Vecow ABP-3000 User manual

USER
Manual
USER
Manual
1.0.0 Edition 20200713
Intel®Core™U-series Processor (Whiskey Lake) Ultra-slim Fanless
Embedded System, 4 GigE LAN with 2 PoE+, 4 USB, 4 COM,
9V to 50V DC-in, -40°C to 75°C
ABP-3000

ii
©Vecow ABP-3000 User Manual
Version Date Page Description Remark
0.10 2020/07/10 All Preliminary Release
1.00 2020/07/13 O󰀩cial Release
Record of Revision

iii
©Vecow ABP-3000 User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
Vecow Co., Ltd. is under no legal commitment to the details of this document.
Vecow shall not be liable for direct, indirect, special, incidental, or consequential
damages arising out of the use of this document, the products, or any third party
infringements, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual comply with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Vecow ABP-3000 User Manual
Part Number Description
ABP-3000-8665U ABP-3000, onboard Intel® Core™ i7-8665UE, 4 GigE LAN with
2 PoE+, 4 USB 3.1, 4 COM, 16 Isolated DIO, 4 M.2, 1 Mini PCIe
ABP-3000-8145U ABP-3000, onboard Intel® Core™ i3-8145UE, 4 GigE LAN with
2 PoE+, 4 USB 3.1, 4 COM, 16 Isolated DIO, 4 M.2, 1 Mini PCIe
Order Information

v
©Vecow ABP-3000 User Manual
Part Number Description
DDR4 32G Certied DDR4 32GB 2666MHz RAM
DDR4 16G Certied DDR4 16GB 2666/2400/2133 MHz RAM
DDR4 8G Certied DDR4 8GB 2666/2400/2133 MHz RAM
DDR4 4G Certied DDR4 4GB 2666/2400/2133 MHz RAM
PWA-120WM4P 120W, 24V, 90V AC to 264V AC Power Adapter with 4-pin
M.2 Storage Module M.2 Key M/Key B PCIe Storage Module
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector and
DIN-Rail Mounting
5G Module 5G Module with Antenna
4G Module 4G/GPS Module with Antenna
WiFi & Bluetooth
Module WiFi & Bluetooth Module with Antenna
Optional Accessories

vi
©Vecow ABP-3000 User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.4 Supported CPU List 5
1.5 Mechanical Dimension 5
CHAPTER 2 GETTING TO KNOW YOUR ABP-3000 6
2.1 Packing List 6
2.2 Front Panel I/O Functions 7
2.3 Rear Panel I/O Functions 12
2.4 Main Board Expansion Connectors 16
2.5 Main Jumper Settings 27
2.6 Ignition Control 30
CHAPTER 3 SYSTEM SETUP 33
3.1 How to Open Your ABP-3000 33
3.2 Installing DDR4 SO-DIMM Modules 35
3.3 Installing Mini PCIe Card 36
3.4 Installing M.2 37
3.5 Installing Antenna Cable 41
3.6 Installing SIM Card 42
3.7 Mount Your ABP-3000 43
CHAPTER 4 BIOS SETUP 44
4.1 Entering BIOS Setup 44
4.2 Main 45
4.3 Advanced 45

vii
©Vecow ABP-3000 User Manual
4.4 Chipset 56
4.5 Security 62
4.6 Boot 64
4.7 Save & Exit 65
APPENDIX A : Isolated DIO Guide 66
APPENDIX B : Software Functions 70
APPENDIX C : RAID Functions 74
APPENDIX D : Power Consumption 81
APPENDIX E : Supported List (Memory/M.2) 84

