Uninet iColor Series User manual

UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]
www.icolorprint.com








iColor®Matrix Remover and Slitter
User Manual

IMPORTANT NOTICE
THE MACHINE CAN ALSO BE USED AS
SLITTER ONLY.
WHENYOUDOTHAT,PLEASEREMOVE
THE TOP MOTORIZED CORE HOLDER
AND ADJUST THE CLUTCH KNOB ON
THE UNWINDER CORE HOLDER.
CORE HOLDER
Non-Motorized core holder
Use only on
unwinder station
Motorized core holder

Waste Matrix
Take up mandrel / Weeder
(Motorized)
Take up mandrel
(Motorized)
Legend
MCH: MOTORIZED CORE HOLDER
Slitter
Blade Housing
Slitter station
Tension arm
Commands
Unwinder
Supply mandrel
(Non-Motorized)

Load the printed and die cut roll on
the supply mandrel (non-motorized).
Push until it touches roll guide.
1
RUN A JOB
WARNING: Before starting a new job, always make sure the
waste matrix from the previous job has been removed.
Do not attach the matrix from a different size label to an existing
roll.
This will cause an uneven wrap which will cause the material
to walk.
Note on Media Environment:
50%humidityand72degreesFahrenheitistheoptimalconditionsforbothstorageand
use of label stock. Store label stock in protective plastic wrappings. Rewrap partially
used stock. Do not store stock directly on concrete oors.
Label stock should be conditioned in this environment for 72 hours prior to use. Failure
to store media in these conditions may result in media tension problems. Too much
humidity will cause labels to curl on the edges.

Place an empty wide core on the
mandrel (motorized).
Push the core until it touches the
core stop. Tighten using the tension
knob.
Insert the empty cardboard core on
the MCH (motorized) to receive the
new labels roll.
Set the supply mandrel in the supply
location. Match the gray handle to
gray holder.
3
4
2

Pull the printed labels for about fty
centimeters.
Set the weeder mandrel in the
weeder location on the top of the
MCH.
6
7
5Paper path.

Separate the matrix from liner at this
point.
the matrix to the empty core on the
weeder mandrel.
Insert the MCH into the lower matrix
support.
9
10
8

Continue pulling the printed labels
and manually turning the weeder
mandrel so that the matrix is
wrapped around the core at least
once.
1. Move the printed label behind the
lower MCH
2. Position the empty cardboard
core on the single future new labels
roll
3. Tighten the roll and the guide in
place by turning the tension knob.
11
12
Temporarily attach the label directly
to the take-up mandrel.
This will provide the necessary
tension in order to start the slitting
process.
13

Slitter module has 3 positions:
- Upper position (A), the blades are closed to allow the media loading;
- Middle position (B), align the blades with the edges and the center of the labels,
tighten the thumb screw once the blade is in position;
- Lower position (C), the blade cut the media.
OPEN CLOSE
B
C
A
A
B C
Position the blades in between
each column and on either edge if
desired.
You can alternate the position of the
thumb screw from the top to the side
to gain easier access.
WARNING!
The slitter blades are exposed
and VERY sharp when the slitter
station is in the “up” position.
Use extreme caution!
14

The black knobs lock the slitter
module in the requested position.
Screw the thumb knobs to move the
blades to the right or to the left.
Turn on the MATRIX REMOVER
using the power switch on the
back.
Make sure the speed knob is in the
slowest position before you switch
on the MATRIX REMOVER.
Slowly turn the speed knob.
Run the machine until the slit labels
reach the bottom of the take-up
mandrel.
16
15

Remove the labels that have
wrapped around the take-up
mandrel.
17
Attach the labels to the core using
waste label or tape.
18

Feed the edge waste under the edge
waste roller.
19
Note:
Make sure the tension on all rolls is even. If they are not even and you
have already attached them to the core you can easily equalize them by
loosening the tension knob on the mandrel just a little. Now turn each
core on the mandrel until all label rolls are taut. Tighten the knob again.
Switch on the MATRIX and
slowly turn to increase the speed.
Evaluate the following areas:
1. Matrix Release
2. Matrix Mandrel
Wrapping
3. Slitting
4. Finished Cores
20

When the roll is nished, the unit
automatically stops when the
contact on the dancer arm touches
the screw on the base.
You will also hear an audible tone.
21
Remove the nished rolls from the
take up location.
Remove the rolls from the take-up
mandrel.
22
23

Separate the nished rolls. Some
interleaving may occur.
This is normal.
Finally, remove the waste matrix
mandrel and discard the matrix
and the core.
We do not recommend reusing
the same core with matrix from a
previous job still attached.
25
24

HOW TO ADD OR REMOVE A BLADE HOLDER
Keep out the iron slide bar unscrewing
the thumb screw.
1
Slide in or out the blade holder.
Relocate the slide iron bar in its
position and rescrew the thumb screw.
2
REPLACING SLITTER BLADES
It is possible to adjust the clutch by just screwing
or loosening the aluminium handle on it.
+ more clutch
- less clutch
HOW TO ADJUST THE CLUTCH ON UNWINDER
Loosen the two screws holding the blade
in place.
Replace the blade.
Fix back the screw to holding the blade in
place.

Paper path
