UEi C165 User manual

C165 QuiCk Start Guide
GETTING STARTED
Press ”Power” in fresh air and allow to count-
down for Fresh Air purge.
Rotate selector dial to Flue 1. In fresh air, O2
reading should be 20.9% ±0.3%.
Rotate selector dial to Flue 2. In fresh air, CO reading
should be zero (0).
Connect the flue probe thermocouple connector to T1.
Connect flue probe to water trap.
Connect optional probe to T2.
T2 T1
P1 P2
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
FRESH
AIR
PURGE
TIME 60
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
NAT GAS
C02 8.3%
O2 20.9%
EfG O2++%
Tf 42.4%
Ta 0.03m
Prs/Temp
BASIC CO/COMBUSTION ANALYSIS
Insert Flue probe into stack.
Adjust cone so end of the probe is
approximately at the center of the
stack.
NOTE: You will have to drill a hole
at least 3/8”. Use appropriate
sealing method after testing.
Rotate selector dial to Flue 1 for:
CO2, O2, Gross efficiency, Flue
temperature, Inlet temperature.
Fuel type can be changed via
MENU or STATUS setting
Rotate selector dial to Flue 2 for:
CO (ppm), Losses calculated, Excess
air %, pressure reading
Fuel type can be changed via
MENU or STATUS setting.
Make any adjustments as needed for
proper combustion and wait for ana-
lyzer to display change in readings.
(Repeat as necessary).
Once complete, remove probe from
stack, allow analyzer to purge in
fresh air until CO sensor readings
return to ZERO (0) and O2readings
reading return to 0% to 21%.
Continue to the next test or power
analyzer off by pressing On/Off, if
finished.
NOTE: Print and store functions may
be used at any time during testing.
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
FRESH AIR
PURGE
TURN
OFF
TIME 5
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
NAT GAS
CO 80P
COa 80P
LOSS O2++%
XAIR O2++%
PRS 0.00i
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
NAT GAS
C02 8.3%
O2 20.9%
EfG O2++%
Tf 42.4%
Ta 0.03m
Prs/Temp
DIFFERENTIAL TEMPERATURE TEST
Rotate the selector dial to
Pressure/Temperature.Press ”Pump” to ZERO
(0) pressure sensor.
Connect probe to T1.
Connect probe to T2.
Compatible with any K-Type
thermocouple probe or clamp.
Connect thermocouples in
test location to start testing
Observe T1, T2 and
differential (Delta T).
Press “Print” to print
results.
Press and Hold to log
results.
T2 T1
P1 P2
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
PRS 0.04i
i= inH20
T1 167,1F
T2 104.3F
T 62.8F
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
PRS/TEMP
PRESS
TO
ZERO
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
Prs/Temp
PRS 0.04i
i= inH20
T1 167,1F
T2 104.3F
T 62.8F
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
Prs/Temp
PRS/TEMP
PRESS
TO
ZERO

Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
BLOWER ON
NAT GAS
CO 0p
O2 20.0%
XAIR 02++%
TIME 60
Prs/Temp
DRAFT & STATIC PRESSURE TEST
T2 T1
P1 P2
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
Prs/Temp
PRS 0.04i
i= inH20
T1 167,1F
T2 104.3F
T 62.8F
Rotate the selector dial to
Pressure/Temperature. Press ”Pump” to ZERO
(0) pressure sensor.
Connect true draft hose to PI.
Connect to P2 for differential.
Place probe tip in stack to
measure draft.
Connect static pressure hose
for measure differential
pressure.
Place true draft probe tip in the
flue to measure draft.
You can also use the
combustion probe for
measuring pressure.
Press “Print” to print
results.
Press and Hold to log
results.
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
PRS/TEMP
PRESS
TO
ZERO
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
Prs/Temp
PRS/TEMP
PRESS
TO
ZERO
HEAT EXCHANGER TEST
Rotate selector dial to
EXCH Test, press the
“Print”.
Confirm the Fuel Type.
Scroll or to switch
a different fuel type.
