Unimax MSN120 User manual

???
??????
WARRANTY CARD
Product: PALM HELD PNEUMATIC NAIL HAMMER MSN120
Type: MSN120
Date of manufacture:
Date of sale, stamp, signature:
Serial number (product series):
Repair centre notes:
Without the correctly filled warranty card or without proof of purchase receipt, including
the product type (invoice, purchase receipt) no warranty claim will be processed.
1. KH Trading machines and tools are covered by 6/24 months warranty, starting on the date of
purchase, as described in the Civil Code (proof of purchase or invoice receipt must be
enclosed with the warranty card when making a claim).
2. This warranty does not cover defects caused by unprofessional handling, machine overloads, not
complying with instructions contained in this manual, using accessories that are not approved,
unauthorized repair, regular wear and tear and damages occurred during transport. Further, this
warranty does not cover parts and accessories such as the motor, carbon brushes, seals and
hot-air operated parts and parts that need to be changed regularly.
3. If the repair is to be found as not covered by the warranty policy, all costs including the repair and ship-
ping to and from the repair centre will be paid by the customer, according to valid price list. See www.
4. When making a claim, you must present the warranty card, showing the date of the purchase, the
serial number of the machine, vendor stamp and signature of sales clerk, as well as the proof of
purchase receipt.
5. Warranty claim shall be made at the vendor shop where you bought your machine or you may mail
it to a service centre. The vendor is obligated to fill out the warranty card (date of sale, serial
number, vendor stamp and signature). All these information must be filled in at the time of sale.
6. The warranty period will be extended for the period of time for which the machine has been in the
service centre possession. If the repair or defect is not covered by the warranty policy, all costs including
the repair and shipping will be paid by the owner of the machine / tool. We recommend sending the
machine in its original packaging. Please, also enclose brief description of the defect with the packaging.
7. Before sending the machine for repair, clean it thoroughly. If the received machine is dirty, it may
be rejected by the service shop or you may be charged a cleaning fee.
SERVICE
Logistic centre Klecany
Topolová 483
250 67 Klecany
Czech Republic
Claim department phone number: 266 190 156 T-mobile: [phone]
266 190 111 O2: 601 218 255
Fax: [phone] Vodafone: 608 227 255
http://www.KHnet.cz
Email: ser[email protected]
PPAALLMMHHEELLDDPPNNEEUUMMAATTIICC
NNAAIILLHHAAMMMMEERR
MMSSNN112200
USER'S MANUAL
MSN120

2
Dear customer. Thank you for purchasing equipment from KH Trading, s.r.o.
Our company is ready to offer you our services - before, during and after you buy our product.
If you have any question, comment or idea, please contact our business centre. We will do our best to address
your comment or question in timely matter.
Before first use, please read this manual carefully. It is your responsibility to study all instructions,
necessary for safe use and operation and to understand all risks that may be involved during the use
of power machines.
WARNING! Do not try to use this machine before reading this entire manual and before you know
how to handle it. Keep this manual for future reference. Pay special attention to safety instructions.
Not complying with safety rules may cause injury to the operating person or to people standing by
or it may cause damage to the machine or to the work piece. Pay special attention to safety notes
and safety labels on the machine. Never remove or damage them.
Please, write information such as the invoice number
and the number of the sale receipt here in this box.
Palm nail hammer MSN 120 is fully automatic tool. It has no start switch. Simply place the nail inside the mag-
netic case and press on the nail's head by placing the machine over the nail's head.
Simple use, easy grip, reliability and high power output enables you to use this unique machine in various type
of work. Your device is not equipped with nail magazine. Nails must be placed inside the magnetic case one by
one.
The hammer inside the machine vibrates, creating impacts that drive the nail easily into the surface of the work
piece.
Your set includes assembly wrench, pneumatic oil container and leather protective sleeve.
The accuracy of instructions, graphs and information contained herein, depends on the printing date. Due to
continuous product improvement, the manufacturer reserves the right to change technical parameters of the
product, without prior customer notification.
Nail dimensions
Maximum length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120 mm
Maximum head diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .∅11.5 mm
Operational compressed air pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .min. 3.5 - max. 8.2 bar
Maximum allowed air pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8.6 bar
Air consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60 - 115 l.min.-1
Air supply hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3/8"
Dimension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100 × 90 × 130 mm
Gross weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.95 kg
DESCRIPTION
TECHNICAL SPECIFICATIONS
REPAIR AND MAINTENANCE REPORT
Report and maintenance report:
DATE SERVICE SHOP REPAIR AND MAINTENANCE REPORT

