Vallox 51 MV User manual

MV
Manual
Model
Vallox 51 MV
Vallox 51K MV
Type
3750
3751
Document
D7597
Valid from
26.03.2019
Updated
22.07.2019
Ventilation units
MANUAL

2
MV
INTRODUCTION............................... . . 2
Safety ...................................................... . 3
Installation ............................................. . . . . 3
Guarantee .................................................. . 3
Intended use ................................................ . 3
Disposal of the ventilation unit ................................ . 3
Safety signs used in the instructions .......................... . 4
Installation options........................................... . 4
Ventilation unit control ....................................... . 4
Ventilation unit control options. .......................... . . . . 4
Changing the ventilation profile .......................... . . . . 5
Vallox 51 MV ........................................... . . . . 5
Vallox 51K MV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
System description .......................................... . 6
Connecting the ventilation unit to the cloud service ........ . . . . 7
Brightness of the light................................... . . . . 7
Guard function ......................................... . . . . 7
Main parts .................................................. . 8
Vallox 51 MV ........................................... . . . . 8
Main parts .................................................. . 9
Vallox 51K MV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
INSTALLATION.................................. 10
Mounting on the wall ......................................... 10
External electrical connections................................ 10
Removal of condensing water ................................. 10
Vallox 51 MV ........................................... . . . 10
Vallox 51K MV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installation of the Vallox Captura Cooker hood ................. 12
Measuring and adjusting the air flows of the ventilation unit ...... 13
Measuring and adjusting the air flows of the cooker hood ........ 13
Standard ventilation .................................... . . . 13
Adjustment:............................................ . . . 13
Vallox 51 MV, 51K MV ........................................ 15
Dimensions and duct outlets.................................. 15
MAINTENANCE ................................ 16
Vallox 51 MV, 51K MV ........................................ 16
Before beginning maintenance work........................... 16
Changing the filters .......................................... 16
Cleaning the heat recovery cell ............................... .17
Condensing water ........................................... .17
Cleaning the fans ............................................ 18
Removing and cleaning the fans ......................... . . . 18
Vallox 51K MV ............................................... 19
Cleaning the grease filter of the cooker hood ................... 19
Removing and mounting the grease filter.................. . . . 19
Light .................................................. . . . 19
NOTE
You can register your
Vallox MV ventilation
unit with the MyVallox
Cloud cloud service
and sign in into your
MyVallox Cloud account
at www.myvallox.com.
CONTENTS
TECHNICAL SPECIFICATIONS ...20
Air flows and sound values.................................... 21
Internal electrical connection ................................ 22
Vallox 51 MV / Vallox 51K MV ............................. . . .22
External electrical connection................................ 23
Vallox Captura Cooker hood ............................. . . .23
External electrical connection................................ 24
Vallox 51 MV ........................................... . . .24
External electrical connection................................ 25
Vallox 51K MV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
External electrical connection for controlling the
MLV Multi duct radiator...................................... 26
MVL Multi duct radiator operation chart ....................... 27
Operation and sample connection ....................... . . .27
Exploded view and parts list ................................. 28
Vallox 51 MV ........................................... . . .28
Vallox 51K MV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Conformity certificates ...................................... 30
INTRODUCTION

3© Vallox Oy - All rights reserved
MV
SAFETY
Safe and appropriate handling requires knowledge of the basic safety
regulations, and of the intended use of the ventilation system. Read
this manual before operating the ventilation unit. Retain the manual for
later reference. If you lose the manual, it can be downloaded from our
website.
This user manual contains all the information necessary for safe
operation of the system. All persons who operate and maintain
the ventilation system must follow the instructions provided in this
manual. Furthermore, all local accident prevention regulations must be
observed.
Installation
Installation and setup should be carried out only by qualified experts.
Electrical installations and connections must be carried out only by an
electrician and in compliance with local regulations.
GUARANTEE
The guarantee and liability exclude damage resulting from:
• Inappropriate use of the ventilation system or the control unit
• Incorrect or inappropriate installation, setup or use
• Neglect of instructions concerning transportation, installation, use,
or maintenance
• Structural or electronic modifications or changes made to the
software
INTENDED USE
All Vallox ventilation units have been designed to provide appropriate
and continuous ventilation so as to present no threat to health and to
maintain structures in good condition.
DISPOSAL OF THE VENTILATION UNIT
Do not dispose of electronic devices with household waste. Follow
local laws and regulations on safe and ecological disposal of the
product.
NOTE
For further information,
go to www.vallox.com
INTRODUCTION
WARNING
The unit is not intended
for use by children
under 8 or by persons
with reduced sensory,
physical or mental
capabilities, or whose
lack of knowledge
and experience do not
ensure safe operation
of the unit.
Such persons can
use the unit under
supervision, or
by following the
instructions of someone
who is responsible for
their safety.
Children must be
supervised and not be
allowed to play with the
device.

