Valeo CC 336 W User manual

Rev.01/ November 2023
Code: 036-00353-001
Owner’s Manual
Warranty Certificate
CC 336 W - CC 356 W
AIR CONDITIONER COACHBUS - CITY BUS

INDEX CC 336 W - CC 356 W
OBSERVATION: to get the best air conditioner
performance we recommend that you read this manual
carefully before starting operation.
Keep this manual with your vehicle for reference.
INTRODUCTION_____________________________________________________________
3
WARRANTY TERMS
Warrant Terms__________________________________________
4
PREVENTIVE MAINTENANCE
Preventive Maintenance Frequency Check List_____________________________
5
Refrigerant Gas R134a_______________________________
6
Dry Filter________________________________________
6
Compressor Sealing Part_____________________________________
6
Heating System________________________________________
6
Oil_________________________________________________________
6
Ducts____________________________________________________
6
Pulley Belts___________________________________________________
6
EQUIPMENT IDENTIFICATION (ID)
- Identification Tag___________________________________________
7
OPERATING THE AIR CONDITIONER
1- Operating the Air Conditioner____________________________________________
8
1.1- SC2000 Controller Operation_____________________________________________________
10
1.2- Description of the Control Panel_____________________________________________
10
1.3- Off Mode____________________________________________
11
1.4- Automatic Mode_________________________________________
11
1.4.1- Automatic Ventilation______________________________________
11
1.4.2- Automatic Compressor_____________________________________
11
1.4.3- Automatic Heating___________________________________________
12
1.5- Compressor Operation________________________
12
1.6- Manual Speed Selection___________________________________
12
1.7- Failures_____________________________________________________
13
EQUIPMENT DESCRIPTION
2- Technical Data Sheet________________________________
11
3- Condenser Components________________________________________
15
3.1- Evaporator Components______________________________________
16
3.2- TM 65 Compressor components_________________________________
17
3.3- Electrics Components____________________________________
18
SAFETY PRECAUTION
4- Safety Precaution______________________________________
19
SUSTAINABILITY
5- Product Discard______________________________________
20

INTRODUCTION
VALEO Climatização do Brasil - Veículos Comerciais S/A offers a full line of
equipment for bus air conditioning systems for vans, micro and midi buses,
commuter, articulated, coaches and double-deckers.
Air conditioning system that is modern and high quality, the products of
VALEO Climatização do Brasil - Veículos Comerciais S/A have been
developed looking for comfort and tranquility to passengers that uses the
public transport.
However, you need to take care to assure a good use and operation of the
air conditioning system, and then you can obtain a better performance of its
technology resources.
It is mandatory to do the preventive and corrective maintenance
procedures, they must be accomplished by experts or dully technicians.
Looking for improving and updating the refrigeration technical teams, this
manual describes the fundamentals of our air conditioning system based on
the most important thermodynamic formulas.
You can find operation instructions of VALEO Climatização do Brasil - Veículos
Comerciais S/A air conditioning too, besides it advises you to follow
technical procedures of adequate preventive maintenance obeying
environmental and safety rules.
Frequent training for technical team make them able to get right diagnosis
from equipment (appliances) to accomplish the servicing.
correctly with quality and responsibility, assuring to the whole fleet a
perfect operation of VALEO Climatização do Brasil - Veículos Comerciais S/A
equipment.
CC 336 W - CC 356 W
3

