Vecow MTC-4015 User manual

USER
Manual
USER
Manual
1.1.0 Edition 20161201
MTC-4015
15” Fanless Multi-Touch Computer, 6 GbE LAN with 4 PoE+,
2 SIM, 5 USB, Intel®Core™i7/i5/i3 Processor (Broadwell-U)

ii
Version Date Page Description Remark
0.1 03/17/2016 All Preliminary Release
1.0 03/22/2016 All Ofcial Release
1.1 12/01/2016 50-51 Update
Record of Revision

iii
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product offerings and specications are subject to change without prior notice. It
does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable for
direct, indirect, special, incidental, or consequential damages arising out of the
use of the product or documentation, nor for any infringements upon the rights
of third parties, which may result from such use.
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
FCC
The product (s) described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names and
trademarks belong to their respective owners.
Declaimer
Declaration of Conformity
Copyright and Trademarks

iv
Part Number Description
MTC-4015-
PoER650U
15" Fanless Multi-Touch Computer, 6 GbE LAN with 4 PoE+, 2 SSD
Tray, 2 SIM, 4 COM, 5 USB, Isolated DIO, Onboard Intel® Core™
i7-5650U
MTC-4015-
PoER350U
15" Fanless Multi-Touch Computer, 6 GbE LAN with 4 PoE+, 2 SSD
Tray, 2 SIM, 4 COM, 5 USB, Isolated DIO, Onboard Intel® Core™
i5-5350U
MTC-4015-
PoER010U
15" Fanless Multi-Touch Computer, 6 GbE LAN with 4 PoE+, 2 SSD
Tray, 2 SIM, 4 COM, 5 USB, Isolated DIO, Onboard Intel® Core™
i3-5010U
MTC-4015-
2R650U
15" Fanless Multi-Touch Computer, 2 GbE LAN, 2 SSD Tray, 2 SIM,
4 COM, 5 USB, DIO, Onboard Intel® Core™ i7-5650U
MTC-4015-
2R350U
15" Fanless Multi-Touch Computer, 2 GbE LAN, 2 SSD Tray, 2 SIM,
4 COM, 5 USB, DIO, Onboard Intel® Core™ i5-5350U
MTC-4015-
2R010U
15" Fanless Multi-Touch Computer, 2 GbE LAN, 2 SSD Tray, 2 SIM,
4 COM, 5 USB, DIO, Onboard Intel® Core™ i3-5010U
MTC-4015P 15" Fanless Multi-Touch Computer with 5th Gen Intel® Core™ i7/ i5/
i3 Processor (Broadwell-U), built with IP65 Front Bezel
Order Information

v
Part Number Description
DDR3L8G Certied DDR3L-1600 8G RAM
DDR3L4G Certied DDR3L-1600 4G RAM
PWA-120W 120W, 24V, 90VAC to 264VAC Power Adapter with 3-pin
Terminal Block
PWA-120WM4P 120W, 24V, 90VAC to 264VAC Power Adapter with 4-pin Mini-
DIN Connector
PWA-160W-WT 160W, 24V, 85VAC to 264VAC Power Adapter with 3-pin
Terminal Block, Wide Temperature -30°C to +70°C
Panel-Mount Panel Mount Kit
VESA Stand VESA Table Stand
TMBK-20P-100 Terminal Block 20-pin to SCSI Cable, 100cm
TMBK-20P-500 Terminal Block 20-pin to SCSI Cable, 500cm
TMB-SCSI-20P Terminal Board with One 20-pin SCSI Connector and DIN-
Rail Mounting
3G Module Mini PCIe 3G/GPS Module with Antenna
4G Module Mini PCIe 4G/GPS Module with Antenna
WiFi Module Mini PCIe WiFi Module with Antenna
WiFi & Bluetooth
Module Mini PCIe WiFi & Bluetooth Module with Antenna
Optional Accessories

vi
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 2
1.3.1 Specications of MTC-4015-PoER 2
1.3.2 Specications of MTC-4015-2R 4
1.4 Supported CPU List 7
1.5 Mechanical Dimensions 8
1.5.1 Dimensions of MTC-4015-PoER 8
1.5.2 Dimensions of MTC-4015-2R 8
1.5.3 Dimensions of MTC-4015P-PoER 9
1.5.4 Dimensions of MTC-4015P-2R 9
CHAPTER 2 GETTING TO KNOW YOUR MTC-4015 10
2.1 Packing List 10
2.2 I/O Functions 10
2.3 Rear Panel I/O and Functions 16
2.4 Main Board Expansion Connectors 21
2.5 Main Board Jumper Settings 32
2.6 Ignition Control 36
CHAPTER 3 SYSTEM SETUP 39
3.1 How to Open Your MTC-4015/MTC-4015P 39
3.2 Installing DDR3L SO-DIMM Modules 43
3.3 Installing Mini PCIe Cards 44
3.4 Installing Antenna Cable 45
3.5 Installing CFast Card and SIM Card 47
3.6 Installing SSD/HDD 48
3.7 Mounting MTC-4015 50

