Vecow RCX-1000 User manual

USER
Manual
USER
Manual
1.1.0 Edition 20190418
Intel®Xeon®/Core™ i7/i5/i3 Expandable Robust Computing System
Workstation-grade, Flexible, Fanless, Extended Temperature
RCX-1000

ii
©Vecow RCX-1000 User Manual
Version Date Page Description Remark
0.10 2019/03/26 All Preliminary Release
1.00 2019/04/17 O󰀩cial Release
1.1 2019/04/18 48, 49 Update
Record of Revision

iii
©Vecow RCX-1000 User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Vecow RCX-1000 User Manual
Part Number Description
RCX-1430FR RCX-1000, 2 GigE LAN, 4 Front-access SSD Tray, 1 PCIe x16,
1 PCIe x4, 1 PCIe x1, 4 COM, 6 USB 3.0, 2 SIM, 32 Isolated DIO
RCX-1430F RCX-1000, 2 GigE LAN, 1 PCIe x16, 1 PCIe x4, 1 PCIe x1, 4 COM,
6 USB 3.0, 2 SIM, 32 Isolated DIO
RCX-1421FR RCX-1000, 2 GigE LAN, 4 Front-access SSD Tray, 1 PCIe x16,
1 PCIe x4, 1 PCI, 4 COM, 6 USB 3.0, 2 SIM, 32 Isolated DIO
RCX-1421F RCX-1000, 2 GigE LAN, 1 PCIe x16, 1 PCIe x4, 1 PCI, 4 COM,
6 USB 3.0, 2 SIM, 32 Isolated DIO
RCX-1412FR RCX-1000, 2 GigE LAN, 4 Front-access SSD Tray, 1 PCIe x16,
2 PCI, 4 COM, 6 USB 3.0, 2 SIM, 32 Isolated DIO
RCX-1412F RCX-1000, 2 GigE LAN, 1 PCIe x16, 2 PCI, 4 COM, 6 USB 3.0, 2
SIM, 32 Isolated DIO
RCX-1440R RCX-1000, 2 GigE LAN, 4 Front-access SSD Tray, 1 PCIe x8,
3 PCIe x4, 4 COM, 6 USB 3.0, 2 SIM, 32 Isolated DIO
RCX-1440 RCX-1000, 2 GigE LAN, 1 PCIe x8, 3 PCIe x4, 4 COM, 6 USB 3.0,
2 SIM, 32 Isolated DIO
RCX-1422R RCX-1000, 2 GigE LAN, 4 Front-access SSD Tray, 1 PCIe x8,
1 PCIe x4, 2 PCI, 4 COM, 6 USB 3.0, 2 SIM, 32 Isolated DIO
RCX-1422 RCX-1000, 2 GigE LAN, 1 PCIe x8, 1 PCIe x4, 2 PCI, 4 COM,
6 USB 3.0, 2 SIM, 32 Isolated DIO
RCX-1404R RCX-1000, 2 GigE LAN, 4 Front-access SSD Tray, 4 PCI, 4 COM,
6 USB 3.0, 2 SIM, 32 Isolated DIO
RCX-1404 RCX-1000, 2 GigE LAN, 4 PCI, 4 COM, 6 USB 3.0, 2 SIM,
32 Isolated DIO
RCX-1220A RCX-1000, 2 GigE LAN, 2 PCIe x8, 4COM, 6 USB 3.0, 2 SIM,
32 Isolated DIO
RCX-1220 RCX-1000, 2 GigE LAN, 1 PCIe x16, 1 PCIe x4, 4COM, 6 USB 3.0,
2 SIM, 32 Isolated DIO
RCX-1211 RCX-1000, 2 GigE LAN, 1 PCIe x16, 1 PCI, 4COM, 6 USB 3.0,
2 SIM, 32 Isolated DIO
Order Information

