UWE W75 Series User manual

W75 Series
Digital Weighing Scale
Operation Manual
Universal Weight Electronics
January 2018 V1
X0W75030000

TABLE OF CONTENT
1. BEFORE USE FOR THE FIRST TIME
2. INTRODUCTION
3. PANEL AND KEYBOARD
4. INTERNAL FUNCTIONS
5. INSTRUCTION TO USE
6. DAILY CARE AND MAINTENANCE
APPENDIX:
-ERROR CODES
-COMPUTER COMMAND
-DISPLAY SEGMENT DEFINITION

1. BEFORE USE FOR THE FIRST TIME
●Thank you for purchasing an UWE product, please read this instruction carefully before start
using. You shall find the following items inside the box:
W75 indicator x 1
Switch power adaptor x 1
Operation manual x 1
Platform (when purchase as complete scale) x 1
If you don’t find all the items as described above, please contact your dealer for further assistance.
●When equips with a platform, place the scale in a stable environment and adjust the
adjustable feet to a level position by referring to the bubble level
●The indicator/scale is equipped with rechargeable battery, please charge it until the charging
indicator turns green to ensure the best battery performance
●Always use factory supplied power adaptor for charging purpose, an unapproved power
adaptor may shorten the battery life and further damages the electronic components
●Warm up the scale for 15 minutes before use for the first time
●Make sure the capacity and division setup on the display when switching on is the same as the
data plate
●Avoid to use the scale when the environment is with strong wind, vibration and strong
magnetic field
●Use it within the recommended temperature range and avoid wet environment
●Recharge the battery immediately when battery status indicator starts flashing
●Use damp cloth to clean the scale if necessary, excessive moisture is prohibited
●When not using, switch off the power and keep the scale in a dry and cool place

2. INTRODUCTION
SPECIFICATION
Model No.
W75
LCD Digits
W75 - 5 1/2 digits
Input Voltage
-15mV ~ +15mV
Input Sensitivity
0.9μV/e (Legal Approved: 1/10000)
Non-Linearity
0.01% of Maximum Capacity
Load Cell Excitation Voltage
DC 5V
A/D Conversion Type
Δ-Σ Delta-Sigma 24 bits
A/D Internal Resolution
1,000,000 Counts
A/D Conversion Rate
10 times/second
External Resolution
Legal Approved: 1/10000
Non-approved: 1/30000 (Recommended)
Power-on Zero Range
±10% of Max
Zero Range
±2% of Max
Tare Range
Full Range Tare
Weighing Units
Kg, g, lb, PCS
Power Source
External AC Adaptor: AC100~240V, DC9V/0.6A
Built-in Rechargeable Battery:
W75/W75: 6V/4Ah
Operating Environment
-10 ~ 40oC Non-condensed. R.H.≦ 85%

3. PANEL AND KEYBOARD
PANEL
W75
1. ZERO INDICATOR
This sign appears when scale is at zero weight status.
2. NEGATIVE INDICATOR
This sign appears when weighing result is below true zero
3. NET INDICATOR
This sign appears when tare function is engaged and weight shown is the net weight.
4. STABLE INDICATOR
This sign appears to indicate the scale is at its equilibrium status.
5. WEIGHING UNIT
This indicates the weight unit which the scale is currently measuring:
A metric unit of kg or g can be set.
An imperial unit of lb can be set.
6. PIECE COUNTING FUNCTION
This sign appears when scale is in piece counting mode.
7. PRESET TARE INDICATOR
This sign appears when a preset tare value is entered and engaged.
8. W1
This indicates the scale is set with dual range, and the weight is within the first range.
9. W2
This indicates the scale is set with dual range, and the weight is within the second range.

