Vecow IVH-9204MX ICY User manual

USER
Manual
USER
Manual
1.0.0 Edition 20200205
Intel®Xeon®/Core™ i7/i5/i3 Fanless In-Vehicle Computing System
EN50155 & EN45545-2 Certied, X-coded M12 PoE+, 16V to 160V DC-in
IVH-9204MX ICY

ii
©Vecow IVH-9204MX ICY User Manual
Version Date Page Description Remark
0.10 2020/01/30 All Preliminary Release
1.00 2020/02/05 O󰀩cial Release
Record of Revision

iii
©Vecow IVH-9204MX ICY User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Vecow IVH-9204MX ICY User Manual
Part Number Description
IVH-9204MX ICYU IVH-9200, 6 GigE LAN w/4 X-coded M12 PoE+, 6 SSD/HDD
Tray, 8 USB 3.0, 4 COM, 3 SIM, 32 Isolated DIO, UPS supported
IVH-9204MX ICY IVH-9200, 6 GigE LAN w/4 X-coded M12 PoE+, 6 SSD/HDD
Tray, 8 USB 3.0, 4 COM, 3 SIM, 32 Isolated DIO
IVH-9204MX ICY4U IVH-9200, 6 GigE LAN w/4 X-coded M12 PoE+, 4 SSD/HDD
Tray, 8 USB 3.0, 4 COM, 3 SIM, 32 Isolated DIO, UPS supported
IVH-9204MX ICY4 IVH-9200, 6 GigE LAN w/4 X-coded M12 PoE+, 4 SSD/HDD
Tray, 8 USB 3.0, 4 COM, 3 SIM, 32 Isolated DIO
Order Information
Part Number Description
E3-1275 v6 7th Gen Intel® Xeon® E3-1275 v6 Processor
(8M Cache, up to 4.20GHz, 80W)
E3-1275 v5 6th Gen Intel® Xeon® E3-1275 v5 Processor
(8M Cache, up to 4.00GHz, 80W)
E3-1225 v5 6th Gen Intel® Xeon® E3-1225 v5 Processor
(6M Cache, up to 3.70GHz, 80W)
E3-1268L v5 6th Gen Intel® Xeon® E3-1268L v5 Processor
(8M Cache, up to 3.40GHz, 35W)
i7-7700 7th Gen Intel® Core™ i7-7700 Processor
(8M Cache, up to 4.20GHz, 65W)
i7-7700T 7th Gen Intel® Core™ i7-7700T Processor
(8M Cache, up to 3.80GHz, 35W)
i7-6700 6th Gen Intel® Core™ i7-6700 Processor
(8M Cache, up to 4.00GHz)
i7-6700TE 6th Gen Intel® Core™ i7-6700TE Processor
(8M Cache, up to 3.40GHz)
i5-7500 7th Gen Intel® Core™ i5-7500 Processor
(6M Cache, up to 3.80GHz, 65W)
i5-7500T 7th Gen Intel® Core™ i5-7500T Processor
(6M Cache, up to 3.30GHz, 35W)
i5-6500 6th Gen Intel® Core™ i5-6500 Processor
(6M Cache, up to 3.60GHz)
i5-6500TE 6th Gen Intel® Core™ i5-6500TE Processor
(6M Cache, up to 3.30GHz)
i3-7101E 7th Gen Intel® Core™ i3-7101E Processor
(3M Cache, up to 3.90GHz, 65W)
i3-7101TE 7th Gen Intel® Core™ i3-7101TE Processor
(3M Cache, up to 3.40GHz, 35W)
i3-6100 6th Gen Intel® Core™ i3-6100 Processor
(3M Cache, 3.70GHz)
i3-6100TE 6th Gen Intel® Core™ i3-6100TE Processor
(4M Cache, 2.70GHz)
i3-8100T 8th Gen Intel® Core™ i3-8100T Processor
(XXM Cache, up to 3.10GHz)
CPU List