v
©Vecow RCX-1000 User Manual
Part Number Description
E-2176G Intel® Xeon® E-2176G Processor, 12M Cache, up to 4.6GHz, 80W
E-2124G Intel® Xeon® E-2124G Processor, 8M Cache, up to 4.5GHz, 71W
i7-8700 Intel® Core™ i7-8700 Processor, 12M Cache, up to 4.6GHz, 65W
i7-8700T Intel® Core™ i7-8700T Processor, 12M Cache, up to 4.0GHz, 35W
i5-8500 Intel® Core™ i5-8500 Processor, 9M Cache, up to 4.1GHz, 65W
i5-8500T Intel® Core™ i5-8500T Processor, 9M Cache, up to 3.5GHz, 35W
i3-8100 Intel® Core™ i3-8100 Processor, 6M Cache, 3.6GHz, 65W
i3-8100T Intel® Core™ i3-8100T Processor, 6M Cache, 3.1GHz, 35W
DDR4 32G Certied DDR4 32GB 2666MHz RAM
DDR4 16G Certied DDR4 16GB 2666/2400/2133 MHz RAM
DDR4 8G Certied DDR4 8GB 2666/2400/2133 MHz RAM
DDR4 4G Certied DDR4 4GB 2666/2400/2133 MHz RAM
PWA-160WB-WT 160W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin Terminal
Block (7.62mm pitch), Wide Temperature -30°C to +70°C
PWA-280WB-WT 280W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin Terminal
Block (7.62mm pitch), Wide Temperature -30°C to +70°C
PWS-480W-WT 480W, 24V, 90V AC to 305V AC Power Supply, Wide-Temp, IP65
PWS-600W 600W, 24V, 90V AC to 305V AC Power Supply
PWS-600W-WT 600W, 28.8V, 90V AC to 305V AC Power Supply, Wide
Temperature -40°C to +70°C
FAN Module Fan Module for RCX-1000 Series
FAN Sink Fan Sink for RCX-1000 Series
PCIE HOLD-DOWN Kit Hold Down Module for PCIe Card
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector and
DIN-Rail Mounting
4G Module Mini PCIe 4G/GPS Module with Antenna
WiFi & Bluetooth WiFi & Bluetooth Module with Antenna
Order Accessories

vi
©Vecow RCX-1000 User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of RCX-1430FR 3
1.3.2 Specications of RCX-1430F 5
1.3.3 Specications of RCX-1421FR 7
1.3.4 Specications of RCX-1421F 9
1.3.5 Specications of RCX-1412FR 11
1.3.6 Specications of RCX-1412F 13
1.3.7 Specications of RCX-1440R 15
1.3.8 Specications of RCX-1440 17
1.3.9 Specications of RCX-1422R 19
1.3.10 Specications of RCX-1422 21
1.3.11 Specications of RCX-1404R 23
1.3.12 Specications of RCX-1404 25
1.3.13 Specications of RCX-1220A 27
1.3.14 Specications of RCX-1220 29
1.3.15 Specications of RCX-1211 31
1.3.16 Specications of RCX-1430FR RTX2080 33
1.3.17 Specications of RCX-1430F RTX2080 35
1.3.18 Specications of RCX-1421FR RTX2080 37
1.3.19 Specications of RCX-1430F RTX2080 39
1.3.20 Specications of RCX-1412FR RTX2080 41
1.3.21 Specications of RCX-1412F RTX2080 43
1.4 Supported CPU List 45
1.5 Mechanical Dimension 45
1.5.1 Dimensions of RCX-1400FR/RCX-1000FR RTX 45
1.5.2 Dimensions of RCX-1400F/RCX-1000F RTX 46
1.5.3 Dimensions of RCX-1440R/RCX-1422R/RCX-1404R 46
1.5.4 Dimensions of RCX-1440/RCX-1422/RCX-1404 47
1.5.5 Dimensions of RCX-1220A/RCX-1220/RCX-1211 47

vii
©Vecow RCX-1000 User Manual
CHAPTER 2 GETTING TO KNOW YOUR RCX-1000 48
2.1 Packing List 48
2.2 Front Panel I/O Functions 50
2.3 Main Board Expansion Connectors 61
2.4 Main Board Jumper Settings 81
2.5 Ignition Control 85
CHAPTER 3 SYSTEM SETUP 88
3.1 How to open your RCX-1000 88
3.2 Installing CPU 89
3.3 Installing DDR4 SO-DIMM Modules 90
3.4 Installing Mini PCIe Card 91
3.5 Installing M.2 (Key E/Key M) 91
3.6 Installing Antenna Cable 92
3.7 Installing Sim Card 93
3.8 Installing PCI/PCIe Card 94
3.9 Installing SSD/HHD 96
3.10 Mounting Your RCX-1000 100
3.11 Cleaning the Air lter of RCX-1400FR/1400F 101
3.12 Installing the hold down bar for RCX-1400F/1400 Series 102
CHAPTER 4 BIOS SETUP 103
4.1 Entering BIOS Setup 103
4.2 Main 104
4.3 Advanced 104
4.4 Chipset 115
4.5 Security 121
4.6 Boot 123
4.7 Save & Exit 124

viii
©Vecow RCX-1000 User Manual
APPENDIX A : Isolated DIO Guide 125
APPENDIX B : Software Functions 130
APPENDIX C : RAID Functions 133
APPENDIX D : Power Consumption 139
APPENDIX E : Supported Memory & Storage List 144
APPENDIX F : How to Install Power Supply 148

