Vanner 20-1000TUL Inverter
Section1:Introduction
Thank you for purchasing a Vanner 20-1000TUL Power Inverter for your emergency
vehicle. We are confident you will be satisfied with its performance.
Vanner products are designed and manufactured by skilled professionals using the
highest standards in workmanship, guaranteeing excellent performance and reliability
for your emergency vehicle. With minimum maintenance and care, you can expect
years of trouble-free service from your Vanner product.
The 20-1000TUL is a 12 VDC to 120 VAC inverter with a transfer relay and Ground
Fault Circuit Interrupter (GFCI) protected AC output. This unit is equipped with an
AC line cord for AC input power (shore/utility power) and a receptacle with a GFCI
for AC output. This enables you to plug AC loads directly into the inverter. The DC
cables have quick connectors to facilitate installation and pre-wiring of emergency
vehicles.
— 1 —

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
Functionality
Inverter
The 20-1000TUL converts battery power to 1050 Watts of 120 VAC modified sine
wave power to operate vital emergency vehicle equipment. The unit is easily connected
to the positive and negative posts of a battery system with appropriate fusing, and
when turned ON, produces 120 VAC True RMS power.
The inverter also has an energy-saving feature called Load Demand. With this feature,
the inverter output is pulsed, significantly reducing the current draw from the battery
until a demand is made on its output. Continuous output of 120 VAC resumes when a
load greater than 5 Watts is applied. The load demand feature can be disabled with the
Setup Switch on the front panel.
A built-in transfer relay senses AC input to the emergency vehicle (shore/utility power)
and connects the AC input directly to the GFCI receptacle. At that time, all equip-
ment which was operating on the inverter is now powered by the AC shore line.
WW
WW
WARNINGARNING
ARNINGARNING
ARNING
Battery input
cables must be
connected to
the battery
with proper
polarity to avoid
damaging the
inverter.
FIGURE 1—SYSTEM DIAGRAM
— 2 —

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
Specifications
InverterInverter
InverterInverter
Inverter 20-1000TUL20-1000TUL
20-1000TUL20-1000TUL
20-1000TUL
Outputat120VACRMS(ContinuousPowerRating) 1050Watts
SurgeCapacityat120VAC(3sec) 2100Watts
InputVoltage,VDC 12VDC,Nominal
(DeepCycleBatteryRecommended) 10.5VDCmin.,16.0VDCmax.
OutputVoltage 120VAC± 5%
DC Current Draw (BatterDC Current Draw (Batter
DC Current Draw (BatterDC Current Draw (Batter
DC Current Draw (Battery)y)
y)y)
y)
OFF 0.017AmpsTypical
LoadDemand(waiting)* 0.09AmpsTypical
FullONatNoLoad 0.7AmpsTypical
FullONwith Load Approx.ACLoadWatts÷10or
ACLoadAmpsx12
Frequency 60Hz±0.1%
OutputWaveForm ModifiedSineWave
Bypass TBypass T
Bypass TBypass T
Bypass Transferransfer
ransferransfer
ransfer
OutputCurrent,GFCIOutlet 12Amps
Other SpecificationsOther Specifications
Other SpecificationsOther Specifications
Other Specifications
AmbientTemperature -20oto+110oF,-29oto+43.4oC
CoolingAir FanCooled,30cfm
Chassis Aluminum
Dimensions 11.57”Wx 5.94”Hx 11.04”D
Weight 22lbs
*DeterminedbySetupSwitchonfrontpanel
Remote Panel—D06638 & D06639 Remote Panel—D06638 & D06639
— 3 —

