UPC 8088 User manual

ASSEMBLY INSTRUCTIONS
PARTS BAG
PARTS LIST
Page 1 of 2
Revised 08/24/2018
Thank you for your purchase of one of many fine products designed & manufactured by UPC.
We have made every effort to make your assembly easy, clear & hassle free. For more information
or if you have any questions contact customer service at 1-800-859-7442.
upcdisplays.com
TOOLS REQUIRED: #2 Phillips Screwdriver
PART Quantity Reference
Connector Bolt 6 A
Screw 4 B
Hinge 2 C
Cap 4 D
Allen Wrench 1 E
UPC 8088 11 Tier 4' Storage Base
PART Quantity Reference
Base 1 F
ABC
F
E
D
A
F
Attach Base (F) to assembly using
(6) Connector Bolts (A).
ASSEMBLY
1
This part used with UPC 8089

Page 2 of 2
ASSEMBLY
upcdisplays.com
Attach (2) Hinges (C) to Front Panel (P)
from 8089 using (4) Screws (B).
Attach Front Panel (P) from 8089 to
assembly by snapping hinges into hinge
plates attached to Base (F).
See DETAIL bottom right.
Peel masking paper and attach (4)
Caps (D) to cover screw holes in front side
of Front Panel (P) from 8089.
Continue assembling full fixture according
to directions included with 8089.
2
D
P
B
C
P
Hinge
Plates
F
1) Place hinge in slightly inclined
position and slide front hook
under baseplate hook.
2) Push hinge end with finger and
snap hinge into mounting plate.
1)
2)
HINGE ATTACHMENT DETAIL
C
