V-tech KidiZoom PrintCam Assembly Instructions

Parent’s Guide

CMYCMMYCYCMYKGrow with VTech(105x148)bw1P-V2.pdf 1 08/18/2014 9:35:53

3
3
3
INTRODUCTION
Take a photo and print it instantly with the KidiZoom®PrintCam by
VTech®! The ip-up lens allows for easy seles too. The camera is
jam-packed with fun features like special photo effects, stamps and
borders, 3 games, panoramic prints and comic strip maker. You can
also turn your photos into line drawings to colour or use the print shop
to print games, design and print your own cards, pretend money,
accessories, and more. Also functions as a normal digital camera:
you can take videos and save photos and videos and transfer by
USB. Memory is expandable by microSD card (SD card not included).
Includes 1 roll of Thermal Paper that allows you to print in black and
white.
Note
The metallic coating on the KidiZoom®PrintCam is insulating.
Micro-USB cable Wrist strap
1 Roll of thermal paper
KidiZoom®PrintCam
(With built-in rechargeable battery.
Battery is non-replaceable).
Parent’s Guide

4
4
4
INCLUDED IN THE PACKAGE
WARNING
All packing materials such as tape, plastic sheets, packaging locks,
removable tags, cable ties, cords and packaging screws are not part of
this toy, and should be discarded for your child’s safety.
NOTE
Please keep this Parent’s Guide as it contains important information.
This toy is only to be connected to equipment bearing either of the
following symbols: or
The battery in this product must not be disposed of with household
waste. This battery is recyclable. Please follow your local recycling
regulations.
The label covering the camera’s screen is packaging material. Please
remove this label before use.
Removing the Packaging Locks:
1: Turn the packaging lock anticlockwise
several times.
2: Pull out and discard the packaging lock.
WARNING
Adult needed to remove small packaging
screw.
Removing the Packaging Lock:
1. With a screwdriver, turn the packaging
screw several times anticlockwise to
loosen and remove.
2. Safely discard the screw and all
packaging products.

5
5
5
K
I
D
I
Z
O
O
M
V
I
D
E
O
P
H
O
T
O
P
R
I
N
T
PRODUCT LAYOUT AND BUTTONS

6
6
6
1. Master Power Switch
When the switch is set to the position, the camera is
disconnected from the battery and the battery will not charge. Move
the switch to the position to connect the camera to the battery
and allow it to be recharged.
Note: The Master Power Switch is only for resetting the camera
with a system reboot. When the camera is in daily use, you should
leave the switch in the position.
2. Shutter Button
Press this button to take a picture in Photo mode or to start
recording in Video mode. When you’re in another mode, pressing
this button will take you to Photo mode.
3. Print Button
In Photo or Video mode, press this button and a print preview
screen will show and ask you to conrm before printing. From the
Home screen or other menu, press this button to go to Photo mode.
4. Star Button
Press this button to change the volume. In Photo or Video modes,
press this button to also change camera options.
5. Home/On/Off Button
Press to turn the camera On. Press and hold for two seconds to
turn it Off. While the camera is On, press this button to go to the
Home screen or to go back to the previous menu.
6. OK Button
Press this button to conrm a choice or action, or as a control in
certain games.
Tip: The OK Button can also be used as the Shutter Button in
Photo and Video modes.
7. Directional Buttons
Use these buttons to select options, or as controls in certain games.
8. Play Button
Press this button to review photos or movies.
9. Delete Button
Press this button to delete a photo or video or to cancel an

7
7
7
operation.
10. Memory Card Slot
Insert a microSD card here to expand the camera’s memory.
(MicroSD card not included).
11. Micro-USB Port
Connect to a computer with the included Micro-USB Cable to
transfer les to a computer and to charge the camera.
12. Flip-Up Selfie Lens
Flip up the lens to see yourself on-screen as you record and take
pictures.
13. LED Indicator Light
This LED is to indicate battery charging status, the LED will light
up red when battery is charging and turn to green when charging
has completed. In normal mode, the LED will only light up during
camera timer countdown or while saving les.

8
8
8
PRODUCT SPECIFICATIONS
Display 2.4" colour LCD
Language Multilingual (US English, UK English, Deutsch,
Español, Français, Nederlands)
Resolution
5 MP: 2560 x 1920 (extrapolated)
2 MP: 1600 x 1200
0.3 MP: 640 x 480
Video
Resolution
320 x 240 default
640 x 480 when using memory card without video
effects
Video Length
Limit
Internal: 5 minutes per each recording le
Memory card: 10 minutes per each recording le
Digital Zoom 4X
Focus Range 1.1 feet - ∞
Internal
Memory
256 MB built-in memory (shared with program data,
actual memory available for user storage will be
less)
File Format Photo: Standard baseline JPEG
Video: AVI (Motion JPEG)
Connectivity Built-in USB port for computer connection and
battery charging
Memory Card
Format and
Capacity
microSD/microSDHC card (not included) with
capacity from 1 GB to 32 GB are recommended
Battery Rechargeable Li-ion battery
(battery is not replaceable)
Printer Printer Type: Black & white thermal printer
(No ink used)
Thermal paper roll
Dimensions: 57 mm width x 28 mm max diameter
Operating
Temperature
32°F to 104°F (0°C to 40°C)