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
NOTENOTE
NOTENOTE
NOTE
Air enters by the
fan at the rear of
the unit, and exits
through the sides
of the unit. For
maximum unit
performance, avoid
recirculating the
same hot air
through the unit.
WW
WW
WARNINGARNING
ARNINGARNING
ARNING
Battery input
cables must be
connected to the
battery with
proper polarity
to avoid
damaging the
inverter.
Section2:Installingthe20-1000TUL
Unpacking the Inverter
Inspect the shipping container and equipment for loose or damaged parts.
` If any damage is found, immediately notify the freight carrier.
Installing the Inverter
Step 1: Turn the inverter OFF/disconnect power to the wiring harness.
Make sure power to the vehicle wiring harness is disconnected. Verify
that the inverter is turned OFF by checking that the ON-OFF/RESET
Inverter Switch is in the OFF-RESET position.
(The button should NOT be pushed in.)
Step 2: Select a location for the unit.
An ideal installation location has the following characteristics:
• Close to the battery (within six feet using #2 AWG wire)
• Protected from the weather
• Well ventilated
Step 3: Route DC input cables.
Route the negative and positive DC input cables from the inverter (through
the quick connector) to the battery. If required, protect cables where they
contact hard, sharp edges.
Step 4: Install in-line fuse.
Install an in-line Bussman ANN 125 or equivalent fuse (Vanner p/n 03640-
fuse and 03637-fuse holder) in the red, positive DC input cable between the
battery and inverter, within 18 in. of the battery or DC wiring bus system.
Step 5: Connect Bonding Lug.
Use a AWG #8 or larger copper conductor to connect the chassis bonding lug
to the vehicle chassis and/or earth ground.
Step 6: Connect the inverter to the battery.
Connect the black, negative DC input cable from the quick connector to the
battery negative (-) terminal. This battery negative terminal is usually where
the battery negative connects to the engine block or frame.
Connect the red, positive DC input cable from the quick connector to the
fuse of the battery positive (+) terminal. This battery terminal is usually
connected to the DC electrical system at the load side of the Battery
Disconnect Switch.
— 4 —
DC Cable LengthDC Cable Length
DC Cable LengthDC Cable Length
DC Cable Length
SizeSize
SizeSize
Size MaximumMaximum
MaximumMaximum
Maximum
2AWG 12ft.
1/O AWG 20 ft.

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
Step 7: Select Load Demand option.
Select Load Demand option, if desired, using the proper switch position on
the front panel Setup Switch. With Load demand ON, the inverter conserves
battery energy and operates only when a load greater than 5 Watts is applied.
Step 8: Connect the AC loads.
Connect the AC loads to the inverter GFCI receptacle. Any time AC power is
applied to the AC input (shore/utility power), it will pass through this GFCI
receptacle.
Step 9: Verify installation.
Verify all connections are tight and secure for maximum performance.
InverterInverter
InverterInverter
Inverter Light ActionLight Action
Light ActionLight Action
Light Action DescriptionDescription
DescriptionDescription
Description
Steady Green Light Inverter is On and operating.
Single Blink Green Light Inverter circuit is Off. Shore power is On and supplying
AC power to the AC loads. The inverter will turn On and
supply the load if shore power is lost.
Double Blink Green Light Inverter circuit is Off. Shore power is Off. The inverter is
waiting for a load greater than 5 watts to be turned on.
Battery LowBattery Low
Battery LowBattery Low
Battery Low Light ActionLight Action
Light ActionLight Action
Light Action DescriptionDescription
DescriptionDescription
Description
Solid Red Inverter is On and the battery is almost too low to
operate the inverter.
Blinking Red The inverter is Off. The battery voltage dropped below
10.5 volts DC and the inverter shut itself Off. Once shut
off, the batteries must be recharged. Then, the inverter
On/Off switch must be cycled to reset the unit.
OvertempOvertemp
OvertempOvertemp
Overtemp Light ActionLight Action
Light ActionLight Action
Light Action DescriptionDescription
DescriptionDescription
Description
Solid Red The unit is Off. The unit has turned itself Off because the
power MOSFET's are operating too hot. This can be
caused by operating an AC load which is too large for
the inverter, or lack of ventilation. When the unit cools
the inverter will start operating again.
OverloadOverload
OverloadOverload
Overload Light ActionLight Action
Light ActionLight Action
Light Action DescriptionDescription
DescriptionDescription
Description
Blinking Red The inverter is On but it is overloaded. Reduce the AC
load quickly or the inverter will shut off due to the
overload condition.
Solid Red The inverter is Off. An overload has occurred and the
inverter has shut off to protect itself. Once shut off, the
inverter On/Off switch must be cycled to reset the unit.
Inverter LED DisplaysInverter LED Displays
Inverter LED DisplaysInverter LED Displays
Inverter LED Displays
— 5 —