1
©Vecow ABP-3000 User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
Vecow ABP-3000 Series is powered by 8th Gen Intel® Core™ U-series
processor with support for wide range temperature from -40°C to 75°C and wide
range 9V to 50V power input. Vecow ABP-3000 Series is designed for edge
computing and harsh industrial applications including Machine Vision, In-vehicle
Computing, Industrial Automation, Intelligent Control, AMR/AGV, or any AIoT/
Industry 4.0 applications.
ABP-3000 Series features an ultra-slim form factor, only 1.28" in height and it
has a complete cable-less design that simplies the cable routing and ensures
system reliability. The system features a small footprint without sacrificing
functionality. ABP-3000 Series integrates 4 USB, 4 GigE LAN brought out 2
PoE+, 4 COM RS-232/422/485, 2 SIM sockets and 16 Isolated DIO. To fulfill
a variety of di󰀨erent applications requirements, ABP-3000 Series supports an
array of M.2 conguration options such as Key B/Key M/Key E, and Mini PCIe
for expansions, delivering faster throughput and simplied installation.
Featuring outstanding performance, ultra-slim integration, rugged reliability
and compact extensions, ABP-3000 Series is a smart solution for industrial
applications including Machine Vision, In-vehicle Computing, Industrial
Automation, Intelligent Control, AMR/AGV, or any AIoT/Industry 4.0 applications.
1

2
©Vecow ABP-3000 User Manual GENERAL INTRODUCTION
1.2 Features
• 8th Generation Intel® Core™ i U-series processor (Whiskey Lake) supports up
to 40% greater productivity than former generation solution
• Ultra-slim and cableless design supports wide range temperature of -40°C to
75°C with fanless operation
• 2 DDR4 2400MHz memory, up to 64GB
• Dual independent DisplayPorts display supports up to 4K resolution
• 4-port USB 3.1 support up to 10Gbps data transfer
• 4 Independent GigE LAN with 2 IEEE 802.3at PoE+
• SIM Socket for 5G/WiFi/4G/3G/LTE/GPRS/UMTS
• 4 COM RS-232/422/485, 16 Isolated DIO
• 9V to 50V DC wide range Power Input
• Ignition Power Control, TPM 2.0
• Expansion : M.2 Key B, M.2 Key M, M.2 Key E and Mini PCIe
• Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI
accelerator and advanced Edge AI applications

3
©Vecow ABP-3000 User Manual GENERAL INTRODUCTION
1.3 Product Specication
System
Processor Quad Core Intel® Core™ i7-8665UE/i3-8145UE Processor
(Whiskey Lake)
Chipset Intel® SoC (Cannon Lake)
BIOS AMI
SIO IT8786E
Memory 2 DDR4 2400MHz SO-DIMM, up to 64 GB
Graphics
Graphics Processor Intel® UHD Graphics 620
Interface 2 DisplayPort : Up to 4096 x 2304 @60Hz
Ethernet
LAN 1 GigE LAN by Intel® Ethernet Controller I350
LAN 2 GigE LAN by Intel® Ethernet Controller I350
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350 with
Power On/O󰀨 Control
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350 with
Power On/O󰀨 Control
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Storage
M.2 • 1 M.2 Key M Socket (PCIe x4/SATA)
• 1 M.2 Key B Socket (PCIe x2/SATA)
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB 4 USB 3.1 (External)
Isolated DIO 16 Isolated DIO : 8 DI, 8 DO
LED HDD, PoE
SIM Card 2 Internal SIM Card Socket
Expansion
M.2 • 1 M.2 Key E Socket (PCIe x1)
• 1 M.2 Key B Socket (PCIe x2/USB 3.1)
Mini PCIe 1 Mini PCIe for PCIe/USB/SIM Card

4
©Vecow ABP-3000 User Manual GENERAL INTRODUCTION
Power
Power Input 9V to 50V DC-in
Power Interface Mini DIN
Ignition Control 16 Mode
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
Microsoft Windows 10
Linux Fedora 19, Ubuntu 10.04 LTS, or Linux Kernel 3.0 above
Mechanical
Dimension (W x L x H) 224.0mm x 149.0mm x 32.6mm (8.82" x 5.87" x 1.28")
Weight 1.4 kg (3.09 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature -40°C to 75°C (-40°F to 167°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