4
MV
SAFETY SIGNS USED IN THE INSTRUCTIONS
INSTALLATION OPTIONS
• Vallox 51 MV and 51K MV can only be mounted on the wall.
NOTE
The standard
equipment and
available accessories
vary from country to
country.
DANGER
Indicates a hazard that
will result in death or
serious injury if not
avoided.
WARNING
Indicates a hazard that
can result in death or
serious injury if not
avoided.
IMPORTANT
Indicates a hazard that
can result in damage to
property or loss of data
if not avoided.
CAUTION
Indicates a hazard that
can result in minor or
moderate injury if not
avoided.
NOTE
Indicates essential
information about the
product.
TIP
Provides additional
information about the
use of the product and
its benefits.
INTRODUCTION
There are two unit models, left- (L) and right-handed (R). In the
right-handed version, outdoor air blows into the unit from the
right. In the left-handed version, outdoor air blows into the unit
from the left side. The location of the filters, bypass damper, and
heating radiator is also mirrored in the left-handed model.
VENTILATION UNIT CONTROL
Ventilation unit control options.
Operation of the Vallox ventilation unit can be controlled by the
following means:
• Through the My Vallox Control control panel installed in the
building.
• Through the MyVallox Home local area network connection
and the MyVallox Home/Cloud user interface.
• Through the MyVallox Cloud cloud service and the MyVallox
Home/Cloud user interface.
• Through a remote monitoring service or building automation
that uses voltage signals or Modbus messages.
In addition to the integrated humidity sensor, ventilation can
also be adjusted automatically by using the optional carbon
dioxide, humidity, or VOC (air quality) sensor. When these are
used, ventilation remains optimal even when the dwelling is
unoccupied. Each user can use the week clock to adjust the
ventilation to fit their individual lifestyle.

5© Vallox Oy - All rights reserved
MV
Vallox 51K MV
The Vallox 51K MV ventilation unit is controlled by using the
Vallox Captura cooker hood that is connected to the unit. The
cooker hood is designed to be used above the cooker top, as
a general extraction valve in the kitchen, and as a ventilation
system control panel.
The front panel of the cooker hood has four buttons.
Position of the damper
The damper is opened by pressing the damper button
(signal light turns on). The damper is closed (signal light
turns o) by pressing the damper button or automatically
after one hour (without a timer or 45-120 min when
programmed).
In normal circumstances, the damper must be closed (the signal
light is o), which boosts the extract air flow from other premises.
The damper must be open (the signal light is turned on) when
the user wants to increase the extract air flow from the cooker
hood e.g.
• when the cooker top or the oven is used for cooking
• the load in the kitchen in exceptional due to the use of
strong detergents, presence of a large number of people, or
similar.
INTRODUCTION
IMPORTANT
Apartment-specific
ventilation units allows
residents to adjust the
ventilation eciency.
Ventilation is controlled
based on the need e.g.
through the cooker
hood, ventilation
control panel, or a
separate control centre.
In order to ensure that
the indoor air presents
no harm to health and
remains optimal also
for the structures of the
building, ventilation
must be kept on
without disruptions.
It is recommended
that ventilation be
left turned on during
long holidays also.
This keeps the
indoor air fresh and
prevents humidity
from condensing in
the ventilation ducts
and structures. It also
reduces the risk of
moisture damage.
IMPORTANT
Prolonged overpressure
can result in damage
to the structures of the
building.
At home
Use this ventilation profile when the apartment is
occupied.
Away
Use this ventilation profile when the apartment is
unoccupied, e.g. during a trip or other long absence.
Fireplace profile
Use this ventilation profile e.g. when making a fire in
the fireplace. The profile is primarily used to create
momentary overpressure in the dwelling.
Boost
Use this profile to enhance ventilation, e.g. when
there are more people than usual in the apartment.
Changing the ventilation profile
Vallox 51 MV
The Vallox 51 MV ventilation unit is controlled by using the
MyVallox Control control panel. Press the left button of the
control panel (see the Figure) repeatedly until the desired status
is shown as the middle option on the display.
MyVallox Control control
panel
At home