9
9
9
STORAGE CAPACITY FOR REFERENCE
Memory
Size
Photos
(5 MP)
Photos
(2 MP)
Photos
(0.3 MP)
Video
(minutes)
Internal Memory 320 380 1,930 8
Memory
Card
2 GB 3,600 4,400 22,100 90
4 GB 7,300 8,800 44,200 180
8 GB 14,700 17,700 88,500 370
16 GB 29,500 35,400 177,000 740
32 GB 59,000 70,800 354,100 1,480
Note: The above amounts are approximations. The actual amount
depends on the shooting environment. The video length limit is 5
minutes (internal memory) or 10 minutes (memory card) per le. The
video length estimation is based on 320 x 240 video resolution.

10
10
10
PRINTER OPERATION
Precautions
• For best results, refill the paper with the KidiZoom®PrintCam
Paper Refill Pack.
• To ensure your child’s safety, only adults should change the paper
rolls, and make sure the Printer Cover is always locked.
• Do not open the cover during or right after printing is finished, let the
Print Head cool down sufficiently before replacing the paper roll.
• Do not pull out the thermal paper when the cover is closed as this
may damage the printer.
• Avoid touching the Print Head with your hands or other objects. If
cleaning is needed, please clean the Print Head with a microfibre
lint-free cloth.
• Thermal printing technology is not designed for long-term storage.
To keep your images looking sharp for as long as possible, keep
them out of direct sunlight. Also keep a backup digital copy of any
important memories.
Paper Installation
For your child's safety, only adults should install the paper rolls.
1. Locate the Screw Lockat the bottom of
the camera, and use a screwdriver (not
included) to turn the screw anticlockwise
and move it to the unlocked position.

11
11
11
2. Locate the finger pull tabs on both sides of
the Printer Cover and lift with two fingers
as illustrated.
3. Remove the sticker to unfasten the roll.
Note: The sticker is not part of this toy and
should be discarded for your child’s safety.
4. Insert the new roll of paper into the Paper
Roll Chamber as illustrated, ensuring that
the tail of the paper comes off the bottom
of the roll and not the top.
5. Leave a small amount of paper protruding
and close the Printer Cover.
6.Tear off the excess paper and use your
screwdriver to secure the Screw Lockin
the closed position.
Printing
In Camera or Video modes, press the Print
Button to bring up the print preview screen. From
here you can adjust the print intensity with the
icon or cancel with the icon. Press the Print
Button or check mark to proceed to print your
image and save a digital copy.
Drawing on Thermal Paper
For best results we recommend using felt-tipped pens or markers.

12
12
12
GETTING STARTED
When you use the KidiZoom®PrintCam
camera for the rst time, switch the
Master Power Switch to the
position.
When the Master Power Switch is in the
position, it is not possible to charge
the camera or play any activities, and the system clock will reset.
Battery Charging
Note: Adult operation required.
• Make sure the camera is not in use and the Master Power Switch
is in the position. Pull up the rubber cover that is over the Micro-
USB Port on the side of the camera.
• Insert the Micro-USB Cable (small end) into the Micro-USB Port
on the camera.
• Insert the large end of the Micro-USB Cable into a USB port on a
computer.
• When the battery is charging, a red LED will
illuminate and you will see the battery charging icon.
• When the battery is fully charged, the LED will turn
green and the screen will turn off. Disconnect the
camera from the power source.
Charging Guidelines
Only charge this device using the included Micro-USB Cable
connected to a computer. Do not charge using a third party adaptor.
Before use, inspect the cord to conrm that it is in good condition
and that there are no breaks or exposed wires. Ensure there are no
particles or liquid (water, juice, etc.) in either of the connectors before
plugging in either end of the cable. The device should be completely
dry with no debris in the cable connectors when charging. Plug in
the cable securely, in the correct orientation. If the device is on when
plugged in, a dialog box may open on your computer to allow you to
access the device’s drive. Never leave the device unattended while
charging. Do not charge your device on soft surfaces, as they can trap
heat around the device. Typical charging time is between four to seven