v
©Vecow IVH-9204MX ICY User Manual
Part Number Description
DDR4 32G Certied DDR4 32GB 2400/2133MHz RAM
DDR4 16G Certied DDR4 16GB 2400/2133MHz RAM
DDR4 8G Certied DDR4 8GB 2400/2133MHz RAM
DDR4 4G Certied DDR4 4GB 2400/2133MHz RAM
PWA-280W-WT 280W, 24V, 85V AC to 264V AC Power Adapter with
3-pin Terminal Block, Wide Temperature -30°C to +70°C
PWA-160W-WT 160W, 24V, 85V AC to 264V AC Power Adaptor with
3-pin Terminal Block, Wide Temperature -30°C to +70°C
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector
and DIN-Rail Mounting
4G Module Mini PCIe 4G/GPS Module with Antenna
WiFi & Bluetooth Mini PCIe WiFi & Bluetooth Module with Antenna
Optional Accessories

vi
©Vecow IVH-9204MX ICY User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of IVH-9204MX ICYU 3
1.3.2 Specications of IVH-9204MX ICY 5
1.3.3 Specications of IVH-9204MX ICY4U 7
1.3.4 Specications of IVH-9204MX ICY4 9
1.4 Supported CPU List 11
1.5 Mechanical Dimension 12
1.5.1 Dimensions of IVH-9204MX ICYU 12
1.5.2 Dimensions of IVH-9204MX ICY 12
1.5.3 Dimensions of IVH-9204MX ICY4U 13
1.5.4 Dimensions of IVH-9204MX ICY4 13
CHAPTER 2 GETTING TO KNOW YOUR IVH-9204MX ICY 14
2.1 Packing List 14
2.2 Front Panel I/O & Functions 15
2.3 Rear Panel I/O & Functions 22
2.4 Main Board Expansion Connectors 28
2.5 Main Board Jumper and DIP Switch Settings 39
2.6 Ignition Control 42
CHAPTER 3 SYSTEM SETUP 46
3.1 How to Open Your IVH-9204MX ICY 46
3.2 Installing CPU 49
3.3 Installing DDR4 SO-DIMM Modules 60
3.4 Installing Mini PCIe Card 61
3.5 Installing Antenna Cable 62
3.6 Installing CFast Card 63

vii
©Vecow IVH-9204MX ICY User Manual
3.7 Installing SIM Card 64
3.8 Installing SSD/HDD 65
3.9 Installing UPM 70
3.10 Mounting Your IVH-9204MX ICY 74
CHAPTER 4 BIOS SETUP 75
4.1 Entering BIOS Setup 75
4.2 Main 76
4.3 Advanced 76
4.4 Chipset 87
4.5 Security 92
4.6 Boot 94
4.7 Save & Exit 95
APPENDIX A : Isolated Guide 96
APPENDIX B : Software Functions 103
APPENDIX C : RAID Functions 107
APPENDIX D : Power Consumption 111
APPENDIX E : Supported Memory & Storage List 115