6
MV
SYSTEM DESCRIPTION
1. Internet
2. WLAN
3. Router
4. WLAN/LAN
5. Additional switch
6. Sensors
INTRODUCTION
Cooker hood light
Turn the light on or o by pressing the light switch. The
brightness of the light can be adjusted. See page 12.
Ventilation profiles
Select the profile by pressing the fan speed button
repeatedly until the signal light indicates the desired
ventilation profile:
Away profile
Use this ventilation profile when the apartment is
unoccupied, e.g. during a trip or other long absence.
At home profile
Use this ventilation profile when the apartment is
occupied.
Boost profile
Use this profile to enhance ventilation, e.g. when there
are more people than usual in the apartment.
Selection button
The selection button is roughly 2 cm to the left from the
light switch.
CAUTION
• Neglecting the
cleaning of the grease
filter can cause a fire
hazard.
• The outer surfaces of
the hood can become
hot when the cooker or
the oven is turned on.
• Flaming is forbidden
underneath the cooker
hood.
• Always follow the
instructions provided
on adjusting the
eciency of ventilation.
• A sucient supply air
flow must be ensured in
the room if the cooker
hood is to be used
simultaneously with
non-electronic devices.
MyVallox Cloud
MyVallox Home
Vallox MV
MyVallox Control
Modbus KNX
KNX bus
module
1
23
4
5
6

7© Vallox Oy - All rights reserved
MV
NOTE
For the MyVallox Cloud/
Home instructions,
please go to www.
techmanuals.info/
ValloxMV/ENG/
onlinehelp/webhelp
Connecting the ventilation unit to the cloud
service
The ventilation unit can be connected to the MyVallox Cloud
cloud service. The cloud service allows for controlling ventilation
remotely also, using e.g. a smartphone or tablet. Also the unit
software is updated automatically through the cloud service.
To connect to the cloud service, the ventilation unit must be
connected to the Internet via LAN and registered with the cloud
service. At the same time you create a MyVallox Cloud account
for yourself. Read more about the service at www.myvallox.com.
Brightness of the light
To adjust the brightness of the light:
1. Turn on the light, close the damper, and set the ventilation to
the Away profile.
2. Press the selection button for roughly 3 seconds until the
setting mode signal light starts to flash.
3. Adjust the brightness of the light by pressing the light button
until the brightness is adequate.
4. To save the setting, press the selection button for roughly 3
seconds until the setting mode signal light stops to flash.
To read about the other functions of the selection button, go to our
website, www.vallox.com.
Guard function
The cooker hood has a guard function that is activated when the
temperature of the cooker hood exceeds +60 °C or after a sudden
increase in temperature (> 8 °C/min). In such a case, all signal lights
of the cooker hood and the LED light will flash, the fans of the
ventilation unit will stop, and the damper of the cooker hood will
close. If this kind of alarm is noticed before fire damage, it can be
acknowledged by pressing any of the cooker hood buttons.
WARNING
• The outer surfaces
of the hood can
become hot when
the cooker or the
oven is turned on.
• Flaming is forbidden
underneath the
cooker hood.
CAUTION
• Always follow the
instructions provided
on adjusting
the eciency of
ventilation.
• Enable a sucient
supply air flow
into the room if
the cooker hood
and non-electric
devices are used
simultaneously.
INTRODUCTION

8
Extract air fan
1
Supply air fan
2
Fine filter for supply air
3
Heat recovery cell
4
Automatic bypass damper
5
Coarse filter for supply air
6
Coarse filter for extract air
7
R model in the figure.
In the L model, the
parts are mirrored.
MAIN PARTS
Vallox 51 MV
Post-heating resistor
8
Control panel
9
Carbon dioxide sensor (optional) 10
Humidity sensor (optional)
VOC sensor (Optional)
Internal humidity sensor
Ceiling bushing for electric wires
INTRODUCTION
11
12
10 11 12
13
5
4
3
2
1
7
6
8
9
14
13
14
A
N
N
U
A
L
E
F
F
I
C
I
E
N
C
Y
R
A
T
I
N
G
O
F
E
X
T
R
A
C
T
A
I
R
H
E
A
T
R
E
C
O
V
E
R
Y
A

