Vecow EVS-2000 Series User manual

USER
Manual
USER
Manual
1.3.0 Edition 20210311
EVS-2000
10th Gen. Intel®Xeon®/Core™i9/i7/i5/i3 Fanless AI Computing System with
NVIDIA®/AMD MXM GPU Graphics, High Performance Expandable

ii
Version Date Page Description Remark
1.00 01/28/2021 All O󰀩cial Release
1.10 01/29/2021 29, 42 Update
1.20 02/25/2021 8, 10 Update
1.30 03/11/2021 4, 6, 8, 10, 20 Update
Record of Revision

iii
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
Vecow Co., Ltd. is under no legal commitment to the details of this document.
Vecow shall not be liable for direct, indirect, special, incidental, or consequential
damages arising out of the use of this document, the products, or any third party
infringements, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual comply with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
Part Number Description
EVS-2010 EVS-2000, 2 GigE LAN, 1 PCIe x4, 6 USB 3.2, 3 COM, 2 SIM,
32 Isolated DIO, Fanless
EVS-2001 EVS-2000, 2 GigE LAN, 1 PCI, 6 USB 3.2, 3 COM, 2 SIM,
32 Isolated DIO, Fanless
EVS-2010F EVS-2000, 2 GigE LAN, 1 PCIe x4, 6 USB 3.2, 3 COM, 2 SIM,
32 Isolated DIO, With System Fan
EVS-2001F EVS-2000, 2 GigE LAN, 1 PCI, 6 USB 3.2, 3 COM, 2 SIM,
32 Isolated DIO, With System Fan
Order Information
CPU List
Series CPU Cores GHz TDP (W) ECC RAM
Intel® Xeon®
W-1290TE 10 4.5 35 Yes
W-1270TE 84.4 35 Yes
W-1250TE 6 3.8 35 Yes
Intel® Core™
i9-10900E 10 4.7 65 NA
i9-10900TE 10 4.5 35 NA
i7-10700E 84.5 65 NA
i7-10700TE 84.4 35 NA
i5-10500E 6 4.2 65 NA
i5-10500TE 6 3.7 35 NA
i3-10100E 4 3.8 65 Yes
i3-10100TE 4 3.6 35 Yes

v
Part Number Description
DDR4 32G Certied DDR4 32GB 3200MHz RAM
DDR4 16G Certied DDR4 16GB 3200MHz RAM
DDR4 8G Certied DDR4 8GB 3200MHz RAM
DDR4 4G Certied DDR4 4GB 3200MHz RAM
PWA-160WB-WT 160W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to +70°C
PWA-280WB-WT 280W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to +70°C
PWS-480W-WT 480W, 24V, 90V AC to 305V AC Power Supply, Wide-Temp, IP65
VESA Mount VESA Mounting Kit
DIN-RAIL DIN Rail Kit and VESA Mounting Kit
Rack Mount 2U Rackmount Kit
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector and
DIN-Rail Mounting
M.2 Storage Module M.2 Key M/Key B PCIe Storage Module
5G Module 5G Module with Antenna
4G Module 4G/GPS Module with Antenna
WiFi & Bluetooth WiFi & Bluetooth Module with Antenna
Order Accessories

vi
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of EVS-2010 3
1.3.2 Specications of EVS-2001 5
1.3.3 Specications of EVS-2010F 7
1.3.4 Specications of EVS-2001F 9
1.4 Supported CPU List 11
1.5 Mechanical Dimension 12
1.5.1 Dimensions of EVS-2000 12
1.5.2 Dimensions of EVS-2000F 12
CHAPTER 2 GETTING TO KNOW YOUR EVS-2000 13
2.1 Packing List 13
2.1.1 Packing List of EVS-2000 13
2.1.2 Packing List of EVS-2000F 14
2.2 Front Panel I/O & Functions 15
2.3 Rear Panel I/O & Functions 22
2.4 Main Board Expansion Connectors 29
2.5 Main Board Jumper Settings 43
2.6 Ignition Control 48
CHAPTER 3 SYSTEM SETUP 51
3.1 How to Open Your EVS-2000 51
3.2 Installing CPU 54
3.3 Installing DDR4 SO-DIMM Modules 60
3.4 Installing Mini PCIe Card 61
3.5 Installing M.2 (Key B/E/M) 62
3.6 Installing Antenna Cable 65
3.7 Installing SIM Card 67

vii
3.8 Installing SD Card 68
3.9 Installing PCI/PCIe Card 69
3.10 Installing SSD/HDD 71
3.11 Mounting Your EVS-2000 73
CHAPTER 4 BIOS AND DRIVER 76
4.1 BIOS Settings 76
4.2 Main 77
4.3 Advanced 77
4.4 Chipset 90
4.5 Security 96
4.6 Boot 98
4.7 Save & Exit 99
APPENDIX A : Isolated DIO Guide 100
APPENDIX B : Software Functions 104
APPENDIX C : RAID Functions 109
APPENDIX D : Power Consumption 114
APPENDIX E : Supported Memory & Storage List 122

