Unitech MS140 User manual

The MS140 family of bar code slot readers is a flexible, cost
effective solution when you demand a reliable and rugged slot
reader.With a resolution of up to 6 mils (0.15 mm), the MS140
is capable of reading any bar coded identification badge.
Its sealed optical system is available in both visible light or
infrared.The infrared units ensure accurate reading of either
visible and laminated badges.Its water resistant base and
rugged housing make the MS140 a popular choice in any
environment.Anoptionalmountingbracket is availabletosafely
secure the unit in any direction.
Likemost ofour products,the MS140is availablewith avariety
ofinterfaces,including undecoded(TTL), keyboard wedge(XT/
AT, PS/2 and Macintosh), and RS232.All Unitech undecoded
products have pen output and can be connected to any of the
ourwedge lineor toany external device that acceptspen input.
Decoded versions are easy to use and configure.Both the
keyboard wedge and RS232 can be configured on-screen by
selecting the desired options from a menu.And the
configuration can be reproduced in other units by generating
custom setup labels.
Features:
•Available with TTL, keyboard wedge
and RS232 interfaces.
•Reads most popular bar code
symbologies.
•Easy to use and configure.
•50 mm to 750 mm/sec Scan Rate.
•6 mil minimum resolution.
•Reads visible and laminated
barcode labels.
•Advanced Data Editing.
•Rugged, lightweight housing.
•Wide slot allows thicker badges.
MS140/I
Bar Code
Slot Reader
Scanners

Scanners
MS140/I
Bar Code Slot
Reader
Ordering Information:
MS140A Visible light, undecoded, DB9 Squeeze & Release connector
MS140-2 Visible light, RS232, DB9 connector (may require 5V AC adapter)
MS140-3 Visible light, keyboard wedge interface, DIN connectors
MS140-3PS2 Visible light, keyboard wedge interface, miniDIN (PS/2) connectors
MS140IA Infrared light, undecoded, DB9 Squeeze & Release connector
MS140I-2 Infrared light, RS232, DB9 connector (may require 5V AC adapter)
MS140I-3 Infrared light, keyboard wedge interface, DIN connectors
MS140I-3PS2 Infrared light, keyboard wedge interface, miniDIN (PS/2) connectors
SNOITACIFICEPS
:ECNAMROFREPecruosthgiL:derarfnI)I041SM(DELmn039)041SM(DELmn066:thgilelbisiV
rosneSedoidotohP
dleiffohtpeDmm2
noituloseRslim6.nim)mm51.0(
SCP.nim6.0
etarnacSces/)mm057("03ot)mm05("0.2
:ECAFRETNIygolobmyS,A-CPU,31-NAE,IICSAllufdnadradnats93edoC2dradnats,E-CPU,8-NAE
,39edoC,821edoC,5fo,edoClebaL,edoCatleD,23edoC,11edoC,ISM
rabadoC,edoCyesselP
ecafretnI)dedocednu(LTT,232SR,hsotnicaM,2/SP,TA/TXCP
noitarugifnoCdraobyeKaivputeS
gnitidEataDop,elbmaerp,dIedoCsatmelb
/LACINAHCEM:LACIRTCELE
snoisnemiD("3.1x"4.2x"9.4HxWxL)mm0.33x5.06x5.321
thgieW)elbachtiwLTT(g091
tuptuOlatigiD)LTT(levelhgih=kcalb,rotcellocnepO
noitpmusnocrewoP%5CDV5@LTTrofAm53noisrevdedoceDrofAm07
droCenilthgiarts)m1.2(.tf9.6
TNEMNORIVNELA:
erutarepmeT)C°05ot°0(F°221otF°23gnitarepO)C°06ot°02-(F°041otF°4-:egarotS
ytidimuHgnisnednocnonHR%59ot%0
kcohSlacinahceMetercnocnopord)m5.1(.tf5