10. MR
This indicator appears when value shown on the display is the total saved value.
11. M+
This indicator appears when memory contains data.
12. AVERAGE FUNCTION
This indicator appears when digital motion filtering function is engaged.
13. ANIMAL WEIGHING FUNCTION
This sign appears when scale is in animal weighing mode, which the scale is now operating at
maximum motion filtering level.
14. BATTERY STATUS
This indicates the power level of the rechargeable battery, and should be charged immediately
when the sign starts flashing to prolong the time of rechargeable battery.
15. CHARGING STATUS
Red light indicates AC power is supplied and charging is in process.
Green light indicates charging completed
KEYBOARD
Press this key to turn on the scale, or press and hold this key to turn off the
scale
1. 1. Press this key to manually set the display value to zero, please refer to
specification for manual zero range
2. Press this key to increase the value under internal setup mode
1. 1. Press this key to tare the weight off from the platter
2. Press and hold this key to enter Pre-Tare setup
3. Press this key to right shift under internal setup mode
1. Press this key to switch weighing unit from metric to imperial(when this
unit is enabled) and to piece counting
Press this key to save the weighing result to memory
Press this key to recall the total accumulated weighing results from memory
Press this key to clear the data saved in memory

4. INTERNAL FUNCTION
Because of metrological legislation, accessing to some internal functions is limited to authorized
person only when this unit is set to legal for trade. DO NOT try to open the scale or manipulate with
the hardware seal when the unit is metrological approved. Please contact your dealer for more
information. All internal functions are listed below, some are restricted for dealers only.
DISPLAY
FUNCTION SETTING
ACCESS CONDITION
F 0
Zero tracking range
Dealer only when LOCKED
F 1
1. Analog to digital offset value
2. Function key test
Open
F 2
1. LCD segment check and software version information
2. Adjusting backlight brightness
Open
F 3
Scale configuration setup
Dealer only when LOCKED
F 4
Auto power off
Dealer only when LOCKED
F 5
Transmission protocol for RS-232/RS-485
Open
F 6
1. Digital motion filter
2. Animal weighing
Open
F 7
transmission mode & data format for RS-232/RS-485
Open
F 9
Auto tare
Open
F 16
Turning on/off real time clock
Open
F 17
Time and date setup
Open
F 18
Buzzer sound
Open
F 20
Manufacturing site gravity value setup
Dealer only when LOCKED
F 21
Final destination gravity value setup
Dealer only when LOCKED
F 38
Backlight timing
Open
F 99
High resolution verification mode
Dealer only when LOCKED
F 100
Reset to factory default
Dealer only when LOCKED

FUNCTION DEFINITION AND SETUP
●Press and hold TARE and press ON/OFF, display shows F1
●Use TARE (next) or MR (previous) to scroll through the internal setting menu, and press MODE
to enter the setting.
●Use ZERO in sub-setting menu to scroll through available options. Press MODE key to confirm
and exit.
●Press ZERO and display will show SAVE. If setting was changed, user can either press MODE for
yes to save the changes made or press ZERO for not to save the changes.
CAUTION: BEFORE LEAVING THE INTERNAL SETTING, ALL CHANGES MUST BE SAVED OTHERWISE
THE SCALE WILL STILL FUNCTION UNDER THE OLD SETTING.
Offset Value & Function Key Test (F1)
Under this function scale will show the offset value and be able to check the function of each key.
LCD Segment Check and Backlight Adjustment (F2)
Under this function all segments and indicators will be in flashing mode as well as backlight for user
to check if function properly.
Press ZERO to adjust the backlight brightness. There are five settings, press MODE to confirm
setting. Backlight brightness also has 5 level selections for optimal viewing.
Auto Power Off (F4)
Under this function, user can select auto power off timing among 5 minutes, 10 minutes, 15
minutes and 20 minutes or disable the function. There are 5 settings, the numerical digit means the
minutes to power off when scale idles. ALL.on means the Scale will never automatically turn off
unless manual intervention.
5.oFF -> 10.oFF -> 15.oFF -> 15.oFF -> ALL.on
Transmission Protocol (F5)
Under this function, user can select the transmission interface, speed, mode and format for RS-232
and also the communication protocol.
When display shows F5, press MODE to enter the function
First level selection:
nonE / rS232
Second level selection:
bAUd / ProtL
Selection under bAud:
2400 / 4800 / 9600 / 19200 / 38400 / 115200bps
Selection under ProtL:
n.8.1 / E.7.1 / o.7.1 / E.8.1
use MODE key to enter, ZERO to change, MODE key to confirm
Terminology:
nonE: no data output
bAud: baud rate
rS232: data output through RS-232
ProtL: transmission protocol