1
GENERAL INTRODUCTION
1
GENERAL INTRODUCTION
1.1 Overview
Vecow EVS-2000 Series is a high-performance Fanless Embedded GPU
Computing System. Designed with MXM Graphics modules, Vecow EVS-2000
Series is based on 10th Gen Intel® Xeon®/Core™ processor and features
advanced Intel® UHD Graphics 630. Equipped with Intel® W480E chipset,
Vecow EVS-2000 Series supports DDR4-2933 with up to 64GB of memory.
Featuring advanced NVIDIA® with NVIDIA Turing™ architecture technology or
AMD Graphics in the support for MXM 3.1 Type A and Type B form factor, Vecow
EVS-2000 supports up to 7 independent displays with up to 8K resolution,
delivering astounding visual computing performance and accelerating compact-
specic applications.
Vecow EVS-2000 Series o󰀨ers a wide range of I/O connectivity including 2 GigE
LAN, 6 USB, 3 COM, 2 SIM, as well as M.2 to allow flexible expansions and
integrations such as WWAN/WLAN/PCIe storage and CAN Bus. It is fanless and
supports -40°C to 60°C extended operating temperature, 9V to 50V DC-in, as
well as software ignition power control and TPM 2.0, Vecow EVS-2000 Series is
ideal for industrial applications.
Powered by 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3 processor, Vecow EVS-2000
Series delivers outstanding computing performance and meets compact AI
applications requirements in Facial Recognition, Factory Automation, Smart
Retail, Machine Vision, Autonomous Car and AIoT or Industry 4.0 applications.

2
GENERAL INTRODUCTION
©Vecow EVS-2000 User Manual
1.2 Features
• LGA 1200 Socket Type 10-core 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3
Processor (Comet Lake-S) with Intel® W480E chipset
• Dual 260-pin SO-DIMM support up to 64GB DDR4 memory
• Compact NVIDIA® Quadro®/GeForce® MXM graphics card delivers leading AI
computing productivity by advanced NVIDIA® CUDA® cores
• Fanless, -25°C to 55°C Operating Temperature
• Nano SIM Sockets for 5G/WiFi/4G/3G/LTE/GPRS/UMTS
• Expansion : 1 M.2 Key B, 1 M.2 Key E, 1 Mini PCIe, optional SUMIT A, B
• Storage : 2 2.5" SSD Tray, 1 Micro SD Card, 1 M.2 Key M, 1 M.2 Key B
• 9V to 50V wide range DC Power Input with 80V Surge Protection
• Supports Configurable Software Ignition Power Control and TPM 2.0
• Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI
accelerator and advanced Edge AI applications

3
GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of EVS-2010
System
Processor LGA 1200 Socket supports 10th Gen Intel® Xeon®/Core™
i9/i7/i5/i3 Processor (Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory
• 2 DDR4 2933MHz
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 3 COM RS-232/422/485 (ESD 8kV)
USB 6 External USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD
SIM Card 2 External Nano SIM Card Socket
SD Card 1 External Micro SD Card Socket
Expansion
Mini PCIe 1 Mini PCIe Socket for PCIe/USB/SIM Card/mSATA
PCI/PCIe 1 PCIe x4 Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
SUMIT A, B 2 SUMIT Slot (Optional)
Graphics
Graphics Processor
• Intel® UHD Graphics 630
• Independent MXM Graphics : By request
• MXM Graphics TDP : 50W
Interface
Up to 7 independent displays :
• 1 VGA : Up to 1920 x 1200 @ 60Hz
• 1 DVI-D : Up to 1920 x 1200 @ 60Hz
• 2 DisplayPort : Up to 4096 x 2304 @ 60Hz
• 4 DisplayPort : Up to 7680 x 3840 @ 60Hz (By requested
MXM)
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
M.2 • 1 M.2 Key B Socket (2280)
• 1 M.2 Key M Socket (2280)
Storage Device • 1 Micro SD Card Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray

