Vega VEGAPULS C 23 User manual

Operating Instructions
Radar sensor for continuous level
measurement
VEGAPULS C 23
Modbus and Levelmaster protocol
Document ID: 58349

2
Contents
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
Contents
1 About this document ............................................................................................................... 4
1.1 Function ........................................................................................................................... 4
1.2 Target group ..................................................................................................................... 4
1.3 Symbols used................................................................................................................... 4
2 For your safety ......................................................................................................................... 5
2.1 Authorised personnel ....................................................................................................... 5
2.2 Appropriate use................................................................................................................ 5
2.3 Warning about incorrect use............................................................................................. 5
2.4 General safety instructions............................................................................................... 5
2.5 Modes for worldwide use.................................................................................................. 6
2.6 Installation and operation in the USA and Canada ........................................................... 6
3 Product description ................................................................................................................. 7
3.1 Conguration.................................................................................................................... 7
3.2 Principle of operation........................................................................................................ 9
3.3 Adjustment ....................................................................................................................... 9
3.4 Packaging, transport and storage................................................................................... 10
3.5 Accessories.................................................................................................................... 11
4 Mounting................................................................................................................................. 12
4.1 General instructions ....................................................................................................... 12
4.2 Mounting versions.......................................................................................................... 12
4.3 Mounting instructions ..................................................................................................... 12
4.4 Measurement setup - Flow............................................................................................. 17
5 Connecting to power supply................................................................................................. 19
5.1 Preparing the connection ............................................................................................... 19
5.2 Wiring plan ..................................................................................................................... 19
6 Access protection.................................................................................................................. 21
6.1 Bluetooth radio interface ................................................................................................ 21
6.2 Protection of the parameterization.................................................................................. 21
6.3 Storing the codes in myVEGA........................................................................................ 22
7 Setup with smartphone/tablet (Bluetooth).......................................................................... 23
7.1 Preparations................................................................................................................... 23
7.2 Connecting..................................................................................................................... 23
7.3 Parameter adjustment .................................................................................................... 24
8 Setup with PC/notebook (Bluetooth)................................................................................... 25
8.1 Preparations................................................................................................................... 25
8.2 Connecting..................................................................................................................... 25
8.3 Parameter adjustment .................................................................................................... 26
9 Setup with PC/notebook (interface adapter) ...................................................................... 28
9.1 Connect the PC.............................................................................................................. 28
9.2 Parameter adjustment with PACTware............................................................................ 28
9.3 Saving the parameterisation data................................................................................... 29
10 Adjustment menu................................................................................................................... 30
10.1 Menu overview ............................................................................................................... 30
10.2 Description of the applications ....................................................................................... 31

3
Contents
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
11 Diagnostics and servicing .................................................................................................... 36
11.1 Maintenance .................................................................................................................. 36
11.2 Rectify faults................................................................................................................... 36
11.3 Status messages according to NE 107 .......................................................................... 37
11.4 Treatment of measurement errors .................................................................................. 39
11.5 Software update ............................................................................................................. 42
11.6 How to proceed if a repair is necessary.......................................................................... 42
12 Dismount................................................................................................................................. 43
12.1 Dismounting steps.......................................................................................................... 43
12.2 Disposal ......................................................................................................................... 43
13 Certicatesandapprovals.................................................................................................... 44
13.1 Radio licenses................................................................................................................ 44
13.2 Approvals for Ex areas ................................................................................................... 44
13.3 Approvalsasoverllprotection....................................................................................... 44
13.4 Foodandpharmaceuticalcerticates............................................................................. 44
13.5 EU conformity................................................................................................................. 44
13.6 Environment management system ................................................................................. 44
14 Supplement ............................................................................................................................ 45
14.1 Technical data ................................................................................................................ 45
14.2 Modbus – Overview........................................................................................................ 49
14.3 Communication.............................................................................................................. 50
14.4 Setup.............................................................................................................................. 50
14.5 Measured values............................................................................................................ 51
14.6 Additional measurement data......................................................................................... 53
14.7 Diagnosis data, device information................................................................................. 53
14.8 Function codes............................................................................................................... 53
14.9 Levelmaster protocol...................................................................................................... 56
14.10CongurationoftypicalModbushosts ........................................................................... 59
14.11 Dimensions .................................................................................................................... 60
14.12 Industrial property rights................................................................................................. 61
14.13 Licensing information for open source software ............................................................. 61
14.14 Trademark ...................................................................................................................... 61
Safety instructions for Ex areas
TakenoteoftheExspecicsafetyinstructionsforExapplications.
These instructions are attached as documents to each instrument
with Ex approval and are part of the operating instructions.
Editing status: 2020-08-04

