UniData Communication Systems WirelessIP3000 User manual

WirelessIP3000 User Guide
Unidata Communication Systems Inc.
WirelessIP3000
User Guide (v.2.2.0)

WirelessIP3000 User Guide
Unidata Communication Systems Inc.
COPYRIGHT NOTICE
UniDataCommunicationSystemsis registered trademarks of UniDataCommunication SystemsInc. Other
referenced trademarks are trademarks (registered or otherwise) ofthe respective trademarkowners.
This document is confidentialandproprietarytoUniData CommunicationSystemsInc. No part of
thdocument maybereproduced, stored,or transmittedin anyformbyanymeans without the prior written
permission ofUniData Communication Systems Inc.
Information furnished herein byUniData Communication SystemsInc., is believed to be accurateand
reliable. The authors haveused their best effortsin preparing this material. These effortsinclude the
development, research, and testing ofthe theories and programs to determine their effectiveness.
However,UniData CommunicationSystemsassumes noliabilityfor errors that mayappear in this
document, or for liabilityotherwisearisingfromthe applicationor useofanysuch information orfor any
infringement ofpatentsor other intellectualpropertyrightsownedbythird partieswhich mayresult from
such application or use. The products, their specifications, and the information appearing in this document
are subject to change without notice.
Printed in Korea
1998-2005 byUniDataCommunication Systems Inc. All rights reserved.

WirelessIP3000 User Guide
Unidata Communication Systems Inc.
Table of Contents
1. SAFETYINFORMATION......................................................................................................................................
2. HOWTHE KEYWORKS....................................................................................................................................... ３
3. ACCESSORY............................................................................................................................................................ ４
3.1 GUIDELINES FOR USE OF ACCESSORY................................................................................................ ４
3.2 AVAILABLE ACCESSORY........................................................................................................................... ４
3.3 INSERTING BATTERY................................................................................................................................... ４
3.4 RELEASING BATTERY................................................................................................................................. ４
3.5 CHARGING BATTERY WITHOUT DESKTOP CHARGER................................................................ ５
4. ICONS ON DISPLAY.............................................................................................................................................. ６
5. INPUTMETHOD.................................................................................................................................................... ７
6. APPLICATION........................................................................................................................................................ ８
6.1 OUTBOUND CALL.......................................................................................................................................... ８
6.1.1APPENDIX (OPTIONS,DIAL MODE)..............................................................................................................
6.2 INBOUND CALL............................................................................................................................................... ９
6.3 PHONE BOOK MENU.................................................................................................................................... ９
6.3.1ADD NEW ENTRY ............................................................................................................................................. ９
6.3.2 CALLFROM PHONE BOOK.......................................................................................................................... １０
6.3.2.1APPENDIX (SUB MENU,DIAL MODE).................................................................................................. １１
6.3.3 EDIT GROUP................................................................................................................................................... １２
6.3.4 DELETE ALL ................................................................................................................................................... １３
6.4 MESSAGE MENU........................................................................................................................................ １３
6.4.1 RECEIVED MESSAGE BOX.......................................................................................................................... １４
6.4.1.1APPENDIX (SUB MENU)........................................................................................................................... １４
6.4.2 WRITE MESSAG ............................................................................................................................................ １６
6.4.3 TEMPORARY BOX ......................................................................................................................................... １７
6.4.4 SENT MESSAGE BOX ................................................................................................................................... １７
6.4.5 DELETE ALL .................................................................................................................................................. １

WirelessIP3000 User Guide
Unidata Communication Systems Inc.
6.5 CALL LOG MENU....................................................................................................................................... １９
6.5.1APPENDIX (OPTION,DIAL MODE)............................................................................................................ ２０
6.5.2 SHOW MORE INFORMATION AND CALLFROM CALL LOG .................................................................. ２０
6.6 PRESENCE MENU....................................................................................................................................... １
6.7 SETUP MENU................................................................................................................................................ ３
6.7.1 BELL /VIB...................................................................................................................................................... ２３
6.7.2 PHONE LOCK.................................................................................................................................................. ２４
6.7.3ALARM............................................................................................................................................................ ２５
6.7.4 VOLUME ......................................................................................................................................................... ２６
6.7.5 ERROR NOTIFY .............................................................................................................................................. ２６
6.7.5.1 SERVICE LAMP ........................................................................................................................................... ２６
6.7.5.2 ERROR MSG................................................................................................................................................ ２６
6.7.6 INFORMATION................................................................................................................................................ ２７
6.7.7ADVANCED..................................................................................................................................................... ２９
6.7.7.1 TIME............................................................................................................................................................. ２９
6.7.7.2 CONTRAST.................................................................................................................................................. ３１
6.7.7.3 LANGUAGE................................................................................................................................................. ３１
6.7.7.4 CALLER ID ................................................................................................................................................. ３１
6.7.7.5 USER DATARESET ..................................................................................................................................... ３１
6.8 NETWORK..................................................................................................................................................... ３
6.8.1 SITE SCAN....................................................................................................................................................... ３２
6.8.2 PING TEST....................................................................................................................................................... ３２
6.8.3 NETWORKRELOAD ...................................................................................................................................... ３４
7 WEB CONFIGURATION TOOL........................................................................................................................ ３５
7.1ABOUT WEB CONFIGURATION TOOL...................................................................................................... ３５
7.2 LOGIN PROCESS............................................................................................................................................. ３５
7.3 USINGTHE WEB CONFIGURATION TOOL.............................................................................................. ３６
8. FAQ........................................................................................................................................................................ ３７
9. GLOSSARY.......................................................................................................................................................... ３８
10. MENU CONSTRUCTION....................................................................................................................................40

