Unfinished Furniture of Wilmington WC-18A User manual

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
: SHERWOOD KITCHEN ISLAND
: WC-18A AND WC-18B

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the
finish of your product. Protect the surface of the product with cloth if you are using any
product with rubber feet or base.
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 3 -
PART LIST WC-18A
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Top
1
B
Leg
(L - R)
4
C
Stretcher
2
D
X-frame
2
E
Cross bar
1

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 4 -
PART LIST WC-18B
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
F
Top
1
G
Apron
2
H
Side panel
(L & R)
2
I
Bottom
1
J
Door
1
K
Vertical panel
1
L
Shelf
2
M
Drawer front
3
N
Drawer side
(L & R)
6
O
Drawer back
3
P
Drawer bottom
3

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 5 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Long Bolt
(M8 x 70mm)
8
2
Medium Bolt
(M6 x 50mm)
10
3
Short Bolt
(M6 x 35mm)
25
4
Large Flat Washer
(2 x ɸ8.5 x 19mm)
8
5
Medium Flat Washer
(ɸ6.5 x 16mm)
25
6
Small Flat Washer
(ɸ6.5 x 13mm)
8
7
Small Lock Washer
(ɸ6.5 x 11mm)
33
8
Large Lock Washer
(ɸ8.5 x 13mm)
8
9
Long Screw
(M4 x 50mm)
4
10
Medium Screw
(M4 x 30mm)
28
11
Short Screw
(M3.5 x 15mm)
8
12
Shelf support
bracket
8
13
Handle
4
14
Pan head screw
(M4 x 20mm)
8
15
Allen key
(M4 x 30mm x 110mm)
1
16
Door pin
(5.2/13 x 1.2mm)
(7 x 10mm)
2
17
U-Washer
2
NOTE: HARDWARE IS PACKED IN CARTON WC-18B.

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 6 -
STEP 1
Attach legs (B) to the top (A) with bolts (1), and washers (8) and (4) as shown below. Tighten with
Allen key (15).
Insert stretchers (C) into legs (B) and attach with screws (9) as shown below. Tighten with a
screwdriver.
STEP 2
Attach top (F) to top (A) with bolts (3), and washers (7) and (5) as shown below. Tighten with Allen key (15).

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 7 -
STEP 3
Attach aprons (G) to top (F) with screws (10) as shown below. Tighten with a screwdriver.
Attach side panels (H) to top (F) with bolts (3), and washers (7) and (5) as shown below. Tighten with
Allen key (15).
STEP 4
Attach x-frames (D) to top (A) with bolts (2), and washers (7) and (6) as shown below. Tighten with
Allen key (15).
Slide vertical panel (K) into the grooves of side panels (H), then attach crossbar (E) to x-frames (D)
with bolts (2), and washers (7) and (6) as shown below. Tighten with Allen key (15).

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 8 -
STEP 5
Attach handle (13) to door (J) with screws (14) as shown below. Tighten with a screwdriver.
STEP 6
Attach door (J) to apron (G) and bottom (I) with door pins (16) as shown below.
Attach bottom (I) to side panels (H) and crossbar (E) with bolts (3), and washers (7) and (5) as shown
below. Tighten with Allen key (15).
Attach crossbar (E) to stretchers (C) with bolts (2) and u-washers (17) as shown below. Tighten with
Allen key (15).

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 9 -
STEP 7
Attach drawer sides (N) to drawer front (M) with screws (10) as shown below. Tighten with a
screwdriver.
Insert drawer bottom (P) into the grooves at bottom of drawer sides (N) and drawer front (M) as
shown below.
Attach drawer back (O) to drawer sides (N) with screws (10) as shown below. Tighten with a
screwdriver.
STEP 8
Attach handles (13) to front of drawers with pan head screws (14) as shown below. Tighten with a
screwdriver.
Carefully put the drawers into the unit.

ITEM NO.: WC-18A AND WC-18B
ISSUED MAY 29, 2018
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 10 -
STEP 9
Insert brackets (12) into the unit as shown below. Place shelves (L) on the brackets and attach with
screws (11). Tighten with a screwdriver.
