VAT 570 Series Assembly instructions

Installation, Operating &
Maintenance Instructions
215086EG.DOCX
Edition
14.02.2019
All-metal angle valve
single acting pneumatic actuator with closing spring
Series 570
DN 100 - 160 mm (I. D. 4" - 6")
This manual is valid for the following product ordering numbers:
57040-.E11/E21/E31/E41
57044-.E11/E21/E31/E41
Sample picture

Series
570
2
/
36
Edition
14.02.2019
215086EG
Imprint
Manufacturer
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Website:
Phone:
Fax:
Email:
www.vatvalve.com
[phone]
[phone]
[email protected]
Publisher VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Editor VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Print VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Copyright © VAT Vakuumventile AG 2019
No part of these Instructions may be reproduced in any way (photo-
copies, microfilms or any other reproduction processes) nor may it be
manipulated with electronic systems, duplicated or distributed without
written permission from VAT. Offenders are liable to pay damages.
The original VAT firmware and updated state of the art versions of the
VAT firmware are intended for use with VAT products. The VAT firmware
contains a limited, time unlimited user license. The VAT firmware may not
be used for purposes other than those intended nor is it permitted to
make copies of the VAT firmware. In particular, it is strictly forbidden to
give copies of the VAT firmware to other people.
The use of trade names, brand names, trademarks, etc. in these
Instructions does not entitle third parties to consider these names to be
unprotected and to use them freely. This is in accordance with the
meaning of the laws and acts covering brand names and trademarks.

Series 570
215086EG
Edition
14.02.2019
3
/
36
Contents
1 Description of product........................................................................5
1.1 Identification of product.......................................................................................5
1.2 Use of product.....................................................................................................5
1.3 Related documents.............................................................................................5
1.4 Important information..........................................................................................5
1.5 Technical data.....................................................................................................5
2 Safety ...................................................................................................6
2.1 Compulsory reading material..............................................................................6
2.2 Danger levels......................................................................................................6
2.3 Personnel qualifications......................................................................................7
2.4 Safety labels........................................................................................................7
3 Design and Function...........................................................................8
3.1 Design.................................................................................................................8
3.2 Function ..............................................................................................................9
4 Installation.........................................................................................10
4.1 Unpacking .........................................................................................................10
4.2 Installation into the system................................................................................12
4.2.1 Preparation for installation....................................................................13
4.2.2 Mounting to the system ........................................................................14
4.2.2.1 Leak detection port...............................................................14
4.3 Compressed air connection ..............................................................................15
4.4 Electrical connection.........................................................................................16
4.4.1 Solenoid................................................................................................16
4.4.2 Position indicators.................................................................................17
5 Operation...........................................................................................19
5.1 Normal operation...............................................................................................19
5.2 Operation under increased temperature...........................................................20
5.3 Bake-out............................................................................................................20
5.4 Behavior in case of compressed air pressure drop ..........................................21
5.5 Behavior in case of power failure......................................................................21
6 Trouble shooting...............................................................................22
7 Maintenance ......................................................................................23
7.1 Maintenance intervals.......................................................................................23
7.2 Preventive Maintenance ...................................................................................24
7.2.1 Instruction how to change the VATRING .............................................24
7.3 Drawing.............................................................................................................25
8 Repairs...............................................................................................26
9 Dismounting and Storage.................................................................27
9.1 Dismounting ......................................................................................................27
9.2 Storage..............................................................................................................28
10 Packaging and Transport.................................................................29
10.1 Packaging .........................................................................................................30

Series
570
4
/
36
Edition
14.02.2019
215086EG
10.2 Transport...........................................................................................................30
11 Disposal............................................................................................. 31
12 Spare parts........................................................................................ 32
12.1 Valve Spare part list ..........................................................................................32
12.2 Solenoid kit (5/2-way standard).........................................................................33
12.3 Position indicators 80°C (single + double) in various versions with adapter ....34
13 Appendix ........................................................................................... 35

Series 570 DESCRIPTION OF PRODUCT
215086EG
Edition
14.02.2019
5
/
36
1 Description of product
1.1 Identification of product
The fabrication number and order number are fixed on the product directly or by means of
an identification plate.
Fabrication No.:
000 . .- . . . .- . . . ./ . . . .
A - . . . . . .


Fabrication number
Order number
1.2 Use of product
Use product for clean and dry vacuum applications only. Other applications are only allowed
with the written permission of VAT. Suitable for XHV applications.
1.3 Related documents
•Product data sheet
•Dimensional drawing
1.4 Important information
This symbol points to a very important statement that requires particular
attention.
Example
:
VAT disclaims any liability for damages resulting from inappropriate packaging.
1.5 Technical data
See on product data sheet, to get »Technical data« details.