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
Section3: InstallingtheIFM1InterfaceModule
This section describes the installation of the optional Vanner Model IFM1 Interface
Module. Refer to the information provided in the IFM1 Interface Module Owner’s
Manual for more information on installing the inverter and interface module in a
vehicle rewired or retrofitted for the 20-1000TUL.
If you are installing a new 20-1000TUL unit, you will need the interface module only
if you are using the inverter status panel (p/n D06638), Remote Switch (p/n D06781),
or if you require the inverter lockout feature.
Installing the IFM1 Interface Module
Step 1: Mount the Interface Module.
Mount the interface module in the vehicle’s existing 12 V electrical system
wiring harness with #8 screws. Select a physical orientation best suited for
your application environment; however, it must be within the 2ft Interface
Cable length to the inverter. Additionally, the unit should not be installed
with pin connections facing upward.
Step 2: Connect the Inverter to the Interface Module.
Install the 2 ft. interface cable by plugging it into the remote RJ-11 connector
on the 20-1000TUL and the J1 connector on the IFM1 Interface Module.
Step 3: Connect the Battery Disconnect Switch.
Connect the +12 V lead from the Module Disconnect Switch circuit to the
inverter lockout Pin 1 (ignition switch or battery disconnect switch). The
+12 V lead from the Battery Disconnect Switch must be fused with an in-line
fuse or circuit breaker of 2 Amps or less. See Figure 2.
Step 4: Wire the Remote Switch (p/n D06781) to Pins 2 through 5.
Red to Pin 2, Black to Pin 3, Green to Pins 4 and 5. If no remote switch is
used, two jumpers must be installed. The first jumper connects Pin 2 to Pin
3, the second jumper connects Pin 4 to Pin 5. See Figure 2.
Step 5: Connect the Inverter Remote Status Display Panel (Optional).
Connect the gray, green, and red wires from the inverter panel, through the
OEM harness, to the IFM1 Module, Pins 6 (grey), 7 (green), and 8 (red).
— 6 —

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
Section4: InstallingtheInverterRemote StatusDisplayPanel
The Inverter Remote Status Display Panel (p/n D06638) contains separate, red and
green LED indicators. The green indicator light signifies the inverter is On or in
Standby mode. The red, Fault LED indicator shows problems such as over tempera-
ture, output overload, or low battery. The panel has a sealed overlay which mounts
easily on a flat surface. A 12-in. pigtail harness is included for easy installation. Use the
following procedure to install the Inverter Remote Status Display Panel.
Step 1: Select a location for the panel.
Identify the desired location for the inverter panel.
Step 2: Identify wires for installation.
Identify the gray, green, and red wires on the inverter panel and vehicle's
electrical system wires that will connect to the IFM1 Interface Module.
Step 3: Splice and arrange wires.
Splice together like-colored wires from the vehicle's electrical system to the
status panel using an insulated butt splice or equivalent. Carefully arrange the
wires such that the panel mounts flush against the surface to which it is
mounted.
Step 4: Secure panels to surface.
Mount the panels using #8 screws through the four holes in the panel.
FIGURE 2—
IFM1 MODULE
REMOTE WIRING
— 7 —

