V-tech 527703 Assembly Instructions

Parent's Guide
4-In-1 Ride-On Fawn

3
INTRODUCTION
Speed into learning with the VTech®4-In-1 Ride-On Fawn!
This 4-in-1 grow with me fawn includes modes for ride-on play, push
walker, scooter and a shape sorting wagon. Little ones can grow and
develop with the fawn. The five light up buttons along with the Learn,
Explore and Music modes introduce the animal characters and
sounds, colours and play melodies and sing-along songs. The four
shape sorting pieces add to the learning and provide little ones with
the opportunity to problem solve.
Mode Switch
On/Off/Volume
Switch
Five Light Up
Buttons
Shape Sorter
Green Lock

4
INCLUDED IN THE PACKAGE
• 4-In-1 Ride-On Fawn
Fawn Head Wagon Body
Scooter Base Walker Handle
2 Rear Wheels 1 Set of Front Wheels
2 Handlebars 3 Shape Blocks 16 Scews
• Quick Start Guide

5
WARNING
All packing materials such as tape, plastic sheets, packaging locks,
removable tags, cable ties, cords and packaging screws are not part
of this toy, and should be discarded for your child’s safety.
NOTE
Please save this Parent's Guide as it contains important information.
WARNING!
This toy should be used in a safe area e.g indoors, in a private
garden, on level flat surfaces and away from any hazards such as
cars, stairs, water etc.
Not for use on pavements or in traffic.
Adult supervision is advised.
Please help your child to sit properly on the seat and to use the toy
correctly.
This toy should be used with caution to avoid falls or collisions that
could cause injury to the user or third parties.
Warning! Protective equipment should be worn. Not to be used in
traffic. 20 kg Max.
Please wear helmet, gloves, knee pads and elbow pads.
CAUTION:
Adult assembly required.
This package contains small screws.
For your child’s safety, do not let your child play with the toy until it is
fully assembled.

6
GETTING STARTED
BATTERY REMOVAL AND INSTALLATION
1. Make sure the unit is turned Off.
2. Find the battery cover on the back of
the electronic activity panel. Use a
screwdriver to loosen the screw and then
open the battery cover.
3. If used batteries are present, remove
these batteries from the unit by pulling
up on one end of each battery.
4. Install 3 new AA batteries following the
diagram inside the battery box. (For best
performance, alkaline batteries or fully
charged Ni-MH rechargeable batteries
are recommended).
5. Replace the battery cover and tighten the
screw to secure.
WARNING:
Adult assembly required for battery installation.
Keep batteries out of reach of children.
IMPORTANT: BATTERY INFORMATION
• Insertbatterieswiththecorrectpolarity(+and-).
• Donotmixoldandnewbatteries.
• Donotmixalkaline,standard(carbon-zinc)orrechargeable
batteries.
• Onlybatteriesofthesameorequivalenttypeasrecommended
are to be used.
• Donotshort-circuitthesupplyterminals.
• Removebatteriesduringlongperiodsofnon-use.
• Removeexhaustedbatteriesfromthetoy.
• Disposeofbatteriessafely.Donotdisposeofbatteriesinfire.

7
RECHARGEABLE BATTERIES
• Removerechargeablebatteriesfromthetoybeforecharging.
• Rechargeablebatteriesareonlytobechargedunderadult
supervision.
• Donotchargenon-rechargeablebatteries.
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and
batteries, or on their respective packaging, indicates they
must not be disposed of in domestic waste as they contain
substances that can be damaging to the environment and
human health.
The chemical symbols Hg, Cd or Pb, where marked,
indicate that the battery contains more than the specified
value of mercury (Hg), cadmium (Cd) or lead (Pb) set out
in the Batteries and Accumulators Regulation.
The solid bar indicates that the product was placed on the
market after 13th August, 2005.
Help protect the environment by disposing of your product
or batteries responsibly.
VTech®cares for the planet.
Care for the environment and give your toy a second life by
disposing of it at a small electricals collection point so all its
materials can be recycled.
In the UK:
Visit www.recyclenow.com to see a list of collection points near you.
In Australia & New Zealand:
Check with your local council for kerbside collections.

8
ASSEMBLY INSTRUCTIONS
With the 4-In-1 Ride-On Fawn, safety comes first. To ensure your
child’s safety, adult assembly is required.
1. Attach the set of Front Wheels to the
underside of the Scooter Base. Use
six of the Screws to secure.
2. Attach the two Rear Wheels to the
underside of the Scooter Base. Use
eight of the Screws to secure.
3. Insert the Handlebars into either
side of the Fawn Head. You will
hear the Handlebars click into place
when inserted correctly. Once the
Handlebars have been attached, they
cannot be removed.

9
4. Push the Fawn Head onto the
Scooter Base. You will hear the Fawn
Head click into place when inserted
correctly. Turn the Scooter Base over
and use two of the Screws to secure.
5. Attach the Wagon Body to the Scooter
Base. You will hear the Wagon
Body click into place when inserted
correctly.
6. Insert the Walker Handle into the top
of the Scooter Base, then push and
turn the Green Lock clockwise to
secure the Walker Handle. Use the
Walker Handle to push or pull the
fawn.
WARNING:
Not to be used by children over 36 months. Insufcient
strength. Protective equipment should be worn. Not to be
used in trafc. 20kg Max. Regularly check for signs of wear or
tear on the snap in or locking devices. If damaged do not use
until repaired or replaced. Only to be used under the direct
supervision of a competent adult.

10
Convert from Ride-On Mode to Scooter Mode
1. Press the small green release button on the back of the Wagon
Body while rotating the Green Lock on the Walker Handle
anticlockwise, then pull the tab while removing the Wagon.
2. Insert the Walker Handle into the slot on the back of the Fawn
Head. Turn the Green Lock clockwise to secure the Walker
Handle. To remove the Walker Handle, press and hold the small
button on the left side of the handle while turning the Green Lock
anticlockwise.
3. You have the option to attach the Wagon
Body to the back of the Scooter. Insert
the hinge on the front of the Wagon Body
to the bottom of the Scooter Base. To
disconnect the Wagon Body, pull on the
hinge.
Convert from Ride-On Mode to Wagon
Mode
Remove the Wagon Body from the Scooter
Base and fold out the seat to make a pull
handle.