1
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
Vecow IVH-9204MX ICY Series is a trusted and powerful rugged in-vehicle
computing engine in the market. Flexible LGA1151 Socket supports workstation-
grade Intel® Xeon®/Core™ i7/i5/i3 processor (Kaby Lake-S/Skylake-S) running
with advanced Intel® C236 chipset and dual-channel DDR4 2400/2133
MHz ECC memory, up to 64GB capacity; Advanced Intel® HD Graphics 630
supporting DirectX 12, OpenGL 4.4 and OpenCL 2.0 API, onboard DVI-I, DVI-D
and DisplayPort display interfaces for Ultra HD 4K resolution, IVH-9204MX ICY
makes excellent CPU performance, power e󰀩ciency, and graphics performance
possible; PCIe 3.0 (8GT/s), Multiple SATA III (6Gbps), USB 3.0 (5Gbps), PoE
(1Gbps) LAN and multiple wireless connections make seamless high-speed data
conveying possible. Vecow IVH-9204MX ICY Series Fanless Embedded System
delivers outstanding system performance, power productivity and flexible
manageability for performance-driven embedded computing applications.
Fully EN50155 certified, EN45545-2 fire protection, all-in-one and cable-
less designs, fanless -40°C to 55°C extended operating temperature, 6 GigE
LAN ports with 4 IEEE 802.3at (25.5W/48V) PoE+ and up to 4 X-coded M12
connections without additional power connections, 6 front-access 2.5" SSD/
HDD trays flexible support 7mm to 15mm storage, up to 24TB capacity with
RAID 0, 1, 5, 10 data protection, 3 external SIM card sockets for WiFi/4G/3G/
LTE/GPRS/UMTS, 1 front-access CFast socket, 8 external USB 3.0, 4 COM
RS-232/422/485, 32 Isolated DIO, 16V to 160V wide range power input with
4kV isolation and max 500V surge protection, configurable ignition power
control, optional supports UPS, smart remote management features, remote
power switch, EN50121-3-2 certied, Vecow IVH-9204MX ICY Series Fanless
Embedded System serves all-in-one integrated features, versatile I/O functions,
and rugged reliability in harsh environments.
With workstation-grade system performance, fanless -40°C to 55°C extended
operating temperature, all-in-one integrated features, smart manageability
& data protection functions, outstanding mobile availability, secure power
protection, and rugged reliability, Vecow IVH-9204MX ICY Series In-Vehicle
Fanless System is your trusted and performance-driven solution for Advanced
Driver Assistance System (ADAS), In-vehicle Surveillance, Mobile In-vehicle
Communication, Passenger Information System (PIS), Pantograph Inspection
and any AIoT/Industry 4.0 applications.
1

2
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
1.2 Features
• LGA 1151 Socket supports Quad Core 7th/6th Generation Intel® Xeon®/Core™
i7/i5/i3 Processor (Kaby Lake-S/Skylake-S) with Intel® C236 Chipset
• Fanless design for railway in-vehicle applications, fully EN50155 certified, -40°C
to 55°C Extended Operating Temperature
• 2 DDR4 2400/2133 MHz Memory, up to 64GB (ECC/Non-ECC)
• 6 Independent GigE LAN with 4 X-coded M12 IEEE 802.3at PoE+, iAMT 11.0
supported
• 6 Front-access 7mm to 15mm in height 2.5" SSD/HDD Tray, up to 24TB capacity,
RAID 0, 1, 5, 10 supported
• 3 Front-access SIM Card Socket for WiFi/4G/3G/LTE/GPRS/UMTS
• DVI-I, DVI-D and DisplayPort triple independent display, up to 4K displays
• 32 Isolated DIO, 8 USB 3.0, 4 COM, 3 Mini PCIe
• 16V to 160V DC Power Input with 4kV DC Isolation, up to 500V Surge Protection
• Configurable Ignition Power Control
• UPS supported (Optional)

3
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of IVH-9204MX ICYU
System
Processor Quad Core 7th/6th Gen Intel® Xeon®/Core™ i7/i5/i3 Processor
(Kaby Lake-S/Skylake-S)
Chipset Intel® C236
BIOS AMI
SIO IT8786E
Memory
• DDR4 2400/2133MHz
• Up to 64GB
• 2 260-pin SO-DIMM Socket (ECC/Non-ECC)
I/O Interface
Serial 4 COM RS-232/422/485 with auto ow control (ESD 8kV)
USB • 8 External USB 3.0 (4 Front, 4 Rear)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 2 External SIM Card Socket (SIM 1 unavailable)
Expansion
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
Graphics
Graphics Processor Intel® HD Graphics 630/530
Interface
• DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 6 SATA III (6Gbps) support software RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 6 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE (M12)
LAN 3 to LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector

