quality of reception.
The antenna flashes when the handset is not
registered on the base.
or Indicates that the displayed number is longer than the screen (12 digits)
or Possible scroll direction in the menu
1.3.1 Standby display
In stanby mode, the display shows the handset name and the handset number:
C500 HS1 or
C600 HS1
1.4 HANDSET INDICATOR (LED)
The handset LED has following function:
• ON when the external line is busy
• OFF when all handset are in stanby mode
• Flashes on all handset when there is an incoming call
Cocoon500_eur.book Page 8 Friday, June 20, 2003 2:49 PM

Cocoon 500 / 600 9
ENGLISH
2.TELEPHONE INSTALLATION
2.1 CONNECTIONS
2.2 RECHARGABLE BATTERIES
To change or insert a rechargeable battery:
1. Slide the cover towards the bottom and then lift it up.
2. Insert the batteries respecting the (+ and -) polarity.
3. Replace the battery cover
+
-
-
+
Cover
Rechargeable
Batteries
back view of hand-set
Power cable
Telephone cord
Bottom view of base
TEL
Before you use your Cocoon 500/600 for the first time, you must first make sure that the batteries
are charged for 6-8 hourse. The telephone will not work optimally if not properly charged.
Cocoon500_eur.book Page 9 Friday, June 20, 2003 2:49 PM

10 Cocoon 500 / 600
ENGLISH
Note:The maximum standby time of the batteries is approx. 250h and the maximum talk time is 15hours!
In the course of time the batteries will start to drain faster. The batteries must be replaced.You can buy
new batteries from any DIY outlet (2 rechargeable batteries, type AAA NiMH)!
3. USING THE TELEPHONE
3.1 CHOOSING MENU LANGUAGE
1. Enter the menu by pressing /OK
2. Select HANDSET using the up and down keys
3. Press OK
4. Select LANGUAGE using the up and down keys
5. Press OK
6. Select the language of choice by means of the up and down keys.
7. Press OK to validate
3.2 HANDSET ON/OFF
• Turn ON handset: Press for 2 sec. The handset will search the base.
• Turn OFF handset: Press for 2 sec. The display will go OFF.
3.3 RECEIVING A CALL
When the handset rings, press to answer. You are then connected to your correspondent. If the hand-set is on the
base when the telephone rings, you just need to pick up the hand-set to answer the call (if the option autoanswer is
activated: See 4.9. Automatic answer).
If you press when the telephone rings, you answer the call automatically and activates the handfree mode.
3.4 MAKING AN EXTERNAL CALL
Normal:
1. Press
2. Enter telephone number
Block dialling:
1. Dial your correspondents number
2. Press
To correct a number use the key to delete an entered digit
3.5 MAKING AN INTERNAL CALL
Only possible when more then one handsets are registered to the base!!
1. Press INT
2. Enter the number of the internal handset (1 to 5)
3.6 HAND FREE MODE
You can speak with your correspondent without picking up the handset.
To activate or deactivate the hands free mode, press the key during a call.
To adjust the volume, refer to the chapter “ Personalisation “- adjusting speaker volume.
3.7 INTERNAL CALL TRANSFER
Only possible when more then one handset are registered to the base!!
When you want to transfer an external call to another handset:
1. During a conversation, press INT
2. Select the number of the internal handset, the external caller is put on hold.
3. When the other handset picks up, press to hang up and transfer the call.
