V-TUF HD140HOT User manual

HD140HOT
Please read this manual before using the HD140HOT
HOT WATER PROFESSIONAL
MOBILE PRESSURE WASHER

2
Congratulations! We wish to thank you
for buying this cleaner. You have shown that you do not accept compromises: you want the best.
We have prepared this manual to enable to fully appreciate the qualities and high performance that this
cleaner can offer you. Please read it completely before using the machine.
The CE mark on your cleaner shows that it has been constructed in compliance with the European
Standards on safety.
We can also offer you a wide range of cleaning machines such as:
VACUUM CLEANERS, and a complete range of ACCESSORIES, CHEMICALS and DETERGENTS suitable
for cleaning all kinds of surfaces.
Ask your Dealer for the complete catalogue of our products.
TRANSLATION OF ORIGINAL INSTRUCTIONS
The text has been carefully checked, however any misprints should be notified to the manufacturer.
The manufacturer also reserves the right to alter and update this publication without prior notice for the sake of
product improvement.
All reproductions of this manual, in whole or in part, are forbidden without the manufacturer's authorization.
PREPARING THE CLEANER
A
Fitting the handlebar
Fitting the lance.
Fitting the rear tank.
Water circuit connection.
A
B
B
C
C
Electrical connection.
30 mA
Continue reading this manual without connecting the cleaner to the power mains and the water supply.

3
DESCRIPTION OF SYMBOLS ON THE CLEANER
DO NOT DIRECT THE
JET AGAINST PEOPLE,
ANI- MALS, POWER
SOCKETS OR THE
MACHINE IT SELF.
SWITCHING OF THE PUMP
MOTOR.
ATTENTION: RISK OF
BURNS.
LIGHTING THE BURNER.
ATTENTION: RISK OF
ELECTRIC SHOCK.
FUEL (DIESEL).
EARTH. CHEMICHALS
(DETERGENT).
WATER INPUT DO NOT FEED WITH
DRINKING WATER.
USE AN EN 12729 TYPE
BA SYSTEM SEPARATOR.
WATER OUTPUT

4
CLASSIFICATION OF RISKS:
Identifies an imminent risk which could lead to
serious or fatal injury.
!
Danger
Identifies a risk situation which could lead to
serious injury.
!
Warning
Identifies a risk situation which could lead to
minor injury or damage to things.
Information
PREFACE
You must read this manual before installing,
starting up and using the high pressure washer.
This manual is an integral part of the product.
!
Warning
Read the warnings and instructions contained in
the manual carefully as they provide important
information on USER SAFETY and MAINTENANCE,
paying particular attention to the general safety
regulations.
KEEP THIS MANUAL IN A SAFE PLACE FOR
FUTURE REFERENCE.
Those operating and servicing the high pressure
washer must be aware of the contents of this
manual.
!
Warning
CLASSIFICATION
The user must observe the conditions of use of the
appliance prescribed by the Rules, and particularly he
must respect the following classification:
As for the protection against electric shock, the H.P.cleaner
belongs to CLASS I.
The H.P. cleaner is factory set and all its safety devices
are sealed. It is forbidden to alter their adjustment
values.
In the Hot water cleaner the water is heated by a burner
feed with Diesel fuel.
The H.P. cleaner must be always used on a firm and flat
ground, furthermore it must not be moved while it is
working or connected to the electric supply.
Failure to observe this prescription may cause danger for
the user.
The H.P. cleaner must not be used in the presence of
corrosive or potentially explosive atmospheres.
(vapours or gas)
GENERAL SAFETY RULES FOR
THE USE OF HIGH PRESSURE
CLEANERS
- The electric connection must be performed by
qualified technicians who are able to work in
observance of the governing rules (in compliance
with the provisions of the IEC 60364-1 standard)
and of the manufacturer’s instructions.
A wrong electric connection may cause damage
to persons, animals or things, and the
manufacturer cannot be considered responsible
for these.
- The H.P. cleaners with power lower than 3 kW
are equipped with a plug for connection to the
electric supply.
In this case please check if the electric power
system and the electric sockets are compatible
with the max. power of the appliance indicated
on the plate. (kW).
In case of doubt, please apply to qualified
personnel. If the socket and the plug of the
machine are not compatible, have the plug
replaced with a suitable type by qualified
personnel.
- Before connecting the machine make sure
that the data indicated on the plate correspond
to those of the electric supply.
- Do not use extensions to power the high
pressure washer.
If you use an extension, the plug and socket
must be watertight. Unsuitable extensions may
be dangerous.
- The electric safety of this machine may be
assured only when it is properly connected to
an efficient grounding system in accordance with
the governing laws for electric safety. (In
compliance with the provisions of the IEC 60364-1
standard)
!
Warning

5
- It is necessary to check this essential safety requisite. In case of doubt, ask for accurate control
of the power system by qualified personnel.
The manufacturer may not be considered responsible for damages occurred because of the lack
of the grounding system.
- The H.P. cleaner must be connected to the electric supply by means of an omnipolar switch with
opening contacts of at least 3 mm. This switch must have electric features which are consistent
with the appliance. (This requisite does not apply to H.P. cle- aners with plug and electric power
lower than 3 kW).
It is recommended that the electric supply to this machine should include a residual current
device that will interrupt the supply if the leakage current to earth exceeds 30 mA for 30 ms or a
device that will prove the earth circuit.
- The appliance is disconnected from the electric supply only by pulling out the plug or switching
off the omnipolar switch.
- Failure to respect the above absolves the manufacturer of all liability and represents negligent
use of the product.
The water cleaner is considered as a fixed device.
- Water cleaners with the “Total Stop” device should be considered as off when the omnipolar
switch is in the “O” position or the plug is unplugged from the socket.
- The high pressure washer is not intended for use by children, adolescents or persons with
reduced physical, sensory or mental capabilities, under the influence of alcohol or lacking
experience and knowledge.
Operators must be made aware of the instructions for using the appliance by a person responsi-
ble for their safety. Children must be supervised to ensure they do not play with the high pres
sure washer.
- Use only original accessories that can allow safe working of the appliance.
- The flexible hose connecting the lance to the H.P. cleaner must not be damaged.
In case of damage, replace it immediately.
- Hoses, connections and fittings for high pressure systems are very important to guarantee the
safety of the H.P. cleaner. Use only original spare parts which have the manufacturer’s approval.
- Do not use the H.P. cleaner when persons or animals are in its of action field.
- High pressure jets may be dangerous if not properly used.
The jet must never be directed at persons or animals, electric appliances or at the appliance itself.
- The high pressure water jet causes a re- action power on the lance. Hold the lance grip
vigorously.
- The use of the H.P. cleaner must be con- sidered according to the kind of washing which
must be performed.