4
1 About this document
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
1 About this document
1.1 Function
This instruction provides all the information you need for mounting,
connection and setup as well as important instructions for mainte-
nance,faultrectication,theexchangeofpartsandthesafetyofthe
user. Please read this information before putting the instrument into
operation and keep this manual accessible in the immediate vicinity
of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Document ID
This symbol on the front page of this instruction refers to the Docu-
ment ID. By entering the Document ID on www.vega.com you will
reach the document download.
Information, note, tip: This symbol indicates helpful additional infor-
mation and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions,
damage to devices or plants.
Caution: Non-observance of the information marked with this symbol
may result in personal injury.
Warning: Non-observance of the information marked with this symbol
may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol
results in serious or fatal personal injury.
Ex applications
This symbol indicates special instructions for Ex applications.
• List
The dot set in front indicates a list with no implied sequence.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of bat-
teries and accumulators.

5
2 For your safety
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
2.2 Appropriate use
VEGAPULS C 23 is a sensor for continuous level measurement.
Youcannddetailedinformationabouttheareaofapplicationin
chapter " Product description".
Operational reliability is ensured only if the instrument is properly
usedaccordingtothespecicationsintheoperatinginstructions
manual as well as possible supplementary instructions.
2.3 Warning about incorrect use
Inappropriate or incorrect use of this product can give rise to applica-
tion-specichazards,e.g.vesseloverllthroughincorrectmounting
or adjustment. Damage to property and persons or environmental
contamination can result. Also, the protective characteristics of the
instrument can be impaired.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives.The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument. When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.Forsafety
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed.
The low transmitting power of the radar sensor is far below the inter-
nationally approved limits. No health impairments are to be expected
with intended use.The band range of the transmission frequency can
be found in chapter " Technical data".

6
2 For your safety
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
2.5 Modes for worldwide use
Countryspecicsettingsfortheradarsignalsaredeterminedviathe
operating mode.The operating mode must be set in the operating
menu via the respective adjustment tool at the beginning of the setup
(see chapter " Setup" resp. " Menu overview".
Caution:
Operating the device without selecting the appropriate country group
constitutes a violation of the regulations of the radio approvals of the
respective country.
Further information can be found in the document " Regulations for
radar level measuring instruments with radio licenses" on our home-
page.
2.6 Installation and operation in the USA and
Canada
This information is only valid for USA and Canada. Hence the follow-
ing text is only available in the English language.
Installations in the US shall comply with the relevant requirements of
the National Electrical Code (ANSI/NFPA 70).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code
A Class 2 power supply unit has to be used for the installation in the
USA and Canada.

7
3 Product description
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• Radar sensor
• Counter nut G1 1)
• Information sheet " Documents and software" with:
– Instrument serial number
– QR code with link for direct scanning
• Information sheet " PINs and Codes" (with Bluetooth versions)
with:
– Bluetooth access code
• Information sheet " Access protection" (with Bluetooth versions)
with:
– Bluetooth access code
– Emergency Bluetooth unlock code
– Emergency device code
The further scope of delivery encompasses:
• Documentation
– Ex-specic"Safety instructions" (with Ex versions)
– Ifnecessary,furthercerticates
Note:
Optional instrument features are also described in this operating
instructions manual.The respective scope of delivery results from the
orderspecication.
This operating instructions manual applies to the following instrument
versions:
• Hardware version from 1.0.0
• Software version from 1.2.0
Scope of delivery
Scope of this operating
instructions
1) G type threaded connections only

