Vanderbilt WPIR-EXT Manual

WPIR-EXT
Two Way Wireless Outdoor Double PIR
Detector with Anti-masking
INSTALLATION INSTRUCTIONS
& USER MANUAL
Edition Date: 01.11.2021 Doc ID: I-200478

WPIR-EXT Installation Instructions/User Manual
Edition Date: 01.11.2021 Vanderbilt Industries Doc ID: I-200478
Data and design subject to change without notice. / Supply subject to availability.
© 2021 Copyright by Vanderbilt
We reserve all rights in this document and in the subject thereof. By acceptance of the document the recipient acknowledges
these rights and undertakes not to publish the document nor the subject thereof in full or in part, nor to make them available
to any third party without our prior express written authorization, nor to use it for any purpose other than for which it was
delivered to him.
http://van.fyi?Link=WPIREXT

WPIR-EXT Installation Instructions/User Manual
Edition Date: 01.11.2021 Vanderbilt Industries Doc ID: I-200478
TABLE OF CONTENTS
Contents
1. Introduction................................................................................................................................................................3
2. Features ....................................................................................................................................................................3
3. Operation...................................................................................................................................................................4
4. Assembly Description.................................................................................................................................................5
5. Installation and Discovery & Enrollment Process ........................................................................................................7
Select Mounting Location...................................................................................................................................................7
6. Detector Installation....................................................................................................................................................8
7. Discovery & Enrollment Process.................................................................................................................................9
8. Settings & Adjustments ............................................................................................................................................11
Detection beam direction .................................................................................................................................................11
Detection range setting....................................................................................................................................................11
Dip Switch Functions .......................................................................................................................................................12
9. Test procedure.........................................................................................................................................................13
10. Specifications...........................................................................................................................................................14

WPIR-EXT Installation Instructions/User Manual
3
Edition Date: 26.07.2021 Doc ID: I-200478
1.Introduction
The WPIR-EXT is a unique two-way wireless outdoor double quad motion detector with active Anti-Mask feature.
The advanced Double PIR Elements provide two detection areas for superior stability.
The WPIR-EXT is designed for outdoor usage in severe and extreme climate conditions
The WPIR-EXT is designed to also accommodate pets.
High reliability is achieved by combining both Dual Quad Sensors with highly sophisticated software aswell as an
adaptive coverage area, reducing false alarms alerts to zero while maintaining high securitystandards for the
detection of human intruders into the protected area.
The detection sensitivity and range are controlled by optical rotary switch allowing 25 calibration levels, sothat the
effective pattern can be set for every installation environment and protection site.
The WPIR-EXT is designed to protect large areas and can easily be installed on walls toprovidea solidprotection of
the area while rejecting interference from birds and small animalsdue to “PETMASK” optics.
Double PIR
Elements
Pet Immunity
Anti-Masking
2 Way Wireless
Remotely
Configurable
2.Features
•GFSK 2 Way Wireless Protocol
•Frequency Band: 868.35MHz
•Powered by 4 Lithium batteries Type AA (Battery life: Up to 5 years)
•Tamper Open/Close transmission
•Supervision transmission
•Battery status transmission
•LED indications
•Maximum distance from control panel up to 500m in open space
•Remotely configurable
•Height installation calibrations free: from 0.8m to 1.5m
•Pet Immunity up to 35kg
•PIR sensitivity adjustment
•Temperature compensation
•Front and Back tamper protection
•Sound indication for walk test and intruder detection
•Unique waterproof and seal plastic design
•Detection Range: Up to 12m
•Protection from: direct sunlight, wind up to 30m/sec, snow and rain, small animals
•Anti-Masking feature enabled by Dip Switches or remotely

