Unfinished Furniture of Wilmington WC-3624 User manual

ITEM NO.: WC-3624
REVISED NOV 04, 2014
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
:KITCHEN ISLAND
: WC-3624

ITEM NO.: WC-3624
REVISED NOV 04, 2014
Printed in Vietnam
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and d amage the finish of your
product. Protect the surface of the product with cloth if you are using any product with rubber feet or
base.
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuin g,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Top
1
B
Leg
(L-R)
4
C
Shelf
2
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: WC-3624
REVISED NOV 04, 2014
Printed in Vietnam
- 3 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Bolt
(M6x50mm)
8
6
Pan head screw
(M4x30mm)
1
2
Spring washer
(ɸ6.5x11mm)
8
7
Long screw
(M4x25mm)
3
3
Flat washer
(ɸ6.5x19mm)
8
8
Wood knob
(ɸ32xH32mm)
2
4
Cup holder
3
9
Shelf support
pin
8
5
Allen key
(4x80mm)
1
10
Short screw
(M3x15mm)
8
STEP 1
Attach cup holders (4) to top (A) with screws (7) as shown below. Tighten with a screwdriver.

ITEM NO.: WC-3624
REVISED NOV 04, 2014
Printed in Vietnam
- 4 -
STEP 2
Attach legs (B) to the top (A) with bolts (1) and washers (2) and (3), as shown below. Tighten with
Allen key (5).
STEP 3
Insert pins (9) into legs (B). Place the shelves (C) on the pins and attach with screws (10) as shown
below. Tighten with a screwdriver.

ITEM NO.: WC-3624
REVISED NOV 04, 2014
Printed in Vietnam
- 5 -
STEP 4
Attach knob (8) to front of drawer with Pan head screw (6). Tighten with a screwdriver.