8
3 Product description
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
4
3
5
1
2
Fig. 1: Components of VEGAPULS C 23
1 Radar antenna
2 Electronics housing
3 Mounting thread
4 Counter nut
5 Connection cable
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument.
0044
12...35V 4...20mA HART
TA G1234
123456
1
5
6
7
2
3
2020
www.vega.com
D-77761 SCHILTACH,
Made in Germany
VEGAPULS C 2. s/n 12345678
15mIP66/IP6 8, TYPE 6P
MWP 3bar (300kPa)
PVDF
L=5m
1½ NPT / 1 NPT
Fig. 2: Layout of the type label (example)
1 Instrument type
2 Field for approvals
3 Technical data
4 Bluetooth access code
5 QR code for device documentation
6 Serial number
Move to " www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Thereyoucanndthefollowinginformationabouttheinstrument:
• Order data
• Documentation
• Software
Alternatively,youcanndallviayoursmartphone:
• Scan the QR-code on the type label of the device or
• Enter serial number manually in the VEGA Tools app (available
free of charge in the respective stores)
Constituent parts
Type label
Documents and software

9
3 Product description
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
3.2 Principle of operation
VEGAPULS C 23 is a radar sensor for non-contact, continuous level
measurement. It is suitable for liquids and solids in practically all
industries.
The instrument emits a continuous, frequency-modulated radar signal
throughitsantenna.Theemittedsignalisreectedbythemedium
andreceivedbytheantennaasanechowithmodiedfrequency.The
frequency change is proportional to the distance and is converted into
the level.
3.3 Adjustment
Devices with integrated Bluetooth module can be adjusted wirelessly
via standard adjustment tools:
• Smartphone/tablet (iOS or Android operating system)
• PC/notebook with Bluetooth USB adapter (Windows operating
system)
13
2
Fig. 3: Wireless connection to standard operating devices with integrated
Bluetooth LE
1 Sensor
2 Smartphone/Tablet
3 PC/Notebook
The adjustment via the signal cable is carried out via an RS 485/USB
interface adapter and a PC/notebook using DTM/PACTware.
Application area
Functional principle
Wireless adjustment
Adjustment via the signal
cable

10
3 Product description
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
RS485
USB
1
2
3
4
5
Fig. 4: Connecting the PC to the signal cable
1 Interface adapter RS 485/USB adapter
2 USB cable to the PC
3 RS 485 cable
4 Sensor
5 Voltage supply
3.4 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging consists of environment-friendly, recyclable card-
board. For special versions, PE foam or PE foil is also used. Dispose
of the packaging material via specialised recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Not exposed to corrosive media
• Protected against solar radiation
• Avoiding mechanical shock and vibration
• Storage and transport temperature see chapter " Supplement -
Technical data - Ambient conditions"
• Relative humidity 20 … 85 %
Packaging
Transport
Transport inspection
Storage
Storage and transport
temperature

11
3 Product description
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
3.5 Accessories
Screwedangesareavailableindierentversionsaccordingtothe
following standards: DIN 2501, EN 1092-1, BS 10, ASME B 16.5,
JIS B 2210-1984, GOST 12821-80.
Welded sockets are used to connect the devices to the process.
Threaded adapters enable simple adaptation of devices with stand-
ardthreadedttings,e.g.toprocess-sidehygieneconnections.
The mounting accessories are used for stable mounting of the device
at the measuring point.The parts are available in various versions and
sizes.
Flanges
Welded sockets and
adapters
Mounting accessories