Digital Motion Filter (F6)
Under this function, user can enable digital motion filtering function if the weighing environment is
unstable. User also can engage animal weighing function for maximum performance. The scale is
equipped with 3 filter speeds:
Filt 0 -> Filt 1 -> Filt 2
Transmission Mode (F7)
Under this function, user can select the transmission mode and data format.
First level selection:
StrM / Manu / CMd / Auto
Second level ForMt:
SEr.1 / SEr.2
use ZERO key to select, MODE key to confirm
StrM: stream mode, data continuous sending when stable (ForMt only has Ser.1 available)
ST, NT, 100.01kg
ST, NT,- 100.01kg
…………………………….
Manu: manual mode, data sends once when manually pressing keypad (press M+ to send one data,
press MC to clear memory and send total value)
●When format is set at Ser.1-
Press M+ to send single data (as Ser.1 ForMt), and will not print total value.
ST, NT, 100.01kg
ST, NT,- 100.01kg
…………………………….
●When format is set at Ser.2-
Press M+ to send single data, press MC to send total value (as Ser.2 format)
S/N WEIGHT UT
1 100.02 kg ←press M+ to print single data
2 99.01 kg
3 1210.05 kg
4 10.12 kg L
…………………………
---------------------------------
Sum 9876.10kg ←press MC to print total value
CMd: command mode, data sends when receiving command from computer
(READ/ZERO/TARE/NTGS..)
When receiving READ command, indicator will only transmit Ser.1 format.
All other commands will not trigger the data transmission but changing the mode
(ZERO/TARE/NETGS)
NOTE:
1. When tare function is not engaged, net weight equals to gross weight, so RS-232 will transmit
data in NET status.

2. When Command Mode is selected in F7, GROSS status will be transmitted under NTGS command.
ST, NT, 100.01kg ←net weight
ST, NT,- 100.01kg
US, GS, 1000.01kg ←gross weight
Auto: automatic mode, data sends once when weighing result stables
●When format is set at Ser.1-
Indicator will automatically send single weighing result when display stables and over 20e, it does
not support to print total value.
ST, NT, 100.01kg
ST, NT,- 100.01kg
US, GS, 1000.01kg
………………………………
●When format is set at Ser.2-
Indicator will automatically send single weighing result when display stables, press MC to clear
memory and print total value (as Ser.2 format)
S/N WEIGHT UT
1 100.02 kg ←automatically send one weighing result when display stables
2 99.01 kg
3 1210.05kg
4 10.12 kg
………………………….
----------------------------------
Sum 9876.10kg ←print total result when MC is pressed
●When Real Time Clock function is enabled
When indicator is set at rtC.on, date and time information will be included in the RS-232 data
stream:
When F7 is set at Ser.1
2015/04/25 10:30:21 ST, NT, 100.01kg
2015/04/25 10:30:39 ST, NT, 210.00kg
When F7 is set at Ser.2
2015/04/25 10:31:21
S/N WEIGHT UT
1 100.02 kg
2 99.01 kg
------------------------------------
Sum 199.03 kg
Printer Selection (F8)
Under this function, user can select the peripheral which the scale will be connected to.
PC for computer -> tEC for Toshiba TEC printer -> ArGoX for Argox printer -> tSC for TSC printer ->
SH-24 for 24 columns Dot Matrix printer
Auto Tare & Automatic Continuous Tare (F9)