vii
CHAPTER 4 BIOS AND DRIVER 52
4.1 BIOS Settings 52
4.2 Main Menu 53
4.3 Advanced Function 54
4.4 Chipset Function 62
4.5 Boot Function 63
4.6 Save & Exit 64
APPENDIX A : GPIO and WDT Functions 65
A.1 Function Description 65
A.2 Entry Functions 65

1
GENERAL INTRODUCTION
1
GENERAL INTRODUCTION
Vecow MTC-4015 Series Fanless Multi-Touch Computer is a 15 inch all-in-
one fanless Multi-Touch Computer for Internet of Thing (IoT) and/ or Industry
4.0 applications with excellent performance and trusted reliability. Powered by
5th generation Intel® Core™ i7/ i5/ i3 U-Series SoC (Broadwell-U) engine, dual
DDR3L 1333/ 1600 MHz SO-DIMMs, up to 16GB memory. Advanced Intel® HD
Graphics 6000 supports 1080p Full HD displays, onboard DVI-D and DisplayPort
display interface delivers up to 20% enhanced graphics performance than former
generation.
Full HD LCD panel with LED backlight, Projected Capacitive 20-point Multi-
Touch Screen with 7H Anti-Scratch Surface, Touchscreen works with gloves, 6
Gigabit LAN ports with 4 IEEE 802.3at PoE+ports, 2 Mini PCIe sockets for PCIe/
USB/ External SIM Card/ mSATA, 2 External SIM Card sockets support 3G/ 4G/
LTE/ WiFi/ GPRS/ UMTS, dual External 2.5” SSD/HDD Tray, 1 External CFast
socket, 16 Isolated DIO, 2 USB 3.0, 3 USB 2.0, 4 COM RS-232/ 422/ 485, Ignition
Control, 6V to 36V wide range power input with up to 80V smart surge protection,
all-in-one fanless design, -20°C to 70°C operating temperature, optional supports
sunlight readable features and IP65 front panel protection, Vecow MTC-4015 is
ready to customize for your requirements.
Vecow MTC-4015 Series Fanless Multi-Touch Computer integrates outstanding
system performance, considerate manageability, smart protection functions and
trusted reliability for Smart Manufacturing, Medical, Industrial Automation, HMI,
Infotainment, Intelligent Control, Self-service, Smart Transportation and any IoT
(Internet of Thing)/ Industry 4.0 applications.
1.1 Overview

2
GENERAL INTRODUCTION
©Vecow MTC-4015 User Manual
1.3 Product Specication
1.3.1 Specications of MTC-4015-PoER
Panel
Panel Type TFT LCD
Active Area 15” (4 : 3)
Max Resolution 1024 x 768
Display Color 16.7M
Backlight LED Backlight
Brightness (cd/m2) 250
Viewing Angle 160°/160° (H/V)
Contrast Ratio 600 : 1
Touch Screen
Touch Screen Type 20-point Projected Capacitive
Transparency 91%
Surface Hardness 7H Surface Hardness
Control Interface USB Interface
System
Processor Intel® Core™ i7-5650U/ i5-5350U/ i3-5010U Processor
(Broadwell-U)
Chipset Intel® SoC
Memory 2 DDR3L 1333/ 1600 MHz SO-DIMM, up to 16GB
Graphics Intel® HD Graphics 6000
=
>
1.2 Features
• 15” 1024 x 768 (4 : 3) LCD Panel with LED Backlight
• Projected Capacitive Multi-Touch Screen with 7H Anti-Scratch Surface, up to
20-point Multi-touch
• Fanless, 5th generation Intel® Core™ i7/ i5/ i3 U-Series Processor (Broadwell-U)
• 6V to 36V DC-in, 80V Surge Protection
• 6 Gigabit LAN with 4 IEEE 802.3at PoE+
• 2 External SIM Socket support 3G/ 4G/ LTE/ WiFi/ GPRS/ UMTS
• External CFast Socket, 2 SSD Tray, 4 COM, 2 USB 3.0, 3 USB 2.0
• 16 Isolated DIO, Ignition Control
• Touchscreen works with gloves
• IP65 Front Panel Protection (Optional)

