Unfinished Furniture of Wilmington 48 IN TALL WINDSOR ARM BENCH BE-2904A User manual

ITEM NO.: BE-2904A
REVISED DEC 28, 2016
Printed in Vietnam
- 1 -
Description
Item No.
: 48 IN TALL WINDSOR ARM BENCH
: BE-2904A
ASSEMBLY INSTRUCTIONS

ITEM NO.: BE-2904A
REVISED DEC 28, 2016
Printed in Vietnam
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws, bolts until completely assembled.
-Keep all hardware parts out of reach of children.
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: BE-2904A
REVISED DEC 28, 2016
Printed in Vietnam
- 3 -
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Back
1
B
Seat
1
C
Arm
(L –R)
2
D
Leg
(L –R)
2
E
Back stretcher
1
F
Middle
stretcher
1
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Bolt
(M6 x 35mm)
10
2
Flat washer
(6.5 x 13mm)
10
3
Lock washer
(6.5 x 11mm)
10
4
Screw
(M4 x 35mm)
10
5
Allen Key
(M4 x 30 x 110mm)
1

ITEM NO.: BE-2904A
REVISED DEC 28, 2016
Printed in Vietnam
- 4 -
STEP 1
Attach seat (B) to the back (A) with bolts (1), and washers (3) and (2) as shown below.
Tighten with Allen key (5).
STEP 2
Attach arms (C) to the back (A) and seat (B) with screws (4) as shown below. Tighten with a screwdriver.

ITEM NO.: BE-2904A
REVISED DEC 28, 2016
Printed in Vietnam
- 5 -
STEP 3
Insert stretchers (E) and (F) into legs (D), as shown below.
Attach legs (D) to seat (B) with bolts (1), and washers (3) and (2) as shown below. Tighten with
Allen key (5).
Attach stretchers (E) and (F) to legs (D) with screws (4) as shown below. Tighten with a screwdriver.