7 - The Warrant Loses its Validity
a) If the installation or use of the product is not in accordance with the VALEO
Climatização do Brasil - Veículos Comerciais S/A technical recommendations.
b) If the product suffers any damage caused by improper use, neglect, accident,
failures caused by external agents and even lack of maintenance (see owner's
manual) or services performed by unqualified person.
WARRANTY TERMS
Warrant Terms
VALEO Climatização do Brasil - Veículos Comerciais S/A warrants its products for
two-years period in accordance with the terms listed below:
1 - The warranty will be valid for the period above specified, counting from the
date when the equipment is installed in keeping with the warrant certificate,
even after the property there of has ben transfered.
2 – Should the equipment be installed by a third part, VALEO Climatização do
Brasil - Veículos Comerciais S/A warrant only the product and not its instalations.
3 - During the stipulated period, the warranty completely covers the workman-
ship and spare parts used to repair defects duly identified as being:
premature failure of material and components defects used on its manufacture.
4 - Only a techinician from the VALEO Climatização do Brasil - Veículos Comerciais
S/A authorized network of services is qualified to repair the defects coverd
under the warranty.
5 - The warranty approval is subject to the technical analysis of the defects
shown in the components and operational conditions to which the equipment
has been subjected.
6 - No claims will be accepted if the vehicle is still in use after the defect is
found, even if there is lack of pieces, delay in transportation or any other such
incident.
c) If the warranty certificate and/or the serial number of the product are
adulterated, overwritten or damaged.
d) If defects or unsatisfactory performance are caused by the use of non original
spare parts and in disagreement with the technical specifications from VALEO
Climatização do Brasil - Veículos Comerciais S/A.
8 - The Warranty Does Not Cover
a) Displacement of the bus for repairing of the equipment. In case the customer
requests to be attended in the same place where products is operating, the
collection or not of the visitation charge will be the criterion of the authorized
service provider.
b) The attending to the consumer, free or paid, in cities that do not have
authorized services providers. So the expenses with displacement are the sole
responsibility of the owner.
c) Lack of proper preventive maintenance, as described in the preventive
maintenance item in this manual.
d) Replacement of bearings, belts, filters in general and lubricating oil, since
they are considered items of natural wear.
Bearings, belts and alternators have limited warranty as follows:
- Bearings in general: 60,000km or 2 years, whichever occurs sooner.
- Belts in general: 20,000km or 3 months, whichever occurs sooner.
- SEG Alternators: 1 year with no mileage limit.
- Prestolite Alternators: 2 years without mileage limit.
For the items listed above, the conditions established in these warranty terms
and the technical specifications of the respective manufacturer must be
respected.
e) Loss or loss of profits caused by the stoppage of the vehicle due to
non-operation of the equipment.
CC 336 W - CC 356 W
4

- Preventive Maintenance Frequency Check List
PREVENTIVE MAINTENANCE
1 - Clean or change the return air filter.
2 - Check out the belt stretchiness condition and compressor with alternator alignment, observing the wear and tear of them.
3 - Check the water level of the radiator reservoir. See note (*)
1-Accomplishtheweeklychecklist.
2 - Clean the condenser capillary tube coil (Apply only water and neutral non-aggressive soup to cooper and aluminum). See note (**)
3 - Check if the evaporator hatches are closed to avoid air intake into the equipment.
4 - Check the refrigerant charge: wait 15 minutes, it has to flow through the liquid display without bulb formation.
5 - Check the compressor oil level: wait 15 minutes, it must be 3/4 up to 1/4 full at oil display.
6 - Test the equipment operation functions: cool / fan (high and low speed) / heat / dry (air renewing) modes.
7 - Lubricate the components of the compressor support. It includes articulation (elbows), axles, bushing and pulleys, if necessary.
8 - Operate the heating system (if any) for at least 30 minutes.
1-Accomplishthemonthlychecklist.
2 - Measure the exhaust suction pressure, temperature and suction line condition.
3 - Check the tightening of alternator potency cables fuses in general, electric board and start motor.
4 - Measure the condenser and evaporator fan flow consumption (check their air outflow).
5 - Measure the electromagnetic clutch coil.
6 - Measure the Voltage and Current from alternator.
1-Accomplishthetrimestralchecklist.
2 - Clean the evaporator capillary tube coil (Apply only water and neutral non-aggressive soup to cooper and aluminum). See note (**)
3 - Clean the evaporator drain.
4 - Check out the oil retainer felt of the compressor sealing part.
5 - Look carefully, if there is any leakage at coupling spots: oil leakage, refrigerant leakage.
Check if there are any loose, free, damaged, broken, worn parts, rusty, melting, cracked or bad fractioning to the bus body.
1-Accomplishthesemesterchecklist.
2 - Test the compressor efficiency at 1500 RPM.
3 - Make notes about the compressor oil pressure at 1000 RPM.
4 - Check the opening and closing pressures of high and low pressure switches.
5 - Check the screws or bolts that attach the compressor support and equipment, checking the right torque.
6 - Clean the air conditioning body getting rid of any dust/scrap at components: evaporator, condenser, clutch compressor, alternator, alternator,
relay and control board. See note (**)
IMPORTANT: If you do not accomplish the preventive maintenance check list as above, it implies to total or partial loss of warranty coverage.
(**): when cleaning using water, protect electrical and electronic components to prevent damage.
The actions of preventive maintenance written in this manual have been based on normal conditions. Just in case of environment contaminated and bad weather
conditions, then you must do the maintenance more frequent.
WEEKLY
MONTHLY
NOTES (*): if necessary, fill it in with water and additives, follow the recommendations of the OEM Body Builder.
YEARLY
SEMESTER
TRIMESTRAL
CC 336 W - CC 356 W
5

