Universal Tool UT5964A Specifications

Manufacturer/Supplier Product Type
RPM
Cycles Per
Tel No Fax No (01494) [phone]
Model No/Nos Serial No
Product Nett Weight Recommended Use Of
Balancer Or Support Recommended Hose Bore Size - Minimum
Recommended Max.
Hose Length
Ins M/M Ft M
Foreseen Use
This screwdriver is designed for the tightening and loosening
of threaded fasteners within the range as specified by the
manufacturer. It should only be used in conjunction with
1/4" male hex shank screwdriver bits and fastener drivers.
Do not use the tool for any other purpose than that specified
without consulting the manufacturer or his authorised
representative.
Putting Into Service
Air Supply
Use a clean lubricated air supply that will give a measured
air pressure at the tool of 90 p.s.i./6.3 bar when the tool
is running with the trigger fully depressed. Use recommended
hose size and length. It is recommended that the tool is
connected to the air supply as shown in figure 1. Do not
connect the tool to the air line system without incorporating
an easy to reach and operate air shut off valve. The air
supply should be lubricated. It is strongly recommended that
an air filter, regulator, lubricator (FRL) is used as shown in
Figure 1 as this will supply clean, lubricated air at the correct
pressure to the tool. Details of such equipment can be
obtained from your supplier. If such equipment is not used
then the tool should be lubricated by shutting off the air
supply to the tool, depressurising the line by pressing the
Work Stations
The tool should only be used as a hand held, hand operated
tool. It is always recommended that the tool is used when
standing on a solid floor. It can be used in other positions,
but before any such use the operator must be in a secure
position having a firm grip and footing. The operator must
adopt a firm grip sufficient to resist the torque reaction of
the tool, i.e. the tool will try
to turn in the hand. The
operator must also be aware
that when loosening fasteners,
the tool can move quite
quickly away from the fastener
being undone. An allowance
must be made for this rear-
ward movement to avoid hand
entrapment. The operator must
also make allowance that if
the tool does turn in the hand,
the hand is not trapped
against any rigid object.
No
Page No 1
Pistol Rev. Screwdriver
A
djustable Clutch
UT5964A
3/8 10 30 10
1,800
Includes - Foreseen Use, Work Stations, Putting Into Service,
Operating, Dismantling, Assembly and Safety Rules
Operator Instructions Important
Read these instructions carefully before installing, operating,
servicing or repairing this tool. Keep these instructions in a
safe accessible place.
Universal Air Tool Company Limited
Unit 8
Lane End Industrial Park
High Wycombe
Bucks
HP14 3BY
lbs
Kg
2.2
1.00
Noise Sound Pressure Level 84.3 dB(A)
Test Method Tested in accordance with
Pneurop test code PN8NTC1 and ISO
Sound Power Level 89.7 dB(A)
Vibration
Test Method Tested in accordance with ISO
standards 8662 Parts 1 & 7
Less than 2.5 Metres / Sec²
Air Pressure
Recommended Working 6.3 bar 90 PSI
Recommended Minimum n/a bar n/a PSI
Maximum 7.0 bar 100 PSI
Personal Safety Equipment
Use - Safety Glasses Yes
Use - Safety Gloves
Use - Safety Boots
Use - Breathing Masks
Use - Ear Protectors

Operating
Select the correct screwdriver bit or fastener driver to suit the
screw or fastener to be tightened or loosened. Slide back the
sleeve (44) and insert appropriate drive bit. This model has
an external adjustable clutch so that the torque applied to the
fastener can be adjusted easily to give the required tightness
within the torque range of the tool. To set the tool to give a
particular torque output, turn the adjust ring (49) If the fastener
is not sufficiently tightened or cannot be loosened then the
tool in adjustable clutch mode has insufficient capacity. Select
a more powerful tool. The person setting up the tool must
be aware of this torque reaction at high setting levels of the
clutch and that the tool will try to turn against the hand. All
that is required is a firm grip. The tool, when the stall torque
position has been reached, can still be used to set or loosen
fasteners, provided the operator is aware of the need to resist
the torque reaction of the tool. The only thing that will affect
the output is a change in the air supply pressure. The output
can be increased up to the use of the maximum allowed
supply pressure and decreased with a reduction in supply
pressure until the tool fails to operate. It must also be
understood that even if the clutch is set to slip it may not do
so if the supply air pressure falls below the pressure at which
the clutch was set. It is therefore strongly recommended that
a pressure control valve is used. Information as to suitable
equipment can be obtained from your supplier. When using
the tool keep the screwdriver bit pressed firmly into the screw
head to avoid cam out and screw head damage.