9© Vallox Oy - All rights reserved
MV
Extract air fan
1
Supply air fan
2
Fine filter for supply air
3
Heat recovery cell
4
Automatic bypass damper
5
Coarse filter for supply air
6
Coarse filter for extract air
7
Post-heating resistor
8
Control panel (Optional)
9
R model in the figure.
In the L model, the
parts are mirrored.
MAIN PARTS
Vallox 51K MV
Carbon dioxide sensor (optional)
10
Humidity sensor (optional)
11
VOC sensor (Optional) 12
Internal humidity sensor
13
Cooker hood
14
Damper button
15
Fan speed adjustment
Light switch
Ceiling bushing for electric wires 18
INTRODUCTION
2
1
910 11
4
3
7
6
5
14
15 16
12
13
8
18
17
16
17
A
N
N
U
A
L
E
F
F
I
C
I
E
N
C
Y
R
A
T
I
N
G
O
F
E
X
T
R
A
C
T
A
I
R
H
E
A
T
R
E
C
O
V
E
R
Y
A

10
MV
INSTALLATION
MOUNTING ON THE WALL
NOTE
Avoid mounting the unit on a hollow, echoing partition wall or
on a bedroom wall, or prevent the conduction of sound.
Note that during mounting the unit rises 10 mm higher than
the final height.
Mount the ventilation unit on the wall with a mounting plate, as
shown in the adjacent figure. Make sure that the unit is horizontally
level after mounting.
Vallox 51K MV must be mounted so that the clearance between
the bottom of the cooker hood and the cooker top is at least 426
mm in case of an electric stove and 650 mm in case a gas stove.
The clearance is 134 mm (i.e. the height of the cooker hood) more
between the bottom of the ventilation unit and the cooker top.
EXTERNAL ELECTRICAL CONNECTIONS
External electrical connections are led to the ventilation unit
through the ceiling bushing for electric wires. The length of the
wires must enable pulling the fan chamber assembly out of the unit
without having to disconnect any of the connections.
NOTE
A space of at least 330
mm must be reserved
in front of the unit for
maintenance purposes.
REMOVAL OF CONDENSING WATER
Vallox 51 MV
The Silent Klick water seal is installed in the bottom pool of Vallox 51
MV. The condensing water tube is led from the water seal e.g. to the
water seal of the sink or to the floor drain. Alternatively, an elbow can
be installed in the bottom pool, in which case the Silent Klick water
seal is installed in the condensing water tube to enable maintenance
measures.
NOTE
The Vallox Silent Klick
water seal package is
delivered with Vallox
51 MV and 51K MV.
Installation instructions
for the water seal are
enclosed with the
packaging, and can also
be found online at www.
vallox.com. When the
alternative water seal
installation method is
used, the ring seal and
the locking part must
be moved to the pipe
connection part that is
mounted on the wall.
175
89
351
668
598
1735
89
28
28
38
38

11 © Vallox Oy - All rights reserved
MV
INSTALLATION
R L
90 90
1
2
1
Observe in the figure:
1. Elbow.
2. Exit hole for the condensing water outlet.
Vallox 51K MV
In Vallox 51K MV, an elbow is mounted on the bottom pool
between the unit and the cooker hood. Condensing water tube
is led from the elbow e.g. into the water seal of the sink or the
floor drain. The water seal must not be installed inside the cooker
hood. Instead, it must be installed in the condensing water tube
so as to enable maintenance measures. There are approx. 2
mm wide holes at the rear of the bottom of the Vallox 51K MV
ventilation unit marking the position where the condensing water
tube must be installed.
1. Install the elbow at the bottom of the ventilation unit
without the water seal (Figure 1). Install the water seal in
the condensing water tube before the drain or odour trap
(Figure 2). The Silent Klick water seal helps prevent noise
disturbance caused by the removal of condensing water.
2. The condensing water tube must be installed either directly
backwards from the cooker hood through the wall, if there
is a sewer connection behind the wall (see figure 2 for the
dimensions of the tube location), or to the odour trap of the
sink (Figure 2).
3. The condensing water pipe must be placed at an angle so
that it always points downwards.
2