SAY NO TO RECONDITIONED PARTS
ATTENTION: under no circumstances, refrigerant cannot be spoiled at the
atmosphere.
IMPORTANT: check reservoir water level. If necessary, fill it in with water
and additives, follow the recommendations of the OEM Body Builder.
PREVENTIVE MAINTENANCE
- Refrigerant Gas R134a
VALEO Climatização do Brasil - Veículos Comerciais S/A products apply for
R 134a. The se of different type of gas, low quality or from unknown brands will
cause low performance from the refrigeration and damage the equipment
components. - Ducts
The cleaning of the air ducts must be done every tree months, it can be earlier,
depending on: the frequency of operation of the air conditioning system,
quantity of passengers and resistivity of the environment where it is driven. This
cleaning is the responsibility of the vehicle owner´s only, he is in charge of this
cleaning in order to offer good air quality to his passengers.
NOTE: ducts are components of the bus body.
- Pulley Belts
In order to increase the lifetime of the belts, the strength/stretchiness must be
as low as possible, but working, not leaving them skidding without any friction.
Too low stretchiness on the pulley belts can cause overheat and too much
skidding, causing early break.
Too much stretched belts diminish their lifetime and from roll bearing and from
sleeves, this problem can cause engine interior and compressor damage.
After changing the belts, check their stretchiness back again after 48 working hours.
It is recommended not use different brands. Install assemblies with the same
diameter/length of the series and do not apply new belts beside old ones.
Putting the assembly into action without one or two belts for a long time can
cause a damage inside the “v” groove of the pulley. It will cause wear in that
“v” groove, so the new belt may not be stretched accordingly.
The application of reconditioned parts will diminish the air
conditioning efficiency, will overcharge the electric system causing
early brake of the compressor and set a fire!
- Oil
We recommend you that you shall preventively change the air system oil every
two years or 10.000 working hours, whatever becomes first.
- Dry Filter
We recommend that you shall preventively change the drier filter every 3 years.
Just in case, you need to refill in the equipment with gas, we recommend you
replace to a new filter to extinguish any dirt out of the system.
- Heating system
We recommend that you enable the heating system frequently (once a month)
to prevent the buildup of solid system particles that lodge in the hot air shutoff
valve seat.
- Compressor Sealing Part
In order to avoid leakage at the sealing part of the compressor due to lack of
lubrication, then the air conditioning must be working at cool mode for at least
15 minutes, once every 15 days.
The sealing part is lubricated by the compressor oil and in its normal operation
allows a small leakage of 0.05 ml per hour under operation.
Check frequently the reservoir and/or felt then remove the excess of it.
Dispose the old oil as your Country regulations and laws.
CC 336 W - CC 356 W
6

PREVENTIVE MAINTENANCE - EQUIPMENT IDENTIFICATION (ID)
ATTENTION: Just in case a problem happens in the refrigeration system, then it
must be repaired in an authorized shop or qualified professional.
If a third party installs the equipment, VALEO Climatização do Brasil - Veículos
Comerciais S/A, guarantees only the product, not the installation of it.
The following items are in charge of the OEM Plant (Bus Body Builder).
• Driver´s evaporator :
Problems with any driver´s air conditioning component, leakage, bad working or
operation.
IMPORTANT: l clean the return filter of the driver´s air conditioning, at least, once
a week.
• Tubes, hoses, drains and wiring harness:
Bad attachment. Leakage at connections and welding points. Damages due to
frictioning / chassis and components frictioning or bad installed.
• Alternator/Compressor Support:
Excess or lack of torque at attaching screws/bolts. Assembly is out of project
designs. Pulleys are not aligned, excess or lack of stretchiness at the belts and
pulleys.
• Gas Charge Process:
Leakage test procedure. Vacuum process and refrigerant gas charge.
Note: in case the installation is bad, VALEO Agent Authorized Service Net will
have to call the OEM Plant first, then get an authorization to do the service,
print and issue the Invoice of repairs.
Identification Tag
It is very important, when you need to ask for spare parts or after sales parts,
and similar ones, customer must identify the model of the air conditioning,
telling the series number, model and manufacturing date.
This information can be found in the Air Conditioning Warranty Certificate and ID
tag.
Application information regarding to: series and bus body model, series and
chassis model are very important to identify which parts the equipment carries.
In order to identify the bus body and chassis, you need to check the bus body
builder manual.
The refrigerant gas amount can vary
according to application.
IMPORTANT: the vehicle owner must do preventive maintenance actions.
If you do not do the preventive maintenance as described in this chapter,
it implies you lose partially or full warranty coverage.
CC 336 W - CC 356 W
7