12
4 Mounting
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
4 Mounting
4.1 General instructions
The instrument is suitable for standard and extended ambient condi-
tions acc. to DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1. It can be used
indoors as well as outdoors.
Note:
For safety reasons, the instrument must only be operated within the
permissibleprocessconditions.Youcannddetailedinformationon
the process conditions in chapter " Technical data" of the operating
instructions or on the type label.
Hence make sure before mounting that all parts of the instrument ex-
posed to the process are suitable for the existing process conditions.
These are mainly:
• Active measuring component
• Processtting
• Process seal
Process conditions in particular are:
• Process pressure
• Process temperature
• Chemical properties of the medium
• Abrasionandmechanicalinuences
4.2 Mounting versions
For the wall mounting, a mounting bracket with opening for thread G1
is recommended.The mounting of the device in the bracket is carried
out via the supplied G1 counter nut of plastic.Take note of chapter "
Mounting instructions" for the recommended distance to the wall.
> 200 mm
(7.87
")
Fig. 5: Mounting via a mounting bracket
4.3 Mounting instructions
The emitted radar impulses of the radar sensor are electromagnetic
waves. The polarisation is the direction of the electrical wave compo-
Ambient conditions
Process conditions
Mounting bracket
Polarisation

13
4 Mounting
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
nent. By turning the instrument in the mounting strap, the polarisation
canbeusedtoreducetheeectsoffalseechoes.
The position of the polarization is in the middle of the type plate on the
device or 90° to the logo.
1
Fig. 6: Position of the polarisation
1 Middle of the type label
When mounting the device, keep a distance of at least 200 mm
(7.874 in) from the vessel wall. If the device is installed in the center
of dished or round vessel tops, multiple echoes can arise. However,
these can be suppressed by an appropriate adjustment (see chapter
" Setup").
If you cannot maintain this distance, you should carry out a false
signal suppression during setup.This applies particularly if buildup on
the vessel wall is expected. In such cases, we recommend repeating
the false signal suppression at a later date with existing buildup.
> 200 mm
(7.87
")
Fig. 7: Mounting of the radar sensor on round vessel tops
In vessels with conical bottom it can be advantageous to mount the
device in the centre of the vessel, as measurement is then possible
down to the bottom.
Installation position

14
4 Mounting
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
Fig. 8: Mounting of the radar sensor on vessels with conical bottom
The centre of the antenna lens is the beginning of the measuring
range and at the same time the reference plane for the min./max.
adjustment, see following diagram:
1
Fig. 9: Reference plane
1 Reference plane
Donotmounttheinstrumentsinorabovethellingstream.Makesure
thatyoudetectthemediumsurface,nottheinowingproduct.
Fig. 10: Mounting of the radar sensor with inowing medium
Reference plane
Inowingmedium

15
4 Mounting
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
For nozzle mounting, the nozzle should be as short as possible and
itsendrounded.Thisreducesfalsereectionsfromthenozzle.
The antenna edge should protrude at least 5 mm (0.2 in) out of the
nozzle.
≥ 5 mm
(0.20")
Fig. 11: Recommended socket mounting of VEGAPULS C 23
Ifthereectivepropertiesofthemediumaregood,youcanmount
VEGAPULS C 23 on sockets longer than the antenna. The socket end
should be smooth and burr-free, if possible also rounded.
Note:
When mounting on longer nozzles, we recommend carrying out a
false signal suppression (see chapter " Parameter adjustment").
Youwillndrecommendedvaluesforsocketheightsinthefollowing
illustration or the table.The values come from typical applications.
Deviating from the proposed dimensions, also longer sockets are
possible, however the local conditions must be taken into account.
d
h
Fig. 12: Socket mounting with deviating socket dimensions
Socket diameter d Socket length h
80 mm 3" ≤300mm ≤11.8in
100 mm 4" ≤400mm ≤15.8in
150 mm 6" ≤600mm ≤23.6in
The mounting location of the radar sensor should be a place where no
otherequipmentorxturescrossthepathoftheradarsignals.
Vessel installations, such as e.g. ladders, limit switches, heating spi-
rals, struts, etc., can cause false echoes and impair the useful echo.
Make sure when planning your measuring point that the radar sensor
has a " clear view" to the measured product.
In case of existing vessel installations, a false signal suppression
should be carried out during setup.
Nozzle
Vessel installations

