ULTRAPROBE 10,000SD
Recording Sound WAV Files
VISUAL INSTRUCTION

10,000SD Recording WAV Files
Ultraprobe 10,000SD –Recording WAV File: How To Guide
NOTE: UE DMS Software and Spectralyzer Software available for download at www.UESystems.com
1. Selecting Record WAV
2. Proper Recording Parameters
3. Recording WAV Files
4. Saving WAV Files
5. Reviewing WAV Files
SAFETY: THE WRIST STRAP SHOULD BE WORN AT ALL TIMES

10,000SD Recording WAV Files
The Ultraprobe 10,000SD Comes Standard with Recording Capabilities. To Record Sound WAV Files, First Select
Record WAV from the Function Bar, Located at the Bottom of the Main Display. Clicking the Sensitivity Dial Until
the Function Bar is Flashing, Then Spin Dial Until Record WAV is Shown, Then Press ENTER.
SAFETY: THE WRIST STRAP SHOULD BE WORN AT ALL TIMES
Function Bar

10,000SD Recording WAV Files
To Ensure Proper Recording Parameters, The Intensity Meter Must Be Between Two (2) to Four (4) Bars. This Will
Avoid Distortion of the Recording and “Clipping” of the Data Within the Software.
SAFETY: THE WRIST STRAP SHOULD BE WORN AT ALL TIMES

10,000SD Recording WAV Files
When Inspectors are Ready to Record, Enter into the Recording WAV Menu. PRESS and HOLD the Sensitivity Dial to
Begin Recording. The Ultraprobe 10,000SD Has a Maximum Recording Time of Two (2) Minutes. When Finished
Recording, Simply Release the Sensitivity Dial. If Record WAV is Selected by Mistake, Press ENTER to Exit.
SAFETY: THE WRIST STRAP SHOULD BE WORN AT ALL TIMES

10,000SD Recording WAV Files
When Active, the Ultraprobe 10,000SD Indicates a Recording is in Progress. This will Remain Within the Display
While the Sensitivity Dial is Pressed. Once the Dial Is Released, Permanent Saving Options are Available. A Timed
Option is Also Available from Five (5) to Thirty (30) Seconds Via Setup Menu #7 –Set Record Time.
SAFETY: THE WRIST STRAP SHOULD BE WORN AT ALL TIMES

10,000SD Recording WAV Files
Once Recording is Completed, Release the Sensitivity Dial. The Ultraprobe 10,000SD Offers a Playback Option. By
Pressing the ENTER Button, Inspectors Can Immediately Listen to the Recording to Ensure Quality. Once Played
Back, or if No Playback is Necessary, Simply Press the Sensitivity Dial to Continue.
SAFETY: THE WRIST STRAP SHOULD BE WORN AT ALL TIMES

10,000SD Recording WAV Files
Once Recording is Completed, Saving WAV Files is Simplified with Two (2) Options. Pressing the ENTER Button to
Permanently Save the File Or Press the Sensitivity Dial to Exit the Record WAV Menu Without Saving the File.
SAFETY: THE WRIST STRAP SHOULD BE WORN AT ALL TIMES

10,000SD Recording WAV Files
Once the ENTER Button is Pressed, Two (2) Confirmation Displays Will Populate. The First Will Be the Store Record
Confirmed, Signifying That All Text Data Has Been Stored to the Preselected Record.
SAFETY: THE WRIST STRAP SHOULD BE WORN AT ALL TIMES

10,000SD Recording WAV Files
Once Permanently Saved, the Ultraprobe 10,000SD Prompts a Confirmation Screen to Alert Inspectors the WAV File
has Been Saved and Stored to That Specific Record Number. Once the WAV File has Been Saved Properly, The Unit
Will Automatically Return to the Main Display and Advance to the Next Test Point.
SAFETY: THE WRIST STRAP SHOULD BE WORN AT ALL TIMES