WirelessIP3000 User Guide
Unidata Communication Systems Inc.Page 1
Revision History
Release Version
Version Date Description Application
Bootrom

WirelessIP3000 User Guide Howthe keyworks
Unidata Communication Systems Inc.Page
1. SafetyInformation
These safetywarnings applyto the Wireless IPPhoneWirelessIP3000. Please read the following sections
before Installing or using your WirelessIP3000.
1.1 EmergencyServices Warning
This phone will not be able to access emergencyservices during a power outage because ofreliance on
utilitypower for normal operation.Alternative arrangements should bemade for accessing emergency
services.
1.2 Explosive Gas Warning
The use ofthe WirelessIP3000 in hazardous environmentswhere highlevel ofexplosivegas maybe
Presentisnotrecommended. Checkwiththesitesafetyengineerbeforeusinganytypeofwireless device
in such an environm8ent.
1.3 BatteryDisposal Warning
Do not dispose ofthe batterypackin fire or water.The batterymayexplode ifplaced in the fire.
1.4 BatterySafety Notices These Batterysafetynotices applyto the batteries that are approved bythe
WirelessIP3000 manufacturer.
ØDo not disassemble, crush, puncture, or incineratethe batterypack.
ØTo avoidriskoffire, burns, or damage to your batterypack, do not allowa metal object to touch the
batterycontacts.
ØHandle a damaged or leaking batterywith extreme care. If youcome in contact with the electrolyte,
wash the exposed areawith soap and water. Iftheelectrolyte has come in contact withyour eye,
flush the eye with water for 15 minutes and seekmedical attention
ØDo not charge the batterypackifthe ambient temperature exceeds 40 degrees Celsius.
ØDo not keep thebatterypack in temperatures above 60degrees Celsius.
ØWhen discarding a batterypack, contact your localwaste disposal provider regarding local
restrictions on the disposalor recycling ofbatteries.
ØTo obtain a replacement battery, contact your local dealer.Use the batteries that are provided by
WirelessIP3000 manufacturer only.
ØUse the power supplythat is provided by WirelessIP3000 manufacturer only.
1.5 RegulatoryCompliance Standards
WirelessIP3000 does notcomply with any standards. Use only as a Marketing Sample.

WirelessIP3000 User Guide Howthe keyworks
Unidata Communication Systems Inc.Page ３
2. Howthe keyworks
LEFTSOFT
RIGHTSOFT
MULTI FUNCTION KEY
CLEAR
SEND
END
DIAL PAD
Use it for enteringmenu, editing something, saving phone number,and
changing character input.
Use it for searching, going back to previous screen, shortcut to presence
menu, and muting.
1. Menu browsing
1) Pressing the keytoLEFTdirection changes thedisp
laytothe
previous screen
2) Pressing thekeyto RIGHTdirection changes the displaytothe
next screen for the itemyou selected in either menu or setup.
3) Pressing the keytoUPor DOWNdirection allowsyouto scroll up
or downthemenu or setup screen.
2. Editing
1) Pressing the keyto LEFT direction moves the cursor left.
2) Pressing the keyto RIGHT direction moves the cursor right.
In text editing, deletes one character (backspace). While browsing
menu, goes backto theprevious menu.
Use this keyto make and receive calls.
During a call,it disconnects the call.While browsing menu, it exits menu.
Power ON: holdingit down till ‘Loading…’ message shows up.
Power OFF: holding it down for a second or longer.
Dialpadis for dialing just likethe normal telephone and entering
alphanumeric characters when editing names and phone numbers.
Also, it can beusedfor quickmenu browsing.