5
©Vecow ABP-3000 User Manual GENERAL INTRODUCTION
1.4 Supported CPU List
Processor No. Cores TDP Cache Max. Frequency ECC Memory
Intel® Core™ i7-8665UE 4 15W 8M Up to 4.4GHz N
Intel® Core™ i3-8145UE 215W 4M Up to 3.9GHz N
1.5 Mechanical Dimension
224.0 (8.82)
239.0 (9.41)
254.0 (10.00)
100.0 (3.94) 136.0 (5.35) 149.0 (5.87)
A
32.6 (1.28)
34.2 (1.35)
A Detail
2:1
20.0 (0.79)
R2.5 (R0.10)
R4.5 (R0.18)
Unit : mm (inch)

6
©Vecow ABP-3000 User Manual GETTING TO KNOW YOUR ABP-3000
2
GETTING TO KNOW YOUR ABP-3000
2.1 Packing List
Item Description Qty
1ABP-3000 Ultra-Compact Embedded System 1
2ABP-3000 series accessory box, which contains
Item Description Outlook Usage P/N Qty
3PHILLPIS
M2.5x6L, Ni
Mini PCIe
slot 53-2426906-30B 1
4PHILLPIS
M3x6L, Ni+Ny M.2 53-2426206-80B 3
5Terminal block
3-pin (3.5mm) Switch 51-2211R03-S1A 1
6Terminal block
20-pin (2.54mm)
Isolated DIO/
GPIO 51-2112R20-S1D 1
7Foot Pad Foot pad 53-4000042-303 4
8
Wall mount
bracket
ABP-3000
Mount 62-00P0423-800 2
9 Flat M3x4L, Ni Wall mount
bracket 53-2466204-30B 4
10 M2x2L Ni M.2 Key B
3042/3052 53-M004600-000 1

7
©Vecow ABP-3000 User Manual GETTING TO KNOW YOUR ABP-3000
2.2 Front Panel I/O Functions
In Vecow's ABP-3000 series family, all I/O connectors are located on the front
panel. Most of the general connections to the computer device, such as audio,
USB, LAN, and Display Port, are placed on the front panel.
2.2.1 Reset Tact Switch
It is a hardware reset switch. Use this switch to reset the system without power
o󰀨 the system. Press the Reset Switch for a few seconds, and then the reset
function will be enabled.
2.2.2 Power Button
The power button is a non-latched switch with dual color LED indication. It
indicates power statuses : S0, S3 and S5. More details on the LED indications
are listed in the following chart :
LED Color Indication System Status
Solid Blue S0 System working
Solid Orange S3, S5 Suspend to RAM, System o󰀨 with standby power
To power on ABP-3000, press the power button which will light the blue LED.
To power o󰀨 ABP-3000, you can either command shutdown by OS operation or
simply press the power button.
If system error appears, press and hold the power button for four seconds to
shut down the machine directly.
Please do note that a four-second interval between each two power-on/power-
o󰀨 operation is necessary in normal working status. (For example, once turning
o󰀨 the system, you have to wait for four seconds to initiate another power-on
operation).

8
©Vecow ABP-3000 User Manual GETTING TO KNOW YOUR ABP-3000
2.2.3 HDD LED Indicator
Yellow-HDD LED : A hard disk LED. If the LED is on, it indicates that the
system's storage is functional. If it is o󰀨, it indicates that the system's storage is
not functional. If it is ashing, it indicates data access activities are in progress.
LED Color Indication System Status
Yellow HDD • On/Off : Storage status, function or not.
• Twinkling : Data transferring.
2.2.4 Audio Connector
There are two audio connectors, mic-in and line-out, on the front side of ABP-
3000. Onboard Realtek ALC892 audio codec supports 5.1 channel HD audio
and fully complies with Intel® High Denition Audio (Azalia) specications.
To utilize the audio function on the Windows platform, you need to install
corresponding drivers for Realtek ALC892 codec.
2.2.5 Remote Power On/O Switch
It is a 3-pin power-on/power-o󰀨 switch through Phoenix Contact terminal block.
You could turn on or o󰀨 the system power by using this contact. This terminal
block supports dual function on soft power-on/power-o󰀨 (instant o󰀨 or delay four
seconds), and suspend mode.
Pin No. Denition
1IGNITION
2SW+
3SW-