3
GENERAL INTRODUCTION
Audio Realtek ALC892, 5.1 Channel HD Audio
OS Support Windows 8, Windows 7, Linux
I/O Interface
Serial 4 COM RS-232/ 422/ 485
USB • 2 External USB 3.0
• 3 External USB 2.0
DIO 16 Isolated DIO : 8DI, 8DO
LAN • LAN 1 : Intel® I218 Gigabit LAN supports iAMT
• LAN 2 : Intel® I210 Gigabit LAN
• LAN 3 : Intel® I210 Gigabit LAN supports support IEEE
802.3at PoE+
• LAN 4 : Intel® I210 Gigabit LAN supports support IEEE
802.3at PoE+
• LAN 5 : Intel® I210 Gigabit LAN supports support IEEE
802.3at PoE+
• LAN 6 : Intel® I210 Gigabit LAN supports support IEEE
802.3at PoE+
Audio 1 Mic-in, 1 Line-out
Display • DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 3840 x 2160 @ 60Hz
LED Power, HDD
CFast 1 External CFast Socket, Push-in/ Push-out Ejector
SIM Card 2 External SIM Card Socket
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Mini PCIe for PCIe/ USB/ External SIM Card
• 1 Mini PCIe for PCIe/ USB/ External SIM Card/ mSATA
Storage
SATA 2 SATA III (External, 6Gbps)
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/ Push-out Ejector
• 2 2.5” SSD/ HDD Tray
Power
Power Input 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Power Adapter AC to DC 120W Power Adapter (Optional)
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power

4
GENERAL INTRODUCTION
©Vecow MTC-4015 User Manual
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Mechanical
Dimension (W x L x H) 350.0mm x 274.0mm x 97.6mm (13.8” x 10.8” x 3.8”)
Weight 5.3 kg (11.7 lb)
Front Panel Protection IP65 Compliant (Optional)
Mounting • VESA Mount (75 x 75mm, 100 x 100mm)
• Panel Mount
Environment
Operating Temperature -20°C to 70°C (-4°F to 158°F)
Storage Temperature -30°C to 80°C (-22°F to 176°F)
Humidity 10% to 90% Humidity, non-condensing
Shock • IEC 60068-2-27
• 20G, Half-sine, 11ms
Vibration • IEC 60068-2-64
• Non-operation : 10Hz to 200Hz, 1.5Grms, X, Y, Z,
30 mins each Axis
EMC CE, FCC
1.3.2 Specications of MTC-4015-2R
Panel
Panel Type TFT LCD
Active Area 15” (4 : 3)
Max Resolution 1024 x 768
Display Color 16.7M
Backlight LED Backlight
Brightness (cd/m2) 250
Viewing Angle 160°/160° (H/V)
Contrast Ratio 600 : 1

5
GENERAL INTRODUCTION
Touch Screen
Touch Screen Type 20-point Projected Capacitive
Transparency 91%
Surface Hardness 7H Surface Hardness
Control Interface USB Interface
System
Processor Intel® Core™ i7-5650U/ i5-5350U/ i3-5010U Processor
(Broadwell-U)
Chipset Intel® SoC
Memory 2 DDR3L 1333/ 1600 MHz SO-DIMM, up to 16GB
Graphics Intel® HD Graphics 6000
Audio Realtek ALC892, 5.1 Channel HD Audio
OS Support Windows 8, Windows 7, Linux
I/O Interface
Serial 4 COM RS-232/ 422/ 485
USB • 2 External USB 3.0
• 3 External USB 2.0
DIO 16 DIO : 8DI, 8DO
LAN • LAN 1 : Intel® I218 Gigabit LAN supports iAMT
• LAN 2 : Intel® I210 Gigabit LAN
Audio 1 Mic-in, 1 Line-out
Display • DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 3840 x 2160 @ 60Hz
LED Power, HDD
CFast 1 External CFast Socket, Push-in/ Push-out Ejector
SIM Card 2 External SIM Card Socket
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Mini PCIe for PCIe/ USB/ External SIM Card
• 1 Mini PCIe for PCIe/ USB/ External SIM Card/ mSATA
Storage
SATA 2 SATA III (External, 6Gbps)
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/ Push-out Ejector
• 2 2.5” SSD/ HDD Tray
=
>