12
MV
CAUTION
The minimum clearance
between the bottom
edge of the cooker
hood and an electric
stove is 426mm.
INSTALLATION
12
3
3 4
INSTALLATION OF THE VALLOX CAPTURA
COOKER HOOD
The Vallox Captura cooker hood is installed on the bottom of Vallox 51K MV.
1. Remove the plug from the feedthrough seal of the condensing
water tube of the cooker hood (Figure 1).
2. Lift the cooker hood and fit the hooks at the rear of the cooker
hood into the holes at the bottom of the ventilation unit. Push in
place (Figure 2).
3. Ensure that the feedthrough seal of the condensing water tube sits
firmly around the tube.
4. Lift the front of the cooker hood to fit the mountings into the
penetrations in the bottom of the ventilation unit (Figure 3).
5. Fasten the M5 hexagon screws (2) through the mountings (Figure 4).
Lead the power cord and the control cable up along the cable channel
(Figure 3). Wind approx. half a metre of the cables behind the cooker
hood so that it can be removed for maintenance purposes where
required. Move the metal cover backwards so that it covers the opening
between the cooker hood and the wall (Figure 5).
3
5

13 © Vallox Oy - All rights reserved
MV
MEASURING AND ADJUSTING THE AIR
FLOWS OF THE VENTILATION UNIT
INSTALLATION
92
1
Ø6
16
The accessories delivered with the unit include four (4) air flow
measuring tubes. These can be inserted in the ducts to allow for
easier ventilation adjustment.
MEASURING AND ADJUSTING THE AIR
FLOWS OF THE COOKER HOOD
Standard ventilation
The volume flow rate of the air inside the cooker hood is
measured with the damper closed and, where required, adjusted
based on the static pressure loss and the performance scheme of
the cooker hood.
• The static pressure loss is measured from the hole in the
damper using the measuring tube found in the accessory bag
(see Figure).
• Determine the volume flow rate from the performance
scheme based on the measured pressure and the number of
open holes in the damper.
Adjustment:
• Cover the required number of holes in the damper with the
magnetic strip that is delivered with the cooker hood.
dp

14
MV
Air flow measurement points
Air flow measuring tubes are placed in
the ventilation ducts in accordance with
the instructions. Standard air flow from
the cooker hood is measured past the
damper. The fan curves indicate the total
pressure accounted for by duct losses.
A Supply air
B Extract air
C Cooker hood extract air
D Supply air fan
E Extract air fan
R model in the figures. In the L model,
the order of the ducts is mirrored.
C
BABA
DEDE
Vallox 51K MV
Vallox 51 MV
INSTALLATION
Damper in the closed position
Adjustment position Holes of the damper open
2 2
3 3
4 4
5 5
6 6
7 7
8 8
Standard ventilation (settings 2-8)
2 3 4 5 6 7 8 9 10
20
30
40
50
60
70
80
90
20
0
30
0
4
00
10
100
45
40
35
30
25
L
pA
, dB(A)
75 6432 8
Static pressure Pa
Air flow dm³/s
STANDARD VENTILATION OF THE
COOKER HOOD

15 © Vallox Oy - All rights reserved
MV
Dimensions
Duct outlets
Inner diameter of the
female collar: 125mm
1. Outdoor air to the unit
2. Exhaust air flowing outdoors from the
unit
3. Supply air from the unit to the apartment
4. Extract air from the apartment to the unit
L model
R model
INSTALLATION
241
105
81
598
241
155 141141
145
1
23
4
241
105
81
598
241
155 141141
145
4
32
1
DIMENSIONS AND DUCT OUTLETS
89 173
17
89
598
668
52
349 10
500mm
349
368
368
597
598
802
668
17
Vallox 51 MV
Vallox 51K MV
A double
socket in
this area