Dismantling & Assembly Instruction
Disconnect tool from air supply.
Grip the tool by hand then unscrew and remove clutch
housing (7) from clamp nut (41) – left hand thread.
Remove adjust cover (47) from clutch housing (7). Pull out
the clutch assembly grip the clutch assembly and with a
sharp pointed needle tool prise out retaining ring (31) and
remove washer (46), spring (45), and ball retainer (44)
being careful not lose screwdriver bit retaining ball (35).
Again with the sharp pointed tool, remove second retaining
ring (31) and pull off spacer (43). Unscrew adjust nut (47)
and pull off washer (46), clutch spring (39) and washer
(38). Tap front end to remove 4 off balls (37). Remove
retaining ring (33) and separate clutch (36). Remove a third
retaining ring (31) and pull off drive clutch (30). Unscrew
clamp nut (41) and push out the internal assembly and
ball bearing(29), internal gear (32), 3 off planet gears (25)
and work spindle (28). Do not remove the 3 off pins from
work spindle (27). Drive out pin (6), unscrew set screw
(23) and pull off trigger (24) and remove spring (22). Grip
valve stem (21) and pull out the complete valve assembly.
Separate reverse lever (20), reverse retainer (19), o-ring
(18), reverse bushing (17) and o-ring (16). Unscrew air
inlet (2) and screw (3) and remove exhaust diffuser (4) and
damping material (5). Grip end of rotor (13) and pull out
the complete motor assembly. Remove 2 pins (11), motor
gasket (9) Grip spacer (15) and with a non metallic or soft
metal (lead of aluminium) hammer tap the splined end of
the rotor (13) to drive it through bearing (8). Remove
cylinder (12) and take out 5 off rotor blades (14) from the
rotor (12). Support end plate (10) and tap the rotor (13)
through the end plate (10) and bearing (8).
Reassembly
Clean all component parts and examine to wear before
reassembling. Look in particular for wear and cuts on o-rings,
wear on rotor blades, gear, and clutch components. Coat
all parts with pneumatic tool lubricating oil and grease all
bearings, gears, and clutch parts with a molybdenum or
lithium based general purpose grease. Before reassembling
the motor make sure that the faces of end plates (10) that
abut cylinder (12) are flat and free from burrs. If necessary,
lap on a flat very fine grade of abrasive paper. Reassemble
in the reverse order. When refitting the complete motor
assembly to housing (7) first make sure that the assembly
is clamped tightly together and the rotor spins freely, slide
the assembly with gasket into the housing (7) ensuring that
motor pin (11) locates in the motor assembly and in the
hole in the bottom of the main bore of housing (7) suited
between the two main ports. Reset the clutch as required
and/ or set the correct air pressure – see Operating.
trigger on the tool. Disconnect the air line and pour into the
intake bushing a teaspoonful (5ml) of a suitable pneumatic
motor lubricating oil preferably incorporating a rust inhibitor.
Reconnect tool to air supply and run tool slowly for a few
seconds to allow air to circulate the oil. If tool is used
frequently lubricate on daily basis and if tool starts to slow
or lose power.
It is recommended that the air pressure at the tool whilst
the tool is running is 90 p.s.i./6.3 bar. The tool can run at
lower and higher pressures with the maximum permitted
working air pressure of 100 p.s.i./7.0 bar.
Page No 2
Safety Rules For A Screwdriver
1) Read all the instructions before using this tool. All operators
must be fully trained in its use and aware of these safety
rules.
2) Do not exceed the maximum working air pressure.
3) Use personal safety equipment.
4) Use only compressed air at the recommended conditions.
5) If the tool appears to malfunction remove from use
immediately and arrange for service and repair.
6) If the tool is used with a balancer or other support device
ensure that it is fixed securely.
7) Always keep hands away from the working attachment
fitted to the tool.
8) The tool is not electrically insulated. Never use the tool
if there is any chance of it coming into contact with live
electricity.
9) Always when using the tool adopt a firm footing and/or
position and grip the tool firmly to be able to counteract
any forces or reaction forces that may be generated whilst
using the tool.
