V-ZUG DSDSR12 User manual

Operating instructions
Ceiling hood DSDSR12
Range hood

Thank you for choosing to buy one of our products. Your appliance is made to
high standards and is easy to use. Nevertheless, please take the time to read
these operating instructions in order to familiarise yourself with the appliance
and get the best use out of it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appliance
at the time these operating instructions went to press. The right to make tech-
nical modifications for the purpose of the further development of the appliance
is reserved.
Validity
The product family (model number) corresponds to the first alphanumerics on
the identification plate. These operating instructions apply to:
Type Product family Size system
DSDSR12 64003 120
Variations depending on the model are noted in the text.
© V-ZUG Ltd, CH-6301 Zug, 2016
2

Table of contents
1 Safety precautions 5
1.1 Symbols used .............................................................................................5
1.2 General safety precautions ......................................................................6
1.3 Before using for the first time ..................................................................7
1.4 Correct use..................................................................................................7
1.5 Children in the home .................................................................................7
1.6 Note on use.................................................................................................8
2 Disposal 10
3 Appliance description 11
3.1 Extraction model...................................................................................... 11
3.2 Recirculation model with recirculation box ........................................ 11
3.3 Equipment................................................................................................. 11
3.4 Construction ............................................................................................. 12
3.5 Operating and display elements .......................................................... 13
3.6 Remote control ........................................................................................ 14
4 Operation 15
4.1 Activating/deactivating the remote control......................................... 15
4.2 Switching the appliance on/off............................................................. 15
4.3 Switching the illumination on/off .......................................................... 16
4.4 Changing the light intensity................................................................... 16
4.5 Changing the power level...................................................................... 16
4.6 Switching the intensive level on / off before time............................. 16
4.7 Switching the after-running time on / off before time....................... 17
4.8 Switching the CleanAir function on / off before time ....................... 18
4.9 Saturation indicator for metal grease filters ....................................... 18
4.10 Operation using the operating and display elements ...................... 19
5 Care and maintenance 21
5.1 Cleaning the housing ............................................................................. 21
5.2 Cleaning the metal grease filters ......................................................... 22
6 Trouble-shooting 24
6.1 What to do if ............................................................................................ 24
7 Accessories and spare parts 25
8 Technical data 26
3

9 Index 27
10 Notes 29
11 Service & Support 31
4

1 Safety precautions
1.1 Symbols used
Denotes important safety precautions.
Failure to observe said precautions can result in injury or in dam-
age to the appliance or fittings!
Information and precautions that should be observed.
Information on disposal
Information about the operating instructions
▸ Indicates step-by-step instructions.
–Describes how the appliance reacts to the steps taken.
▪Indicates a list.
5

1 Safety precautions
1.2 General safety precautions
▪Read the operating instructions before using the appliance for
the first time!
▪This appliance can be used by children aged 8 and above
and by persons with reduced physical, sensory or mental cap-
abilities, or lack of experience and/or knowledge, provided
they are supervised or have been instructed on the safe use
of the appliance and have understood the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be undertaken by children without su-
pervision.
▪If an appliance is not equipped with a mains cable and a plug
or other means for disconnecting from the mains with a con-
tact opening on each pole complying with the conditions of
overvoltage category III for full isolation, an isolating device
must be incorporated into the permanently installed electrical
installation in accordance with the installation regulations.
▪If the mains cable of this appliance is damaged, it must be re-
placed by the manufacturer or its Customer Services or a sim-
ilarly qualified person in order to avoid hazard.
6

1 Safety precautions
1.3 Before using for the first time
▪The appliance must be installed and connected to the electricity supply in
accordance with the separate installation instructions. Have a qualified fitter/
electrician carry out the necessary work.
▪Dispose of the packaging material in accordance with local regulations.
1.4 Correct use
▪The appliance is designed for use in the home for extracting cooking
odours from above a cooking area.
▪Any repairs, modifications or manipulations to the appliance, especially any
electrically live parts, may only be carried out by the manufacturer, its Cus-
tomer Services or a similarly qualified person. Repairs if carried out incor-
rectly could cause serious injury or damage to the appliance and fittings as
well as affect the functioning of the appliance. If the appliance is not work-
ing properly or in case of a repair order, follow the instructions given in the
'Service & Support' section. If necessary, please contact our Customer Ser-
vices.
▪Use original spare parts only.
▪Retain these operating instructions for future reference. If you sell the appli-
ance or pass it on to a third party, please ensure these operating instruc-
tions accompany the appliance, together with the instructions on installation.
In this way, the new owner can inform themselves about how to use the ap-
pliance correctly and read the pertinent safety precautions.
1.5 Children in the home
▪Packaging material, e.g. plastic film and polystyrene, can be dangerous for
children. Danger of suffocation! Keep packaging material away from chil-
dren.
▪The appliance is designed for use by adults who are familiar with these op-
erating instructions. Children are often unable to recognize the danger of
electrical appliances. Ensure proper supervision and do not allow children
to play with the appliance – there is a danger that children could hurt them-
selves.
7