3
???
•This device may be used by a qualified person, 18 years or older who has been
trained in work and environmental safety procedures.
Symbols used in this manual
Warning!
This symbol informs you about the risk of personal injury or damage to the machine
or materials.
General instructions
•Plastic bags and packaging materials pose danger for small children and animals.
•Make sure you know your tool or machine and that you are familiar with its operating procedure. Know the
hazards if not used correctly.
•If other person will be using this machine make sure that he knows how to safely operate this equipment
and that he is familiar with hazards and risk that may occur if not used correctly.
•Observe your work continuously and use all your senses during work. Do not continue to work if you
cannot pay full attention.
•Maintain your tools clean.
•Handles must be kept free of grease and dirt.
•Use only for purposes for which it has been designed.
•Never work under the influence of alcohol or other drugs.
•Any modifications or improvements to the machine are strictly prohibited. DO NOT USE if you discover
bent part, crack or other damage.
•If you see any unusual sign or hear any strange sound, stop the device immediately and stop working.
•Perform maintenance regularly. Before use make sure the machine is in good working conditions and
without any damage.
•Use only original spare parts during repairs.
•Using non-original spare parts or other parts not approved by the manufacturer may cause injury to the
operating personnel.
•Do not expose to extremely high temperatures or direct sunlight.
•This machine is not design for use in humid environments or under water.
•if you are not using your machine, store it in a dry and safe place, out of reach of children.
•If not stated otherwise in this manual, all damaged parts must be repaired or changed.
Palm held nail hammer
•Always use safety goggles.
•Do not insert the nail inside the magnetic case if your device is not connected to the air supply source.
•Before starting your work make sure that all screws, including the screws of the upper lid, are tightened
securely.
SAFETY PRECAUTIONS

4
•Before performing any maintenance, repair or adjustment, make sure that the device is disconnected from
the air supply.
•It is strictly prohibited to aim the pneumatic hammer with inserted nail against persons or animals.
Compressed air
•Dry and compressed air must have a defined pressure at the device's admission and must be supplied in
sufficient quantity. Higher pressure shortens the service life as a result of faster wear and tear and bears
the risk of injury.
•The joint, through which the compressed air flows into the device, must correspond to the prescribed
dimensions.
•Pay special attention to water, which damages tools when present. Do not forget to release the
condensed water from the pressure tank of the compressor on a daily basis and to also dry the hose,
which is used to supply the air into the tool.
•Make sure no dirt may enter your device. It is necessary to keep inlet and outlet openings clean.
•Before uncoupling compressed air piping or hose, wait until the pressure equalizes.
•Before starting your work, inspect all couplings and piping for leakage. If leak is found repair it
immediately. Leakage overloads the compressor and causes significant increase in operational loads.
•Inspect the pressure hoses and piping system regularly. If you discover damage or leak, stop working
immediately and have the defective house changed immediately. Pressurized hoses cannot be twisted.
Observe the line on the hose surface. Keep the line as straight as possible.
•Do not run the pressure hoses over sharp edges or through places where they may be damaged or cut.
•Blow compressed air through new hoses.
•When you have to run the hose through a various structures, use protective bushing and inspect them
regularly.
•Use protective covers or plugs to prevent dirt from entering the inside of your machine.
Power equipment
•Before performing any maintenance make sure to lower the air pressure inside the air system down to the
atmospheric pressure.
•If your machine is equipped with depressed springs, use a suitable device to release them slowly and
safely.
Hand tools
•Never use vise to hold your tool/machine.
•Make sure to have your work piece securely fastened. Use caution during manipulation and/or releasing
the work piece from the fastening device.
9
LIST OF PARTS
No. Description
1 Screw
2 Cylinder cover
3 O-ring
4 Rubber sealing ring
5 Seal
6 O-ring
7 Friction casing
8 Sealing ring
9 Cylinder
10 Cylinder cover
11 O-ring
12 Piston
13 Piston rod
14 O-ring
15 Stopper
16 Casing
17 Body
18 Speed clutch piece
19 Washer
20 Spring
21 Guide
22 Magnet
23 Guide bushings