13
13
13
hours if the battery is fully depleted. Disconnect the device when it is
fully charged. Do not leave the device charging for more than 7 hours.
Note: The actual charging time depends on the charging current,
the existing charge and the ambient temperature of the charging
environment.
The optimal ambient temperature is 32°F to 104°F (0°C to 40°C).
Battery Life
Like with other electronic devices, the more the camera is used, the more
quickly the battery will drain. The battery will last approximately four hours
with continuous use while taking photos and videos. However, with more
printing usage, the battery will run down quicker. The remaining battery
capacity will display in the top right corner of the screen. When the
battery level is low , the system will restrict printing and reduce the
speaker volume. Recharge the battery before further use. When the
battery level is too low , the camera will not turn on until it is charged.
Automatic Shut-Off
To preserve battery life, the KidiZoom®PrintCam will automatically
shut off after a few minutes without input.
Battery Maintenance
Charge the camera regularly to keep it operating at optimal
performance, even when the camera isn’t in use. Be sure to charge the
camera at least every six months.
This toy contains batteries that are non-replaceable.
Australia/New Zealand
WARNING! SAFETY INSTRUCTIONS, PLEASE READ
THOROUGHLY BEFORE GIVING THIS PRODUCT TO A CHILD.
KEEP AWAY FROM FIRE OR HEAT SOURCE.
BATTERIES CANNOT BE REPLACED.
The batteries within this toy are permanently encased. Before giving
this toy to a child make sure there are no signs of damage. Regularly
check the toy and dispose of it immediately if there are any signs of
damage. Do not dispose of the toy in a re, as the batteries may leak
and explode. Keep batteries safely out of children’s reach before
disposing of them via a safe disposal system.

14
14
14
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and batteries, or
on their respective packaging, indicates they must not be
disposed of in domestic waste as they contain substances that
can be damaging to the environment and human health.
The chemical symbols Hg, Cd or Pb, where marked, indicate
that the battery contains more than the specied value of
mercury (Hg), cadmium (Cd) or lead (Pb) set out in the
Batteries and Accumulators Regulation.
The solid bar indicates that the product was placed on the
market after 13th August, 2005.
Help protect the environment by disposing of your product or
batteries responsibly.
VTech® cares for the planet.
Care for the environment and give your toy a second life by disposing
of it at a small electricals collection point so all its materials can be
recycled.
In the UK:
Visit www.recyclenow.com to see a list of collection points near you.
In Australia & New Zealand:
Check with your local council for kerbside collections.
Battery disposal/recycling
As a responsible distributor, VTech® is committed to ensuring the correct
disposal of batteries and reducing the environmental damage they can
cause.
VTech® offers a returns program for products with inaccessible batteries
(i.e. built-in Lithium Polymer batteries).
Please email [email protected] with the subject “battery
disposal” to obtain a returns form.

15
15
15
Memory Card Installation
The KidiZoom®PrintCam camera
is compatible with microSD and
microSDHC memory cards up to 32 GB.
To install:
• Make sure the camera is Off.
• Open the cover over the Memory
Card Slot on the side of the camera.
• Insert a memory card (not included) as illustrated. Once the
memory card is detected, the memory card will automatically be
used as the default memory.
• To remove the memory card from the camera, push the card once
and it will eject.
Note
• VTech® recommends that you format your memory card before using
it with the KidiZoom®PrintCam camera.
• Data stored on the camera’s internal memory will not be accessible
while the memory card is in use. Be sure to back up all data to a
computer regularly to prevent loss of photos and video.
Frequency is set correctly in the camera’s Settings menu. (See the
Settings section in this Parent’s Guide). Avoid having a direct light
source pointing towards the camera.
TO BEGIN USING KIDIZOOM®PRINTCAM
Make sure the Master Power Switch is in the position and charge
the camera before using.
Press the Home/On/Off Button to turn the camera On. When
turning the camera On for the rst time, you will be asked to select the
language and set the date and time.
Note: If the battery level is too low and cannot keep the clock running,
enter the time and date again after recharging. If you wish to later
change the language, date or time, you can do so from the Settings
menu.

16
16
16
Home Menu
There are eight modes:
1. Photo
2. Video
3. Click and Colour
4. Panorama
5. Comic Strip Maker
6. Print Shop
7. Games
8. Settings
NOTE: The Games icon will be replaced by the Playback icon if
games are disabled. To disable games, please refer to Parental
Control section of this Parent’s Guide.
Adjust Speaker Volume
Press the Star Button to show the option panel. Select the
Speaker icon and press the Left or Right Directional Buttons
to adjust the volume.
Photo and Video Playback
Press the Play Button to view your photos and videos.
• The most recent le will appear rst.
Press the Left or Right Directional Buttons to select the
previous or next le. Press the Up or Down Directional
Buttons to jump to the previous 10 or next 10 les.
• Press the OK or Play Button to enlarge a photo to 2X or
4X or view a video/panoramic photo. Press the Delete Button
to delete the current le or choose to delete all photo and video
les in the memory. Further conrmation is necessary to delete all
photo and video les.
• While playing a video, press the Left and Right Directional
Buttons to toggle fast-forward or fast-rewind functions at 1X, 2X,
and 4X speeds. Press the OK Button to pause or resume
playing.
• Panoramic photos will automatically scroll horizontally when being
viewed. Press the OK Button to pause or resume the scrolling