1 Safety precautions
1.6 Note on use
▪If the appliance is visibly damaged, do not use it. Contact our Customer
Services.
▪If the appliance is not functioning properly, disconnect it from the power
supply immediately.
▪If the mains cable of the appliance is damaged, it must be replaced by Cus-
tomer Services in order to avoid hazard.
▪Caution: Accessible parts may become hot when used with cooking appli-
ances.
▪Do not flambé food underneath the appliance. Metal grease filters if laden
with grease could catch fire.
▪When frying on the cooking surface, do not leave the appliance unattended.
The cooking oil in the frying appliance could overheat and catch fire. Con-
stantly monitor the temperature of the cooking oil, keeping it below the tem-
perature at which it can catch fire. Change the cooking oil regularly – dirty
oil catches fire more easily than clean oil.
▪Observe the cleaning intervals. Failure to do so can increase the fire hazard
due to the build-up of grease in the metal grease filters.
▪Do not operate the individual cooking zones of the cooking surface without
a pan on them or with an empty pan on them so as to avoid damaging the
appliance or the kitchen fittings through a build-up of heat. Avoid open fires
with oil, gas, wood and coal fired cookers.
▪Ensure there is adequate ventilation when the extractor fan is on so as to
avoid creating a disturbing underpressure in the kitchen and to achieve op-
timal air extraction.
▪Avoid a cross-current of air, which could blow the cooking vapours over the
cooking area.
▪If other appliances – fuelled by gas or other fuels – are being used at the
same time, ensure that there is a sufficient supply of fresh air. This does not
apply to air recirculation appliances.
▪If other firing systems are being used at the same time (e.g. wood, gas, oil
or coal fired heating appliances), safe operation is only possible providing a
room negative pressure of 4Pa (0.04mbar) is not exceeded at the location
of the appliance. Risk of toxic fumes! An adequate flow of fresh air must be
guaranteed e.g. via non-closable openings in doors or windows and in com-
bination with an air-intake/exhaust-air wall box or by other technical means.
8

1 Safety precautions
▪When carrying out maintenance work on the appliance, including replacing
the light bulb, cut off the electricity supply to the appliance: remove the
screw fuse from the holder or switch the circuit breaker off, or disconnect
from the mains supply.
▪When cleaning the appliance make sure no water gets inside the appliance.
Use a moderately damp cloth. Do not spray the inside or outside of the ap-
pliance with water. Do not use a steam cleaner. If water gets inside the ap-
pliance, it can cause damage.
9

2 Disposal
Packaging
▪All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS))
are marked and should, if possible, be collected for recycling and disposed
of in an environmentally friendly way.
Disconnection
▪Disconnect the appliance from the mains. With a fixed appliance, this is to
be carried out by a qualified electrician!
Safety
▪Disable the appliance to prevent accidents caused by improper use, espe-
cially through children playing.
▪Pull the plug out of the mains socket or have the appliance disconnected
from the mains by an electrician. Then cut the mains cable off flush with the
appliance.
Disposal
▪The old appliance should not be discarded as worthless rubbish. If dis-
posed of correctly, the raw materials can be recovered for recycling.
▪The symbol on the identification plate warns that the appliance may not
be disposed of in normal household waste.
▪The appliance must be disposed of in accordance with local regulations on
waste disposal. For more information on the handling, disposal and recyc-
ling of the product, please contact the local authorities, the local recycling
facilities for household waste or the retailer from whom you purchased the
appliance.
10

3 Appliance description
The appliance is designed for use in the home for extracting cooking fumes
and smells from above the cooking surface.
The appliance is used in extraction mode.
3.1 Extraction model
A fan draws cooking fumes and smells from above the cooking area. The
metal grease filters clean the extracted air, which is passed through a connect-
ing pipe fitted with an integrated non-return valve and through the air duct to
the outside.
When in use, ensure there is a sufficient supply of fresh air to replace the
air that is being extracted.
3.2 Recirculation model with recirculation box
After being filtered through the metal grease filters, the cooking fumes and
smells above the cooking area are passed through a recirculation box with in-
tegrated activated charcoal filters. The filtered air is then circulated back into
the room.
3.3 Equipment
▪1 extractor fan
▪4 metal grease filters
▪Illumination
▪Remote control
The extractor fan has 4 power levels:
▪1 = low, 2 = medium, 3 = high, and intensive level.
▪Power levels 1–3 are suitable for continuous operation.
▪The intensive level is used for short bursts of intensive extraction of cooking
fumes and smells, e.g. when searing meat. The intensive level runs for six
minutes.
11

3 Appliance description
3.4 Construction
1
2
4
3
1Operating and display elements
2Metal grease filters
3Folding panel
4Illumination
12

3 Appliance description
3.5 Operating and display elements
2 3 I
Infrared port for remote control
Switches the illumination on/off and changes the light intensity
Switches power level 1 and remote control on/off
2
Switches power level 2 on/off
3
Switches power level 3 on/off
I
Switches intensive power level on and resets the saturation indicator
Saturation indicator for metal grease filters
Depending on the model and features, the specification of the appliance
may differ from the standard specification described here.
13