16
MV
BEFORE BEGINNING
MAINTENANCE WORK
WARNING
Always disconnect the power plug before starting
maintenance on the ventilation unit. The unit has no
safety switch that would switch the power o when
the door of the unit is opened.
CHANGING THE FILTERS
The Vallox ventilation unit has three filters:
• Coarse filter for supply air filters insects, heavy pollen
and other relatively large foreign objects out of the
outdoor air.
• Fine filter for supply air filters microscopic pollen and
dust particles out of the supply air.
• Coarse filter for extract air filters the extract air and
keeps the heat recovery cell clean.
The filter replacement interval depends on the ambient
particle concentration. It is recommended that the filters
be replaced every spring and autumn, or at the very least
once a year.
To replace the filters:
1. Disconnect the ventilation unit from the mains
electricity supply.
2. Open the door of the unit.
CAUTION
The door is heavy.
3. Remove the old filters (A, B, C) and discard them.
4. Install the new filters (A, B, C).
5. Close the door of the unit.
6. Plug the ventilation unit back into the mains.
7. The filters have now been successfully replaced.
TIP
Using original Vallox
filters ensures that the
ventilation unit remains
in top condition, giving
the best results. To
select and order
filter packages,
please go to: https://
valloxsuodattimet.fi
MAINTENANCE
MAINTENANCE
NOTE
The service space in
front of the ventilation
unit must be at least
330 mm.
A
B
C

17 © Vallox Oy - All rights reserved
MV
CLEANING THE HEAT RECOVERY
CELL
Check that the heat recovery cell is clean roughly once a year,
or whenever the filters are being replaced. Clean by washing
as required.
IMPORTANT
If the unit has an enthalpy cell, it must not be washed.
Only aluminium or plastic cells can be washed.
Cleaning the heat recovery cell:
1. Disconnect the ventilation unit from the mains electricity
supply.
2. Open the door of the ventilation unit by undoing the
finger screws and by lifting the door o.
CAUTION
The door is heavy.
3. Pull out the black upper support of the cell (E) located
above the cell.
4. Lift and pull the cell (D) out of the unit.
IMPORTANT
Handle the cell carefully! Do not lift the cell by the
layers. The cell layers are very thin and easily damaged.
5. If the cell is dirty, clean it by immersing it in warm water,
to which a small amount of a mild detergent has been
added.
6. Rinse the cell clean with a water spray. Do not use a high-
pressure cleaner.
7. When all the water has drained from between the layers,
reassemble the ventilation unit in the reverse order.
8. Close the door.
9. Plug the ventilation unit back into the mains. The heat
recovery cell has now been cleaned.
MAINTENANCE
CONDENSING WATER
In the heating season, the extract air humidity condenses to
water. In new buildings, condensation runo can form rapidly.
Condensed water must be able to freely leave the unit.
At some time before the heating season begins (e.g. during
autumn maintenance), check that the water seal or the
condensing water outlet in the bottom pool are not clogged. To
check this, pour some water into the pool. Clean as required.
NOTE
Some condensing water
may have accumulated
in the bottom pool
of the unit; this is
normal and requires no
corrective action.
WARNING
Water must at all times
be kept out of the
electrical system.
D
E
D

18
MV
CLEANING THE FANS
Check the cleanliness of the fans when servicing the filters and
the heat recovery cell. Clean the fans as required.
Removing and cleaning the fans
To clean the fans:
1. Disconnect the ventilation unit from the mains electricity
supply.
2. Undo the door screws to open the door of the Vallox
ventilation unit.
3. Lift the door o.
CAUTION
The door is heavy.
4. If the length of the cables that are led out of the unit through
the ceiling bushing (G) and connected to the connection
card (F) in the electric box prevents moving the fan chamber
suciently far from the ventilation unit, disconnect the
cables. Pull these cables out of the unit through the ceiling
bushing.
5. Detach outdoor and extract air temperature sensors from the
ceiling mounts. Remove the round feedthrough rubbers (H)
from the slots on the intermediate walls of the unit by pulling.
6. Undo the earthing screw (K) on the upper left corner of the
electric box.
7. Release the damper motor (J) by placing an orange magnet
(I) on the magnet icon on the damper motor. Observe the
location of the magnet so that you will be able to return it to
its original location after maintenance. Remove the bar from
the joint of the damper. Turn the crank of the damper motor
so that the bar comes o from the bypass damper and turn
the damper into the cell bypass position.
8. Pull out the upper support of the cell (E). Lift and pull the cell
(D) out of the unit.
9. Pull the fan chamber (K) out of the unit (contains the fans,
electric box, and the bypass duct incl. the damper motor).
10. The fans are mounted on the fan chamber by means of three
screws (L). Do not undo the earthing screw at the bottom
edge on the rear wall side.
11. Disconnect the quick connectors of the fan cable.
12. Clean the fans. The fan can be cleaned with compressed air
(wear protective goggles) or by brushing it gently.
13. To reassemble the ventilation unit, follow the above steps in
reverse order.
NOTE! Remember to reconnect the bar of the damper
motor into the joint of the damper and to lock the
connection with the orange magnet. Ensure that the
sensors and their feedthrough rubbers are in correct
locations. Also ensure that all the connections have been
correctly implemented and the earthing screw is in place in
the left corner.
MAINTENANCE
IMPORTANT
The fans are
extremely sensitive
to external shocks. It
is recommended that
the fans be cleaned
in place, i.e. without
attempting to remove
them. Handle the fan
blades carefully.
It is recommended that
the fans be cleaned by
a professional.
D
F
I
E
J
H
G
K
K
L
K