OPERATING THE AIR CONDITIONER
1- Operating the Air Conditioner
Note: illustrative drawing.
17
14
2
8
1
16
7
15
6
13
11
13
5
4
3
12
18
9
9
10
19
19
16
11
CC 336 W - CC 356 W
8

Condenser Fan
Condenser fan and the compressor will only work at
“Cool Mode”.
Refrigerant Fluid
Its main goal is dissipate the heat out, which was
absorbed by the refrigerant fluid along the
refrigeration system.
At the condenser, the overheat refrigerant fluid is
sent to outside losing its force, changing from
gaseous state to liquid state.
Condenser
Dryer filter
Valve hinders the refrigerant inlet that comes from
de condenser at high pressure and its goal is adjust
the refrigerant gas flow that passed by the
evaporator looking for making the pressure steady
and temperature at the capillary tubes output.
Compressor
When it is working, the compressor sucks the refrigerant
fluid from evaporator at gaseous state and under low
pressure, compressing it, so temperature and pressure
increase, then the compressor puts it into the condenser.
MECHANIC SYSTEM
Compressor Operation
It is started up by the vehicle engine though a
pulley-and-belt system and put into action by an
electromagnetic clutch when air conditioning is
operating at “Cool Mode”.
Air refrechment
This permits the entry of the exernal in order to expel
unwanted odors and impurities from the vehicle.
Evaporator Fan
Evaporator fans are working at cool and fan modes,
fans can be set in two speeds.
Sped control can be manual or automatic.
Temperature Sensor
The interior temperature is measured by the
temperature sensor placed at the air return spot.
Pressure Switches
Pressure switches are electric devices that monitor the air
conditioning equipment operation pressure. Every time a
strong change happens from the NORMAL temperature,
they turn off the compressor immediately to avoid break.
Observation: pressures are always monitored, even if the
air conditioning is turned off.
ELECTRIC SYSTEM
Evaporators
Now at evaporators, the refrigerant fluid, at low
pressure, turns from liquid to gaseous state,
absorbing the interior heat of the vehicle in this
process.
Controller
It is installed in the instrument panel, it offers to the
driver to set-point of temperature, to see by display the
interior temperature, offering full climatic control inside
de bus.
Set-point: it is the temperature the driver wishes to set
inside the vehicle for passengers.
Relay Board
Relay board has the controller controls, condenser fan
control, evaporator control and compressor control.
Air filter
Air return filter retains impurities from air avoiding
any block of dirt at evaporator capillary tubes and
coil.
Air circulation
Air being cooled by the evaporator, then it follows
to the bus interior through fans.
Drain
It is a way to get the condensed moisture from
evaporator tubes from the condensed tray to putting
out.
MECHANIC SYSTEM
ELECTRIC SYSTEM
1
2
3
4
5Expansion Thermostatic Valve
6
7
8
9
10
11 18
ECU module
19
12
13
14
16
Solenoid Valve
15
17
Solenoid valve is applied to stop refrigerant flow through a
line. It is a closing valve controlled remotely and under
electric operation.
AIR CONDITIONING OPERATION
It is inside the air conditioning equipment, inside the
system. It works absorbing the heat from the interior
/ room of the vehicle, at the evaporator, and then it
goes to the condenser where the heat is thrown to
the outside. VALEO Climatização do Brasil - Veículos
Comerciais S/A, products apply refrigerant R134a,
according to the Protection Environmental Law.
It has the purpose of retaining impurities and/or
moisture that can exist in the system, preventing
them from leaking into the expansion valve.
CC 336 W - CC 356 W
ECU (Engine Control Unit), refers to a module which
controls the vehicle's electronic systems.
Receives signals sent by sensors (input), performs the
processing and immediately sends to the appropriate
actuators (output).
9

