UPC 3637A User manual

C
B
C
B
C
Revised 01/21/15 Page 1 of 2
UPC #3637A 36" 2-Tier PETG Rackwith 2/3 Exposure
ASSEMBLY INSTRUCTIONS
PARTS BAG
PARTS LIST
Align hole in Slatwall Adapter (B) with
back side of hole in Rack (G). Prongs extend
back toward Slatwall and up. Attach using
Screw Post (A) from front and Hex Nut (C)
on back.
Slatwall Assembly
Insert Card Clips (F) into
Rack (G).
1
2
NOTE: Assemble for EITHER Slatwall or Drywall, not both.
A
G
C
B
F
D
E
PART Quantity Reference
Screw Posts 3A
Slatwall Adapters 3B
Hex Nuts 3C
Wall Togglers 3D
Phillips Head Screws 3E
Card Clips 12 F
PART Quantity Reference
Rack 1G
A
A
B
A
F
G
TOOLS REQUIRED: Flathead Screwdriver (Slatwall)
Drill with 3/8” Drywall Bit & Phillips Screwdriver (Drywall)

G
G
E
D
E
E
Determine position on wall
and drill 3/8" hole.
Squeeze Wall Toggler (D) flat
and insert into hole.
Tap flange flush with wall.
Place Rack (G) against Toggler
and insert Phillips Head Screw (E),
tightening until secure.
12
Drywall Assembly
WALLWALL
WALLWALL
D
E
D
G
NOTE: Assemble for EITHER Slatwall or Drywall, not both.
Page 2 of 2
Insert Card Clips (F) into
Rack (G).
3
F
D
D