6
GENERAL INTRODUCTION
©Vecow MTC-4015 User Manual
Power
Power Input 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Power Adapter AC to DC 120W Power Adapter (Optional)
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Mechanical
Dimension (W x L x H) 350.0mm x 274.0mm x 97.6mm (13.8” x 10.8” x 3.8”)
Weight 5.3 kg (11.7 lb)
Front Panel Protection IP65 Compliant (Optional)
Mounting • VESA Mount (75 x 75mm, 100 x 100mm)
• Panel Mount
Environment
Operating Temperature -20°C to 70°C (-4°F to 158°F)
Storage Temperature -30°C to 80°C (-22°F to 176°F)
Humidity 10% to 90% Humidity, non-condensing
Shock • IEC 60068-2-27
• 20G, Half-sine, 11ms
Vibration • IEC 60068-2-64
• Non-operation : 10Hz to 200Hz, 1.5Grms, X, Y, Z,
30 mins each Axis
EMC CE, FCC

7
GENERAL INTRODUCTION
1.4 Supported CPU List
CPU Name TDP Cache Max. Frequency Embedded
i7-5557U 28W 4M Up to 3.40 GHz
i7-5650U 15W 4M Up to 3.20 GHz Yes
i7-5600U 15W 4M Up to 3.20 GHz
i7-5550U 15W 4M Up to 3.00 GHz
i7-5500U 15W 4M Up to 3.00 GHz
i5-5287U 28W 3M Up to 3.30 GHz
i5-5257U 28W 3M Up to 3.10 GHz
i5-5350U 15W 3M Up to 2.90 GHz Yes
i5-5300U 15W 3M Up to 2.90 GHz
i5-5250U 15W 3M Up to 2.70 GHz
i5-5200U 15W 3M Up to 2.70 GHz
i3-5157U 28W 3M Up to 2.5 0 GHz
i3-5020U 15W 3M Up to 2.20 GHz
i3-5015U 15W 3M Up to 2.10 GHz Yes
i3-5010U 15W 3M Up to 2.10 GHz
i3-5005U 15W 3M Up to 2.00 GHz
Pentium 3805U 15W 2M Up to 1.90 GHz
Pentium 3825U 15W 2M Up to 1.90 GHz
Celeron 3765U 15W 2M Up to 1.90 GHz
Celeron 3755U 15W 2M Up to 1.70 GHz Yes
Celeron 3215U 15W 2M Up to 1.70 GHz
Celeron 3205U 15W 2M Up to 1.50 GHz

8
GENERAL INTRODUCTION
©Vecow MTC-4015 User Manual
75.0 (3.0”)
100.0 (3,9”)
75.0 (3.0”)
100.0 (3.9”)
306.2 (12.1”)
350.0 (13.8”)
230.2 (9.1”)
274.0 (10.8”)
86.0 (3.4”) 102.0 (4.0”) 86.0 (3.4”)
86.0 (3.4”) 175.2 (6.9”) 88.9 (3.5”)
252.2 (9.9”)
328.2 (12.9”) 21.5 (0.8”)
97.6 (3.8”)
1.5 Mechanical Dimensions
1.5.1 Dimensions of MTC-4015-PoER
1.5.2 Dimensions of MTC-4015-2R
75.0 (3.0”)
100.0 (3,9”)
75.0 (3.0”)
100.0 (3.9”)
306.2 (12.1”)
350.0 (13.8”)
230.2 (9.1”)
274.0 (10.8”)
86.0 (3.4”) 102.0 (4.0”) 86.0 (3.4”)
86.0 (3.4”) 175.2 (6.9”) 88.9 (3.5”)
252.2 (9.9”)
328.2 (12.9”) 21.5 (0.8”)
97.6 (3.8”)
Unit: mm (inch)
Unit: mm (inch)

9
GENERAL INTRODUCTION
328.2 (12.9”) 306.2 (12.1”)
252.2 (9.9”)
230.2 (9.1”)
353.0 (13.9”)
429,0 (16.9”)
125.5 (4.9”) 175.2 (6.9”) 128.4 (5.1”)
25.0 (1.0”)
101.1 (4.0”)
125.5 (4.9”) 102.0 (4.0”) 125.5 (4.9”)
328.2 (12.9”) 306.2 (12.1”)
252.2 (9.9”)
230.2 (9.1”)
353.0 (13.9”)
429,0 (16.9”)
125.5 (4.9”) 175.2 (6.9”) 128.4 (5.1”)
25.0 (1.0”)
101.1 (4.0”)
125.5 (4.9”) 102.0 (4.0”) 125.5 (4.9”)
1.5.3 Dimensions of MTC-4015P-PoER
1.5.4 Dimensions of MTC-4015P-2R
Unit: mm (inch)
Unit: mm (inch)