16
4 Mounting
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
If large vessel installations such as struts or supports cause false
echoes, these can be attenuated through supplementary measures.
Small,inclinedsheetmetalbaesabovetheinstallations"scatter"
theradarsignalsandpreventdirectinterferingreections.
Fig. 13: Cover at, large-area proles with deectors
In liquids, direct the device as perpendicular as possible to the me-
dium surface to achieve optimum measurement results.
Fig. 14: Alignment in liquids
If there are agitators in the vessel, a false signal suppression should
be carried out with the agitators in motion.This ensures that the
interferingreectionsfromtheagitatorsaresavedwiththebladesin
dierentpositions.
Fig. 15: Agitators
Throughtheactionoflling,stirringandotherprocessesinthevessel,
compact foams which considerably damp the emitted signals may
form on the medium surface.
If foams lead to measurement errors, you should use the biggest pos-
sible radar antennas or sensors with guided radar.
Alignment - Liquids
Agitators
Foam generation

17
4 Mounting
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
4.4 Measurement setup - Flow
In general, the following must be observed while mounting the device:
• Mounting the sensor on the upstream or inlet side
• Installationinthecentreoftheumeandverticaltotheliquid
surface
• DistancetotheoverfalloriceorVenturiume
• Min. distance to the max. height of damming for optimum accu-
racy: 250 mm (9.843 in) 2)
Detailed project planning data can be found at the channel manufac-
turers and in the technical literature.
Thefollowingexamplesserveasanoverviewforowmeasurement.
3 ... 4 hmax
90°
23
1
hmax
≥ 2 x hmax
90°
42 3
≥ 250 mm
(9.84")
≥ 250 mm
(9.84")
Fig. 16: Flow measurement with rectangular ume: hmax. = max. lling of the
rectangular ume
1 Overfall orice (side view)
2 Upstream water
3 Tailwater
4 Overfall orice (view from tailwater)
Rectangular overfall
2) At smaller distances the measuring accuracy is reduced, see "Technical
data".

18
4 Mounting
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
2
3 ... 4 x hmax
90°
hmax
B
1
≥ 250 mm
(9.84")
Fig. 17: Flow measurement with Khafagi-Venturi ume: hmax. = max. lling of the
ume; B = tightest constriction in the ume
1 Position sensor
2 Venturi ume
Khafagi-Venturiume

19
5 Connecting to power supply
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
5 Connecting to power supply
5.1 Preparing the connection
Always keep in mind the following safety instructions:
• Carryoutelectricalconnectionbytrained,qualiedpersonnel
authorised by the plant operator
Warning:
Only connect or disconnect in de-energized state.
The operating voltage and the digital bus signal are routed via sepa-
rate two-wire connection cables.
Thedataforpowersupplyarespeciedinchapter"Technical data".
Note:
Power the instrument via an energy-limited circuit (power max. 100 W)
acc. to IEC 61010-1, e.g.
• Class 2 power supply unit (acc. to UL1310)
• SELV power supply unit (safety extra-low voltage) with suitable
internal or external limitation of the output current
Thedeviceissuppliedwithaxedcable.Ifanextensionisrequired,
twisted two-wire cable suitable for RS 485 should be used for the
Modbus signal.
If electromagnetic interference is expected which is above the test
values of EN 61326-1 for industrial areas, shielded cable should be
used.
Make sure that the entire installation is carried out according to the
Fieldbusspecication.Inparticular,makesurethatthebusistermi-
nated with suitable terminating resistors.
We recommend to connect the cable screening to ground potential at
one end on the supply side when using shielded cable.
5.2 Wiring plan
5
1
2
3
4
Fig. 18: Wire assignment in permanently connected connection cable
Wire colour Function Polarity
1 Brown Voltage supply Plus (+)
2 Blue Voltage supply Minus (-)
Safety instructions
Voltage supply
Connection cable
Cable screening and
grounding
Wire assignment, con-
nection cable

20
5 Connecting to power supply
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
Wire colour Function Polarity
3 Black Modbus signal D+ Plus (+)
4 White Modbus signal D- Minus (-)
5 Shielding