8
PART DRAWING
5
???
•Before throwing the packaging material out, make sure no part is left inside. If so, take it out and install it.
Use the part listing for check-up and the installation drawing for guidance.
Connecting your device to the compressed air supply
Supply hoses and threaded couplings
•Even though your machine needs small amount of air to work properly (about 60 - 115 l.min -1) you must
use the proper size of air hose and couplings (3/8").
•Your device requires operational air pressure of 3.5 bar to work properly.
•The maximum air pressure must not be greater then 8.2 bar.
Start up
•Before using your machine, drop few drops of pneumatic oil into the air supply opening.
•Make sure that no dirt may enter the inside of your machine. Use protective plugs to cover inlets and
outlets when uncoupling the air supply hose.
•Ensure proper lubrication during work.
•When using your device only for small work loads, it is usually sufficient to drop few drops of oil into the air
supply inlet.
•If you plan on performing heavier work, we recommend using automatic lubrication system.
Always use protective goggles during work.
Air pressure
•The maximum air pressure must not be greater then 8.2 bar.
WARNING:
Do not overload your machine.
Using higher pressure then 8,6 bar may damage the inner mechanism of your machine and
it will not be covered by the warranty.
Using your machine
Palm nail hammer MSN 120 is fully automatic tool.
It has no start switch. It will start to work when your press the stopper (21) on the nail's head.
•Set the pressure according to the used nail size:
Nail dimensions Air pressure
6d - 8d 3.5 - 5.5 bar
8d - 12d 5.5 - 6.9 bar
12d - 50d 6.9 - 8.2 bar
ASSEMBLY
OPERATION

•Place the nail's head inside the magnet case (22).
•Hold the nail in your left or right hand as you would do when using normal hammer.
•Hold your machine in other hand and place it straight over the nail's head.Then release the nail.
•Slowly press the pneumatic hammer on the nail's head.
•The machine will start automatically drive the nail into the surface.
•When the nail is completely hammered in and out of reach of the hammer, the machine will shut off
automatically.
•Repeat the process to nail other nails down.
TROUBLESHOOTING
•If you experience sudden air pressure fall, the inner mechanism may get stuck in a middle position and
the air may blow through but the machine will not work.
•This is will not cause any damages and it is not considered as malfunctioning.
•To stop the air from escaping, clap the machine against the palm of the other hand (note 2). It is
prohibited to clap the machine against hard surface such as wood or metal, brick, concrete etc.
The upper lid may crack. Such damages are not covered by the warranty.
•This action will stop the air from escaping and the functionality of your machine will be restored.
•Keep your device clean. Dirt may enter the inner mechanism of your machine and cause damage.
•Do not use aggressive cleaning solution or paint thinners to clean the machine.
•Clean plastic parts with cloth dipped in soup water.
•Clean and lubricate metal surfaces with a cloth dipped in paraffin oil.
•If you are not using your machine, lubricate it with suitable grease and store it in a dry place to prevent
corrosion.
Lubrication
•Use only special oil designed for lubrication of pneumatic systems.
•Do not use other oils or lubricants.
When the operational life of your device is over, dispose off it in accordance with valid rules and regulations.
Your product is made of metal and plastic parts that may be recycled when separated.
1. Disassemble all parts.
2. Separate all parts according to the material they are made of (e.g. metals, rubber, plastics, etc.).
Take the separated parts to the recycling facility near you for further processing.
Information about the location of recycling centres may be found at your local City office or throughout an
Internet search.
6
MAINTENANCE
DISPOSAL
7
???
If the machine breaks down, send it back to the vendor for quick repair.
Please, enclose brief description of the defect. That makes repair easier. If the machine is still covered by
warranty, enclose the warranty card and proof of purchase receipt. After the warranty period expires, we
repair your machine for a special price.
To prevent possible damages during shipping, packed the machine carefully or use the original packaging
material. We are not liable for shipping damages due to incorrect packaging of your machine. If making
a claim at the shipping company the level and method of packaging plays a major role during claim evaluation
process.
Note: Pictures and contents in this manual may slightly differ from the actual product or accessories.
It is due to continuous improvement of our products. Such small differences have no effect on the product
functionality.
CAUTION
