Vallox 252 M User manual

TECHNICAL SPECIFICATION
VALLOX-product code:
VALLOX 252 M
HVAC code:
VALLOX 252 M
3158500 L
3158510 R
7911076 L
7911077 R
PRESSURE DIFFERENCE
SWITCH
(OPTIONAL)
SOUND ATTENUATOR
(OPTIONAL)
IVALLOX 252
VALLOX 252 M
WATER OPERATED POST-
HEATING UNIT (OPTIONAL)
ELECTRICAL
POST-HEATING UNIT
(OPTIONAL)
MANUAL
CONTROL CENTER
REMOTE MONITORING
CONNECTION
ELECTRICAL PREHEATER
(OPTIONAL)
Supply air
Discharge air
Supply air
Discharge air
210 dm3/s 100 Pa
230 dm3/s 100 Pa
2 heat recovery cells, η>70 %
Manual or remote monitoring control
2,5 kW 11 A
2,5 kW 11 A
Approx. 5kW
EU 3
EU 7
EU 3
EU 5
210 kg
2x230 W 1 A
2x230 W 1 A
Fans
Heat recovery
Heat recovery bypass
Preheater
Electric post-heating unit
Water post-heating unit
Filters
– manual control (manual control unit)
– remote monitoring control
– sound attenuator
– preheater
– electric post-heating unit
– water post-heating
– pressure difference switch unit
Ventilation adjustment
options
Options
Power supply 230 V, 50 Hz, (230 V / 400 V)
13,9 A (+preheater 10,9 A)
Protection class IP 34
Weight/basic unit

VALLOX 252 M
OPERATING PRINCIPLE OF THE VENTILATION UNIT
Sound
attenuator unit
2
2
Installed above the unit
Models:
VALLOX 252 M L
VALLOX 252 M R
VALLOX 252 M removes contaminated air and replaces
it with filtered and heated outdoor air.
Efficient filtering of outdoor air (EU3 + EU7) prevents
harmful particles from entering the ductwork and
rooms via the unit. Good filtering of discharge air (EU3
+ EU5) diminishes the contamination of the unit and
ensures effective operation of heat recovery and the
discharge air fans. Clogging of the filters and the duct-
work can be monitored if the unit is equipped with
pressure difference switches.
With efficient 2-step heat recovery, most of the heat
of contaminated discharge air can be transmitted to
outdoor air coming inside. The efficiency of the heat
recovery cells is approx. 70%, or 75...80% if supply
air fan heat is taken into account. If outdoor air does
not get sufficiently warm in the heat recovery cells, it
is possible to use an (optional) heating unit operated
by water or electricity.
In the summertime, needless heating of outdoor air
can be avoided with the heat recovery bypass function,
operated either manually or by remote control.
The automatic defrosting of the heat recovery cells in-
termittently stops the supply air fans when the tempe-
rature of discharge air goes under the pre-set threshold
value. To avoid or to decrease the stopping of the supp-
ly air fans, supply air can be heated with an electrical
preheater. If the unit is equipped with a preheater, def-
rosting starts when outdoor air temperature goes be-
low ca. -15/-25°C (max./min. supply air stream). Wit-
hout preheating, the operation starts when outdoor air
temperature falls below ca. -5°C.
VALLOX 252 M can be operated with the manual cont-
rol unit contained in the delivery. With the manual
control unit, you can select the min. or max. ventilation
power, and stop the unit. The control unit also features
a heat recovery bypass switch. The manual control unit
cannot be used in remote monitoring control.
In remote monitoring, you can stop the unit, and adjust
three different power positions (min, half, max). Heat
recovery bypass can also be controlled in remote mo-
nitoring. Control voltage in remote monitoring is 24
VAC.
The unit gives potential-free signals of operation mo-
des of the selected power positions and the optionally
installed pressure difference switches of the ductwork.
The unit can supply control voltage (24VAC) to separate
damper motors of the outdoor air and extract air ducts.
This control voltage is switched off when the unit is
stopped. The function can be used in both manual and
remote monitoring control.
The separate damper motors are not included in the
delivery.
2370
665
220 220
1100
187 222 282 222 187
1000
1370
Ø 250 Pcs.
VALLOX M 252-R
= EXTRACT AIR
= DISCHARGE AIR
= SUPPLY AIR
= OUTDOOR AIR
VALLOX 252 M-L
= OUTDOOR AIR
= SUPPLY AIR
= DISCHARGE AIR
= EXTRACT AIR
Main parts
Optional equipment
12
13
14
1
2
3
5
6
7
8
9
1010
4
11
Post-heating unit
• water operated or electrical
Preheater
• electrical
Pressure difference switch unit
187
220
222
1100
187
222
282
1370
220
(Door and insulation 55 mm)
Ø250 4Pcs.l
610 +
*
14
6
1
4
5
8
12
10
11
7
13
3
9
2
A
B
CD
Supply air fans
Discharge air fans
Heat recovery cells
Heat recovery bypass
Supply air filter EU7
Discharge air filter EU5
Discharge air filter EU3
Outdoor air filter EU3
Condensing water reservoir
Condensing water outlet
Electrical connection lead-throughs
A
B
C
D
A
B
C
D
Internal
outlet collar
* detachable inner coupling