3 Appliance description
3.6 Remote control
This appliance can be controlled by remote control, which requires standard
1.5V LR03-AAA alkali zinc-carbon batteries (not supplied).
Do not place the remote control near heat sources. Please dispose
of the batteries according to the applicable regulations.
Operating and display elements
Switches the illumination on/off and changes the light intensity
Switches the appliance on/off
Reduces the power level step by step
Increases the power level step by step
i
Switches the intensive level on / off before time
Switches the after-running time and CleanAir function on / off before
time
14

4 Operation
4.1 Activating/deactivating the remote control
The appliance can be operated using the operating and display elements on
the appliance or using the remote control.
We recommend operating the appliance using the remote control.
▸ When the appliance is switched off, hold the button depressed for five
seconds.
–The LED on the button flashes twice.
–The appliance can now be operated using the remote control.
▸ When the appliance is switched off, hold the button depressed for five
seconds again.
–The LED on the button flashes once.
–The appliance can only be operated using the operating and display
elements again.
4.2 Switching the appliance on/off
▸ Press the button.
–The appliance switches on at power level 1.
▸ Press the button again.
–The appliance switches off.
15

4 Operation
4.3 Switching the illumination on/off
▸ Press the button.
–The illumination switches on at maximum intensity.
▸ Press the button again.
–The illumination switches off at maximum intensity.
4.4 Changing the light intensity
▸ When the illumination is switched on, hold the button depressed for two
seconds.
–The light intensity lowers.
▸ When the light intensity is low, press the button.
–The light intensity increases.
▪The illumination switches off if, prior to this, the button has been held de-
pressed for two seconds when the light intensity is low or if it is pressed
when the light intensity is normal.
The illumination can be used independently of the extractor fan.
4.5 Changing the power level
▸ Press the button.
–The next lowest power level is set.
▸ Press the button.
–The next highest power level is set.
4.6 Switching the intensive level on / off before time
▸ Press the
i
button.
–The
I
button illuminates.
–The intensive level switches on.
16

4 Operation
▪If a power level had been running beforehand, then the appliance will auto-
matically revert to this power level after six minutes have elapsed.
▪If the appliance had not been switched on beforehand, then the appliance
will automatically switch off after six minutes have elapsed.
▸ Press the
i
button again.
–The
I
button light goes out.
–The intensive level switches off before time.
4.7 Switching the after-running time on / off before time
During after-running time, the motor, fan blades and illumination run for a fur-
ther 30 minutes and then switch off.
The after-running time can only be selected using the remote control.
▸ Press the button.
▸ Press the or button repeatedly until the desired power level is
reached.
▸ Press the button.
–The after-running time switches on.
–The LED for the corresponding power level flashes once per second
for 30 minutes.
▸ Press the button again.
–The LED for the corresponding power level does not flash any more.
–The after-running time switches off before time.
17

4 Operation
4.8 Switching the CleanAir function on / off before time
The air extraction is switched on every hour for ten minutes at power level 1.
After 24 hours, the CleanAir function switches off.
The CleanAir function can only be selected using the remote control.
▸ Hold the button depressed for two seconds.
–The CleanAir function switches on.
–The LED on the button flashes twice per second.
▸ Hold the button depressed for two seconds again.
–The LED on the button goes out.
–The CleanAir function switches off before time.
4.9 Saturation indicator for metal grease filters
After 100 operating hours, the saturation indicator flashes when the range
hood is switched on and off. The saturation level has been reached and the
metal grease filters must be cleaned.
Resetting the saturation indicator
▸ Switch the appliance and the illumination off.
▸ Hold the
3
button depressed for three seconds.
–The LED on the
3
button flashes three times.
–The saturation indicator goes out.
18

4 Operation
4.10 Operation using the operating and display elements
Switching the appliance on/off
▸ Press the /
2
/
3
or
I
button.
–The LED on the corresponding button is illuminated.
–The corresponding power level switches on.
▸ Press the button again.
–The appliance switches off.
Switching the illumination on/off
▸ Press the button.
–The illumination switches on at maximum intensity.
▸ Press the button.
–The illumination switches off at maximum intensity.
Changing the light intensity
▸ When the illumination is switched on, hold the button depressed for
two seconds.
–The light intensity lowers.
▸ When the light intensity is low, press the button.
–The light intensity increases.
The illumination can be used independently of the extractor fan.
Changing the power level
▸ Press the /
2
or
3
button.
–The LED on the corresponding button is illuminated.
–The corresponding power level switches on.
Switching the intensive level on / off before time
▸ Press the
I
button.
19

4 Operation
–The LED on the
I
button is illuminated.
▪If a power level had been running beforehand, then the appliance will auto-
matically revert to this power level after six minutes have elapsed.
▪If the appliance had not been switched on beforehand, then the appliance
will automatically switch off after six minutes have elapsed.
▸ Press the /
2
or
3
button.
–The LED on the
I
button goes out.
–The intensive level switches off before time.
–The corresponding power level switches on.
20