Under this function, user can enable or disable auto tare function of the first weight, or the
consecutive loads place on the platter.
Tr.on (auto tare first weight) -> tr.Cnt (auto tare consecutive loads)-> tr.oFF (auto tare off)
Turning On/Off Real Time Clock (F16 Optional)
Under this function, user can turn on or off real time clock function.
rtC.on -> rtC.oF
Time and Date Setup (F17)
Use this function to setup year, month and date as well as time in 24 hours format.
a. display shows Y=XX
b. Press ZERO for increasing and TARE to change flashing digit, and press MODE to confirm and
entering the next setting
c. Display shows M=XX, press ZERO for increasing and TARE to change flashing digit, and press
MODE to confirm and entering the next setting
d. Display shows d=XX, press ZERO for increasing and TARE to change flashing digit, and press
MODE to confirm and entering the next setting
e. Display shows H=XX, press ZERO for increasing and TARE to change flashing digit, and press
MODE to confirm and entering the next setting
f. Display show M=XX, press ZERO for increasing and TARE to change flashing digit
g. Press MODE to confirm to complete the setting
Buzzer Sound (F18)
Under this function, user can select buzzer sound on or off.
Sd.on -> Sd.oFF
Backlight Timing (F38)
Under this function, user can select when to turn off backlight.
There are 5 settings, bL.on for always on, bL.oFF for always off and bL.X means the backlight will
automatically turn off after X seconds when scale idles.
bL.5 -> bL.10 -> bL.15 -> bL.on -> bL.oFF

5. INSTRUCTION TO USE
The W75 series are equipped with user friendly functions, including preset tare, manual tare, auto
tare, automatic continuous tare, simple counting and memory plus functions. It also comes with
interfaces including RS-232 and RS-485 for data output and 4 channel relay output for controlling
purpose. (Optional) Furthermore, the gravity compensation in the internal function also allows user
to calibrate the weighing result correctly without involving actual mass.
Before start weighing:
a. Make sure load cell cable is connected to indicator
b. The scale is placed on a solid surface
c. Use adjustable feet and referring to the bubble level to make sure scale is in a level position
d. Power on the scale and wait for the counting down
e. Scale is in zero weight status and display showing zero indicator and stable indicator
f. If Zero indicator is not on, press ZERO to set the display to zero
g. If zero weight status cannot be obtained, re-install the platter again
h. If stable indicator is not on, check the environment and relocate the scale in a stable
environment
5.1 WEIGHING UNIT SELECTION
Press MODE to switch between metric, imperial and piece counting mode.
5.2 TARE FUNCTION SETTING
This indicator equips with auto tare, continuous tare (please refer to F9 of internal setting) and
manual tare.
a. If auto tare function is enabled, the first weight being placed on platter will be automatically
tared
b. If continuous tare function is enabled, each weight being placed on platter will be automatically
tared
c. If manual tare is needed, place the load/container on the platter first and press TARE to tare off
the weight. After weight is tared, NET indicator will appear indicating the weight showing on
display is net weight
d. If preset tare is needed, press and hold TARE and display will show PrE.Tr and enter preset tare
value setup
e. Use TARE to shift the flashing cursor and ZERO for increment to adjust the preset tare value
f. When desire value is entered, press MODE to confirm and save the change
g. Scale will exit the function and return to normal weighing mode while NET indicator and PT
indicator appears
h. The ZERO indicator points out the negative value shown means the platter is at zero weight
status
i. When the goods is placed on the platter with a positive value shown, this indicates the actual
weight of the goods
How To Clear Tare Function (auto tare, automatic continuous tare, manual tare, preset tare)
a. To clear auto tare, remove the initial weight/load from the platter and NET indicator will turn
off. Press ZERO to return to zero weight status if ZERO indicator does not appear
b. To clear continuous tare, remove all loads from platter and NET indicator will switch off. Press
ZERO to return to zero weight status if ZERO indicator does not appear
c. To clear manual tare, remove everything from platter and press TARE, the NET indicator will
turn off. Press ZERO to return to zero weight status if ZERO indicator does not appear