9
©Vecow ABP-3000 User Manual GETTING TO KNOW YOUR ABP-3000
2.2.6 USB 3.1
There are 4 USB 3.1 connections available supporting up to 10GB per second data
rate in the front side of ABP-3000 series. It also compliant with the requirements of
Super Speed (SS), high speed (HS), full speed (FS) and low speed (LS).
2.2.7 Display Port
Onboard Display Port support auxiliary channel dual mode, connection supports
up to 4096x2304 resolution at 60Hz.
2.2.8 PoE Ports
There are 2 RJ45 connectors in the rear side of ABP-3000. It supports IEEE 802.3at
(PoE+) Power over Ethernet (PoE) connection delivering up to 37W/54V per port
and 1000BASE-T gigabit data signals over standard Ethernet Cat 5/Cat 6 cable.
Each PoE connection is powered by Intel® I350 Gigabit Ethernet controller and
independent PCI express interface to connect with multi-core processor for
network and data transmit optimization. Only when PoE port starts to supply
power to power devices, the dedicated LED will be lightened.
PS. Suggest to use PoE function when power input is over 12V.
The pin-outs of LAN 3 and LAN 4 are listed as follows :
Pin No. 10/100 Mbps 1000Mbps PoE
1E_TX+ MDI0_P PoE+
2E_TX- MDI0_N PoE+
3E_RX+ MDI1_P PoE-
4 ------ MDI2_P ------
5 ------ MDI2_N ------
6 E_RX- MDI1_N PoE-
7------ MDI3_P ------
8 ------ MDI3_N ------

10
©Vecow ABP-3000 User Manual GETTING TO KNOW YOUR ABP-3000
Each LAN port is supported by standard RJ-45 connector with LED indicators to
present Active/Link/Speed status of the connection.
The LED indicator on the right bottom corner lightens in solid green when the
cable is properly connected to a 100Mbps Ethernet network; The LED indicator
on the right bottom corner lightens in solid orange when the cable is properly
connected to a 1000Mbps Ethernet network; The left LED will keep twinkling/o󰀨
when Ethernet data packets are being transmitted/received.
LED Location LED Color 10Mbps 100Mbps 1000Mbps
Right Green/
Orange O󰀨 Solid Green
Solid
Orange
Left Yellow Twinkling
Yellow
Twinkling
Yellow
Twinkling
Yellow 18
PoE LED LED Color PoE Status
LED 1 - 2 Solid Green PoE ON
2.2.9 10/100/1000 Mbps Ethernet Port
There are two 8-pin RJ-45 jacks supporting 10/100/1000 Mbps Ethernet connections
on the front side of ABP-3000. LAN 1 and LAN 2 are powered by Intel® I350 Ethernet
engine.
• Intel® I350 Gigabit Ethernet Controller supports 1Gbps data ratet
• IEEE 802.3 Fast Ethernet over optical fiber standard compliant
• IEEE 1588 Precision Time Protocol (PTP)
• Up to 9.5KB Jumbo Frame
• Dual 100BASE-FX fiber ports
• Supports Wake-on-LAN (WoL) & PXE
Using suitable RJ-45 cable, you can connect the ABP-3000 system to a
computer or to any other devices with Ethernet connection, for example, a hub
or a switch. Moreover, both LAN 1 and LAN 2 support "Wake" on LAN and pre-
boot functions. The pinouts of LAN 1 and LAN 2 are listed in the following chart :