WPIR-EXT Installation Instructions/User Manual
4
Edition Date: 26.07.2021 Doc ID: I-200478
3.Operation
This WPIR-EXT detector transmits the following events data:
•SUPERVISION–A periodical transmission (configurable) indicating detector’s presence.
•ALARM –Alarm transmission triggered by the device indicating Motion detection.The Red LED will blink once.
•LOW BAT –Whenever the battery reaches the low level (2.5V), a Battery Low signal will be sent. When Battery
level drops below Cut Off level (2.3V) the device will stop functioning and the Red LED will blink for 10 seconds
and then turned Off.
•TAMPER –Whenever the cover is removed from Bracket or the device is tear off from the wall, a message will
be transmitted with “Tamper ON” signal. When cover will be returned a “Tamper OFF” signal will be transmitted.
•ANTI-MASKING–If an attempt ismade to mask the lens with a sticker orto put amasking object closeto the
lens, a trouble alert will result up to 180 seconds after masking. A mask signal is also reported on your SPC
system.

WPIR-EXT Installation Instructions/User Manual
5
Edition Date: 26.07.2021 Doc ID: I-200478
4.Assembly Description
The WPIR-EXT is a robust detector which includes indication LED prism that can be easily observed from long
distance.
Having a back metal bracket, the WPIR-EXT can be easily mounted to walls and poles using mounting screws
(supplied) or Jubilee clips/metal bands (supplied).
1
Front Cover
3
Detector Main Unit
2
LED Indicator
4
Back Metal Bracket

WPIR-EXT Installation Instructions/User Manual
6
Edition Date: 26.07.2021 Doc ID: I-200478
Front view
Back view with battery
2
LED Detector
9
Battery Cover
4
Upper PIR Element
10
Back Tamper Switch (Removal)
5
Anti-Mask Sensor
6
Lower PIR Element
7
Dip Switches
8
Front Tamper Switch (Opening)

WPIR-EXT Installation Instructions/User Manual
7
Edition Date: 26.07.2021 Doc ID: I-200478
5.Installation and Discovery & Enrollment Process
Select Mounting Location
The installation of the WPIR-EXT requires a flat and secure mounting surface for the detector to perform correctly.
The protected area must be free from obstacles like walls, fences, trees, ditches, and other microwave detectors, as
well as systems of anti-intrusion surveillance.
The back metal bracket enables WPIR-EXT installation on a level wall or pole.
Choose a location most likely to intercept an intruder according to the detection pattern on page 6.
Avoid the following installation locations:
•Facing direct sunlight
•Facing areas subject to rapid temperature changes
•Wall angle of more than 10º from perpendicular line
•Mounting at more than 10º Deviation from horizontal line
•Facing metal doors
•Do not install near direct source of heat or air gust
•Clear all physical obstacles from the detection area(for example
Plants, laundry, etc.)
•Clear all light reflecting surfaces from the detection area, as wellas
water puddles
•Avoid installation on the following types of ground:
Thick vegetation, Grass (un-mown), Water, Sand, and Metal.
NOTE:
•Recommended installation height is 1.2m.
•If there is a risk of the protected area may contain tall pets (over 60cm), install the detector at a height of
1.5m.
•The Double Quad high quality sensor detects motion crossing the beam; it is less sensitive detecting motion
towards the detector.
•The WPIR-EXT performs best when provided with a constant and stable environment.
•To ensure suitable operation of the WPIR-EXT type of ground should be one of the following: Asphalt
concrete, Cement, Soil, Clay, Gravel, or Grass (mown).

WPIR-EXT Installation Instructions/User Manual
8
Edition Date: 26.07.2021 Doc ID: I-200478
6.Detector Installation
Important! Before installing the WPIR-EXT, read “Select mounting location” section carefully.
1. The detector must be installed in such manner
that the intruder is most likely to cross the
detection area from side to side.
2. The detector must be installed at height of 0.8m
to 1.5m
3. Draw metal bracket holes on the wall, leaving
15cm from all sides, for easy installation and
maintenance.
4. Install the metal bracket on the wall or a pole
using either mounting screws or Jubilee
clips/metal bands.
5. Install the detector unit on the metal bracket.
6. Screw the detector unit to the back metal bracket.
7. Adjust the detection beam to reach the best
detection range (refer to Part 7 "Settings &
Adjustments).
8. Close the detector cover screwing the bottom
screw.
After detector closure, the detector starts calibration process.
Do not stand in detector's range during this period of 3 minutes.
After this period, the detector is ready for operation.

