Vaxcel T0479 Instruction manual

WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
ASSEMBLY AND INSTALLATION
INSTRUCTIONS
T0479
Turn off the power at fuse or circuit box.
Installation Steps
181205
T
IMPORTANT:
The sensor has an excellent photocell function
to enable the light to turn on at dusk and off at
dawn automatically.
Bulb Type B
Max.60W
(not included)
Hardware Package (included):
Green Grounding Screw (E)
Headless screw (D)
Mounting Screw (B) Wire Connector (C)
Lock Nut (F)
Mounting plate (A)
Ball Nut (G) Rubber Pad (H)
House Grounding Wire
Fixture Grounding Wire
Wire Connector (C)
Mounting Plate (A)
Outlet Box
Fixture
Wire
Lock Nut (F)
Headless Screw (D)
Mounting Screw (B)
Green Grounding Screw (E)
Glass Panel
Photocell Ball Nut (G)
Metal Frame
Back Plate Rubber Pad (H)
Candle Tube
Socket
1. Thread two headless screws (D) through the mounting plate (A), and then secure them with four lock nuts (F) (two on each
side of the mounting plate (A).) Adjust the length of the headless screws (D) if necessary.
Note: Make sure the headless screws are lined up horizontally to make the fixture level.

181205
2. Attach the mounting plate (A) to the outlet box by using two mounting screws (B).
3. Make the bottom of the fixture upward, gently place four glass panels into the metal
frame, then press the clips to secure the glass panels.(Fig.1)
4. Pull out the source wires from the outlet box. Make wire connections using wire
connectors (C) as follows:
---Connect the hot wire (usually black insulation) from the fixture to the
black wire from the power source.
---Connect the neutral wire (usually white insulation) from the fixture to the
white wire from the power source.
---Attach the fixture grounding wire (usually green insulation or bare wire) to
the mounting plate (A) with the green grounding screw (E), and then
connect it to the house grounding wire with the wire connector (C).
Carefully put the wires back into the outlet box.
5. Attach the fixture to the mounting plate (A) by inserting headless screws (D) into holes on back plate, and then secure it
with two rubber pads (H) and two ball nuts (G).
NOTE: With silicone caulking compound,caulk complete around the back plate meets with the wall surface to
prevent water from seeping into the outlet box.
6. Attach the candle tubes onto the sockets.
7. Install three bulbs (not included). See relamping label at socket area or packaging for maximum allowed wattage.
Turn on the power at fuse or circuit box.
1. Turn off the power at the fuse or circuit box before starting installation.
2. Loosen the wire connector connected with the wires from photocell. (See Fig.2)
Note: Do not move the photocell to prevent water from seeping into the outlet box.
3. Take a white pigtail and black pigtail and make wire connections using wire connector (C): (See Fig.3)
a. The black wire from the fixture to one end of the black pigtail.
b. The white wire from the fixture to one end of the white pigtail.
c. The other end of the black pigtail to the black wire from the power source.
d. The other end of the white pigtail to the white wire from the power source.
Put all wires back into the back plate of the fixture.
Operation the Unit Without Photocell
Photocell
White Wires From Photocell
Wire Connector
Wires From Fixture White Pigtail
Red Wires From Photocell
Black wires From Photocell
Fig.2
Wires From Fixture
Wires From
Main Power
Wire Connector (C)
Pigtail
Fig.3
Turn on the power at fuse or circuit box.
Glass Panel
Clip
Metal
Frame Fig.1

181205
The following parts are available for re-order if damaged or missing.
Spare Parts List:
Mounting Hardware
6046MM (1SET)
Glass Shade
10066RG (4PCS)
A: 9"
B:15-3/4"
C: 10-1/4"
Green Grounding
Screw (C)
Headless screw (D)
Mounting Screw (B)
Wire Connector (F)
Lock Nut (E)
Ball Nut (G) Rubber Pad (H)
Mounting plate (A)
A
C
B