Press to select fuel
type.
NOTE: The analyzer will
perform a fresh air purge
if it did not perform one on
start up. Otherwise it will
skip past the zeroing step to
the Blower Off screen. See
manual for details.
Press to continue.
Ensure the analyzer is
in fresh air during the
countdown. The screen
will automatically advance
when complete.
Call for heat.
Observe and wait for O2
readings to stabilize.
After the blower turns on,
press the Button to
start the Post-Blower test.
There are many methods to test heat exchanger integrity. One of these is to observe Excess Air, O2AND CO readings both before and after the blower turns
on. If the heat exchanger is sealed your O2and CO readings should remain fairly stable. A breach in the heat exchanger may allow fresh air to be forced into
the flue after the blower turns on due to a pressure increase in the plenum. The result may be a rise in the measured O2in the stack gas and an increase in the
Excess Air. In some sealed systems the fresh air drawn in the breach may reduce the combustion available leading to an increase in the CO reading. If either of
these situations are present it is probable that there is a problem with the Heat Exchanger which may require additional testing and inspection.
NOTE: Many cracks are invisible to borescopes or the naked eye and only open or separate from pressure or temperature during operation.
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
EXCHANGE
TEST
TO
START
PRESS
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
SETUP
FUEL TYPE
NAT GAS
PRESS
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
EXCHANGE
WITH PROBE
IN FRESH
AIR
PRESS
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
BLOWER OFF
NAT GAS
CO 0p
O2 20.0%
XAIR 02++%
PRESS
Prs/Temp
The analyzer will wait 60
seconds and then record the
Post-Blower values for CO,
02and Excess Air.
Test results will automati-
cally be stored to exchange
reports. Report includes both
Pre and post Blower test
segments.
Press to start printing.
See REPORTS section in
this guide.
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
EXCHANGE
ZEROING
TIME 60
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
LOG No. 10
12:00:00
CO 0p
O2 20.0%
XAIR 02++%
PRINT
Prs/Temp

Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
Prs/Temp
O2 20.9%
CO 0P
C02 8.3%
XAIR 42.4%
PRS -0.02i
Ta 80.3F
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
MENU
SETUP
UNITS
SCREEN
REPORT
SERVICE
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
ROOM CO
TEST 1/15
INT. 120s
CO 5p
LIMIT 10p
ALARM 30p
Prs/Temp
REPORTS: PRINTING & VIEWING
HIGH CO ALERT
Press ”Print” to start
printouts of results from any
test screen.
Press during printing to
cancel.
Press and hold to log
current readings.
Align printer above Analyzer.
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
NAT GAS
Ra 0.0010
CO 80P
C02 8.3%
XAIR 42.4%
PRS 0.03m
Prs/Temp
To view test results,
rotate dial to Menu.
Scroll or to Report
Press to select.
Scroll or to type
of test wanted.
Press to select.
[Exchange shown]
Press to select View.
Press to select
report log number. When
indicator lights blink,
use or to scroll
through logged reports.
Press to view a
selected report log.
Menu Room CO
Status
Aux
Flue1 Flue2
C165
Com Test
Exch Test
NAT GAS
Ra 0.0010
CO 80P
C02 8.3%
XAIR 42.4%
PRS 0.03m
Prs/Temp
At 1000 ppm CO the screen will display HIGH CO and an indicator light will flash and analyzer will beep several times. Above 2000 ppm the purge pump starts.
Print and Log easily from the following test screens: Aux, Flue 1, Flue 2, Commission Test, Pressure/Temperature, Exchange Test and Room CO
CO ROOM TEST
No probes or hose connections
required for this test.
Rotate selector dial to ROOM CO.
Press ”Print” to start the
GENERAL test.
Press start the test. CO readings will be logged every 2
minutes for a 30 minute time span.
Readings will be stored once the 30
minute test is completed.
Press to print results.
Test results will automatically be
stored in ROOM CO reports.
See REPORTS section in this guide.