VALLOX 252 M
PERFORMANCE
VALLOX 252 M VALLOX 252 M
Measuring Points
VALLOX 252 M
with Sound Attenuator
Measuring Points
VALLOX 252 M with Sound Attenuator
FAN CAPACITY
Fan curves: P = discharge air fan, T = supply air fan
Measuring points after the outlet collar.
Fan curves indicate the total pressure
available for duct losses.
Measuring points after the outlet collar.
Fan curves indicate the total pressure
available for duct losses.
1
2
3
4
5
6
7
8
Fan
speeds
90
100
110
130
140
160
200
230
Control
voltage
V
200
230
275
350
390
450
590
675
Input
power
W
3
1
2
3
4
5
6
7
8
90
100
110
130
140
160
200
230
200
230
275
350
390
450
590
675
74
85
99
127
143
170
206
220
Pressure loss in ducts. Total pressure
Suositeltava
toiminta-alue
80
95
110
135
150
175
205
230
Air
flow
l/s
FAN CAPACITY
Pressure loss in ducts. Total pressure
Volume flow rate
Fan curves: P = discharge air fan, T = supply air fan
Recommended
operating range
Volume flow rate
Recommended
operating range
Supply air Discharge air
P
Supply air Discharge air
Model L
Fan
speeds
Control
voltage
V
Input
power
W
Air
flow
l/s
Model L
T