1
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
RCX-1000 is a high-performance, flexible and rugged computing engine for
AIoT and Industry 4.0 applications. LGA1151 Socket supports 6-core 8th
Generation Intel® Xeon®/Core™ i7/i5/i3 processor (Co󰀨ee Lake-S) running with
workstation-grade Intel® C246 chipset; 4 SO-DIMM support dual channel DDR4
2666MHz up to 128GB ECC memory; advanced Intel® UHD Graphics P630/630
supporting DirectX 12, OpenGL 4.5 and OpenCL 2.0 API, multiple DVI, HDMI
and DisplayPort display interfaces, up to Ultra HD 4K resolution; USB 3.1 Gen
2 (10Gbps), PCIe 3.0 (8GT/s), Multiple SATA III (6Gbps), USB 3.0 (5Gbps),
PoE (1Gbps) LAN and multiple wireless connections make seamless real-
time high-speed data conveying possible; optimized power budget for optional
independent graphics or any PCI/PCIe expansion functions. Vecow RCX-1000
Series Fanless Robust Computing System serves leading system performance,
power productivity, and system-oriented integration for demanding workloads in
real-time embedded applications.
Fanless -40°C to 75°C operating temperature, onboard multiple DVI, HDMI and
DisplayPort display interfaces support triple independent displays, 2 GigE LAN
ports support iAMT 12.0, 6 external USB 3.1 Gen 2 connections up to 10Gbps
SuperSpeed data rate, 4 front-access 2.5" SSD/HDD trays with RAID 0, 1, 5, 10
data protection, multiple WiFi/4G/3G/LTE/GPRS/UMTS for seamless wireless
data transfer, 4 COM RS-232/422/485, 2 M.2 expansions, 32 Isolated DIO, 6V
to 36V wide range power input with 80V surge protection, congurable ignition
power control, remote management functions, remote power switch, EN50155
and EN50121-3-2 compliant, 4 PCI/PCIe expansion slots with optimized power
budget, exible support NVIDIA® GeForce® RTX series graphics, Vecow RCX-
1000 Series Fanless Robust Computing System features integrated functions
for AI-oriented Computer Vision applications in harsh environment.
With leading performance, system-oriented integration, versatile conguration,
smart manageability and industrial-grade reliability, Vecow RCX-1000 series
expandable embedded workstation is your powerful solution for Machine Vision,
Factory Automation, Robotic Control, Intelligent Surveillance, Machine Learning,
Deep Learning, and any Articial Intelligence (AI) edge computing applications
in harsh environments.
1

2
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
1.2 Features
• 6 cores 8th generation Intel® Xeon®/Core™ i7/i5/i3 (Coffee Lake-S) processor
with workstation-grade Intel® C246 chipset
• 4 DDR4 2666MHz memory, up to 128GB (ECC/Non-ECC)
• 6 ports external USB 3.1 Gen 2 support up to 10Gbps data transfer
• Rugged & Fanless design, -40°C to 75°C operating temperature
• Multiple DVI-I and DisplayPort display interface, up to 3 independent HD displays
• Powered by advanced NVIDIA Turing™ GPU architecture and all-new RTX
platform, NVIDIA® GeForce RTX™ series graphics engine supports up to 6X the
performance of previous generation graphics cards for real-time AI computing
(RCX-1000 RTX Series only)
• 7 displays : 1 DVI, 1 HDMI, and 5 DisplayPort, up to 8K resolution (RCX-1000
RTX Series only)
• 2 independent GigE LAN, iAMT 12.0 supported
• 2 external SIM sockets for WiFi/4G/3G/LTE/GPRS/UMTS
• 4 front-access 2.5" SSD trays, RAID 0, 1, 5, 10 supported
• 3 PCI/PCIe slots, max 300W Power Budget for independent graphics operation
• 32 Isolated DIO, 4 COM RS-232/422/485
• 2 M.2 sockets : 1 M.2 Key M, 1 M.2 Key E
• 6V to 36V DC Power Input with 80V Surge Protection
• 24V to 36V DC Power Input with 80V Surge Protection (RCX-1000 RTX Series only)
• Configurable Ignition Power Control