4
GETTING TO KNOW YOUR EVS-2000©Vecow EVS-2000 User Manual
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
Power
Input Voltage 9V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16-mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 280.0mm x 215.0mm x 79.1mm (11.02" x 8.46" x 3.11")
Weight 4.9 kg (10.80 lbs)
Mounting
• Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature 35W TDP CPU : -25°C to 55°C (-13°F to 131°F)
65W TDP CPU : -25°C to 45°C (-13°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% @55°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

5
GENERAL INTRODUCTION
1.3.2 Specications of EVS-2001
System
Processor LGA 1200 Socket supports 10th Gen Intel® Xeon®/Core™
i9/i7/i5/i3 Processor (Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory
• 2 DDR4 2933MHz
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 3 COM RS-232/422/485 (ESD 8kV)
USB 6 External USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD
SIM Card 2 External Nano SIM Card Socket
SD Card 1 External Micro SD Card Socket
Expansion
Mini PCIe 1 Mini PCIe Socket for PCIe/USB/SIM Card/mSATA
PCI/PCIe 1 PCI Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
SUMIT A, B 2 SUMIT Slot (Optional)
Graphics
Graphics Processor
• Intel® UHD Graphics 630
• Independent MXM Graphics : By request
• MXM Graphics TDP : 50W
Interface
Up to 7 independent displays :
• 1 VGA : Up to 1920 x 1200 @ 60Hz
• 1 DVI-D : Up to 1920 x 1200 @ 60Hz
• 2 DisplayPort : Up to 4096 x 2304 @ 60Hz
• 4 DisplayPort : Up to 7680 x 3840 @ 60Hz (By requested
MXM)
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
M.2 • 1 M.2 Key B Socket (2280)
• 1 M.2 Key M Socket (2280)
Storage Device • 1 Micro SD Card Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray

6
GENERAL INTRODUCTION
©Vecow EVS-2000 User Manual
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
Power
Input Voltage 9V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16-mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 280.0mm x 215.0mm x 79.1mm (11.02" x 8.46" x 3.11")
Weight 4.9 kg (10.80 lbs)
Mounting
• Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature 35W TDP CPU : -25°C to 55°C (-13°F to 131°F)
65W TDP CPU : -25°C to 45°C (-13°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% @55°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

7
GENERAL INTRODUCTION
1.3.3 Specications of EVS-2010F
System
Processor LGA 1200 Socket supports 10th Gen Intel® Xeon®/Core™
i9/i7/i5/i3 Processor (Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory
• 2 DDR4 2933MHz
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 3 COM RS-232/422/485 (ESD 8kV)
USB 6 External USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD
SIM Card 2 External Nano SIM Card Socket
SD Card 1 External Micro SD Card Socket
Expansion
Mini PCIe 1 Mini PCIe Socket for PCIe/USB/SIM Card/mSATA
PCI/PCIe 1 PCIe x4 Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
SUMIT A, B 2 SUMIT Slot (Optional)
Graphics
Graphics Processor
• Intel® UHD Graphics 630
• Independent MXM Graphics : By request
• MXM Graphics TDP : 80W to 150W
Interface
Up to 7 independent displays :
• 1 VGA : Up to 1920 x 1200 @ 60Hz
• 1 DVI-D : Up to 1920 x 1200 @ 60Hz
• 2 DisplayPort : Up to 4096 x 2304 @ 60Hz
• 4 DisplayPort : Up to 7680 x 3840 @ 60Hz (By requested
MXM)
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
M.2 • 1 M.2 Key B Socket (2280)
• 1 M.2 Key M Socket (2280)
Storage Device • 1 Micro SD Card Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray

8
GENERAL INTRODUCTION
©Vecow EVS-2000 User Manual
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
Power
Input Voltage • 9V to 50V, DC-in
• 20V to 50V, DC-in (For MXM module >120W)
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16-mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 280.0mm x 215.0mm x 86.5mm (11.02" x 8.46" x 3.41")
Weight 5 kg (11.02 lbs)
Mounting
• Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature 35W TDP CPU : -25°C to 55°C (-13°F to 131°F)
65W TDP CPU : -25°C to 45°C (-13°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% @55°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

