Velleman WC8708 User manual

WC8708
WALL/DESKTOP DCF CLOCK
DCF WAND-/BUREAUKLOK
HORLOGE DCF MURALE/DE BUREAU
RELOJ DCF MURAL/DE SOBREMESA
DCF WAND-/TISCHUHR
STEROWANY DCF ŚCIENNY/BIURKOWY
USER MANUAL 3
GEBRUIKERSHANDLEIDING 8
NOTICE D’EMPLOI 14
MANUAL DEL USUARIO 20
BEDIENUNGSANLEITUNG 25
Rev. 01

WC8708 Rev. 01
11.07.2013 Velleman nv
2

WC8708 Rev. 01
11.07.2013 Velleman nv
3
Use manual
1. Int oduction
To all esidents of the Eu opean Union
Impo tant envi onmental info mation about this p oduct
This symbol on the device or the package indicates that disposal of
the device after its lifecycle could harm the environment. Do not
dispose of the unit (or batteries) as unsorted municipal waste; it
should be taken to a specialized company for recycling.
This device should be returned to your distributor or to a local
recycling service. Respect the local environmental rules.
If in doubt, contact you local waste disposal autho ities.
Thank you for choosing Velleman! Please read the manual thoroughly before
bringing this device into service. If the device was damaged in transit, don't
install or use it and contact your dealer.
2. Safety Inst uctions
Keep the device away from children and unauthorised users.
There are no user-
serviceable parts inside the device. Refer to an
authorized dealer for service and/or spare parts.
3. Gene al Guidelines
Refer to the Velleman® Se vice and Quality Wa anty on the last pages
of this manual.
Indoo use only. Keep this device away form rain,
moisture, splashing and dripping liquids.
Keep this device away from dust and extreme heat.
Protect this device from shocks and abuse. Avoid brute force
when operating the device.
•Familiarise yourself with the functions of the device before actually using
it.
•All modifications of the device are forbidden for safety reasons. Damage
caused by user modifications to the device is not covered by the warranty.
•Only use the device for its intended purpose. Using the device in an
unauthorised way will void the warranty.
•Damage caused by disregard of certain guidelines in this manual is not
covered by the warranty and the dealer will not accept responsibility for
any ensuing defects or problems.

WC8708 Rev. 01
11.07.2013 Velleman nv
4
4. Featu es
•DCF clock with 7 languages (English - German - French - Italian - Spanish
- Dutch - Danish)
•100 year indication (2000-2099)
•temperature indication (°C or °F)
•humidity indication
•weather forecast indication
•alarm with snooze-function
•moon phase indication (8 phases)
5. Ove view
Refer to the illustrations on page 2 of this manual.
display
1 time and status indication
daylight saving time (DST) active
snooze function activated
battery low
alarm enabled
DCF signal OK
2 date and month indication
3 day of the week and moon phase indication (8 phases)
4 weather forecast (4 indications)
5 temperature (°C or °F), trend and comfort indication
trend indication
comfort indication
6 humidity indication
ea D ALARM-button
A
SNOOZE-button E UP-button
B
MAX/MIN-button F DOWN/CF button
C
SET-button G battery compartment
6. Wo king p inciple
The WC8708 contains a receiver which receives a radio-signal from a radio
station located at Mainflingen near Frankfurt, Germany. This long-wave
radio-signal (DCF77, 77.5 kHz) is based on atomic clocks and contains time
and date information. For more information refer to www.ptb.de (PTB =
Physikalisch- Technische Bundesanstalt).
The WC8708 automatically synchronizes with this master clock radio-signal.

WC8708 Rev. 01
11.07.2013 Velleman nv
5
Due to its nature, the radio-signal can be received indoors. However, it
should be noted that the signal is weakened by the presence of concrete and
metal. Therefore the clock must not be installed in concrete basements or
inside metal cages. In large concrete office buildings or apartments, the
clock should be located near a window for better reception. Also avoid
installing the clock near strong magnetic fields or other devices that
generate a lot of electrical noise (e.g. engines).
7. Setting
Refer to the illustrations on page 2 of this manual.
•Insert batteries in the battery compartment [G] (see §10).
Time setting
•Choose a location for the clock (refer to §5). The clock can be wall
mounted or placed on a desktop using the included stand.
•Wait until the clock receives the synchronization signal from the master
clock. The clock will attempt to contact the master clock for 7 minutes. It
will automatically synchronize once every day at a fixed time (2:00 in the
morning). Note that the received signal is usually stronger at night time.
•During synchronization, the DCF-icon flashes. Once synchronized, the
icon is fixed on the display.
•When the clock doesn’t receive the radio-signal, it will not show the DCF-
icon and starts running showing the wrong time. The clock can be set to
the correct time manually (see below).
•To force wave detection, press and hold the CF- button [F] for ±5s. Note
that frequent use of this feature will shorten battery life time.
•To stop wave detection, press the CF- button [F] for ±2s.
•Default the clock is in 24h format. Press the UP-button [E] to switch to
12h format (AM or PM indicated in front of the time). Press and hold the
CF- button [F] for ±5s to re-synchronize the clock.
Setting the date / clock manually
•The date and time can be set manually when the clock is used in a place
without DCF reception (e.g. a basement) or in case synchronization is
temporarily not possible. Note that because of atmospheric conditions at
night time the DCF signal is stronger and travels further.
•Press and hold the SET-button [C] for ±5s. The display shows the year
(flashing).
•To change the setting, use the UP-[E] or DOWN-[F] button. Press the
SET-button [C] to confirm and move to the next adjustable parameter.
Parameter sequence = year – month – date – day language* - hour –
minutes – time zone offset - exit
* language options are: EN (English), GE (German), DA (Danish), ES
(Spanish), NE (Dutch), FR (French) or IT (Italian).
•If no key is pressed within 8s the clock returns to normal operation.

