Vacron VVH-MDE304 User manual

4ch Vehicle DVR System
WiFi / GPS / 3G (optional)
This product contains accessories as below:
※ Storage devices such as hard drives, memory cards are not supplied, please purchase.
Accessories
Standard
Optional
Main Device / Power Cable / ALARM Cable / IR Extension Cord
IR Remote Control / Software Disc / User Manual
3G Module and Antenna / G-Mouse / SD Card / Camera / Microphone pad / Camera
extension cable
Take and review some testing video initially to make sure the images were recorded correctly. Please note
that manufacturer, its subsidiaries and affiliates, and its distributors are not liable for consequential
damages arising from any malfunction of main device accessory, including memory device that results in
the failure of an image to be recorded or to be recorded in a way that is machine readable.
Before using the product, please ensure that you read the safety precautions described below. Always
ensure that the product is used correctly.
Before using 3G products, please ensure that you read the safety notifications
described below.
• Please keep device away from children.
• Use only recommended power sources.
• Do not attempt to disassemble, alter or apply heat to the product.
• Avoid dropping or subjecting the product to severe impacts.
• To avoid the risk of injury, do not touch the interior of the product if it has been dropped or otherwise
damaged.
• Stop using the product immediately if it emits smoke, a strange smell, or otherwise behaves abnormally.
• Do not use organic solvents such as alcohol, benzene, or thinner to clean the product.
• Do not let the product come into contact with water (e.g. sea water) or other liquids.
• Do not allow liquids or foreign objects to enter the VVR.
• Do not place the VVR near or in direct flame.
• Do not handle the power cord with wet hands.
• Do not use the equipment in a manner that exceeds the rated capacity of the electrical outlet or wiring
accessories. Do not use if the power cord or plug are damaged, or not fully plugged into the outlet.
• Do not allow direct or metal objects (such as pins or keys) to contact the terminals or plug.
• Avoid using, placing or storing the product in the humid or dusty areas.
• Company and user shall not modify certified low power radio frequency device the frequency, increase
the power and change the characteristics and functions without permit.
• Use low power radio frequency device shall not affect flight safety and interfere with legal communications;
when there is interference happened should be immediately suspended, and improve without interfering
may continue to use.
• Legal communication means operation of radio communication in accordance with the provisions of the
Telecommunications Act Low-power radio frequency device must endure the interference of legal
communications, industrial, scientific and medical radiation wave equipment.
Safety Precautions
H12AE30404
Product Appearance
SD CARD 2 SD CARD 1 REC GPS LAN
SD Slot 2 SD Slot 1
SD Slot Cover
REC
GPS
IR Receiver
Network
SIM CARD
GPS WI-FI
USB
ALARM IN
ALARM
OUT
ALARM
IN
AUDIO IR
GND +12V OUT
DC
8~32V
ACC
GND
IN
1234G
12 6 5
3G Antenna
Camera 2-4CH Camera 1CH / AV out
GPS Connector
SIM Slot
WIFI USB Slot
Alarm/Audio
IR Ext
Power Connector
※GPS / 3G / WiFi are optional
GND +12V OUT
1 2 3
4 5 6
DC
8~32V
ACC
GND
◆ Power Connector
1. GNDP (-)
2. ACC
3. DC8~32V IN (+)
4. Signal and DC grounding
5. Signal and DC grounding
6. DC+12V Out
◆ Alarm/Audio Connector
ALARM IN
ALARM
OUT
ALARM
IN
AUDIO
IN
1234G
12 6 5
黑橘黃棕紅
紫紫藍綠
ALARM IN
G4 3 2 1
AUDIO ALARM OUT ALARM IN
AUDIO 2
(spare) 16 (spare)
5
(spare)
Power On / Power Off
IR Remote controller
Remote control inspection
?
ˇCheck the battery’s positive and
negative polarity.
ˇCheck the battery if run out.
ˇCheck the sensor of remote control
if be obscured.
ˇCheck if there are fluorescent
lamps are used nearby.
Remote Control Precautions
1CH Screen
Display
Force Recording Button
4CH Screen Display
Mute Menu
Arrow
Confirm
Backward
Playback/
Play
Pause
Stop/Left
DC 8~32V
4CH
GUI
OPTIONALMIC
Note 1: Vehicle Camera optional, 720P and D1 camera can not be used simultaneously
Note 2: SD Card is not included; suggest to apply Class 10 or above., 8-128G acceptable
Note 3: No further notice for any modifications afterwards.
Light Indicator
Two SD Card Mechanism
● Recording/Power Light(Red Light)：
(1) Power On
Insert SD Card into SD slot and closet SD slot lock, then turn on the power and it
will take approximately 30 seconds. When lights start flashing as the recording is
in progress.
(2) Power Off
Turn off the power; please wait for 5 seconds until super capacitor without
electric. Then take the SD Card out out and playback the recording files in
computer.
Light Off- non-recording. Light Flashing- recording.
Rapidly Flashing-Event/Trigger recording.
● GPS Light(Blue Light)：
Light Off-GPS is not ready. Light On- GPS is locating position.
● Network Light (Orange Light)：
Light Off-network disconnected. Light On-network connected.
While both of the SD Cards are blank, the videos will be recorded in SD1;
When both of the SD Cards have videos; new videos will be recorded in the
SD Card with latest videos
Before the first recording,
please set the video format. CARBOX Player on PC
Execute player software CarBox2.exe
 GPS Direction / GPS Latitude & Longitude / Speed for GPS models.
GPS Direction
GPS Latitude &
Longitude
G-Sensor
Volume
Play Bar
Play Speed
Speed
Google Map
Playback Date Selection
1~4 CH
Control Interface
4ch / 9ch
*Support windows operating system
Configuration
Before execute this function, please insert the SD Card into your computer.
When finish all setting and click 『Save』, all the setting will save to the SD
CARD device. When you insert the SD CARD device into your DVR, the DVR
will read the setting and follow the setting to start recording.
Setup the SD Card Setting