•Sound power levels in the ducts measured in accordance
with the standard ISO/DIS 5135:1995.
•Sound pressure levels in the room (10 m
2
sound absorption)
determined according to the regulation 4873/531/84
issued by the Finnish Ministry of Environmental Affairs
LwA = A-weighted sound pressure level
* = difference between sound power level and pressure level when unit location and total absorption
area are taken into account (in a classroom, for instance, t.ex. LwA -* = 12 dB)
LpA, dB(A)
63
125
250
500
1000
2000
4000
8000
Lw, dB
LwA dB(A)
Hz
LwA, dB(A)
LpA = A-weighted sound pressure level (10 m
2
sound absorption)
Sound power level from VALLOX to supply
air ducts by octave band Lw, dB
Medium
frequency
of the
octave
band,
Hz
CONTROL POSITION / AIR FLOW
Sound power level from VALLOX to
discharge air ducts by octave band Lw, dB
CONTROL POSITION / AIR FLOW
63
125
250
500
1000
2000
4000
8000
Lw, dB
LwA dB(A)
Hz
Sound power level coming from VALLOX through
the envelope to the rooms where the unit has
been installed
CONTROL POSITION / l/s
LpA, dB(A)
Sound power level from VALLOX to supply
air ducts by octave band Lw, dB
CONTROL POSITION / AIR FLOW
Sound power level from VALLOX to
discharge air ducts by octave band Lw, dB
CONTROL POSITION / AIR FLOW
Medium
frequency
of the
octave
band,
Hz
Sound power level coming from VALLOX through
the envelope to the rooms where the unit has
been installed
CONTROL POSITION / l/s
VALLOX 252 M
SOUND VALUES
2
4
VALLOX 252
with Sound Attenuator
6
169l/s
68.0
63.5
61.0
49.5
47.0
45.0
35.0
27.0
70.0
55.5
4
129/139
40
6
166/176
44
8
212/217
47
VALLOX 252 M
8
226 l/s
74.5
72.0
66.0
52.0
49.5
49.5
38.0
31.0
77.0
61.0
6
179/s
72.0
68.5
61.0
48.0
48.0
45.0
34.0
27.0
74.0
57.0
4
141 l/s
68.5
66.0
57.0
43.5
43.5
38.5
28.5
18.5
70.5
53.5
1
85 l/s
63.0
59.0
47.5
36.5
36.0
28.0
15.5
64.5
45.0
8
208 l/s
69.5
67.0
64.5
54.5
50.0
50.0
39.5
32.0
72.0
59.0
4
138 l/s
65.5
60.0
55.5
44.5
43.5
38.5
20.0
66.5
50.5
30.0
1
76l/s
62.0
55.0
48.0
36.0
38.5
28.5
20.0
63.0
44.0
1
78/85
33
8
204 l/s
67.0
65.0
51.5
36.5
30.0
27.0
18.5
69.0
49.5
6
167 l/s
63.0
62.5
48.0
31.0
24.5
20.5
65.5
46.5
4
135 l/s
59.5
59.0
43.0
25.5
17.0
62.5
42.5
1
80/s
55.5
53.5
34.0
57.5
37.0
8
209 l/s
66.5
62.5
50.5
41.5
32.0
27.0
15.5
68.0
48.0
6
169l/s
63.0
60.0
46.5
35.0
25.0
19.0
65.0
44.5
4
133 l/s
61.0
57.5
40.5
27.5
16.0
62.5
41.0
1
77 l/s
55.0
52.0
33.0
18.0
13.5
14.0
57.0
35.5
4
131/138
42.5-*
38.5
6
167/175
47-*
43
8
208/221
50.5-*
46.5
1
74/82
36-*
32

VALLOX 252 M
WATER RADIATOR PERFORMANCE
Pressure Loss in the Water Radiator
5
Water Radiator Output
Temperature of water entering the radiator (tv) 70 ˚C
Temperature of air entering the radiator (ti)15 ˚CTemperature of water entering the radiator (tv) 55 ˚C
Temperature of air entering the radiator (ti)15 ˚C
Cooling of water in the radiator ˚C
Water flow dm3/s
Total output of the radiator kW
Cooling of water in the radiator ˚C
Water flow dm3/s
Total output of the radiator kW
Air flow
dm3/s
Air flow dm3/s
Total pressure loss kPa
The recommended area of operation is ruled. Determined for 100% water.
Water flow
dm3/s
dm3/h
Radiator + valve (KVS 1.0)
Radiator

VALLOX 252 M
CONTROL DIAGRAM VALLOX 252 M - MANUAL CONTROL
2
6
Control Diagram VALLOX 252 M - MANUAL CONTROL UNIT
Distribution Panel
2x16A if equipped with a preheater
Internal electrical and control connections
Post-heating unit, electric
Preheater, electric
Sound attenuator
Manual control unit
VENTILATION ZONE

