INSTALLATION INSTRUCTIONS:
HONDA REBEL SLIP-ON
PART# 48421
Page 1 of 6 H490IN RevC
Congratulations, you have purchased the nest exhaust system available for your motorcycle. Your Vance & Hines exhaust
is designed and crafted for performance, quality, and style. Please follow the instructions below, check exhaust system for
missing or damaged parts and if you need any assistance please contact our technical support line [phone].
FOR CLOSED COURSE COMPETITION USE ONLY. NOT INTENDED FOR STREET USE.
1
2
SCALE 1:4
SHEET 1 OF 1
WT. LBS.
REV
PART #
SIZE
B
01
TITLE
UNLESS OTHERWISE SPECIFIED
INTERPRET DIMENSIONS
AND TOLERANCES
PER ANSI Y14.5M
THIRD ANGLE PROJECTION
MATERIAL
SEE INDIV. DWGS
SEE INDIV. DWGS
APPROVED
9/13/2018
DATE NAME
DRAWN
CHECKED
T. BARRY
DIMENSIONS ARE INCHES
TOLERANCES ARE:
FRACTIONAL: 1/16"
ANGULAR: 2
X.X 0.030"
X.XX 0.015"
X.XXX 0.010"
FINISH
HONDA REBEL TAPERED SLIP-ON
SANTA FE SPRINGS, CA
BROWNSBURG, IN
www.vanceandhines.com
PROJECT
48421
17-'18 HONDA REBEL S/O BLACK
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF VANCE & HINES AND SHALL NOT BE REPRODUCED, USED, OR
DISCLOSED TO OTHERS FOR MANUFACTURE OR FOR ANY OTHER PURPOSE, UNLESS SPECIFICALLY AUTHORIZED, IN WRITING, BY VANCE & HINES.
= CRITICAL FEATURE
6.03
CAD
T. BARRY 9/13/2018
A A
B B
C C
D D
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY.
1H635RP-S HON REBEL MUFFLER W/BADGE 1
2 1112-P MOUNT BRACKET 1
3A328HW-B BLK 1.81-1.99IN BARREL BAND CL 1
4A852HW M8 X 1.25MM SER FLNG NUT BLK 1
5 A746ST-P FRONT SPACER BLACK 1
6 A913HW M8 X 1.25 - 45MM SHCS ZINC 1
7 A544HW SCREW M6X1X10MM BHCS 2
HARDWARE
3 4 5 6 7
NOTE: UNLESS OTHERWISE SPECIFIED
1.
REVISIONS
REV.
ECO DESCRIPTION REVISED BY DATE APPROVED
01 - -
A
B
C
A
B
C
D
1
23
4
1234
D
= CRITICAL FEATURE
CAD
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF VANCE & HINES AND SHALL NOT BE REPRODUCED, USED, OR
DISCLOSED TO OTHERS FOR MANUFACTURE OR FOR ANY OTHER PURPOSE, UNLESS SPECIFICALLY AUTHORIZED, IN WRITING, BY VANCE & HINES.
PROJECT
SANTA FE SPRINGS, CA
BROWNSBURG, IN
www.vanceandhines.com
FINISH
DIMENSIONS ARE INCHES
TOLERANCES ARE:
FRACTIONAL: 1/16"
ANGULAR: 2
X.X 0.030"
X.XX 0.015"
X.XXX 0.010"
CHECKED
DRAWN
NAME DATE
APPROVED
MATERIAL
THIRD ANGLE PROJECTION
INTERPRET DIMENSIONS
AND TOLERANCES
PER ANSI Y14.5M
UNLESS OTHERWISE SPECIFIED
TITLE
01
A
SIZE
PART #
REV
WT. LBS.
SHEET 1 OF 1
SCALE 1:2

STOCK SYSTEM REMOVAL
1. Loosen the clamp at the front of the mufer.
2. Remove the bolt that attaches the mufer to the stock mounting bracket.
3. Remove the mufer assembly from the vehicle and remove the stock gasket from the
head pipe.
TOOLS REQUIRED
Page 2 of 6 H490IN RevC
12mm combination wrench
4mm Allen wrench
6mm Allen wrench
12mm socket
10mm socket
3/8” Drive Ratchet

Page 3 of 6 H490IN Rev C
VANCE & HINES SYSTEM INSTALLATION
1. Install supplied M8x1.25x45mm SHCS and spacer in stock mufer mounting bracket.
(Fig. 1)
2. Loosely install 1112-P bracket to mufer using two M6x1x10mm BHCS.
3. Slide provided barrel clamp over new V&H mufer, slip mufer onto stock mid-pipe.
(Leave clamp loose). Make sure that barrel clamp bolt is accessible from bottom.
4. Line up mufer bracket to the inside of the mufer mounitng bracket and install
supplied M8x1.25 ange nut nger tight. (Fig. 1)
5. Tighten M8 mufer bracket mounting bolt to nut.
6. Tighten M6 mufer bolts.
7. Align mufer and rotate barrel clamp to be as out of sight as possible, align with
leading edge of mufer and tighten.
8. Be sure all hardware is tight. Before starting the motorcycle, completely clean tail pipes
and mufers with warm soapy water and a clean soft cloth that will not leave residue.
Dry with a clean towel. NOTE: Any residue, oil, or ngerprints will stain the nish when
the exhaust system heats up. Do NOT use anything abrasive to clean black mufers as it
may remove the nish.
EXHAUST CARE (BLACK)
1. When installing a new set of black pipes, make sure your hands are clean and free
from oil. After installation, thoroughly clean pipes with warm soapy water and a soft
cloth. Dry with a clean towel remove any residue before starting the motorcycle. Do
NOT use anything abrasive to clean pipes.
2. Avoid long periods of idling as this can cause discoloration.
3. Intake leaks can cause the engine to run lean and overheat, this could lead to
discoloration.
4. Make sure there are no exhaust leaks at the junction of the exhaust pipes and the
cylinder head. We recommend replacing gaskets if they are worn.

Page 4 of 5 H490IN RevC
FIGURE 1
FIGURE 2
A852HW
STOCK BRACKET MOUNT
1112-P
A746ST-P
A913HW

H490IN RevC
Emissions Notice:
In California, in order to meet Air Resources Board emissions requirements, certain aftermarket part applications
have been identied as replacements, and others have received ARB Executive Orders. All other emissions
related aftermarket parts are for competition use only. A list of replacement parts and EO parts, and
corresponding tment is provided at vanceandhines.com/California.
Warranty:
All Vance & Hines products are warranted against defects in material and workmanship for a period of 90 days.
This warranty does not cover discoloration or rust. This warranty shall be limited to the repair or replacement of
the product, which may be proven defective under normal use. Vance & Hines will not warranty any system
that has been abused, misused, improperly installed or modied.
Dealers or distributors are not authorized to make dispositions binding upon Vance & Hines. Vance & Hines will
not be responsible for any labor charges incurred in removing or replacing any system under warranty. A return
authorization number and a copy of the original purchase invoice must accompany all returns. Parts returned
without a return authorization may be refused.