17
17
17
or press the Left and Right Directional Buttons to move
through the image manually. Press the Home Button to pause
or resume playing.
Turning Off the KidiZoom®PrintCam Camera
To turn the camera Off, press and hold the Home/On/Off Button
for two seconds. The camera will also automatically turn off after a few
minutes without input.
MODES
Take Photos
• Press the Shutter Button or OK Button to take a photo.
• Press the Left and Right Directional Buttons to cycle through
different photo effects.
• Press the Up and Down Directional Buttons for 1X to 4X
digital zoom.
• Press the Print Button to bring up the print preview screen.
Press the Print Button or tick to proceed to print your image and
save a digital copy.
Self-Timer or Face-Timer Modes
From the camera preview screen, press the Star Button to
view the Option menu. In Timer mode, select Self-Timer to use a 10
second countdown timer before taking a photo or select Face-Timer to
automatically take a photo when a stable face is detected. The Timer
mode will turn off every time the camera is switched off.
Video
Record Video
• Press the Left and Right Directional Buttons to cycle through
video themes and effects.
• Press the Shutter Button or OK Button to start recording a
video. Press either button to stop recording.
• Press the Up and Down Directional Buttons for 1X to 4X
digital zoom.

18
18
18
• After recording completes, press the OK Button to play your
video, or press the Delete Button to delete the video. When a
video is playing, press the OK Button or Shutter Button to
skip review and return to Record mode.
• Press the Print Button to print an instant video frame if recording
has not started. The instant video frame will not be saved to
memory.
Self-Timer or Face-Timer Modes
In video preview screen, press the Star Button to pop up the
option menu. In Timer mode, select Self-Timer to use a 10 second
countdown timer before video capture begins or select Face-Timer to
automatically start capturing when a stable face is detected.
The Timer mode will turn off every time the camera is switched off.
Click and Colour
In this mode you can take a photo or select a previous photo and
convert it into a line drawing and print it for colouring.
First, take a photo or select a photo previously taken and press the OK
Button to go to next screen.
Next, the selected photo will be converted into a line drawing and be
shown on the next screen, press the Up and Down Directional
Buttons to adjust the effect intensity in three levels if needed, then
select the Print icon to print the picture and the Tick icon to save
the picture and start over with another one.
Panorama
After watching the introduction animation, press the OK Button to
go to the Capture screen and take two to four photos to stitch together
for your panoramic photo. You can view or print your completed
panoramic photos in Playback mode.

19
19
19
Comic Strip Maker
In this mode you can create your very own comic strip.
1. Comic Template
Select Sample Comic or Make Your Own to
start. The Sample Comic story comes with a
four-panel preset story with speech bubbles.
You can replace the background with other
subjects or add new stamps to customise the
comic strip. Select Make Your Own to create a
comic from your own imagination.
2. Strip Editor
In this screen you can select a panel and edit
from the Panel Editor screen. Each strip can
have a maximum of four panels.
When you nish all panels, press the Down
Directional Button to select the bottom
icons to change the outline border style, print
the comic strip, or save the comic strip as a picture and nish.
To remove a panel from the comic strip, press the Delete Button
.
You can view or print the saved comic strip in Playback later.
3. Panel Editor
If the selected panel is empty, you will be taken
to the Background Photo screen automatically.
You can edit the selected panel in this screen
with these tools:
Background Photo
Select this icon to change the comic background. You can either
take an instant photo or select a photo from memory and convert
it into one of the comic effects provided in the next step. Press the
OK Button to conrm changes to the background.
Border
Select a comic border for the background. If you want to remove the
added border, press the Delete Button .

20
20
20
Stamp
Select a stamp to add, follow the steps to ip or resize and move
the stamp. You can add maximum 10 stamps in each panel. If you
want to remove the added stamps, press the Delete Button .
Return
Select this icon to return to the Strip Editor screen.
Print Shop
In this mode you can select a print template from
the library, customise or take a photo to make
your creation unique, and then print and colour.
Print Shop Menu
Mini Cards
Customise a single-fold or tri-fold card to give to
a friend!
Costume Party
Mix and match different costumes and hairstyles
with your face to print out and colour.
Colour By Numbers
Choose a template to print, then follow the key
and colour within the lines to reveal the hidden
picture.
Tic-Tac-Toe
Customise and print out a best-of-ve Tic-Tac-Toe
tournament game board.
Mazes
Print out mazes to complete and customise them
with your photo.