4
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
Power
Input Voltage 16V to 160V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Isolation 4kV DC
Surge Protection 0.5kV DC 8/20us Surge
UPS (UPM-100) Optional supports 3 stackable 18650 LFP batteries (1.1mA/h)
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimension 260.0mm x 215.0mm x 155.1mm (10.24" x 8.46" x 6.10")
Weight 10 kg (22.04 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 40°C
Shock IEC 61373
Vibration IEC 61373
EMC CE, FCC, EN50155:2017, EN50121-3-2, EN45545-2

5
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
1.3.2 Specications of IVH-9204MX ICY
System
Processor Quad Core 7th/6th Gen Intel® Xeon®/Core™ i7/i5/i3 Processor
(Kaby Lake-S/Skylake-S)
Chipset Intel® C236
BIOS AMI
SIO IT8786E
Memory
• DDR4 2400/2133MHz
• Up to 64GB
• 2 260-pin SO-DIMM Socket (ECC/Non-ECC)
I/O Interface
Serial 4 COM RS-232/422/485 with auto ow control (ESD 8kV)
USB • 8 External USB 3.0 (4 Front, 4 Rear)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 2 External SIM Card Socket (SIM 1 unavailable)
Expansion
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
Graphics
Graphics Processor Intel® HD Graphics 630/530
Interface
• DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 6 SATA III (6Gbps) support software RAID 0, 1, 5, 10
mSATA 3 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 6 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE (M12)
LAN 3 to LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210

6
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
Power
Input Voltage 16V to 160V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Isolation 4kV DC
Surge Protection 0.5kV DC 8/20us Surge
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimension 260.0mm x 215.0mm x 155.1mm (10.24" x 8.46" x 6.10")
Weight 10 kg (22.04 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature
35W TDP CPU :
-40°C to 55°C (-40°F to 131°F)
65W/80W TDP CPU :
-40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 55°C
Shock IEC 61373
Vibration IEC 61373
EMC CE, FCC, EN50155:2017, EN50121-3-2, EN45545-2

7
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
1.3.3 Specications of IVH-9204MX ICY4U
System
Processor Quad Core 7th/6th Gen Intel® Xeon®/Core™ i7/i5/i3 Processor
(Kaby Lake-S/Skylake-S)
Chipset Intel® C236
BIOS AMI
SIO IT8786E
Memory
• DDR4 2400/2133MHz
• Up to 64GB
• 2 260-pin SO-DIMM Socket (ECC/Non-ECC)
I/O Interface
Serial 4 COM RS-232/422/485 with auto ow control (ESD 8kV)
USB • 8 External USB 3.0 (4 Front, 4 Rear)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 3 External SIM Card Socket
Expansion
Mini PCIe 3 Full-size for PCIe/USB/External SIM Card/mSATA
Graphics
Graphics Processor Intel® HD Graphics 630/530
Interface
• DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III (6Gbps) support software RAID 0, 1, 5, 10
mSATA 3 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 4 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE (M12)
LAN 3 to LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector

8
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
Power
Input Voltage 16V to 160V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Isolation 4kV DC
Surge Protection 0.5kV DC 8/20us Surge
UPS (UPM-100) Optional supports 3 stackable 18650 LFP batteries (1.1mA/h)
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimension 260.0mm x 215.0mm x 155.1mm (10.24" x 8.46" x 6.10")
Weight 8.8 kg (19.40 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 40°C
Shock IEC 61373
Vibration IEC 61373
EMC CE, FCC, EN50155:2017, EN50121-3-2, EN45545-2

9
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
1.3.4 Specications of IVH-9204MX ICY4
System
Processor Quad Core 7th/6th Gen Intel® Xeon®/Core™ i7/i5/i3 Processor
(Kaby Lake-S/Skylake-S)
Chipset Intel® C236
BIOS AMI
SIO IT8786E
Memory
• DDR4 2400/2133MHz
• Up to 64GB
• 2 260-pin SO-DIMM Socket (ECC/Non-ECC)
I/O Interface
Serial 4 COM RS-232/422/485 with auto ow control (ESD 8kV)
USB • 8 External USB 3.0 (4 Front, 4 Rear)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 3 External SIM Card Socket
Expansion
Mini PCIe 3 Full-size for PCIe/USB/External SIM Card/mSATA
Graphics
Graphics Processor Intel® HD Graphics 630/530
Interface
• DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III (6Gbps) support software RAID 0, 1, 5, 10
mSATA 3 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 4 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE (M12)
LAN 3 to LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210