10
GETTING TO KNOW YOUR MTC-4015©Vecow MTC-4015 User Manual
2
GETTING TO KNOW YOUR MTC-4015
2.1 Packing List
Item Description Qty
1MTC-4015, 15” Fanless Multi-Touch Computer (According
to the conguration you order, the MTC-4015 series may
contain SSD/HDD and DDR3L SO-DIMM. Please do verify
these items if possible.)
1
2Accessory box, it contains
● Vecow Drivers & Utilities DVD
● M2.5x6 screw for Mini PCIe Socket
● 3-pin pluggable terminal block
● 20-pin pluggable terminal block
● M3x6 screw for HDD
● HDD Tray Key
1
4
2
1
4
2
2.2 I/O Functions
USB 2.0USB 3.0
POWER
RESET
HDD
PWR
DPLAN1 LAN2 DVI-D
CFast
SIM 1 SIM 2

11
GETTING TO KNOW YOUR MTC-4015
2.2.1 Reset Tact Switch
It is a hardware reset switch. Use this switch to reset the system without power
off the MTC-4015. Press the Reset Switch for a few seconds, then reset will be
enabled.
USB 2.0USB 3.0
POWER
RESET
HDD
PWR
DPLAN1 LAN2 DVI-D
CFast
SIM 1 SIM 2
2.2.2 Power Button
The Power Button is a non-latched switch with dual color LED indication. It
indicates power status: S0, S3 and S5. More detail LED indications are listed as
follows:
To power on MTC-4015, press the power button and then the blue LED is
lightened. To power off MTC-4015, you can either command shutdown by OS
operation, or just simply press the power button.
If system error, you can just press the power button for 4 seconds to shut down
the machine directly.
Please do note that a 4-second interval between each 2 power-on/ power-off
operation is necessary in normal working status. (For example, once turning
off the system, you have to wait for 4 seconds to initiate another power-on
operation).
LED Color Power Status System Status
Solid Blue S0 System working
Solid Orange S3, S5 Suspend to RAM, System off with standby
power
USB 2.0USB 3.0
POWER
RESET
HDD
PWR
DPLAN1 LAN2 DVI-D
CFast
SIM 1 SIM 2

12
GETTING TO KNOW YOUR MTC-4015©Vecow MTC-4015 User Manual
2.2.3 CFast Card
Pin No. Description Pin No. Description
S1 GND PC6 NC
S2 SATA_TXP PC7 GND
S3 SATA_TXN PC8 CFAST_LED
S4 GND PC9 NC
S5 SATA_RXN PC10 NC
S6 SATA_RXP PC11 NC
S7 GND PC12 NC
PC1 GND PC13 +3.3V
PC2 GND PC14 +3.3V
PC3 GND PC15 GND
PC4 NC PC16 GND
PC5 NC PC17 NC
There is a CFast socket on the front panel supporting Type-I/ Type-II Compact
Flash card.
It is implemented by a SATA II Port from Broadwell-U PCH. Be sure to
disconnect the power source and unscrew the CFast socket cover before
installing a CFast card. The MTC-4015 does not support the CFast hot swap
and PnP (Plug and Play) functions. It is necessary to remove power source rst
before inserting or removing the CFast card.
The pinouts of CFast port are listed as follows:
USB 2.0USB 3.0
POWER
RESET
HDD
PWR
DPLAN1 LAN2 DVI-D
CFast
SIM 1 SIM 2

13
GETTING TO KNOW YOUR MTC-4015
2.2.4 PWR and HDD LED Indicator
LED Color Power Status System Status
Yellow HDD/ CFast • On/ Off : Storage status, function or not.
• Twinkling : Data transferring.
Green Power System power status (on/ off)
Yellow-HDD LED: A hard disk/ CFast LED. If the LED is on, it indicates that the
system’s storage is functional. If it is off, it indicates that the system’s storage is
not functional. If it is ashing, it indicates data access activities.
Green-Power LED: If the LED is solid green, it indicates that the system is
powered on.
USB 2.0USB 3.0
POWER
RESET
HDD
PWR
DPLAN1 LAN2 DVI-D
CFast
SIM 1 SIM 2
2.2.5 DVI-D Connector
The DVI-D connector on the front panel supports DVI display modes. The DVI
output mode supports up to 1920 x 1080 resolutions.
USB 2.0USB 3.0
POWER
RESET
HDD
PWR
DPLAN1 LAN2 DVI-D
CFast
SIM 1 SIM 2
2.2.6 DisplayPort
Onboard DisplayPort connection supports up to 3840 x 2160 resolutions at 60 Hz.
USB 2.0USB 3.0
POWER
RESET
HDD
PWR
DPLAN1 LAN2 DVI-D
CFast
SIM 1 SIM 2
