Vaxcel T0080 Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
NOTE: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
T0080
Dome
Bulb Type B Max.60W
(not included)
Door
Front Glass Panel (I)
Parts:
140324
Parts Number (9587CE)
Front Glass panel (I) (X1)
Metal Frame
Parts Number (9571CE)
Side Glass Panel (K) (X3)
Ball Nut Assembly
Back Plate
Ball Nut (G)
Rubber Pad (H)
Parts Number (5046MM)
Mounting Screw (B)
Green Grounding
Screw (C)
Lock Nut (F)
Wire Nut (E)
Ball Nut (G)
Headless Screw (D)
Rubber Pad (H)
Parts Number (9570CE)
Upper Glass panel (J) (X4)
Clip
Upper Glass panel (J)
Side Glass Panel (K)
Candle Tube (L)
Latch
Parts Number (5005DD)
Candle Tube (L) (X3)
House Grounding Wire
Green Grounding Screw (C)
Wire Nut (E)
Mounting Screw (B)
Headless Screw (D)
Outlet Box
Lock Nut (F)
Mounting Plate (A)
Fixture Grounding Wire
Mounting Plate (A)
Finial
Nipple
WARNING: Turn off the main power at circuit breaker before installing fixture.
AVERTISSEMENT: Coupez la source d’alimentation principale au panneau
central de disjoncteurs avant d’installer le luminaire.

140324
1. Take a side glass panel and gently place the side
glass panel into the metal frame in place, then
pressing the clips of the metal frame to secure the
side glass panel. (See Fig. 1)
2. Repeat this process to complete all glass panel
installation of side glass panels and front glass
panel.
3. Take an upper glass panel and gently place the
upper glass panel into the dome in place, then
pressing the clips of the dome to secure the upper
glass panel. (See Fig. 2) Repeat with other upper
glass panels.
4. Secure the finial onto the nipple, then attach the
dome to the metal frames, secure it with the ball nut
assemblies.
5. Thread two headless screws to the mounting plate,
and secure them with four lock nuts (two on each
side of the mounting plate). Adjust the length of the
headless screws if necessary.
6. Attach the mounting plate to the outlet box by using
two mounting screws.
7. Pull out the outlet wires and the house grounding
wire from the outlet box. Make wire connections
by using the wire nuts:
---Connect the black (hot) wire from the fixture to the
black (hot) wire from the power source.
---Connect the white (neutral) wire from the fixture to
the white (neutral) wire from the power source.
---Attach the fixture grounding wire to the mounting
plate with the green grounding screw. Then
connect it to the house grounding wire with a wire
nut.
Carefully put the wires back into the outlet box.
8. Attach the back plate to the mounting plate by
inserting the headless screws, then secure it with
two rubber pads and two ball nuts.
Note: With silicone caulking compound, caulk completely around where the back plate
meets with the wall surface to prevent water from seeping into the outlet box.
9. Open the door of the fixture by pushing up the latch, attach the candle tube onto the socket.
10. Install bulbs (not included). See relamping label at socket area or packaging for maximum
allowed wattage. Close the door of the fixture by pulling down the latch.
11. Turn on the power at the main fuse or circuit breaker box.
A: 12"
B: 26-3/4"
C:13-5/8"
A
B
C
Fig. 1 Clip
Fig. 2
Glass Panel
Clip Glass Panel
Clip
Clip