19 © Vallox Oy - All rights reserved
MV
MAINTENANCE
CLEANING THE GREASE FILTER OF THE
COOKER HOOD
Keep the cooker hood clean. Wipe outer surfaces regularly with
water containing a small amount of a mild detergent. Clean o
any grease stains immediately. Do not use abrasive or corrosive
detergents or tools.
Keep the grease filter clean to ensure an adequate extract air
flow. The grease filter must be washed with warm water and
detergent or in a dishwasher at least 1-2 times a month.
Removing and mounting the grease filter
1. Pull the locking device of the grease filter towards the front
edge of the cooker hood while pulling the grease filter
downwards until it comes o.
2. Clean the grease filter either by washing it with hot water
and hand-washing detergent or in a dishwasher.
3. Mount the grease filter back in place. Push the front edge of
the filter onto the shelf of the cooker hood and lift the rear
edge in place with the locking device pressed down.
NOTE! Ensure that the locking device points downwards.
Removing the filter
Mounting the filter
WARNING
Neglecting the cleaning
of the grease filter can
cause a fire hazard.
Light
The cooker hood has a long-lasting LED lighting module. If the
light is not working, contact a servicing company.
1
2

20
MV
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS VALLOX 51 MV
Product title
Vallox 51 MV R
Vallox 51 MV L
Product number
4105064
4105063
HVAC code
7912132
7912134
Air volumes
Supply air
Extract air
47 dm³/s, 100 Pa
51 dm³/s, 100 Pa
Fans
Supply air
Extract air
0.035 kW 0.35 A EC
0.035 kW 0.35 A EC
Post-heating resistor Electric, 900W Electrical connection 230 V, 50 Hz, 4.24 A 2 x power plug
Preheating resistor –Enclosure protection class IP34
Additional heating resistor –Heat recovery bypass Automatic
Filters
Supply air
Extract air
ISO Coarse > 75 % + ISO ePM₁
ISO Coarse > 75%
Specific energy consumption (SEC)
in a cold climate
in a temperate climate
A+
A
Operating eciencies
Annual eciency
Supply air eciency
Specific Fan Power (SFP)
70% A
84%
0.94 kW / (25 dm³/s)
Dimensions (w x h x d) 598x668x349 mm Weight 60 kg
TECHNICAL SPECIFICATIONS VALLOX 51K MV
Product title
Vallox 51K MV R
Vallox 51K MV L
Vallox Captura white hood
Vallox Captura stainless steel hood
Product number
4106455
4106217
2145203
2146700
HVAC code
7912135
7912136
7912137
7912138
Air volumes
Supply air
Extract air
47 dm³/s, 100 Pa
51 dm³/s, 100 Pa
Fans
Supply air
Extract air
0.035 kW 0.35 A EC
0.035 kW 0.35 A EC
Post-heating resistor Electric, 900W Electrical connection 230 V, 50 Hz, 4.24 A 2 x power plug
Preheating resistor –Enclosure protection class IP34
Additional heating resistor –Heat recovery bypass Automatic
Filters
Supply air
Extract air
ISO Coarse > 75 % + ISO ePM₁
ISO Coarse > 75%
Specific energy consumption (SEC)
in a cold climate
in a temperate climate
A+
A
Operating eciencies
Annual eciency
Supply air eciency
Specific Fan Power (SFP)
70% A
84%
0.94 kW / (25 dm³/s)
Dimensions (w x h x d) 598 x 802 x 349 mm Weight 66.2 kg