11
©Vecow ABP-3000 User Manual GETTING TO KNOW YOUR ABP-3000
Pin No. 10/100 Mbps 1000Mbps
1E_TX+ MDI0_P
2E_TX- MDI0_N
3E_RX+ MDI1_P
4 ------ MDI2_P
5 ------ MDI2_N
6 E_RX- MDI1_N
7------ MDI3_P
8 ------ MDI3_N
LED Location LED Color 10Mbps 100Mbps 1000Mbps
Right Green/
Yellow O󰀨 Solid Green
Solid
Yellow
Left Green Blinking
Green
Blinking
Green
Blinking
Green
Each LAN port is supported by a standard RJ-45 connector with LED indicators
to present active/link/speed statuses of the connection.
The LED indicator on the right bottom corner becomes solid green when the
cable is properly connected to a 100Mbps Ethernet network; it becomes solid
orange when the cable is properly connected to a 1000Mbps Ethernet network.
The left LED will keep blinking off when Ethernet data packets are being
transmitted or received.
18

12
©Vecow ABP-3000 User Manual GETTING TO KNOW YOUR ABP-3000
2.3 Rear Panel I/O Functions
2.3.1 Isolated DIO
There is a 16-bit (8-bit DI, 8-bit DO) connectors in the rear side. DI/DIO support
NPN (sink) and PNP (Source) mode, Each DI channel is equipped with a
photocouper for isolated protection.
Each DO with isolator chip, Cong by a Jumper for each DIO connector.
DO Safety-Related Certications :
• 4242-VPK Basic Isolation per DIN V VDE V 0884-10
and DIN EN 61010-1
• 3-KVRMS Isolation for 1 minute per UL 1577
• CSA Component Acceptance Notice 5A, IEC 60950-1
and IEC 61010-1 End Equipment Standards
• GB4943.1-2011 CQC Certified
DIO Connectors pin out :
Pin No. Denition Function
1INPUT 0 SIO_GPI80
2INPUT 1 SIO_GPI81
3INPUT 2 SIO_GPI82
4 INPUT 3 SIO_GPI83
5 INPUT 4 SIO_GPI84
6 INPUT 5 SIO_GPI85
7INPUT 6 SIO_GPI86
8 INPUT 7 SIO_GPI87
9 +VDI_COM1
10 GND_ISO_DIO1
11 OUTPUT 0 SIO_GPO70
12 OUTPUT 1 SIO_GPO71
13 OUTPUT 2 SIO_GPO72
14 OUTPUT 3 SIO_GPO73
15 OUTPUT 4 SIO_GPO74
16 OUTPUT 5 SIO_GPO75
17 OUTPUT 6 SIO_GPO76
18 OUTPUT 7 SIO_GPO77
19 GND_ISO_DIO1
20 External 6-40VDC (NPN)
External 6-48VDC (PNP) -

13
©Vecow ABP-3000 User Manual GETTING TO KNOW YOUR ABP-3000
DI reference circuit :
Sink Mode
(NPN) Power
Supply
6-48V DC
V+
V-
DIO Connector
DI_COM (Pin 9)
DI (Pin 1-8)
Source Mode
(PNP) Power
Supply
6-48V DC
V+
V-
DIO Connector
DI_COM (Pin 9)
DI (Pin 1-8)
LDO
ISOLATION
LOGIC
Driver
OCP
OTP
VCCI VEXT
GNDI GNDO
INXOUTX
ENX
DIO_VDC (20)
OUT (11)
GNDO (10.19)
Internal Circuit External Device
DO Signal circuit in SINK mode (NPN)
(300mA)
LOAD
VDD
6-40V
VDC
+
-
P
N
R
I
DO reference circuit :
Sink Mode (NPN, Default)
LDO
ISOLATION
VCCI VEXT
GNDI GNDO
INXOUTX
ENX
DIO_VDC (20)
OUT (11)
GNDO (10.19)
Internal Circuit External Device
DO Signal circuit in source mode (PNp)
(300mA)
20K
1.5K
3K
7.2K
GNDO
LOAD
VDD
6-40V
VDC
+
-
P
R
I
N
Source (PNP)