WirelessIP3000 User Guide Accessory
Unidata Communication Systems Inc.Page ４
3. Accessory
3.1 Guidelines for Use of Accessory
Followthese guidelines in using accessories withyourWireless IPPhone WirelessIP3000.
nWhen disconnecting the power cord ofanyaccessory,grasp bythe plug, not the cord and pull.
nKeep the accessories away fromchildren.
nUse onlycharger, batteries,accessories that are approvedbytheWirelessIP Phone manufacturer.
Usingunapprovedcharger,batteries,andaccessories maybedangerous, andmayinvalidatethe
warrantyon your phone.
3.2 AvailableAccessory
nExtended Battery
nAC Adapter
nDesktop Charger
nUSB Cable
3.3 Inserting Battery
Placethebatteryinto the batterybayon the backside ofthe phoneand pushuptowards the release button
until it clicks.
3.4 Releasing Battery
Take the batteryoff fromthe phone bypressing the release button and pull out the batterytowards the
bottomofthe phone.
Note : For more information about releasingbattery, refer to page 10.

WirelessIP3000 User Guide Accessory
Unidata Communication Systems Inc.Page ５
3.5 Charging BatterywithoutDesktop Charger
Step 1. Plug theAC adapter into awall outlet.Step 2. Remove the protective connector cover ofthe phone.
Step 3. Insert theAC adapter connector into base ofthe phone.
Note : It is also possible tocharge the phone byusing the USB cable instead ofthe
AC adapter as shown in Figure 6.

WirelessIP3000 User Guide Icons on Display
Unidata Communication Systems Inc.Page ６
4. Icons on Display
Status message of idlemode display
Indicates user is online.
Indicates user is busy.
Indicates user is going to be right back.
Indicates user is awayfor awhile.
Indicates user is on the phone.
Indicates user is out tolunch.
Indicates user is offline.
Indicate signal strength.
More bars displayed
indicate better isolation
Indicate lampmode is on.
LED blinks when there is
an incoming call.
Indicate vibration mode is on.
It gets displayedwhenring
mode is set to vibration.
Indicate alarmis on.
It gets displayedwhenalarm
clocksetup is on.
Indicates new message(s).
It gets displayedwhenthere is/are
newmessages(s) that has not
beenread
Indicate batterylife.
More bars displayed
indicate more energy.
Indicate user is online.
For more description
refer to below.
Indicate keylock.
While this mode is on,
pressing keyswill do nothing
Figure 1. Icons on Display

WirelessIP3000 User Guide Input Method
Unidata Communication Systems Inc.Page ７
5. Input Method
Dial pad is formed with integer 0~9, *, and # and usedfor inputting3 or 4 alphabetletters and some
symbols. Once a Dial keyhas been pressed,pressing it again while the rectangular cursor keeps blinking
will change the current input to the next letter assigned for that specific key.See the table belowfor theDial
keyassignment. Notethatafter the rectangular cursor blinks couple oftimes, it will change into a vertical
bar cursor.
Dial Pad
Key 1234567890*#
.ADGJMPTW Space *#
@
BEHKNQUX.@
CFILORVY-_
F
O
N
T SZ
Dial Pad
Key 1234567890*#
.adgjm ptwSpace *#
@
behknqux.@
cfilorvy-_
F
O
N
T sz
Dial Pad
Key
1 2 3 4 5 6 7 8 9 0
Font 1 2 3 4 5 6 7 8 9 0

WirelessIP3000 User Guide Application
Unidata Communication Systems Inc.Page ８
6. Application
6.1 Outbound Call
6.1.1 Appendix (Options, Dial Mode)
If you dial a desired number,
you can seetheOption
Menuand Dial Mode. Let’s
see what can we dowith this
menu.
1. Prefix = 0
2. 184= 184
3. 186= 186
When you select, each
numbers will go in front
ofdialed number.
Once registered, you can
make calls to others that are
registered to the same SIP
server.
Dial number & press Send
Key.If your call reach the
otherparty,youwill hear ring
backtone
IfCallee receives your call,
timer starts activating on the
top ofthe screen.
You can savethedialed
number as Phone BookMenu.
You can see the search result that
the number you dialed.
Note : You cansee the search result ofdialed number
onlyifthe number was alreadysaved in Phone Book.

WirelessIP3000 User Guide Application
Unidata Communication Systems Inc.Page ９
6.2 Inbound Call
6.3 Phone Book Menu
z
6.3.1 Add NewEntry
You can store info such as phone number of your family,friends and others. It must have
at least one stored number in the phone bookto search.
Use Left Soft Keyto
enter the menu fromidle
screen.
Enter Phone book.
Once registered, you
can alsoreceive calls.
Ifsomeone calls you, it says
"Incoming call" onthetopof the
screen and displays caller number.
If you receive a call, timer
activates on the top ofthe
screen.
If you press Enter Keyto save
without enteringanydata,
<Warning> message popsup.
Inputinformation: Name Read Name Phone Number
Group Index. After done inputting information you need,
press Enter Keyto save. It is not requiredto fill everything out
but the Phone number is essential.

