Unimac NALFRMUMCACB5 User manual

Cordless Framing Nailer
User Manual
[Revision 4.0 April 2017]
READ THIS MANUAL CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE – FAILURE TO DO SO MAY
RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • Products covered by this manual may vary in
appearance, assembly, inclusions, specifications, description and packaging.

Cordless Framing Nailer
E&OE © 2017 Unimac i
Table of Contents
Safety.................................................................................................................................................................1
Operation...........................................................................................................................................................2
Description....................................................................................................................................................2
Air supply......................................................................................................................................................2
Loading fastener and operation.....................................................................................................................2
Maintenance ......................................................................................................................................................3
Troubleshooting ............................................................................................................................................3
Technical Specifications...................................................................................................................................4

Cordless Framing Nailer
E&OE © 2017 Unimac 1
Safety
WARNING! ENSURE THAT NO PART OF ANY HUMAN, ANIMAL OR CLOTHING IS PLACED IN/NEAR THE
AREA WHERE NAILS ARE FIRED OUT OF THE GUN, REGARDLESS OF WHETHER YOU THINK THE GUN IS
EMPTY OR LOADED WITH NAILS.
•KEEP CHILDREN AWAY. All children should be kept away from the work area. Don’t let them handle the
tool.
•USE SAFETY GLASS AND EAR PROTECTION: Air tool operators and others in work area should always
wear safety glass to prevent the injury from fasteners and flying debris when loading and unloading this tool.
Maybe the noise would harm your hearing, wear the ear protection to safeguard. (See fig 1.)
•NEVER USE OXYGEN, COMBUSTIBLE OR ANY OTHER BOTTLE GAS as a power source or would
cause explosion and serious personal injury. (See fig 2.)
•DO NOT CONNECT TOOL TO COMPRESSED AIR which pressure exceeds 120psi.
•DO NOT PLACE OVER-LONG AIR HOSE in working area in case of the operator’s unexpected tripping.
Make sure all connections are tight
•CARRING TOOL ONLY BY THE HANDLE do not keep the trigger pull on safety yoke mechanism to avoid
unintentional firing of fastener.
•KEEP THE TOOL POINTED AWAY FROM YOURSELF and others at all time and keep hands, any body
parts away rear area to Safety guard against possible injury.
•DISCONNECT TOOL FROM AIR SUPPLY BEFORE LOADING fasteners to prevent a fastener from being
fired during connection. (See fig3.)
•DO NOT KEEP THE TRIGGER OR SAFETY DEPRESSED during loading fasteners or the unintentional
firing of a fastener would cause personal injury
•DISCONNECT TOOL FROM AIR SUPPLY HOSE and close the compressor before performing
maintenance, alter the accessories or during non-operation.
•DO NOT DRIVE FASTENER ON SCAFFOLDINGS, LADDERS and on such similarly construction, not
working on airtight case, and vehicles.
•DO NOT DRIVE FASTENERS CLOSE TO THE EDGE OF THE WORK PIECE. The workpiece would split
allowing fastener to fly free or ricochet causing personal injury.
•DO NOT DRIVE FASTENER ON TOP OF NAILED FASTENER, or the fastener can ricochet causing
personal injury.
•NEVER USE A TOOL that is leaking air, had missing or damaged parts or requires repair and make sure all
the screws and securely tightened.
•MAKE DAILY INSPECTION FOR FREE MOVEMENT of trigger, safety mechanism and spring to insure the
tool can operate well.
•ONLY USE PARTS AND ACCESSORIES recommend by manufacturer.

Cordless Framing Nailer
E&OE © 2017 Unimac 2
Operation
Description
This angle finish nailer drives Ga. 15 finish nails from 32mm to 64mm length. Large cast aluminum body provide
more power to easily drive nails in to hard wood. The well balance design can make you work efficient. The
angle magazine can make you shoot any corners. Features 360-degree exhaust port can be adjusted to any
direction. And quick release nose cover to easily clear jams. Angle finish nailer is ideal for door and window
trims, exterior trims, and cabinet work, finish paneling, decorative trims and etc.
Air supply
1. Use clean, Dry and Regulated compressed air at 4-7 bar (60-100psi)
2. Never exceed maximum and minimum pressure. Too low or too high pressure would cause noise, fast-worn
or misfiring.
3. When connecting air supply always keep hands and body from discharge area of tool.
4. A filter-regulator-lubrication is required and should be located as close to tool as possible.
5. Keep air filter clean. A dirty filter will reduce the air pressure to the tool causing a reduction in power and
efficiency.
6. For better performance, install a quick connector in your tool and quick coupler on the hose if possible.
7. Be sure all connections in air supply system are sealed to prevent air loss.
Loading fastener and operation
Always disconnect the tool from the compressed air before loading. When loading the tool always point the tool
away from yourself and others. Make sure that you are not holding the tool with trigger depressed while loading
the tool.
1. Insert a strip of fasteners into magazine keeping it point down.
2. Release the latch and pusher, slid the pusher against the nails.
3. Connect the tool to the air supply. Make sure the air pressure is in the correct range denoted in the
Technical Data.
4. Then test the driving depth in a sample piece of wood before using. If the fasteners are being driven too far
or not far enough, adjust the regulator to provide less air pressure or more air pressure.
5. Never operate tool unless safety nose is contact with workpiece. Do not operate tool without fasteners or
damage to tool may result.
6. Never fire fasteners into air because fasteners may injury operator or others and damage to tool may result.
7. The air tool is equipped with safety stand mechanism that disable tool unless safety stand is pushed against
work. Hold gun body firmly and press safety stand on workpiece where fastener is to be applied. Pull the
trigger to drive fastener into workpiece.
8. This operating procedure provides rapid-fire fastener driving. Never operate tool unless safety stand is in
contact with workpiece.