WPIR-EXT Installation Instructions/User Manual
9
Edition Date: 26.07.2021 Doc ID: I-200478
7.Discovery & Enrollment Process
1. Open the detector unscrewing the bottom screw.
2. Unscrew the detector unit from the back metal bracket and
remove the detector from the bracket by tilting it.
3. Remove the battery cover
4. Discover the WPIR-EXT detector from the SPC control panel or
from the keypad.
To discover the WPIR detector from the SPC control panel:
I. In the SPC browser, select Configuration>Wireless
and click Enroll New Sensor.
II. Open the detector and insert the batteries taking
care to observe correct polarity (+/-).
Inserting the batteries starts the discovery process
from the device.
III. Enroll the device by configuring the Description,
Zone, Zone Type, and other settings in the SPC
system.
OR To discover and enroll the WPIR detector from the keypad:
I. On the keypad, select
WIRELESS>SENSORS>ADD>ENROL.
The keypad displays the ADD screen with a
flashing ENROL DEVICE message.
II. Open the detector and insert the batteries taking
care to observe correct polarity (+/-).
Inserting the batteries starts the discovery process
from the device.
The keypad displays the FOUND SENSOR
message.
III. Click OK.
IV. You can now enroll the device by configuring the
AREA, ZONE TYPE and ZONE settings.
V. Click OK.
The keypad displays the UPDATED message. The WPIR-EXT is
now enrolled on your SPC system.

WPIR-EXT Installation Instructions/User Manual
10
Edition Date: 26.07.2021 Doc ID: I-200478
5. Close the battery cover
*DISCOVERY FAILED
Remove the batteries, wait for around 10 seconds, and repeat the
process.

WPIR-EXT Installation Instructions/User Manual
11
Edition Date: 26.07.2021 Doc ID: I-200478
8.Settings & Adjustments
Detection beam direction
The WPIR-EXT detection beam direction may vary between 0º and 180º.
In orderto change the detection beam direction, rotate the internal detection element housing to thedesired direction.
Detection range setting
The WPIR-EXT detection range may vary between 3m and 12m, while installed on 1.2mheight above the ground
surface.
You can change the detection range by sliding the upper detection element up or down:
Long Range
Short Range
Straight
beam
Moving
beam

WPIR-EXT Installation Instructions/User Manual
12
Edition Date: 26.07.2021 Doc ID: I-200478
Dip Switch Functions
There are 5 DIP switches on the WPIR-EXT board that enable settings of following functions:
Factory default
positions
Switches 1 & 2 –PIR ELEMENTS SENSITIVITY SETTING
Use the following combinations for setting PIR upper and lower element sensitivity control according to the
environment.
Switch Position
DESCRIPTION
SW1
SW2
OFF
OFF
LOW SENSITIVITY
OFF
ON
MEDIUM SENSITIVITY
**ON
**OFF
** NORMAL SENSITIVITY
ON
ON
HIGH SENSITIVITY
Switch 3 –LED VISUAL INDICATION
Use for setting LED Enable / Disable
** UP Position (ON) –LED enabled
DOWN Position (OFF) –LED disabled
Note: the state of the switch “LED” does not affect the operation of the ALARM and TROUBLE relays.
Switch 4 –ANTI-MASK ACTIVATION
Use for Anti Mask function setting.
** UP Position (ON) –AM feature enabled Down Position (OFF) –AM feature disabled.
MASKING CONDITION
If an attempt is made to mask the lens with a sticker or to put a masking object close to the lens, a troublealert will
result up to 180 seconds aftermasking:
The Red LED will blink, and the TROUBLE (Tamper) will be transmitted.
RESET AFTER TROUBLE OR MASKING
In case ofmasking alarm, proceed as follows:
Search for masking material or objects on the lens or in front of the detector and remove them. Reset the detector by
walking in front of it. Cross its field detection causing it to alarm several times.
If everything is back to normal, the LED should stop blinking, and the TROUBLE should reset.
Note: If walk testing does not cause the trouble alert to stop, recheck for masking.
Switch 5 –BUZZER AUDIO INDICATION
Use for setting Audio Buzzer Enable / Disable
** Up Position (ON) –Buzzer enabled Down Position (OFF) –Buzzer disabled
Setting thebuzzerONgives the installer the ability to hear a beep on each detection for 1.8 seconds duringthe
adjustments and walk test. After this process it is recommended to switch the buzzer OFF.
ON = ENABLE
SW1
PIR Sensitivity
SW2
SW3
LED Indication
SW4
Anti-Mask Activation
SW5
Buzzer Audio
OFF = DISABLE

