Unfinished Furniture of Wilmington WC-7 User manual

ITEM NO.: WC
-
7
REVISED SEP 25, 2012
Printed in Vietn
am
- 1 -
Description
Item No.
:
KITCHEN WORKCENTER
: WC - 7
ASSEMBLY INSTRUCTIONS

ITEM NO.: WC
-
7
REVISED SEP 25, 2012
Printed in Vietn
am
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
BEFORE ASSEMBLY
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: WC
-
7
REVISED SEP 25, 2012
Printed in Vietn
am
- 3 -
PART
LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Q
ty
Sketch
NO
Description
Q
ty
Sketch
A Top 1 B Side panel
(R)
1
C Side panel
(L)
1
D
Vertical panel
1
E
Back panel
1
F Bottom panel 1
G Door 1 H
Shelf panel 1
I Rail 1 J
Middle drawer
1
K
Upper drawer
front
1
L
Lower drawer
front
1
M
Drawer side
(L – R)
4 N
Drawer bottom
2
O
Drawer back
2

ITEM NO.: WC
-
7
REVISED SEP 25, 2012
Printed in Vietn
am
- 4 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Q
ty
Sketch
1
Bolt
(M6x35mm)
12 2
Spring washer
(6.5 x 13mm)
12
3
Flat Washer
(6.5 x 19 mm)
12 4
Long screw
(M4x30mm)
18
5
Screw
(M3.5 x 15mm)
4 6 Bracket 4
7
Door pin
(5.2/13x1.2mm)
(7x10mm)
2 8
Pan head
screw
(M4 x 20 mm)
6
9 Handle 3 10 Castor 2
11 Lock castor 2 12
Allen key
(K4)
1
13
Wrench
(19 mm)
1

ITEM NO.: WC
-
7
REVISED SEP 25, 2012
Printed in Vietn
am
- 5 -
STEP 1
Attach side panel (B) to top (A) with bolts (1) and washers (2) and (3) as shown below. Tighten with
Allen key (12).
Attach vertical panel (D) to top (A) with bolts (1) and washers (2) and (3) as shown below. Tighten
with Allen key (12).
Attach rail (I), side panel (B) and vertical panel (D) with screws (4) as shown below. Tighten with a
screwdriver.
STEP 2
Insert back panel (E) to top (A) and side panel (B) as shown below.
Attach side panel (C) to top (A) with bolts (1) and washers (2) and (3) as shown below. Tighten with
Allen key (12).

ITEM NO.: WC
-
7
REVISED SEP 25, 2012
Printed in Vietn
am
- 6 -
STEP 3
`
Attach bottom panel (F) to side panels (B) and (C) with bolts (1) and washers (2) and (3) as shown
below. Tighten with Allen key (12).
Attach doors (G) to top (A) and bottom (F) with door pins (7).
STEP 4
Attach bottom panel (F) to vertical panel (D) with bolts (1) and washers (2) and (3) as shown below.
Tighten with Allen key (12).
Attach castors (10) and lock castors (11) to the bottom of legs as shown below.Tighten with the
wrench (13).
TEP 4

ITEM NO.: WC
-
7
REVISED SEP 25, 2012
Printed in Vietn
am
- 7 -
STEP 5
Attach a drawer side (M) to drawer front (K) and drawer back (O) with screws (4).Tighten with a
screwdriver. Insert drawer bottom (N) into the grooves at bottom of drawer side (M), drawer front (K)
and drawer back (O). Attach the other drawer side (M) to drawer front (K) and drawer back (O) with
screws (4).Tighten with a screwdriver. Attach handles (9) to drawer front (K) with screws (8) as shown
below. Tighten with a screwdriver.
STEP 6
Attach a drawer side (M) to drawer front (L) and drawer back (O) with screws (4).Tighten with a
screwdriver. Insert drawer bottom (N) into the grooves at bottom of drawer side (M), drawer front (L)
and drawer back (O). Attach the other drawer side (M) to drawer front (L) and drawer back (O) with
screws (4).Tighten with a screwdriver. Attach handles (9) to drawer front (L) with screws (8) as shown
below. Tighten with a screwdriver.

ITEM NO.: WC
-
7
REVISED SEP 25, 2012
Printed in Vietn
am
- 8 -
Put the drawers into the unit.
Attach brackets (6) to the unit. Place the shelf (H) on the brackets, and secure with screws (5).
Tighten with a screwdriver.
Attach handles (9) to the door with screws (8). Tighten with a screwdriver.
STEP
7
