URVOLAX UR71C User manual

Wireless Touch Screen Carplay
UR71C User Manual
Please read this manual thoroughly before operating the device,
and keep it for future reference.

Contents
1. Introduction ..............................................................................................................3
2. Packing List ............................................................................................................4
3. Product Specification ............................................................................................5
4. Installation ............................................................................................................6-7
5. Product Structure ...................................................................................................8
6. Operation & Settings .......................................................................................9-13
7. CONNECTION METHOD ............................................................................14-20
Part One: iOS Device - iPhone .....................................................................................14-19
Ⅰ. "CarPlay" for synchronization ............................................................................................................14-16
Ⅱ. "Airplay" for Mirror Link .................................................................................................................17-19
Part Two: Android Phone ...............................................................................................19-20
Ⅰ. "Android Auto" for synchronization ........................................................................................................19
Ⅱ. "AutoLink" for Mirror Link ..................................................................................................................20
8. SD Card ..................................................................................................................21
9. Bluetooth Music ...................................................................................................21
10. Bluetooth Call ....................................................................................................22
11. Independent Built-in Speaker .........................................................................22
12. Sound Transmission from 71C to Car Speaker ...................................23-24
OPTION 1: WIRED - AUX Cable ......................................................................................23
OPTION 2: WIRELESS - FM Transmit ...........................................................................24
13. TROUBLE SHOOTING .............................................................................25-26
14. Warranty Activate & Customer Support Contacts .....................................27

3
THANK YOU for purchasing URVOLAX Wireless Touch
Screen Carplay!
This manual will help you install and operate it properly.
This Carplay works as an alternative of your smart phone in
car, connecting your Apple or Android Auto Phone without wire.
With this Carplay, you can watch videos, make phone calls,
navigate, play music and so on, it helps you focus more on
safe driving.
Introduction
Email: [email protected]

4
Packing List
Power Cable
7 Inch Screen
Screen Sunshade Screen Bracket
AUX Cable User Manual
Flat base for
screen bracket on
dashboard
Email: [email protected]

5
Product Specification
Email: [email protected]
Screen Size 7 INCH IPS Touch Screen
Resolution 1024x600
Screen Brightness 500cd/m2
System Support Apple, Android
Audio Transmit Bluetooth + FM transmit
RCA output RCA 2.0 output (camera)
WIFI Bluetooth Antenna Built-in Dual Antenna
WIFI 5.8G WiFi
Bluetooth 5.0 Bluetooth
Bluetooth Call Support YES
Bluetooth Address Book
Synchronization Support YES
Bluetooth Music Control
Support YES
USB interface Yes(one)
AUX in Yes(one)
System Startup Time Approx 10 seconds
Power Supply DC 12V-24V 2.5A
Models Available All models including Jeep,Truck, Motorhome,
Trailer (12-24V)
SD Card Storage
Support 8GB - 512GB (not included)
Storage Temperature
Operating Temperature -20℃~70℃
-40~85℃
Video Format Support
Audio Format Support
3GP/ASF/AVI/DivX/mkv/MOV/MP4/MPG/TS/VOB/
WEBM/M4V/FLV
MP3/MP2/WAV/AAC/AMR/M4A/OGG/APE(lossless)/
FLAC(lossless)

6
Installation
STEP1.Installthesunshadeonscreen
STEP2.Installthebracketonthebackofscreen
STEP3.Usethesuctioncuptosuckthescreenonwindshield
❶
❷
The bracket can be extended for
convenient viewing.
❸
Email: [email protected]

7
Installation
① Suck on windshield by suction
cup
② Place on dashboard by suction
cup with flat base
■TWO MOUNTING WAY
Step4.Onlyforplacingscreenondashboard:Sticktheflatbasetothe
bracketsuctioncup.
❹
Email: [email protected]

8
Product Structure
① Audio OUT (Connect to car speaker with Aux Cable)
② AV IN (For Optional Backup Camera)
③ USB Port
④ TF Card Slot (8GB -512GB)
⑤ Power Plug (12-24V 2.5A)
RESET
Email: [email protected]
①
②
③
④
⑤

9
Operation and Settings
① iPhone Carplay: iPhone Synchronization
② Android Auto: Android Synchronization
③ Airplay: iPhone Mirror Link
④ AutoLink: Android Mirror Link
⑤ FM transmit: Adjust the 71C FM to the same frequency as the car, the
sound can be played through the car speaker directly.
⑥ USB: For playing music/video/pictures from USB flash drive, or
connecting mobile phone via compatible USB cable.
⑦ Micro SD Card: For playing music/video/pictures from memory card.
Email: [email protected]
① ②
③ ④ ⑤ ⑥ ⑦

Operation and Settings
⑧ BT Music: Play music from a mobile phone through Bluetooth.
⑨ Phone: Enter the Bluetooth call interface.
⑩ Settings: Set/Adjust other functions.
⑪ EQ: Select/Control the car speaker (Only work with AUX cable
connected)
⑫ Wallpaper: Change the background image.
10
Email: [email protected]
⑨ ⑩ ⑫⑪⑧