1.1- SC2000 Controller Operation
SC2000 Controller
1.2- Description of the Control Panel
1
2
7
8
3
4 5 6
This product aims to control the temperature of SD (Single Deck) vehicles. The
intelligence of the system and charge activation is done by Smart ECU in
conjunction with the relay board, while the panel is used for user interface only.
The following ECU configurations are available:
• SC2000 - HVAC SD
• SC2000 - VAC SD
Below is a description of each of the keys with their respective functions.
1- ON/OFF Turns the product ON / OFF.
2- AC Indicates that the compressor is ready for
operation.
3- Increment of the set-point Defines the desired temperature in the room.
4- Decrease of the set-point Defines the desired temperature in the room.
5- Auto Activates the automatic fan speed and air
renewal mode.
6- VENT Manual speed control of the evaporator fans.
7- Re-Heat Turns on / off the passenger window defroster.
8- Air recirculation Turns on / off air recirculation on the bus.
AIR CONDITIONING OPERATION CC 336 W - CC 356 W
10

OPERATING THE AIR CONDITIONER
1.3- Off Mode 1.4- Automatic Mode
1.4.1- Automatic Ventilation
1
2 34
The controller can be started by the ON/OFF key or through the auto start
function. To turn on the controller, a +15 signal (ignition) is required. With that,
the standby light will be on, allowing the visualization of the temperatures if the
panel is on.
Note 1: If the standby light is off and the Power button is pressed, the standby
light will come on and the panel can be turned on. However, if no
communication is established, the product will return to sleep mode.
Note 2: emergency mode: if the control panel does not establish communication
with the panel, after 1 minute the control panel starts to operate automatically.
Note 3: when turning on the panel, the Firmware versions of the ECU SU021 and
the Panel SC2000 are informed respectively by the abbreviations SUV xx and
SCV xx.
1- Status indication of the actuators;
2- Set-point temperature;
3- Outside Temperature;
4- Return Temperature.
When starting the panel, automatic mode is activated (the corresponding key is
illuminated in amber color).
The auto mode activated indicates that the evaporator fan speed and the air
recirculation function are operating in automatic mode, as well as the compres-
sor drive. Automatic mode is disabled when any of the following occurs:
• AC key pressed disabling the compressor;
• Changing the fan speed using the key.
Evaporator ventilation is controlled by the Set-point together with the suction
and discharge pressure values. To maintain the appropriate pressure value for
the operation and reach the defined Set-point.
1.4.2- Automatic Compressor
The compressor is activated according to the difference between the Set-point
and the return temperature, values defined by the parameters (P68 and P69).
CC 336 W - CC 356 W
11

1.4.3- Automatic Heating
1.5- Compressor Operation
1.6- Manual Speed Selection
The heating mode is controlled by the Set-Point and by parameters P62 and P63.
In heating mode, the speed of the evaporators will be at a low level and trigger
the valve for heating.
By default, the control will always have the AC key in amber color, indicating
that the compressor is enabled for operation.
Disable Compressor: pressing the AC button when the illumination is amber
will disable the compressor. If the compressor is activated, it will be turned off
respecting the minimum operating time. The cooling function will be disabled.
Activate Compressor: when pressing the AC button when the illumination is
white, the compressor will be activated. The air conditioning compressor is
enabled and turns on if necessary and if the minimum operating times are
maintained. The cooling function will be enabled.
Note: the air conditioning compressor must be turned off for at least 1 minute
before it can be turned on again. If the AC button is pressed during this time, the
device reactivates the air conditioning compressor after 1 minute. The air
conditioning compressor runs for at least 1 minute before turning off. If it is
disabled right after activation, it will keep working for 1 minute.
The speed of the evaporator fans can be changed manually using the ventilation
key and its value defined using the increment and decrement keys.
Auto key will be disabled.
2 speeds (brush fans) or 5 speeds (electronic fans) are available for manual
definition, these speeds are a request to the control system, which depending on
its point of operation and control will seek to define the necessary speed.
CC 336 W - CC 356 WOPERATING THE AIR CONDITIONER
12