10) Use only correct spare parts. Do not improvise or make
temporary repairs.
11) Do not lock, tape, wire, etc. the on/off valve in the run
position. The trigger/lever etc. must always be free to return
to the 'off' position when it is released.
12) Always shut off the air supply to the tool, and depress
the trigger/lever etc. to exhaust air from the feed hose before
fitting, adjusting or removing the working attachment.
13) Check hose and fittings regularly for wear. Replace if
necessary. Do not carry the tool by its hose and ensure the
hand is remote from the on/off control when carrying the
tool with the air supply connected.
14) Take care against entanglement of moving parts of the
tool with clothing, ties, hair, cleaning rags, etc. This will
cause the body to be drawn towards the tool and can be
very dangerous.
15) It is expected that users will adopt safe working practices
and observe all relevant legal requirements when installing,
using or maintaining the tool.
16) Do not install the tool unless an easily accessible and
easily operable on/off valve is incorporated in the air supply.
17) Take care that the tool exhaust air does not cause a
problem or blows on another person.
18) Never lay a tool down unless the working attachment
has stopped moving.

UT5964A
Page No 3
1,800RPM Pistol Grip Reversible Screwdriver - Adj. Clutch
Nov 2004 Ver 1.00
Ref No Part No Description
1 82253-12 Rubber Grip
2 70103 Air Inlet
3 40309 Screw (2)
4 70110 Exhaust Diffuser
5 82250 Damping Material
6 82202 Pin
7 822101 Motor Housing
8 030113 Ball Bearing (2)
9 80211 Motor Gasket
10 80214 End Plate (2)
11 80217 Spring Pin (2)
12 80218 Cylinder
13 80215 Rotor
14 80216 Rotor Blades (5)
15 80219 Spacer
16 82247 O-Ring
17 82206 Reverse Retainer
18 82209 O-Ring
19 82212 Reverse Retainer
20 82210 Reverse Lever
21 82205A Valve Stem Set
22 82208 Valve Spring
23 82246 Set Screw
24 82204 Trigger
25 80223 Planet Gear (3)
26 80225 Bushing (3)
Ref No Part No Description
27 30124 Pin (3)
28 80226 Work Spindle
29 080227 Ball Bearing
30 80229 Drive Clutch
31 80230 Retaining Ring (3)
32 80222 Internal Gear
33 80231 Snap Ring
34 80232 Cam Spindle
35 40145 Steel Ball (9)
36 80234 Clutch
37 80235 Steel Ball (4)
38 80236 Thrust Washer
39 812E37 Spring
40 812E36 Thrust Washer
41 812E28 Clamp Nut
42 812E38 Guide
43 80240 Spacer
44 80242 Ball Retainer
45 80243 Spring
46 80244 Washer
47 812E21 Adjust Nut
48 812E12 O-Ring
49 812E20 Adjust Ring
50 812E41 Head Cap
51 812E39 Indicator

Distributor
Notes
Page No 4
Accessories
19) Always ensure that the reverse button is in the selected
position before starting the tool.
20) Do not use bits or sockets with excessive wear to the
input and output drives. Make sure the bit, socket, extension
is firmly fixed to the tool.
21) When loosening fasteners first ensure that there is
sufficient clearance behind the tool to avoid hand entrapment.
The tool will move away from the threaded joint as the
nut/bolt is loosened and rides up the thread moving the
tool with it.
Declaration of Conformity
Universal Air Tool Company Limited
Unit 8, Lane End Industrial Park, High Wycombe, Bucks, HP14 3BY, England
declare under our sole responsibility that the product
Model UT5964A Pistol Reversible Screwdriver, Serial Number
to which this declaration relates is in conformity with the following standard(s) or other normative document(s)
EN792 (Draft), EN292 Parts 1 & 2, ISO 8662 Parts 1 & 7, Pneurop PN8NTC1
following the provisions of
89/392/EEC as amended by 91/368/EEC & 93/44/EEC Directives
Place and date of issue Name and signature or equivalent marking of authorised
Lane End D.H.Moppett (Man. Director)
This document may not be copied wholly or in part by anyone without the consent of the Directors of Universal Air Tool
©Copyright of Universal Air Tool Company Limited, established in the United Kingdom, 1994
Designed & Written in the U.K.
