Vaxcel T0396 Instruction manual

House Grounding Wire
Green Grounding Screw (E)
Wire Connector (C)
Back Plate
Mounting Screw (B)
Mounting Plate (A)
Outlet Box
Fixture Wire
Set Screw (D)
ASSEMBLY AND INSTALLATION
INSTRUCTIONS
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
T0396 / T0399
Hardware Package (included):
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
180129
Green Grounding
Screw (E)
Set screw (D)
Mounting Screw (B) Wire Connector (C)
Mounting Plate (A)
THIS SIDE UP
label
1. When mounting to a wall, the “THIS SIDE UP” arrow must point upward and remove the label.
2. Attach the mounting plate to the outlet box by using two mounting screws.
3. Pull out the outlet wires and house grounding wire from the outlet box. Make wire connections using the wire connectors:
---Connect the black wire from the fixture to the black wire from the power source.
---Connect the white wire from the fixture to the white wire from the power source.
---Attach the fixture grounding wire to the mounting plate with the green grounding screw. Then connect it to the house
grounding wire with a wire connector.
Carefully put the wires back into the outlet box.
4. Attach the back plate to the mounting plate by aligning holes, secure the set screws from the side hole of the back plate
into the hole in the side of the mounting plate.
5. With silicone caulking compound, caulk completely around where the back plate meets the wall surface.
CAUTION: Be sure to caulk completely where the back plate meets the wall surface to prevent water from
seeping into the outlet box.
Turn off the power at fuse or circuit box
Installation Steps
Turn on the power at fuse or circuit box

180129
The following parts are available for re-order if damaged or missing.
Spare Parts List:
Mounting Hardware 5818MM (1 SET) For T0396
Mounting Hardware 5819MM (1 SET) For T0399
A: 4”
B: 4-3/4”
C: 5-1/2”
Green Grounding
Screw (E)
Set screw (D)
Mounting Screw (B) Wire Connector (C)
Mounting Plate (A)