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
ROOM CO
LOG No. 1
TEST 1
CO 5p
GENEAL
PRINT
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
SELECT
ROOM CO
TEST TYPE
GENERAL
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
ROOM CO
PRESS
TO
START
Prs/Temp
Great for checking ambient CO and back drafting situations
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
MENU
SETUP
UNITS
SCREEN
REPORT
SERVICE
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
SCREEN
CONTRAST
BACKLIGHT
AUX
BACK
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
AUX
LINE 1
LINE 2
LINE 3
LINE 4
LINE 5
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
SCREEN
AUX
LINE 5
PRS 0.02i
Prs/Temp
AUX SETTING
Rotate selector dial to Menu.
Scroll or to Screen.
Press ”Print” to select.
Scroll or to AUX.
Press to select.
Scroll or to customize
any Line.
Press to select.
[Line 5 shown]
Scroll or to select
the parameter for this line.
Press to select.
[Pressure shown]
Rotate selector dial to AUX
to view.
Custom selections will now
display in AUX mode.
Programmable Auxiliary screen allows for Tech selectable test parameters to be chosen.
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
REPORT
AUX
COMBUSTION
COMBUSTION
PRS/TEMP
EXCHANGE
Prs/Temp
Menu Room CO
Status
Aux
Flue1 Flue 2
C165
Com Test
Exch Test
LOG No. 9
12:00:00
CO 0p
02 20.9%
XAIR O2++%
PRINT
Prs/Temp

www.ueitest.com Email: [email protected]
USA: 1-800-547-5740 • 503-643-6322
CANADA: 1-877-475-0648 • 604-278-4311
Copyright © 2019 Kane USA, Inc. All Rights Reserved L466 0119
MAIN MENU SUB MENU OPTIONS / COMMENTS
SETUP LANGUAGE English
SET TIME HH:MM:SS format
e.g. 7 am = 07:00:00, 7 pm = 19:00:00
SET DATE MM/DD/YY format
PRINTER KM IRP
KANE IRP-2
WIRELESS (if installed)
SERIAL
PASSKEY 1111 (wait 5 secs after entering last digit)
BACK
UNITS FUEL TYPE NAT GAS, TOWN GAS, COKE GAS, PROPANE, BUTANE, LPG, LIGHT OIL, BIO OIL, WOOD
PELLETS, BIO GAS, USER 1 to 5
FUEL ORIGIN UK, FRANCE, SPAIN, N AMERICA, BELGIUM, NETHERLAND
EFFICIENCY GROSS, NET, GROSS COND, NET COND
PRESSURE FILTER: OFF = normal response. ON = slower (damped) response
RESOLUTION: LOW = e.g. 0.00i inH20 resolution. HIGH = displays to an extra decimal place
UNITS: mbar, Pa, PSI, mmHg, hPa, inH2O, mmH20, kPa, psi
TIME: Test units not available in North American market
BACK:
GAS ppm, ppm(n), mg/m3, mg/m3(n), mg/kWh, mg/kWh(n)
TEMP C, F
02REF Up/down to set value (3% default)
NOx CALC Up/down to set value (5% default)
BACK
SCREEN CONTRAST Factory setting is 14
BACKLIGHT 0 to 300 secs
AUX Enables users to customize the parameters on the AUX display: LINE 1, LINE 2, LINE 3,
LINE 4, LINE 5, LINE 6, BACK
BACK
REPORT AUX Stored AUX tests
VIEW, DEL ALL, BACK
COMBUSTION Stored combustion tests:
VIEW, DEL ALL, BACK
COMMISSION Stored commission tests:
VIEW, DEL ALL, BACK
PRS/TEMP Stored pressure tests:
VIEW, DEL ALL, BACK
EXCH Stored exchange tests:
VIEW, DEL ALL, BACK
ROOM CO Stored room CO tests:
VIEW, DEL ALL, BACK
HEADER LINE 1
LINE 2
BACK
BACK
SERVICE CODE Password protected for authorized service agents only. Leave set to 000000.