1.7- Falhas
Description of errors according to the following table:
Error Component Cause
F01 System Check supply voltage.
F03 Compressor Pressures out of operating limits, error of compressor on,
coil freezing.
F09 External Sensor Sensor open or short circuited.
F11 Duct Sensor Short circuited sensor.
F13 Duct Sensor Sensor aberto.
F15 Loop Sensor Sensor open or short circuited.
F17 Ice Sensor Sensor open or short circuited.
F19 UV Disinfection System Damaged lamps or ballasts.
1.7- Failures
When an error occurs, an exclamation symbol will appear on the display in the
upper right corner.
The error table can be viewed when there is an exclamation mark on the screen
and the Auto key is pressed.
The current error is indicated by flashing and with the value 1.
CC 336 W - CC 356 WOPERATING THE AIR CONDITIONER
13

EQUIPMENT DESCRIPTION
2- Technical Data Sheet
CC 336 W - CC 356 W
Maximum Capacity 120.000 BTU/h (35 kW) 136.500 BTU/h (40 kW)
Heating Capacity 136.500 BTU/h (40 kW) 136.500 BTU/h (40 kW)
Type HFC-134a HFC-134a
quantity (*) 5 kg 5 kg
Model of blowers Centrifugal Centrifugal
Quantity of blowers 6 6
Air flow (free blowing) 6.600 m3/h 6.600 m3/h
Corriente Nominal 90A 124A
Model of Fans Axial Axial
Quantity of Fans 3 4
Air flow 8.700 m3/h 11.600 m3/h
Nominal Current 90A 124A
Model (Alternative Type) TM65 (Heavy Oscillating Plate) TM65 (Heavy Oscillating Plate)
Displacement 635 CM3635 CM3
Maximum Rotation Allowed 4.000 RPM 4.000 RPM
Aceite Lubricante 027-00002-000 027-00002-000
Amount Used 1,5 Litros 1,5 Litros
Type Electromagnetic Electromagnetic
Voltage/Current 24V - 80A 24V - 88A
(*) The quantity of refrigerant gas can vary according to the application and installation. When you have defrost, add 1kg more in the amount of refrigerant.
CC356W
CLUTCH
Component
AIR CONDITIONING
CC336W
REFRIGERANT GAS
EVAPORATOR
CONDENSER
COMPRESSOR
Features
14

3
24
6
15 7
8
EQUIPMENT DESCRIPTION
3- Condenser Components
NOTE: visit https://www.valeo-thermalbus.com/br_pt/PRODUTOS/PECAS-DE-REPOSICAO
ITEM CODE DESCRIPTION QTY.
SEE NOTE Condenser / Evaporator Module
SEE NOTE Condenser / Evaporator Module w/ UV Purifier
2 SEE NOTE Condenser Central Closing 1
3 SEE NOTE Extruded Aluminum C Profile 1
4 SEE NOTE Extruded Aluminum C Profile 1
5 SEE NOTE MPHE Condenser Coil 1
6 SEE NOTE Axial 24V 12" Electronic Condenser Fan 4
7 SEE NOTE Discharge Pipe Set 1
8 SEE NOTE Front Finish Cover 1
9 SEE NOTE Condenser Liquid Line Set 1
10 SEE NOTE Liquid Tank / Drier Filter 1
11 SEE NOTE Tank Liquid Line Set 1
12 SEE NOTE Finishing Rubber 2
13 SEE NOTE Condenser / Evaporator Base w/ Renewall R.1 1
14 SEE NOTE AM2 24VDC 20W CASTEL 91 Coil 1
15 SEE NOTE Condenser Electric Wiring Harness 1
1 1
1
5
910 13 11 1214
CC 336 W - CC 356 W
15

3.1- Evaporator Components
ITEM CODE DESCRIPTION QTY.
1 SEE NOTE Central Evaporator Closing 1
2 SEE NOTE Front Finish Cover 1
SEE NOTE Air Renewal Set With Filter 1
SEE NOTE Air Renewal Filter Set 1
4 SEE NOTE 24V Air Renewal Eletric Engine 1
5 SEE NOTE 7/8" Hot Water Valve 1
6 SEE NOTE 7/8" 24V Solenoid Valve 1
7 SEE NOTE TGEN 3,5 TR Expansion Valve 2
8 SEE NOTE RH Evaporator Coil 1
9 SEE NOTE LH Evaporator Coil 1
10 SEE NOTE RH Heating Coil 1
11 SEE NOTE LH Heating Coi 1
12 SEE NOTE Evaporator Liquid Line Tube Set 1
13 SEE NOTE Suction Tube Set 1
14 SEE NOTE 24V Radial Electronic Fan 6
15 SEE NOTE Evaporator Electrical Harness 1
3
3
4
1
5
6
2
7
14
4
10
8 7 13
7 9 111215
NOTE: visit https://www.valeo-thermalbus.com/br_pt/PRODUTOS/PECAS-DE-REPOSICAO
CC 336 W - CC 356 W EQUIPMENT DESCRIPTION
16