9
GENERAL INTRODUCTION
1.3.4 Specications of EVS-2001F
System
Processor LGA 1200 Socket supports 10th Gen Intel® Xeon®/Core™
i9/i7/i5/i3 Processor (Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory
• 2 DDR4 2933MHz
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 3 COM RS-232/422/485 (ESD 8kV)
USB 6 External USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD
SIM Card 2 External Nano SIM Card Socket
SD Card 1 External Micro SD Card Socket
Expansion
Mini PCIe 1 Mini PCIe Socket for PCIe/USB/SIM Card/mSATA
PCI/PCIe 1 PCI Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
SUMIT A, B 2 SUMIT Slot (Optional)
Graphics
Graphics Processor
• Intel® UHD Graphics 630
• Independent MXM Graphics : By request
• MXM Graphics TDP : 80W to 150W
Interface
Up to 7 independent displays :
• 1 VGA : Up to 1920 x 1200 @ 60Hz
• 1 DVI-D : Up to 1920 x 1200 @ 60Hz
• 2 DisplayPort : Up to 4096 x 2304 @ 60Hz
• 4 DisplayPort : Up to 7680 x 3840 @ 60Hz (By requested
MXM)
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
M.2 • 1 M.2 Key B Socket (2280)
• 1 M.2 Key M Socket (2280)
Storage Device • 1 Micro SD Card Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray

10
GENERAL INTRODUCTION
©Vecow EVS-2000 User Manual
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
Power
Input Voltage • 9V to 50V, DC-in
• 20V to 50V, DC-in (For MXM module >120W)
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16-mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 280.0mm x 215.0mm x 86.5mm (11.02" x 8.46" x 3.41")
Weight 5 kg (11.02 lbs)
Mounting
• Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature 35W TDP CPU : -25°C to 55°C (-13°F to 131°F)
65W TDP CPU : -25°C to 45°C (-13°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% @55°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

11
GENERAL INTRODUCTION
1.4 Supported CPU List
Series CPU Cores TDP Cache Max.
Frequency
ECC
Memory
Intel®
Xeon®
W-1290TE 10 35W 20M Up to 4.5GHz Y
W-1270TE 835W 16M Up to 4.4GHz Y
W-1250TE 6 35W 12M Up to 3.8GHz Y
Intel®
Core™
i9-10900E 10 65W 20M Up to 4.7GHz NA
i9-10900TE 10 35W 20M Up to 4.5GHz NA
i7-10700E 865W 16M Up to 4.5GHz NA
i7-10700TE 835W 16M Up to 4.4GHz NA
i5-10500E 6 65W 12M Up to 4.2GHz NA
i5-10500TE 6 35W 12M Up to 3.7GHz NA
i3-10100E 4 65W 6M Up to 3.8GHz Y
i3-10100TE 4 35W 6M Up to 3.6GHz Y

12
GENERAL INTRODUCTION
©Vecow EVS-2000 User Manual
1.5 Mechanical Dimension
1.5.1 Dimensions of EVS-2000
5.0 (0.20)
20.0 (0.79)
R4.5 (0.18)
A
317.0 (12.48)
302.0 (11.89)
280.0 (11.02)
155.0 (6.10) 215.0 (8.46)
79.1 (3.11)
Unit: mm (inch)
1.5.2 Dimensions of EVS-2000F
86.5 (3.41)
5.0 (0.20)
20.0 (0.79)
R4.5 (0.18)
A
317.0 (12.48)
302.0 (11.89)
280.0 (11.02)
155.0 (6.10) 215.0 (8.46)
79.1 (3.11)
Unit: mm (inch)

13
GETTING TO KNOW YOUR EVS-2000
2
GETTING TO KNOW YOUR EVS-2000
2.1 Packing List of EVS-2000/2000F
2.1.1 Packing List of EVS-2000
Item Description Qty
1
EVS-2000 Expandable Fanless Embedded System (According to
the conguration of you order, the EVS-2000 series may contain
SSD/HDD and DDR4 SO-DIMM. Please verify these items if necessary.)
1
2EVS-2000 series accessory box, which contains
• Vecow Drivers & Utilities DVD 1
Item Description Outlook Usage P/N Qty
1PHILLPIS
M2.5x6L,Ni
Mini PCIe
module card 53-2426906-30B 1
2PHILLPIS
M3x4L,Ni+Ny M.2 53-2426204-80B 4
3Terminal block
3-pin (7.62mm) DC-IN 51-2611R03-S1F 1
4Terminal block
3-pin (3.5mm) Switch 51-2211R03-S1A 1
5
Terminal
block 20-pin
(2.54mm)
Isolated
DIO/GPIO 51-2112R20-S1D 2
6Wall-mounting
bracket Mount 62-00P0047-000 2
7PHILLPIS
F-M3x4L SSD/HDD 53-M000450-301 4
8PHILLPIS
I-M3x6L
Fasten Wall
mount 53-2450000-218 4
9Thermal
grease CPU 53-4000342-203 1
