UPC 1461 Quick start guide

ASSEMBLY INSTRUCTIONS
UPC #1461 UPC - Slotwall Pinwheel Spinner
Page 1 of 4
Revised 10/07/19
Finished Display
Thank you for your purchase of one of many fine products designed & manufactured by UPC.
We have made every effort to make your assembly easy, clear & hassle free. For more information
or if you have any questions contact customer service at 1-800-859-7442.
upcdisplays.com
PART Quantity Reference
PART Quantity Reference
Header Clip 1 A
Hex Wrench 1 B
Connector Bolt 24 (1 Extra) C
Top Cap 1 D
Slotwall Panel 4 E
Base 1 F
PARTS LIST
PARTS BAG
E
F
D
A
B
C

Page 2 of 4
ASSEMBLY
upcdisplays.com
E
C
C
D
Stand up (1) Slotwall Panel (E) with the
finished edge up and the slots facing toward you.
Line up 2nd Slotwall Panel (E) to form a “T” with
the first as shown. Align and Attach the two panels
as shown below using (4) Connector Bolts (C)
in the pre-drilled holes using Hex Wrench (B).
1
Hold Top Cap (D) into place, align and attach to
(2) Slotwall Panels (E) using
(2) Connector Bolts (C) and Hex Wrench (B).
2
E

Page 3 of 4
ASSEMBLY
upcdisplays.com
C
C
E
D
C
F
F
E
E
Align and Attach 3rd Slotwall Panel (E)
to assemby as shown on right using
(4) Connector Bolts (C) and
Hex Wrench (B).
Align & Attach 3rd Slotwall Panel (E) to
Top Cap (D) using (1) Connector Bolts (C)
using Hex Wrench (B).
3
Place the Slotwall Panel Assembly (E) onto
Base (F) and line up pre-drilled
holes at the bottom of
Slotwall Panel Assembly (E) with holes in
base using (3) Connector Bolts (C)
using Hex Wrench (B).
4

Page 4 of 4
ASSEMBLY
upcdisplays.com
C
E
C
A
D
E
F
Align and attach the 4th Slotwall Panel (E) to
Assembly (D, E, F) by using
(8) Connector Bolts (C) using Hex Wrench (B).
5
Complete assembly by aligning and attaching the
4th Slotwall Panel (E) to the top and bottom
of the Assembly (D, E, F) by using
(2) Connector Bolts (C) using Hex Wrench (B).
Peel protecive layer from Header Clip (A) and attach to
Top Cap (D).
6