d. To clear preset tare, press and hold TARE to enter preset tare setting, set all value to zero and
press MODE to confirm cancelling. Please make sure scale is not engaged in any kind of tare
before proceed to modify the preset tare value
5.3 MEMORY FUNCTION
How To Save A Weighing Result To Memory
a. Place a load on the platter and result will show on the display
b. Wait the Stable signal appears then press M+
c. Weight result is now saved to memory and M+ indicator appears indicating memory contains
data
d. Remove the load and scale will return to zero weight status
e. Put on another weight and press M+ to save the next weight
NOTE:
Memory plus function can be temporary switch off if needed, particularly when the weighing result
does not need to be saved and requiring print out only. To disable memory plus function, press and
hold M+ and display shows ACC.on, press ZERO to select between ACC.on and ACC.oF and press
MODE to confirm.
How To Recall A Weighing Result From Memory
a. Press MR at anytime to recall the total result saved in memory, MR indicator appears indicating
the value shown on display is total result
b. Result will remain on display for a short while before return to the previous screen
How To Clear Weighing Result From Memory
Follow the below steps to clear saved data from memory after all transactions completed.
a. Press MR first to recall the total saved result from memory, the MR indicator will appear
b. Press MC immediately to clear the memory and M+ indicator will off indicating there is no data
in the memory
5.4 PIECE COUNTING FUNCTION
This indicator equips with simple piece counting function, please follow the below procedure to
enable the function and sampling method.
a. Indicator is on and both Zero indicator and Stable indicator are on
b. Press MODE until display shows PCS as weighing unit on the display
c. Press MR and display shows S: 10, this means count 10pcs of the same item to put on platter for
sampling the average unit piece weight
d. If 10pcs is not needed, continue to press ZERO and display will show S:20, S:50, S:100, S:200,
S:500 and S:1000. When the ideal quantity is reached, press MODE to confirm and put the
sample quantity on platter
e. The display will return to normal weighing mode with PCS indicator showing the scale is now in
piece counting mode.
f. Remove the load and put new batch, display will show the batch quantity.
g. If display shows a value while platter is empty, press ZERO to zero off the weight.
h. If new sampling is needed, press and hold MR to start new sampling by following step c to d.
NOTE:

1. If scale detects the total weight of samples on the platter are smaller than 20d, the PCS sign will
start flashing as warning. Press ZERO key to change the sampling quantity setting or add more
samples until the signal is off.
2. If scale detects the unit piece weight of the sample is smaller than minimum unit weight, the
PCS sign will start flashing as warning (unit piece weight must not small than 0.5d). It is
recommended using smaller capacity scale for this sampling.
3. When PCS sign flashes, sampling process can still in process but might result errors.
5.5 CHECK WEIGHING FUNCTION
This indicator is equipped with check weighing function which allowing users to set high and low
limits to quickly checking the weight of each product within the range or not.
a. Indicator is on and both Zero indicator and Stable indicator are on
b. Press and hold MODE until display shows CHK W
c. Press MODE to enter and display shows Hi for hi limit setting, press ZERO for value increment
and TARE for shifting digits. Press MODE to confirm and entering low limit setting
d. Display shows LoW, press ZERO for value increment and TARE for shifting digits. Press MODE
again to confirm and entering alarm setting
e. Display shows bEEP first and then showing bb-no, press ZERO for options bb-Go, bb-H.L, bb-Hi,
and bb-Lo
Display
Description
bb-no
No alarm for any weighing result
bb-Go
Alarm activates when weighing result falls within the range
bb-H.L
Alarm activates when weighing result falls outside the range
bb-Hi
Alarm activates when weighing result higher than the range
bb-Lo
Alarm activates when weighing result lower than the range
NOTE:
1. Check weighing function can be engaged under any weighing unit including piece counting
mode. When the weighing unit is PCS and check weighing mode is activated, display will show
CHK P for checking piece.
2. If check weighing limits have been programmed before, display will show PrEV for resuming the
previous setting or not when entering the setup. Press MODE to confirm using the previous
setting or ZERO to set new limits.
3. To temporary disable check weighing function, press and hold MODE again to enter check
weighing setup and press ZERO when displays CHK W