SAFETY Series
570
6
/
36
Edition
14.02.2019
215086EG
2 Safety
2.1 Compulsory reading material
Read this chapter prior to performing any work with or on the product. It contains important
information that is significant for your own personal safety. This chapter must have been
read and understood by all persons who perform any kind of work with or on the product
during any stage of its serviceable life.
NOTICE
Lack of knowledge
Failing to read this manual may result in property damage.
Firstly, read manual.
These Installation, Operating & Maintenance Instructions are an integral part
of a comprehensive documentation belonging to a complete technical
system. They must be stored together with the other documentation and
accessible for anybody who is authorized to work with the system at any
time.
2.2 Danger levels
DANGER
High risk
Indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING
Medium risk
Indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION
Low risk
Indicates a hazardous situation which, if not avoided, may result in minor or
moderate injury.
NOTICE
Command
Indicates a hazardous situation which, if not avoided, may result in property
damage.

Series 570 SAFETY
215086EG
Edition
14.02.2019
7
/
36
2.3 Personnel qualifications
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
2.4 Safety labels
Label Part No. Location on valve
T-9001-156 On protective covers of
flanges

DESIGN AND FUNCTION Series
570
8
/
36
Edition
14.02.2019
215086EG
3 Design and Function
3.1 Design
1 Actuator
2 Valve body
3 Connecting flange
4 Sealing surface
5 Solenoid
6 Position indicator
1
2
3+4
3
4
5
6
Sample picture

Series 570 DESIGN AND FUNCTION
215086EG
Edition
14.02.2019
9
/
36
3.2 Function
Opening of closed valve
- without solenoid:
•air supply to connection plate
- with solenoid:
•supply specified control voltage to the coil
Closing of open valve
- without solenoid:
•air release through connection plate
- with solenoid:
•release control voltage
Ascertain that the circlip connecting the lid to the cylinder is correctly in
place. Even with disconnected supply, loaded springs and/or air cushions in
cylinders can be potential hazards.

INSTALLATION Series
570
10
/
36
Edition
14.02.2019
215086EG
4 Installation
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
WARNING
Heavy weight
Physical overstraining.
Use a crane to lift the product.
4.1 Unpacking
Handling of the valve must take place under clean conditions normally observed in good
vacuum practice. The valve may only be touched with clean gloves. After the protective
covers have been removed, the sealing surfaces of the flanges have to be cleaned carefully
with alcohol. The screws of the flanges have to be tightened uniformly in diagonal crosswise
order. Determine that the valve and existing plumbing in the vacuum system will be
adequately supported.
•Make sure that the supplied products are in accordance with your order.
•Inspect the quality of the supplied products visually. If it does not meet
your requirements, please contact VAT immediately.
•Store the original packaging material. It may be useful if products must be
returned to VAT.
Open the plastic bag protecting the valve only at the points where you need
access to the eyebolts (1) for fastening the crane hooks; see below. Keep
valve in the plastic bag until it is being installed into the system.

Series 570 INSTALLATION
215086EG
Edition
14.02.2019
11
/
36
NOTICE
Wrong lifting
Valve may crash and get damaged.
Use only the eyebolts shown in the dimensional drawing and in on sample
picture to lift the valve. Using any other components (e. g. position indicators,
solenoids) to lift the valve is strictly forbidden.
NOTICE
Sensitive product
Valve parts may get damaged.
–
When lifting the valve, pay attention that the valve does not touch any solid
objects.
–
Lift valve carefully and put it down on a clean surface or mount it to a clean
system.
Use a crane for lifting valve out of the transport box
To see the Weight of valve, take a look into the product data sheet.
1 Eyebolts
2 Lifting ropes
A Valve movement
direction
B Support required to
stabilize the valve
1
1
2 A
B
Sample picture

INSTALLATION Series
570
12
/
36
Edition
14.02.2019
215086EG
4.2 Installation into the system
The valve must not support other components and has to be protected from forces of the
system (e.g. by bellows sections).
WARNING
Movable parts
Human body parts may get jammed and severely injured.
Do not connect or supply electrical power and compressed air before the
product is completely mounted in the system.
NOTICE
Contamination
Product may get contaminated.
Always wear cleanroom gloves when handling the product.
NOTICE
Force effect from other components of the system
Valve body may get deformed and/or malfunctions may occur.
– Do not use valve to support other components.
– Make sure that forces from other components do not impair the valve;
use bellows sections, for instance.

Series 570 INSTALLATION
215086EG
Edition
14.02.2019
13
/
36
4.2.1 Preparation for installation
WARNING
Danger of injury in case of insufficient skills
Inappropriate handling may cause serious injury or property damage.
Make sure that the valve does not topple or fall down while removing the
protective covers from the flanges.
NOTICE
Sensitive product
Valve parts may get damaged.
When removing the protective covers from the flanges, be careful to avoid
damage to the valve.
1. Remove plastic bag.
2. Remove screws, Nuts and protective covers
3. Remove O-rings.
Store protective covers, O-rings, nuts and screws. They may be useful when
valve needs to be repacked.
4. Clean sealing surfaces with cleanroom wiper soaked with pure alcohol (Isopropanol).
5. Clean sealing surface with clean, oil free compressed air.