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
Section5:InverterStatusPanelOperation
Two LEDs on the front of the Remote Status Display Panel indicate the status of the
inverter. The status indicated by the LED displays is directly related to the status
indicated by the LEDs on the front of the inverter.
Inverter LEDInverter LED
Inverter LEDInverter LED
Inverter LED Light ActionLight Action
Light ActionLight Action
Light Action DescriptionDescription
DescriptionDescription
Description
Steady Green Light Inverter is operational.
Single Blink-Green Light Inverter is not being used. Shore power is applied to load. Inverter will
activate when shore power is unavailable.
Double Blink-Green Light Inverter is on in the Load Demand mode and is waiting for AC load to be
turned ON.
Inverter FInverter F
Inverter FInverter F
Inverter Fault LEDault LED
ault LEDault LED
ault LED Light ActionLight Action
Light ActionLight Action
Light Action DescriptionDescription
DescriptionDescription
Description
Red Light Unitshutdown * — Check theinverter'sfront panel LEDsforreason of
shutdown: Low Battery, Overload, or Overtemp.
*Refer to the Troubleshooting section of this manual for fault diagnostic information.
Section6:Operatingthe20-1000TULInverter
— 8 —

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
Use the following instructions to operate the 20-1000TUL Inverter.
Step 1: Install the 20-1000TUL unit.
Completely install the inverter and charger using the instructions provided in
Section 2 of this manual.
Step 2: Apply an AC load.
Apply an AC load with AC input power present. The AC load is run directly
from AC input power. The ON-OFF/RESET Inverter Switch does not affect
the inverter's AC output when shore power is present.
Step 3: Turn on the inverter Remote Switch.
Step 4: Apply shore power to the 20-1000TUL/Ambulance shore line connection.
Push the ON-OFF/RESET Inverter Switch to the ON position. When
powered by the AC power, the ON lamp flashes, indicating that the inverter
is standing by.
Step 5: Verify Power.
Apply an AC load, such as a shop light or drill. The AC load is run directly
from AC input power.
Step 6: Observe the inverter operation.
Remove the shore line connection from the emergency vehicle. The unit will
automatically switch to Inverter mode and operate the AC load using battery
power. When shore power is restored, the unit examines the AC input for five
seconds and then switches the loads back to run directly from AC input
power.
With the ON-OFF/RESET Switch in the ON position, a double flash of the
ON light indicates the load demand is turned ON and the load is less than
5 Watts.
NOTENOTE
NOTENOTE
NOTE
Throughout this
manual, shore/
utility power is
referred to as AC
input power.
— 9 —

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
Section7:Troubleshootingthe20-1000TUL
The following are the most common questions heard by Vanner service professionals.
If your situation does not apply to the following categories, please contact your local
Vanner Power Group Service Center.
Vanner Power Group Customer Service:
1-800-AC-POWER
SYMPTSYMPT
SYMPTSYMPT
SYMPTOMOM
OMOM
OM The LEDsonthe frontpanelblink in sequence.
SOLSOL
SOLSOL
SOLUTIONUTION
UTIONUTION
UTION Itisnormalfor this to occuriftheinverterswitch is On whentheDCinputis connected to theunit.
Ifthe DCisalready connectedandthe LEDsblinkin sequencethenthe DCinputvoltage isdropping.
Checkfor poorconnectionsin the DCwiring,bad battery ora heavy DCload.
SYMPTSYMPT
SYMPTSYMPT
SYMPTOMOM
OMOM
OM ON lamp does not light steadily after pushing in the ON-OFF/RESET Inverter
Switch.
SOLSOL
SOLSOL
SOLUTIONUTION
UTIONUTION
UTION Lampflashes whenutilitypower ispresent.
Lamp flashes in Load Demand Waiting mode.
Check/Reset GFCI on the receptacle.
Check battery connections if utility power is OFF.
CheckDC fusesifutility powerisOFF.
SYMPTSYMPT
SYMPTSYMPT
SYMPTOMOM
OMOM
OM ON lamp fully illuminates. AC load does not run.
SOLSOL
SOLSOL
SOLUTIONUTION
UTIONUTION
UTION Check and reset circuit breaker.
Verify AC load and cord are in proper condition.
SYMPTSYMPT
SYMPTSYMPT
SYMPTOMOM
OMOM
OM BATTERY LOW lamp illuminates when AC load is applied.
SOLSOL
SOLSOL
SOLUTIONUTION
UTIONUTION
UTION Check battery connections.
Check battery condition.
Recharge battery if voltage is less than 10.5 VDC.
Check AC loads for shorted circuit.
Check the vehicle's alternator charging system for proper operation.
SYMPTSYMPT
SYMPTSYMPT
SYMPTOMOM
OMOM
OM OVERTEMP lamp illuminates.
SOLSOL
SOLSOL
SOLUTIONUTION
UTIONUTION
UTION Something has caused the unit to overheat. Check for obstruction of air flow to the cooling fan or from
ventilation holes. VerifyAC load iswithinunit’s rated
capacity.
SYMPTSYMPT
SYMPTSYMPT
SYMPTOMOM
OMOM
OM OVERLOAD lamp illuminates with AC load applied.
SOLSOL
SOLSOL
SOLUTIONUTION
UTIONUTION
UTION Verify AC load is within unit’s rated capacity.
SYMPTSYMPT
SYMPTSYMPT
SYMPTOMOM
OMOM
OM DC fuse blows when connecting DC input cables.
SOLSOL
SOLSOL
SOLUTIONUTION
UTIONUTION
UTION Checkfor reversepolarity:red cabletobattery positive(+),black cabletobattery negative(-).The
unit may be damaged and require repair service.
— 10 —