WPIR-EXT Installation Instructions/User Manual
13
Edition Date: 26.07.2021 Doc ID: I-200478
9.Test procedure
Walk Test Procedure:
1. Allow 3 minutes of warm up time.
2. Make sure that the protected area is cleared of all people.
3. Initialize the "Walk test" mode on your control panel.
4. Start walking across the detection zone.
5. Listen to ALARM sound whenever motion is detected (the red LED and the Buzzer also turns ONwhenever
motion is detected).
6. Allow 5 sec. between each test for the detector to stabilize.
7. Upon installation, the unit should be thoroughly tested to verify proper operation.
8. Walk across the entire area where coverage is desired. Should the coverage be incomplete, readjust
coverage range or relocate the detector.
NOTE: Walk Test procedure should be conducted at least once a year, to verify proper operation and range
coverage of the detector.

WPIR-EXT Installation Instructions/User Manual
14
Issued by
Vanderbilt International (IRL) Ltd.
Clonshaugh Business and Technology Park
Clonshaugh
Dublin 17
Ireland
www.vanderbiltindustries.com
© 2021 Copyright by Vanderbilt International (IRL) Ltd.
Data and design subject to change without notice.
Supply subject to availability.
Edition: 26.07.2021
Document ID: I-200478
10. Specifications
Specifications are subject to change without prior notice.
Article number
V54538-F124-A100
Short Description
WPIR-EXT AM Wrls. Ext PIR c/w pet
Detection Method
Double PIR Elements with optional Anti-masking feature
WA Detection Pattern
90⁰ with 30 zones detection
Data Protocol
Freewave2 Two Way Protocol with unique serial ID
Modulation Type
GFSK
Frequency
868-869MHz
Events Transmission
Alarm, Anti-Mask, Tamper, Supervision, Low Battery
Supervision Time
7 min by default (configurable between 1 to 30 minutes)
Detection Range
Configurable from 3m to 12m
Installation Height
From 0.8m to 1.5m (Optimal 1.2m)
Range in open space
500m
Battery
4 Lithium Batteries 1,5V Type AA LR06
Battery life
Up to 5 years
Current Consumptions
Standby ~22 A
Receive mode ~24 mA
Transmit mode ~45 mA
Transmit Power: ~14dBm
Tamper Switch
Front Cover and Wall Removal (Back Tamper)
Weatherproofing
All openings with gasket and sealed.
Protection against water and dust
RFI Protection
10V/m plus 80% AM from 80MHz to 2GHz
EMI Protection
6kV contact, 8kV air
Tamper Switch
Front Cover and Wall Removal (Back Tamper)
Temperature Compensation
Yes, Dual slop temperature compensation
Alarm Period
2 sec (±0.5sec)
Warm up Period
30 sec (± 5sec)
LED Indicator
LED is ON during ALARM and TROUBLE
Operation Temp
-25ºC ~ +55ºC
Protection Degree
IP 65
Dimensions
200mm x 86mm x 80mm
Weight (Nett)
0.640 Kg