VALLOX 252 M
7
Heat Recovery Defrosting
The TS5 temperature thermostat directs the operation of the preheater (LP1)
on the basis of the measurement data supplied by the temperature sensor,
preventing the risk of freezing and the stopping of the supply air fan (TF).
If the capacity of the preheater (LP1) is not sufficient, or if there is no
preheater, the TS1 defrosting thermostat of the heat recovery cells stops
the TF supply air fan on the basis of the measuring data on the temperature
sensor, thereby preventing the heat recovery cell from freezing. As soon
as the risk of frosting passes, the fan restarts automatically. The threshold
temperature for defrosting (-2...+6 ˚C) and the difference area (2 ˚C) can
be set on the thermostat.
Overheating Protection of the Heating Unit
Overheat protection thermostats TZ1 and TZ2 monitor the surface tempe-
rature in the LP1 and LP2 heating units. If surface temperature exceeds the
threshold, overheat protection is triggered and power supply to the hea-
ting unit is stopped. The TZ1 overheating protector is reset automatically,
and the TZ2 protector manually.
Damper Motors of the Outdoor and/or Extract Air Ducts
The spring return damper motors (24VAC) that may be installed outside
the ventilation unit, in the outdoor or extract air ducts, can be controlled
with control voltage (24 VAC) coming from the ventilation unit: when the
ventilation unit is stopped, also the control voltage fed from the unit is
stopped.
Control of Operation
The ventilation unit can be stopped by the fan speed switch on the ma-
nual control unit.
Fan Speed Adjustment
The users can control the fan capacity of the ventilation unit in two steps
using the speed selection switch on the manual control unit (H) in the
ventilation zone.
Supply Air Temperature
The control / adjustment center of the unit directs the operation of the
post-heating unit (LP2) on the basis of the measuring data on the sensor of
the TS2 temperature thermostat, aiming at keeping supply air temperatu-
re at the temperature value set with the TS2 thermostat (10....25 C).
Heat Recovery Bypass
Heat recovery can be bypassed using the Summer / Winter switch on the
manual control unit (H).
When the switch is in the Winter position, heat recovery is on. The
Summer position bypasses heat recovery and deactivates the preheater
(LP1), if used, and the post-heating unit (LP2).
DESCRIPTION OF OPERATION VALLOX 252 M - MANUAL CONTROL UNIT
Parts List
Code Name Technical details Equip- Delivery
(factory settings in parentheses) Note! ment responsibility
FG Damper motor Automatic heat recovery bypass 24V, 2W, 8Nm Standard X IU
H Manual control unit Fan speed adjustment,
control of heat recovery bypass Standard X IU
LP1 Preheater Electric radiator 2.5kW Options IU
LP2 Post-heating unit Electric radiator 2.5kW Options IU
LTO1 Heat recovery cells 2-step, = 70 % Standard X IU
LTO2
PF Discharge air fan qv = 230 dm3/s (100Pa) Standard X IU
SU Filter Supply air EU7, discharge air EU5 Standard X IU
TS1 Temperature thermostat Discharge air temperature
Heat recovery defrosting Adjustment range -2...6 ˚C (2) Standard X IU
TS2 Temperature thermostat Supply air temperature Standard X IU
Post-heating, electric
TS5 Temperature thermostat Discharge air temperature
Preheating, electric Adjustment range -0...8 ˚C (2) Standard X IU
TF Supply air fan qv = 210 dm3/s (100Pa) Standard X IU
TZ1 Overheat protector of the electric radiator Automatic reset (+60 ˚C) Included in LP1 / LP2 IU
TZ2 Overheat protector of the electric radiator Manual reset (+95 ˚C) Included in LP1 / LP2 IU
FGU Damper motor Damper motor in the outdoor air duct
(spring return) 24VAC IU
FGJ Damper motor Damper motor in the extract air duct
(spring return) 24VAC IU

VALLOX 252 M
CONTROL DIAGRAM VALLOX 252 M VKL - MANUAL CONTROL UNIT
2
8
Control Diagram VALLOX 252 M VKL MANUAL CONTROL UNIT
Distribution
Internal electrical and control connections
Post-heating unit (water circulation)
Preheater, electric
Sound attenuator
Manual control unit
VENTILATION ZONE
VALLOX 252 M