Vanner Power Group 20-1000TULINVERTER—OWNER'SMANUAL
— 11 —
ENTERENTER
ENTERENTER
ENTER JANJAN
JANJAN
JAN FEBFEB
FEBFEB
FEB MARMAR
MARMAR
MAR APRAPR
APRAPR
APR MAMA
MAMA
MAYY
YY
YJUNEJUNE
JUNEJUNE
JUNE JULJUL
JULJUL
JULYY
YY
YAUGAUG
AUGAUG
AUG SEPTSEPT
SEPTSEPT
SEPT OCTOCT
OCTOCT
OCT NOVNOV
NOVNOV
NOV DECDEC
DECDEC
DEC
YEARYEAR
YEARYEAR
YEAR
19____
NOTENOTE
NOTENOTE
NOTE
Photocopy
this page and
place it in your
maintenance
notebook.
Section8:GFCITestRecord
For maximum protection against electrical shock hazard, operate the Test Switch on
the Ground Fault Circuit Interrupter at least once a month.

Limited Warranty
1. Vanner Weldon, Inc., referred to herein as Vanner, warrants that this
product is free from defects in materials and workmanship for a period of
one(1)year from itsdateof shipmentfromVanner'sfactory.
2. This warranty does not cover defects caused by misuse, neglect, accident,
reversed polarity, unauthorized repairs, and/or replacements.
3. All warranties of merchantability and fitness for a particular purpose;
writtenororal, expressorimplied, shallextendonly foraperiod ofone
(1)year.Thereare nootherwarranties which extendbeyond those
described on the face of this warranty.
4. Vanner does not undertake responsibility to any purchaser of its product
for any undertaking, representation, or warranty made by any dealers or
distributors selling its products beyond herein expressed.
5. Vanner does not assume responsibility for incidental or consequential
damages,including,butnot limited toresponsibility for lossofuse of this
product,lossof time, inconvenience,expensefor telephonecalls,shipping
expense,lossor damage toproperty, orloss of revenue.
6. Vanner reserves the right to repair, replace, or allow credit for any
material returned under this warranty. Any damage caused by the
customer will be charged or deducted from the allowance.
7. All warranty work will be performed at Vanner's factory, or authorized
repair facility. Products shall be delivered to Vanner's facility, freight
prepaid. Products repaired under warranty, or replacement parts or
products will be returned, F.O.B. Vanner factory.
— 12 —

VV
VV
Vanner Panner P
anner Panner P
anner Power Groupower Group
ower Groupower Group
ower Group
4282ReynoldsDrive
Hilliard,Ohio43026
Tel[phone]
Fax[phone]
Specifications Subject to Change
© Copyright 1996, Vanner Weldon Inc.
Printed in the U.S.A.
OM/A96751 REV. A 5/96