5.6 HOW TO CONNECT RS-232 (D-sub 9 pin female connector)
Refer to F5 and F7 in Internal Function to setup transmission protocol
Indicator end
Pin 7 & 8 Shorted internally
Pin Assignment (PC end)
Pin
Assignment
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
NC

5.7 HOW TO CONNECT RS-485 (D-sub 9 pin male connector)
Pin
Assignment
1
A(+)
2
B(-)
3
4
5
6
7
8
9
NOTE: when connect with multiple devices, parallel a 120ohm resistor in the last device

6. DAILY CARE AND MAINTENANCE
-Do not attempt to open the indicator or try to repair except authorized technicians only
-Always aware of the using environment to avoid excessive moisture and extreme temperature
-Use original factory supplied switch adaptor for charging only
-Recharge the battery immediately when the battery level indicator starts flashing to avoid
permanent damage to the rechargeable battery
-Do not put anything on the platter after weighing completes to avoid causing damage to the load
cell
-If cleaning is needed, use damp cloth to clean the surface
-If cleaning agent is needed, please use mild detergent and avoid excessive water. Do not use any
chemical or alcohol for cleaning purpose
-If you are uncertain about how to properly maintaining your scale to the optimal condition, please
contact your dealer for further assistance

APPENDIX:
ERROR CODES
ERROR CODE
DESCRIPTION
SOLUTION
Err 0
Flash memory accessing error
Change MCU, contact dealer for assistance
Err 1
A/D accessing error
Check A/D, contact dealer for assistance
Err 2
Load cell wiring error
Check load cell wiring pin assignment
------
No load cell signal/load cell reading error
Check load cell and connection

COMPUTER COMMAND
1. PC→”READ” command
R
E
A
D
CR
LF
52H
45H
41H
44H
0DH
0AH
Indicator→sending data string
，
，
……
，
CR
LF
HEADER 1 HEADER 2 weighing data (8 digits, including negative sign and decimal point) UNIT
2. PC→”ZERO” command
Z
E
R
O
CR
LF
5AH
45H
52H
4FH
0DH
0AH
Indicator→executing zero command
3. PC→”TARE” command
T
A
R
E
CR
LF
54H
41H
52H
45H
0DH
0AH
Indicator→executing tare command
4. PC→”NTGS” command
N
T
G
S
CR
LF
4EH
54H
47H
53H
0DH
0AH
Indicator→executing net weight/gross weight switching
5. PC→”MODE” command
M
O
D
E
CR
LF
4DH
4FH
44H
45H
0DH
0AH
Indicator→executing weighing mode switching
Data Format：Ser.1 (strictly only weighing result, such as ST, NT, 100.01 kg)
ST, NT, 100.01 kg
ST, NT,- 100.01 kg
US, GS, 1000.01 kg
…………………..
…………………..

HEADER 1
OL: overload
ST: stabled
US: unstable
HEADER 2
NT: net weight
GS: gross weight
UNIT
kg, g, lb, t
Ser.2 (print Total)
S/N WEIGHT UT
1 100.02 kg ←press M+ to print single data
2 99.01 kg
3 1210.05 kg
4 10.12 kg
……………………………..
--------------------------
Sum 9876.10 kg ←press MC to print total value
NOTE: weighing unit on print result reflects the weighing unit been engaged in operation
1
2
3
4
5
6
7
8
9
1
0
1
1
1
2
1
3
1
4
1
5
16
1
7
1
8
1
9
S
/
N
W
E
I
G
H
T
U
T
CR
LF
1
1
0
0
.
0
2
k
g
G
2
9
9
.
0
1
k
g
L
3
1
2
1
0
.
0
5
k
g
H
4
-
1
0
.
1
2
k
g
-