Cordless Framing Nailer
E&OE © 2017 Unimac 3
Maintenance
Disconnect the tool from the air compressor before adjusting, clearing jams, servicing, relocating and during
non-operation.
•Regular lubrication, if your tool without using the in-liner automatic oilier, place 2 or 6 drops of pneumatic tool
oil into the air inlet before each work day or after 2 hours of continuous use depending on the characteristic
of workpiece or type of fasteners.
•Check and change all worn or damaged O-rings, seals, etc. Tight all the screws and caps in case personal
injury.
•Inspect trigger and safety mechanism to assure safe system is complete and functional: no loose and
missing parts, no building or sticking parts.
•Keep magazine and nose of tool clean and free of any dirt lint or abrasive particles.
Troubleshooting
The following form lists the common operating system with problem and solutions. Please read the form
carefully and follow it.
If any of the following symptoms appears during your operating, stop using the tool immediately, or serious
personal injury could result. Only a qualified persons or an authorized service center can perform repairs or
replacement of tool.
Disconnect tool from air supply before attempting repair or adjustment. When replacing O-rings or Cylinder,
lubricate with air tool oil before assembly.
SYMPTOM PROBLEM SOLUTIONS
Air leak near top of tool or in trigger
area 1. O-ring in trigger valve are damage.
2. Trigger valve head are damage.
3. Trigger valve stem, seal or O-ring
are damaged.
1. Check and replace O-ring.
2. Check and replace.
3. Check and replace trigger valve
stem, seal or O-ring
Air leak near bottom of tool. 1. Loose screws.
2. Worn or damaged O-rings or
bumper.
1. Tighten screws.
2. Check and replace O-rings or
bumper.
Air leak between body and cylinder
cap. 1. Loose screws.
2. Worn or damaged O-rings or seals.
1. Tighten screw.
2. Check and replace O-rings or
bumper.
Blade driving fastener too deep. 1. Worn bumper.
2. Air pressure is too high.
1. Replace bumper.
2. Adjust the air pressure.
Tool does not operate well: cannot
drive fastener or operate sluggishly. 1. Inadequate air supply.
2. Inadequate lubrication.
3. Worn or damaged O-rings or seals.
4. Exhaust port in cylinder head is
blocked.
1. Verify adequate air supply.
2. Place 2 or 6 drops of oil into air
inlet.
3. Check and replace O-rings or seal.
4. Replace damaged internal parts.

Cordless Framing Nailer
E&OE © 2017 Unimac 4
SYMPTOM PROBLEM SOLUTIONS
Tool skips fasteners. 1. Worn bumper or damaged spring.
2. Dirt in front plate.
3. Dirt or damage prevents fasteners
from moving freely in magazine.
4. Worn or dry O-ring on piston or lack
of lubrication.
5. Cylinder cover seal leaking.
1. Replace bumper or pusher spring.
2. Clean drive channel on front plate.
3. Magazine needs to be cleaned.
4. O-ring need to be replaced.
And lubricate.
5. Replace Sealing washer.
Tool jams. 1. Incorrect or damaged fasteners.
2. Damaged or worn driver guide.
3. Magazine or nose screw loose.
4. Magazine is dirty.
1. Change and use correct fastener.
2. Check and replace the driver.
3. Tighten the magazine.
4. Clean the magazine.
Technical Specifications
Capacity 80pcs
Nail length 50mm - 90mm
Operation pressure 80-120PSi (5.5-8.3bar); Max = 120PSI (8.3bar)
Air inlet ¼”N.P.T.
Weight 4kg

Cordless Framing Nailer
E&OE © 2017 Unimac 5