VALLOX 252 M
9
Heat Recovery Defrosting
The TS5 temperature thermostat directs the operation of the preheater
(LP1) on the basis of the measurement data supplied by the temperature
sensor, preventing the risk of freezing and the stopping of the supply air
fan (TF). If the capacity of the preheater (LP1) is not sufficient, or if there is
no preheater, the TS1 defrosting thermostat of the heat recovery cells
stops the TF supply air fan on the basis of the measuring data on the
temperature sensor, thereby preventing the heat recovery cell from free-
zing. As soon as the risk of frosting passes, the fan restarts automatically.
The threshold temperature for defrosting (-2...+6 ˚C) and the difference
area (2 ˚C) can be set on the thermostat.
Overheating Protection of the Heating Unit
Overheat protection thermostats TZ1 and TZ2 monitor the surface tempe-
rature in the LP1 heating unit. If surface temperature exceeds the
threshold, overheat protection is triggered and power supply to the hea-
ting unit is stopped. The TZ1 overheating protector is reset automatically,
and the TZ2 protector manually.
Damper Motors of the Outdoor and/or Extract Air Ducts
The spring return damper motors (24VAC) that may be installed outside
the ventilation unit, in the outdoor or extract air ducts, can be controlled
with control voltage (24 VAC) coming from the ventilation unit: when the
ventilation unit is stopped, also the control voltage fed from the unit is
stopped.
Control of Operation
The ventilation unit can be stopped by the fan speed switch on the manual
control unit.
Fan Speed Adjustment
The users can control the fan capacity of the ventilation unit in two steps
using the speed selection switch on the manual control unit (H) in the
ventilation zone.
Supply Air Temperature
A regulating valve (not included in the VALLOX 252 M delivery) directs
the operation of the LP2 post-heating unit on the basis of the measurement
data given by the thermostat sensor in the supply air duct. The aiming is to
keep supply air temperature at the temperature value set with the regula-
ting valve (10...25 ˚C)
Heat Recovery Bypass
Heat recovery can be bypassed using the Summer / Winter switch on the
manual control unit (H).
When the switch is in the Winter position, heat recovery is on. The
Summer position bypasses heat recovery and deactivates the preheater
(LP1), if preheating is used.
DESCRIPTION OF OPERATION VALLOX 252 M VKL MANUAL CONTROL UNIT
Parts List
Code Name Technical details Note! Equip- Delivery
(factory settings in parentheses) ment responsibility
FG Damper motor Automatic heat recovery bypass 24V, 2W, 8Nm Standard X IU
H Manual control unit Fan speed adjustment,
control of heat recovery bypass Standard X IU
LP1 Preheater Electric radiator 2.5kW Options IU
LP2 Post-heating unit Water radiator 5kW, 70/50 ˚C Options IU
LTO1 Heat recovery cells 2-step, = 70 % Standard X IU
LTO2
PF Discharge air fan qv = 230 dm3/s (100Pa) Standard X IU
SU Filter Supply air EU7, discharge air EU5 Standard X IU
SV Regulating valve Self-operating radiator thermostat Not included in the
ventilation unit delivery
TS1 Temperature thermostat Discharge air temperature
Heat recovery defrosting Adjustment range -2...6 ˚C (2) Standard X IU
TS5 Temperature thermostat Discharge air temperature
Preheating, electric Adjustment range -0...8 ˚C (2) Standard X IU
TF Supply air fan qv = 210 dm3/s (100Pa) Standard X IU
TZ1 Overheat protector of the electric radiator Automatic reset (+60 ˚C) Included in LP1 / LP2 IU
TZ2 Overheat protector of the electric radiator Manual reset (+95 ˚C) Included in LP1 / LP2 IU
FGU Damper motor Damper motor in the outdoor air duct
(spring return) 24VAC IU
FGJ Damper motor Damper motor in the extract air duct
(spring return) 24VAC IU

VALLOX 252 M
CONTROL DIAGRAM VALLOX 252 M REMOTE MONITORING CONTROL
2
10
Control Diagram VALLOX 252 M REMOTE MONITORING CONTROL
Distribution Panel
Internal electrical and control connections
Post-heating unit, electric
Preheater, electric
VENTILATION ZONE
2x16A if equipped with a preheater
Pressure unit
Pressure unit
Sound attenuator
Remote monitoring center of the property Alarm Operation mode Control Measurement Adjustment
VALLOX 252 M