10
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
Power
Input Voltage 16V to 160V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Isolation 4kV DC
Surge Protection 0.5kV DC 8/20us Surge
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimension 260.0mm x 215.0mm x 155.1mm (10.24" x 8.46" x 6.10")
Weight 8.5 kg (18.74 lb)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature
35W TDP CPU :
-40°C to 55°C (-40°F to 131°F)
65W/80W TDP CPU :
-40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 55°C
Shock IEC 61373
Vibration IEC 61373
EMC CE, FCC, EN50155:2017, EN50121-3-2, EN45545-2

11
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
1.4 Supported CPU List
Processor No. Cores TDP Cache Max. Frequency ECC Memory
Intel® Xeon® E3-1275 v6 4 80W 16M Up to 4.2GHz Y
Intel® Xeon® E3-1275 v5 4 80W 16M Up to 4.0GHz Y
Intel® Xeon® E3-1225 v5 4 80W 12M Up to 3.7GHz Y
Intel® Xeon® E3-1268L v5 4 35W 12M Up to 3.4GHz Y
Intel® Core™ i7-7700 4 65W 12M Up to 4.2GHz N
Intel® Core™ i7-7700T 4 35W 12M Up to 3.8GHz N
Intel® Core™ i7-6700 4 65W 12M Up to 4.0GHz N
Intel® Core™ i7-6700TE 4 35W 12M Up to 3.4GHz N
Intel® Core™ i5-7500 4 65W 9M Up to 3.8GHz N
Intel® Core™ i5-7500T 4 35W 9M Up to 3.3GHz N
Intel® Core™ i5-6500 4 65W 9M Up to 3.6GHz N
Intel® Core™ i5-6500TE 4 35W 9M Up to 3.3GHz N
Intel® Core™ i3-7101E 265W 6M Up to 3.9GHz Y
Intel® Core™ i3-7101TE 235W 6M Up to 3.4GHz Y
Intel® Core™ i3-6100 265W 6M Up to 3.7GHz Y
Intel® Core™ i3-6100TE 235W 6M Up to 2.7GHz Y

12
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
1.5 Mechanical Dimension
1.5.1 Dimensions of IVH-9204MX ICYU
155.1 (6.10”)
A Detail
2:1
5.0 (0.20”)
25.0 (0.98”)
Ø9.0 (Ø0.35”)
260.0 (10.24”)
282.0 (11.10”)
297.0 (11.69”)
155.0 (6.10”)
215.0 (8.46”)
A
1.5.2 Dimensions of IVH-9204MX ICY
155.1 (6.10”)
A Detail
2:1
5.0 (0.20”)
25.0 (0.98”)
Ø9.0 (Ø0.35”)
260.0 (10.24”)
282.0 (11.10”)
297.0 (11.69”)
155.0 (6.10”)
215.0 (8.46”)
A
Unit : mm (inch)
Unit : mm (inch)

13
©Vecow IVH-9204MX ICY User Manual GENERAL INTRODUCTION
1.5.3 Dimensions of IVH-9204MX ICY4U
155.1 (6.10”)
A Detail
2:1
5.0 (0.20”)
25.0 (0.98”)
Ø9.0 (Ø0.35”)
260.0 (10.24”)
282.0 (11.10”)
297.0 (11.69”)
155.0 (6.10”)
215.0 (8.46”)
A
1.5.4 Dimensions of IVH-9204MX ICY4
155.1 (6.10”)
A Detail
2:1
5.0 (0.20”)
25.0 (0.98”)
Ø9.0 (Ø0.35”)
260.0 (10.24”)
282.0 (11.10”)
297.0 (11.69”)
155.0 (6.10”)
215.0 (8.46”)
A