WirelessIP3000 User Guide Application
Unidata Communication Systems Inc.Page １０
6.3.2 Call from Phone Book
Calling fromthe PhoneBook is another wayto make a call instead ofdialing fromidle screen.
So as to do, you need to search phone number stored in PhoneBookbyfollowing the stepsbelow.
There are 5 ways to searchthe number.
①ByKana
②ByName
③ByPhoneNumber
④ByGroup
⑤ByIndex
If you didn’tinput the exact information
whichever wayamong theabove, phone will
search the name or number that contains the
input character that you entered.
Select Andyand press Enter Keythen it
will showAndy’s information: Read
Name, Phone Number, Group and Index.
Note : For example, let’s saythat onepersonis Kim, and second person is Kimberly.Theyboth have
‘K’in their name. So if you don’twantto enter whole name to search one person byName,
you can just input one letter ‘K’then press Enter Key. Result will show Kimand Kimberly.
Press SendKeyor Enter Keywherever
the focus at canmake a call to the
person.

WirelessIP3000 User Guide Application
Unidata Communication Systems Inc.Page １１
6.3.2.1 Appendix (Sub Menu, Dial Mode)
You can see theAppendix Menuat
Search Resultbyname.
Press Left Soft keyto enterSubMenu.
You can store another
phone number in here.
You can edit the stored
number in here.
You can deletethestored
number in here.
You can send SMS message
directlyin here, Instead of
sending at message menu.
You can adda friendto
presence menu friends list.

WirelessIP3000 User Guide Application
Unidata Communication Systems Inc.Page １
6.3.3 Edit Group
This section explains youhowto add, delete or edit group.
Undefined is a default group, which cannot
be edited or deleted. You can add or edit a
group byusing Options menu.
Note : Maximum10 groupscan be
made.
The picture on the left shows adding a group
named as “WirelessIP”. Press Enter Keyto
save a new group and it goes backto Phone
Bookmenu.
Use Options menu or select a group you
want to edit andpress Enter Key.
Press Enter Keyagain to saveand itgoes
backto PhoneBookmenu.
Before using Options menu to delete the
cursor should be at the group you wantto
delete. Press Enter Keyto delete.
Removed dialog will disappear ina second; it
goes backto Phone Bookmenu.

WirelessIP3000 User Guide Application
Unidata Communication Systems Inc.Page １３
6.3.4 Delete all
This function deletes all thephone numbers stored in Phone Bookbut the groupsdon’t get deleted.
6.4 MessageMenu
Message is usedfor short communication bytransmitting words to each other.
Select “Deleteall”and
press Enter Key.
Phone will ask you to
make confirmation. Use
◁▷ keyto choose
“Yes”or “No”.
Selecting “Yes”will show
the process ofdeleting
the entirePhone Book
datum.
In a second, “Removed”
dialogshows and it goes
backto PhoneBook
menu.
Use Left Soft Keyto select
the menu fromthe idle
screen.
Select “Message”and press
Enter Key.

WirelessIP3000 User Guide Application
Unidata Communication Systems Inc.Page １４
6.4.1 Received Message Box
All the messages you receivedgetstored in here. If youwant to see old/newmessages check
the “Received Message Box”.
6.4.1.1 Appendix (Sub Menu)
uReply
You can replystraightlyto the person
who has sent the message to you.
Ifthere are unread messages, it will show the dialog howmany
unread messages are left. Right after thatdialog disappears, it
will show thelist ofmessages.
Select “Recv.Msg Box”and
press Enter Key.
Select the message you want to read in larger windowand press
Enter Keythen screenwill looklike picture on the left.
ØYou can see the entire message manuallybyusing △▽ key.
*Message contains the date, time, phone number and contents.

WirelessIP3000 User Guide Application
Unidata Communication Systems Inc.Page １５
uForward
uSave
uDelete
You can forward received
message to another person.
You can deletea message here.
You can store the number who
has sent you the message.

WirelessIP3000 User Guide Application
Unidata Communication Systems Inc.Page １６
6.4.2 Write Messag
You can write andsendmessage here.
Select “Write Msg”and press
Enter Key.
Use dial padandLeft Soft Keyto
write amessage.
* Holding down a Clear button
clears the whole text.
Enter the number that you
want to send a message
to.
Select “Yes”byusing ◁▷
keyand press Enter Keyto
delete.
It shows the process of
sending amessage.