INSTALLATION Series
570
14
/
36
Edition
14.02.2019
215086EG
4.2.2 Mounting to the system
The valve must not support other components and has to be protected from
forces of the system (e.g. by bellows sections).
4.2.2.1 Leak detection port
The exact position of the leak detection port is referenced on the dimensional drawing
Do not block or cover the leak detection port,
as shown on the sample picture
Sample picture
Symbol for
Leak detection port

Series 570 INSTALLATION
215086EG
Edition
14.02.2019
15
/
36
4.3 Compressed air connection
WARNING
Valve in open or closed position
Risk of injury when compressed air is connected to the valve.
Connect compressed air only when:
– valve is installed in the vacuum system
– moving parts cannot be touched
NOTICE
Wrong sequence of connections
Valve mechanism may get damaged when electrical power is being
connected before compressed air is connected.
Always connect compressed air before connecting electrical power.
Check if the circlip connecting the lid to the cylinder is in the proper position.
Use clean, dry or slightly oiled air only.
Admissible air pressure range, see product data sheet.
Check if the circlip connecting the lid to the cylinder is in the proper position.
Supply compressed air pressure only after the supply line is properly
mounted to the actuator.
Execution Procedure
Without solenoid Connection OPEN for air supply
With solenoid Connection «1» for air supply, connection «3» for exhaust

INSTALLATION Series
570
16
/
36
Edition
14.02.2019
215086EG
4.4 Electrical connection
DANGER
Electric shock
Parts being under voltage will result in serious injury or death.
Do not touch parts being under voltage.
NOTICE
Wrong sequence of connections
Valve mechanism may get damaged when electrical power is being is
connected.
Always install the valve into the vacuum system before connecting electrical
power.
NOTICE
Wrong voltage
Electrical components may get damaged.
Supply electrical components with the correct voltage.
4.4.1 Solenoid
Wiring diagrams:
MV
2
1
power 2
1
MV = coil of solenoid

Series 570 INSTALLATION
215086EG
Edition
14.02.2019
17
/
36
4.4.2 Position indicators
Wiring diagrams:
Position indicators for max. 80°C

contact rating ≤50 V AC / DC; ≤1.2 A
Standard position indicator
with make contact switches
Double position indicator
with make contact switches - two each
(option)
12
3
4
56
1
2
6
5
4
3
Lo
Lg
12
3
4
56
1
2
6
5
4
3
Lo
Lg
12
3
4
56
1
2
6
5
4
3
Lo
Lg
Lo = position indicator «open»
Lg = position indicator «closed» Lo = position indicator «open» Lg = position indicator «closed»
Position indicator with double throw switches
(option)
Double position indicator with double throw
switches - two each (option)
6
5
43
2
1
3
1
2
4
6
5
Lo
Lg
6
5
43
2
1
3
1
2
4
6
5
Lo
Lg
6
5
43
2
1
3
1
2
4
6
5
Lo
Lg
Lo = position indicator «open»
Lg = position indicator «closed» Lo = position indicator «open» Lg = position indicator «closed»
Position indicator for max. 80°C contact rating ≤50 V AC / DC; ≤1.2 A
Position indicator radiation resistant 10E6Gy with make contact switches
1 2
34
5 6
1
2
6
5
4
3
Lo
Lg
Lo = position indicator «open»
Lg = position indicator «closed»

INSTALLATION Series
570
18
/
36
Edition
14.02.2019
215086EG
Position indicators for max. 200°C and 300°C

contact rating ≤50 V AC / DC; ≤1 A
Single position indicator (option) Double position indicator (option)
3
1
2
4
6
5
Lo
Lg
3
1
2
4
6
5
Lo
Lg
3
1
2
4
6
5
Lo
Lg
Lo = position indicator «open»
Lg = position indicator «closed» Lo = position indicator «open» Lg = position indicator «closed»
Position indicator for max. 80°C contact rating ≤50 V AC / DC; ≤1.2 A
Common plug for pos. indicator and solenoid, pos. indicator with make contact switches
(option)
1
2
3 4
5
6
Lg
Lo
power 4
3
5
6
2
1
MV
Lo = position indicator «open»
Lg = position indicator «closed»

Series 570 OPERATION
215086EG
Edition
14.02.2019
19
/
36
5 Operation
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
WARNING
Movable parts
Human body parts may get jammed and severely injured.
Do not operate before product is installed completely into the vacuum system.
5.1 Normal operation
Opening of closed valve
- without solenoid:
•air supply to connection plate
- with solenoid:
•supply specified control voltage to the coil
Closing of open valve
- without solenoid:
•air release through connection plate
- with solenoid:
•release control voltage
Ascertain that the circlip connecting the lid to the cylinder is correctly in
place. Even with disconnected supply, loaded springs and/or air cushions in
cylinders can be potential hazards.

OPERATION Series
570
20
/
36
Edition
14.02.2019
215086EG
5.2 Operation under increased temperature
Maximum allowed temperature see product data sheet.
NOTICE
Inconstant temperatures
Performance of the valve may deteriorate.
– Actuate valve only after the bake-out temperature has been stable for two
hours.
– If valve must be actuated during bake-out, make sure that the heating or
cooling rate does not exceed 30 °C per hour in the temperature range
from 200°C to 450 °C
5.3 Bake-out
See on product data sheet, to get »Bake out« details.