11
Smart phone > Android Device > Android Auto
To Connect and Synchronize Android Phone to 71C device
Smart phone > Android Device > Auto Link
To Mirror Link Android Phone to 71C device
Email: [email protected]
Operation and Settings
Wallpaper, Language, Date/Time, Version Information
System >
Smart phone >

12
Email: [email protected]
Operation and Settings
Smart phone > Apple Device > iOSMirror
To Mirror Link iPhone to 71C device
Smart phone > Wireless connection mode > Carplay/AirPlay and
Android Auto
Carplay: iPhone synchronization
Airplay: iPhone Mirror Link
Android Anto: Android Phone synchronization
Smart phone > Apple Device > CarPlay
To Connect and Synchronize iPhone to 71C device
Smart phone > Wireless connection mode > Autolink
Android Phone Mirror Link
IMPORTANT REMINDER:
Please make sure to select the "Smart Phone" options correctly for
connection.
Specific choices please refer to PAGE 14.
Please do not hesitate to contact us if you have any question during
operation: [email protected]

13
Operation and Settings
Connect WiFi and Check WiFi Name & Password
(WiFi Name will vary based on different FW versions.)
WiFi >
Connect Bluetooth and Check Bluetooth Name
(Bluetooth Name will vary based on different FW versions.)
Bluetooth >
Email: [email protected]
Screen Display Brightness
Display >
Backup Camera Display (with Backup Camera connected)
CVBS OUT >
Sound from Car Speaker (with AUX cable connected)
Sound effect >
With backup camera connected
Reversing setting
Only need to set when there is an issue, feel free to contact us for solution.
Factory

14
Email: [email protected]
CONNECTION METHOD
1. Settings→Smart phone→Apple device→Carplay
2. Settings→Smart phone→Wireless connection mode→Carplay/Airplay
and Android Auto
3. Bluetooth
Ⅰ. "CarPlay" for synchronization
OPTION 1: WIRELESS Connection
iPhone searches
for Bluetooth
“CarBt_c7748b”
for Pair
❶
Connection succeeded
❹
Click “Pair”
❷
Click “Allow”
❸
Part One: iOS Device - iPhone

15
Email: [email protected]
CONNECTION METHOD
4. WIFI
Turn ON the WIFI setting of 71C device and connect to iPhone
iPhone searches and
choose the WiFi
“CarWIFI_c7748b”
to connect
❶
Enter the password
“88888888”,click “Join”
❷
Connection succeeded
❸
The name of Bluetooth and Wifi will vary based on different FW versions.

16
Email: [email protected]
CONNECTION METHOD
◘ Siri
◘ SMS Messages
◘ iTunes
◘ Apple Maps
◘ Hands-free Calls
1. Settings→Smart phone→Apple device→Carplay
2. Connect iPhone to 71C device by USB cable directly for
synchronization.
(No need to connect Bluetooth or WIFI)
a) Apps display on 71C device will vary depend on the phone applications.
b) Music Audio App can use with Maps simultaneously: Keep playing
music and then back to maps for navigation.
c) Following and more features can be synchronized between iPhone
and 71C.
If more applications are needed, please can search in iPhone APP store
for "Carplay"
OPTION 2: WIRED Connection
For BOTH wireless and wired connections:

17
Email: [email protected]
1. Settings→Smart phone→Apple device→iOSMirror
2. Settings→Smart phone→Wireless connection mode→Carplay/Airplay
and Android Auto
3. Turn OFF Bluetooth
4. Turn ON Wifi and connect, password: 88888888
5. Select "Screen Mirroring" on iPhone and mirror linked successfully.
Ⅱ. "Airplay" for Mirror Link
OPTION 1: WIRELESS Connection
CONNECTION METHOD

18
Email: [email protected]
CONNECTION METHOD
Please disconnect the "Carplay" before using the "Airplay", to make sure
Airplay can work properly.

19
Email: [email protected]
CONNECTION METHOD
1. Settings→Smart phone→Apple device→iOSMirror
2. Connect iPhone to 71C device by USB cable directly for Mirror Link
(No need to connect Bluetooth or WIFI)
OPTION 2: WIRED Connection
1. Settings→Smart phone→Android device→Android Auto
2. Settings→Smart phone→Wireless connection mode→Carplay/Airplay
and Android Auto
3. Install "Android Auto" from APP or Google Store on Android Phone
4. Connect 71C BLUETOOTH to Android phone
5. Connect 71C WIFI to Android phone
Ⅰ. "Android Auto" for synchronization
Part Two: Android Phone

CONNECTION METHOD
20
Email: [email protected]
1. Settings→Smart phone→Android device→Auto Link
2. Settings→Smart phone→Wireless connection mode→Auto Link
3. Install "Autolink PRO" by scanning below QR CODE or from
Google Store
4. Open "Autolink PRO" and search 71C WIFI for connection
Ⅱ. "AutoLink" for Mirror Link
WIRED CONNECTION:
Select corresponding "Smart phone" menu options and Connect Android
phone to 71C device by USB cable directly.