3
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of RCX-1430FR
System
Processor 6 cores Intel®Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory
• DDR4 2666MHz (ECC/Non-ECC)
• Up to 128GB
• 4 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 Gen 2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless
SIM Card 2 External SIM Card Socket
Expansion
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe
• 1 PCIe x16 Slot
• 1 PCIe x4 Slot
• 1 PCIe x1 Slot
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • 1 DVI-I : Up to 1920 x 1200 @ 60Hz
• 2 DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III (6Gbps) support software RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 4 Front-access 2.5" SSD/HDD Tray
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM Gigabit LAN supports iAMT 12.0
LAN 2 Intel® I210 Gigabit LAN

4
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension 330.0mm x 210.0mm x 172.0mm (12.99" x 8.27" x 6.77")
Weight 5.3 kg (11.7 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

5
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
1.3.2 Specications of RCX-1430F
System
Processor 6 cores Intel®Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory
• DDR4 2666MHz (ECC/Non-ECC)
• Up to 128GB
• 4 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 Gen 2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless
SIM Card 2 External SIM Card Socket
Expansion
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe
• 1 PCIe x16 Slot
• 1 PCIe x4 Slot
• 1 PCIe x1 Slot
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • 1 DVI-I : Up to 1920 x 1200 @ 60Hz
• 2 DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III (6Gbps) support software RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 4 2.5" SSD/HDD Bracket (Internal)
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM Gigabit LAN supports iAMT 12.0
LAN 2 Intel® I210 Gigabit LAN

6
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension 330.0mm x 210.0mm x 172.0mm (12.99" x 8.27" x 6.77")
Weight 4.9 kg (10.8 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

7
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
1.3.3 Specications of RCX-1421FR
System
Processor 6 cores Intel®Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory
• DDR4 2666MHz (ECC/Non-ECC)
• Up to 128GB
• 4 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 Gen 2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless
SIM Card 2 External SIM Card Socket
Expansion
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe
• 1 PCIe x16 Slot
• 1 PCIe x4 Slot
• 1 PCI Slot
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • 1 DVI-I : Up to 1920 x 1200 @ 60Hz
• 2 DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III (6Gbps) support software RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 4 Front-access 2.5" SSD/HDD Tray
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM Gigabit LAN supports iAMT 12.0
LAN 2 Intel® I210 Gigabit LAN

8
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension 330.0mm x 210.0mm x 172.0mm (12.99" x 8.27" x 6.77")
Weight 5.3 kg (11.7 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

9
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
1.3.4 Specications of RCX-1421F
System
Processor 6 cores Intel®Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory
• DDR4 2666MHz (ECC/Non-ECC)
• Up to 128GB
• 4 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 Gen 2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless
SIM Card 2 External SIM Card Socket
Expansion
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe
• 1 PCIe x16 Slot
• 1 PCIe x4 Slot
• 1 PCI Slot
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • 1 DVI-I : Up to 1920 x 1200 @ 60Hz
• 2 DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III (6Gbps) support software RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 4 2.5" SSD/HDD Bracket (Internal)
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM Gigabit LAN supports iAMT 12.0
LAN 2 Intel® I210 Gigabit LAN

10
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension 330.0mm x 210.0mm x 172.0mm (12.99" x 8.27" x 6.77")
Weight 4.9 kg (10.8 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

11
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
1.3.5 Specications of RCX-1412FR
System
Processor 6 cores Intel®Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory
• DDR4 2666MHz (ECC/Non-ECC)
• Up to 128GB
• 4 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 Gen 2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless
SIM Card 2 External SIM Card Socket
Expansion
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe • 1 PCIe x16 Slot
• 2 PCI Slot
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • 1 DVI-I : Up to 1920 x 1200 @ 60Hz
• 2 DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III (6Gbps) support software RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 4 Front-access 2.5" SSD/HDD Tray
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM Gigabit LAN supports iAMT 12.0
LAN 2 Intel® I210 Gigabit LAN

12
©Vecow RCX-1000 User Manual GENERAL INTRODUCTION
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension 330.0mm x 210.0mm x 172.0mm (12.99" x 8.27" x 6.77")
Weight 5.3 kg (11.7 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
