Vaxcel T0521 Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
190611
1. Unscrew the four set screws (C) from the cover.
2. Install a bulb (not included).
See relamping label at socket area or packaging
for maximum allowed wattage.
3. Alight the holes on the lamp frame to the fixture’s,
secure them by threading the set screws (C) going
through the holes one by one.
4. Pull out the wires and grounding wire from the post.
Make wire connections using the wire connectors (B):
---The hot wire (usually black insulation) from the
fixture to the black wire from the post.
---The neutral wire (usually white insulation) from
the fixture to the white wire from the post.
---The grounding wire (usually green insulation or
bare wire from the fixture to the grounding wire
from the post.
Carefully put the wires back into the post.
5. Place the fitter on the top of the post, and then
secure it with three fitter screws (A).
NOTE: With silicone caulking compound,
caulk completely around where the fitter
meets with the post surface to prevent water
from seeping into the post.
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
T0521 T0526
Hardware Package (included):
Fitter Screw (A) Wire Connector (B)
Turn off the power at fuse or circuit box
Installation Steps
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
Turn on the power at fuse or circuit box
Cover
Set Screw
Lamp Frame
Fitter
Fitter Screw (A)
Wire Connector (B)
Grounding Wire
Post
Bulb Type A MAX 60W
(not included)

190611
Assembly Kit
6132MM (1SET) for T0521
6133MM (1SET) for T0526
The following parts are available for re-order if damaged or missing.
Spare Parts List:
B
A
Glass
10106CS
A: 8-1/2"
B: 19-3/4"
Fitter Screw (A) Wire Connector (B)
