UPC 7134A User manual

Revised 01/19/15 Page 1 of 8
PART Quantity Reference
Left Side 1I
Right Side 1J
Center Plate 1K
Bottom Plate 1L
Top Panel 1M
Cross Panel 2N
Door 1O
Kick Panel 1P
Bottom Lip 1Q
Rack 12 R
Top Cap 1S
PART Quantity Reference
Connector Bolt 2A
Connector Nut 2B
Screw 2C
Push Pin 29 (5 extra) D
Hinge Plate 2E
Hinge Screw 4F
Leveler Foot 4G
Hex Wrench 2H
UPC 7134A, 7136A, 7138A 13 Tier Traditional Card Fixture
PARTS
ABCD
H
I
J
TOOLS REQUIRED: #2 Phillips Screwdriver & Flat Blade Screwdriver
K
L
M
N
O
P
Q
R
S
EF
Assembly will be
much easier with
two people!
G
ASSEMBLY INSTRUCTIONS
PARTS BAG

Page 2 of 8
To assemble plate to sides, slide plate down
over shoulder screws until they are in line with
clip raceway and slide plate toward back of sides
until plate "clicks" into place.
Position Left and Right Side Panels (I & J)
on floor and screw (4) Leveler Feet (G) into
brackets. Be sure threaded rod does NOT
extend beyond top of bracket.
Attach Bottom Plate (L).
See Connector Example below.
Attach Center Plate (K)
to the assembly.
See Detail below right.
Connector Example
L
J
I
K
DETAIL
Screw must NOT
extend above bracket.
G
ASSEMBLY
1
2

Page 3 of 8
Stand fixture upright.
Attach (2) Cross Panels (N) to assembly.
See Connector Example below.
Attach Kick Panel (P) by inserting protruding dowels
into corresponding holes in Bottom Plate (L) and
securing to Sides with (2) Screws (C).
To assemble panels to sides, slide panel down
over shoulder screws until they are in line with
clip raceway and slide brace down the back of the sides
until panel "clicks" into place.
Connector Example
N
C
L
P
ASSEMBLY
3
4

Page 4 of 8
Attach Top Panel (M)
to assembly.
M
Connector Example
ASSEMBLY
5

Page 5 of 8
Attach (2) Hinge Plates (E) to
Bottom Plate (L) using (4)
Hinge Screws (F).
Mount Door (O) to Bottom Plate (L).
See Hinge Instructions below.
1) Place hinge in slightly inclined position
and slide front hook under base plate hook.
2) Push hinge end with finger and snap hinge
into mounting plate.
1)
2)
HINGE INSTRUCTIONS HINGE ADJUSTMENT
NOTE: If hinges do not align,
loosen screws and adjust
right to left as needed to align
hinge and base plate. Then
retighten the screws.
Screws
NOTE: When attaching – listen for the click!
After attaching Door (O) pull and
twist it to be sure it is
securely attached.
E
F
LO
ASSEMBLY
6

Page 6 of 8
A
B
A
B
NOTE: If you are NOT using two or more fixtures
together, move ahead to STEP 8.
ASSEMBLY
7For SIDE TO SIDE:
Secure fixtures together using
(2) Connector Bolts (A) and
(2) Connector Nuts (B)
as shown at right.
For BACK TO BACK:
Secure fixtures together using
(4) Connector Bolts (A) and
(4) Connector Nuts (B)
as shown at right.

Page 7 of 8
Install (12) Racks (R) with (24) Push-Pins (D)
starting with the bottom and
working your way up.
Remove masking from double sided tape,
center side to side,
and attach Top Cap (S).
Press down firmly to adhere.
NOTE: Make sure
racks lock together
as shown below.
TIP: Many installers gently bend
the rack open (below) and
use the end of a screwdriver
handle or hammer handle
to press Push-Pins (D)
firmly into place.
D
R
R
R
D
S
ASSEMBLY
8
9

Page 8 of 8
Bottom Rack
Groove
Q
Q
Install Bottom Lip (Q) sliding top edge into
the slot in the Bottom Rack.
Peel protective plastic off Door (O) and
Center Plate (K).
O
K
By turning clockwise,
you will raise the fixture.
By turning counter-clockwise,
you will lower the fixture.
Open the Door (O) to access the slotted ends
of the threaded rods on the Leveler Feet.
Adjust the feet to level the assembly.
O
ASSEMBLY
10
11