3.2- TM 65 Compressor components
1
3
2
Pulley Models
8PK 2A
4
NOTE: visit https://www.valeo-thermalbus.com/br_pt/PRODUTOS/PECAS-DE-REPOSICAO
ITEM CODE DESCRIPTION QTY.
1 SEE NOTE TM 65 Compressor 1
SEE NOTE 2A/2B Pulley 1
SEE NOTE
8PK Pulley 1
3 SEE NOTE
Clutch Set without Pulley 1
4 SEE NOTE
Compressor Oil -
2
CC 336 W - CC 356 W EQUIPMENT DESCRIPTION
17

3.3- Electrics Components
6
39
8
5
47
11
1012
2
1
NOTE: visit https://www.valeo-thermalbus.com/br_pt/PRODUTOS/PECAS-DE-REPOSICAO
ITEM CODE DESCRIPTION QTY.
1 SEE NOTE SC2000 Controller 1
2 SEE NOTE 2CP45-4 Temperature Sensor 1
3 SEE NOTE 24V Water Pump 1
4 SEE NOTE High Pressure Switch 1
5 SEE NOTE Low Pressure Switch 1
6 SEE NOTE External Temperature Sensor 1
7 SEE NOTE EPCOS 3K Temperature Sensor 1
8 SEE NOTE Fuse 125A 1
9 SEE NOTE Fuse Holder 1
10 SEE NOTE 24V Electric Command Plate 1
11 SEE NOTE Relay -
12 SEE NOTE ECU Module 1
CC 336 W - CC 356 W EQUIPMENT DESCRIPTION
18

SAFETY PRECAUTION
4- Safety Precaution
1- Personal Protection:
Air conditioning systems offers chemic, mechanic
and electric risks.
It is mandatory to wear IPE (Individual Protection
Equipment), picture 1 to protect yourself from
refrigerant gas, refrigerant oil, battery acid, waste
launched, engine high temperature and noise.
2- High Pressure:
The refrigerant in liquid state and high pressure
causes a potential risk. When the refrigerant is
sprayed to natural air, it can cause serious injuries to
eyes and skin.
3- Hoses:
Check if manometer hoses are in good conditions,
when holding them; stay far from belts, pulleys and
hot surfaces.
4- Hot Surface:
The compressor discharges, exhaust pipes and other
engine components can be extremely hot.
5- Rotation Components:
The fans, pulleys and belts are not visible under
certain conditions. Special care must be taken when
putting your hands near them.
6- Welding:
Welding must be done carefully; it causes burns and
spray toxic gases out. Provide ventilated places to
do it.
7- Toxic Gases:
The refrigerant gas along with flame becomes into
toxic gases and can cause very serious breathing
illness. Take special care in closed places, if gases
scape somehow (leakage) and then it can cause no
toxygen in the air.
Other Care:
• When handling and going up and down stairs, ladders and platforms, you can
slide or they can break.
• Wear a seat belt always when working over 1.5m high.
• Never apply heat in recipients or pressured lines.
• Never operate the equipment if discharge service valve is closed.
• The refrigeration oil can cause irritation to your skin and eyes.
• Check if every screw are long enough and right tight.
•Components that are not in good conditions must be replaced by new
ones due to safety reasons.
CC 336 W - CC 356 W
19

5- Product Discard
SUSTAINABILITY
Concerned about sustainability at Valeo Climatização do Brasil - Veículos
Comerciais S/A guides its customers and its authorized service network to
discard products in an environmentally sound and safe manner.
Proper disposal of the product or components at the end of their useful life will
contribute with the preservation and pollutinon reduction of the environment,
creating economic growth through the Reverse Logistics Program.
According to Law 12,305 / 2010, the environmentally adequate destination of
components (parts, oil, refrigerant) is required.
It is the responsibility of all to ensure that products and components are sent to
appropriate treatment to companies approved by the environmental agencies.
For more information about our Reverse Logistics Program, please see our
website: https://www.valeo-thermalbus.com/us_en/Home
CC 336 W - CC 356 W
20
