Upergy RCL0618 User manual

CHARGER FOR POLYCOM TPH900
WITH RESET FUNCTION
Product Code RCL0618
Thank you for choosing our product. Our charger with reset function for a correct charge status display.
Please read these operating instructions carefully before using the product.
If used properly, we provide 24 months manufacturer‘s guarantee.
The removable side panels allow the assembly of several individual stations. (no electrical connection)
1. Charger con igurations DC Input USB Output 2.1 A
Reset Button
Radio Charger
Battery LEDRadio LED
Battery Charger
Power Supply:
100 to 240 AC Volts, 50 to 60 Hz,
1.2A Max / 12.0 VDC @ 4.0 A Max. / 48 Watts
Weight: 420 g
2. Warnings
• This charger can only be used to charge TPH900 radios
and the appropriate batteries.
• Only use our power supply 12V 4 A for operation.
• The ideal operating temperature is between 0 and 40° C.
Avoid extremely high or low ambient temperatures.
• Protect the device from humidity and dirt.
• During charging and discharging, the battery heats up. If
a battery gets very hot, disconnect the charger from the
power supply and check the battery or radio for a defect.
• Opening the charger will void the manufacturer‘s guarantee.
• Please contact us in case of a defect.
• If the charger is not used for a long time, we recommend
disconnecting it from the power supply. Li-ion batteries
age faster if you keep them 100% charged.
UPERGY •11C rue des Aulnes - BP 10020 - 69542
Champagne au Mont d'Or 10 •Tel. [phone]

UPERGY •11C rue des Aulnes - BP 10020 - 69542
Champagne au Mont d'Or 10 •Tel. [phone]
3. LED configurations
CHARGE STATUS RADIO LED BATTERY LED PICTURE
Power On Green
Radio Present Blue
Radio Battery Full Green
Battery Absent OFF
Battery Charge-in-progress Flashing Green
Battery Charge-in-progress
≥80% Capacity Fast Flashing Green
Battery Charge Complete Green
Reset function active Red
Battery Faulty or Over-Temperature
Remove and check battery Flashing Red
Protection circuit activated
Battery charge for safety aborted
Dispose defective battery