WC8708 Rev. 01
11.07.2013 Velleman nv
6
Ala m setting
•Press and hold the ALARM-button [D] for ±5s. The display shows the
alarm time; the hours are flashing.
•To change the setting, use the UP-[E] or DOWN-[F] button.
•Press the ALARM-button [D] to confirm and move to the minutes-setting.
•After setting the alarm minutes, press the ALARM-button [D] to confirm
and exit to normal display.
•If no key is pressed within 8s the clock returns to normal operation.
8. Ope ation
Ala m handling
•To enable the alarm, press the ALARM-button [D] shortly. The alarm-icon
appears. To disable it, press the ALARM-button [D] again.
•When the set time is reached, the alarm will sound. Format:
0~10s: 1 beep per second
11~20s: 2 beeps per second
21~30s: 4 beeps per second
31~120s: continuous beep.
•To go into snooze mode, press the SNOOZE-button [A]. The alarm is
postponed for ±5 minutes and the snooze-icon appears.
•Pressing any other button will stop and exit the alarm.
Weathe fo ecast [4]
• The weather icon shows a forecast of the weather for the next 24h.
• There are 4 icons:
sun
sun/clouds
clouds
rain
• Place the weather station in a natural ventilated area (e.g. not in a room
with air-conditioning) to get more accurate results.
Tempe atu e display [5]
• The temperature range is 0~50°C (32~122°F).
• To switch between °C and °F display, press the CF button [F] shortly.
• The trend indicator is based on the difference between a recorded
temperature and the current temperature. When the current temperature
is at least 1°C higher than the recorded, the arrow will point up and the
current temperature becomes the recorded. If the temperature is at least
1°C lower than the recorded value, the arrow will point down and the
current temperature becomes the recorded. In all other cases, the arrow
will be flat.
Note: the recorded temperature is set to the current temperature at
start-up or reset of the weather station.

WC8708 Rev. 01
11.07.2013 Velleman nv
7
raising steady falling
Humidity display [6]
• The humidity range is 20~95%.
Comfo t indication [5]
• The comfort level is based on the current temperature and humidity and is
indicated by following icons:
d y
temp.: 0~50°C
humidity <40%
wet
temp.: 0~50°C
humidity >70%
comfo t
temp. 20~28°C
humidity: 40~70%
no icon temp. <20°C or >28°C
humidity: 40~70%
Moon phase [3]
• One of the eight moon phase icons is shown depending on the position of
the moon, the earth and the sun:
new moon waxing crescent first quarter waxing gibbous
full moon waning gibbous last quarter waning crescent
9. Maintenance
• Gently wipe the device regularly with a moist, lint-free cloth. Do not use
alcohol or solvents. Do not apply p essu e on the display.
• Neve submerge the weather station in any liquid.
10. Batte y
• When the battery low icon is shown, insert batteries into the battery
compartment [G] at the back of the weather station.
• Open the battery cover [G] and insert two new 1.5V type AA batteries
(not incl.) following the polarity markings inside the battery compartment.
• Close the battery cover [G].
WARNING:
Do not punctu e o th ow batte ies in fi e as they might
explode. Do not attempt to echa ge non- echa geable
batte ies (Alkaline).
Dispose of batte ies in acco dance with local egulations.
Keep batte ies away f om child en.

WC8708 Rev. 01
11.07.2013 Velleman nv
8
11. Technical specifications
temperature range 0 ~ +50°C (32 ~ 122°F)
humidity range 20 ~ 95%
sampling period 15s
power supply 2 x 1.5V AA batteries LR6C (not incl.)
dimensions 175 x 175 x 28mm
weight 360g
Use this device with o iginal accesso ies only. Velleman nv cannot
be held esponsible in the event of damage o inju y esulted f om
(inco ect) use of this device. Fo mo e info conce ning this p oduct
and the latest ve sion of this use manual, please visit ou website
www.velleman.eu. The info mation in this manual is subject to
change without p io notice.
COPYRIGHT NOTICE
This manual is copy ighted. The copy ight to this manual is owned by Velleman
nv. All worldwide rights reserved. No part of this manual may be copied, reproduced,
translated or reduced to any electronic medium or otherwise without the prior written
consent of the copyright holder.
GEBRUIKERSHANDLEIDING
1. Inleiding
Aan alle ingezetenen van de Eu opese Unie
Belang ijke milieu-info matie bet effende dit p oduct
Dit symbool op het toestel of de verpakking geeft aan dat, als het
na zijn levenscyclus wordt weggeworpen, dit toestel schade kan
toebrengen aan het milieu. Gooi dit toestel (en eventuele
batterijen) niet bij het gewone huishoudelijke afval; het moet bij
een gespecialiseerd bedrijf terechtkomen voor recyclage. U moet
dit toestel naar uw verdeler of naar een lokaal recyclagepunt
brengen. Respecteer de plaatselijke milieuwetgeving.
Hebt u v agen, contactee dan de plaatselijke auto iteiten
bet effende de ve wijde ing.
Dank u voor uw aankoop! Lees deze handleiding grondig voor u het toestel
in gebruik neemt. Werd het toestel beschadigd tijdens het transport,
installeer het dan niet en raadpleeg uw dealer.
2. Veiligheidsinst ucties
Houd buiten het bereik van kinderen en onbevoegden.

WC8708 Rev. 01
11.07.2013 Velleman nv
9
Er zijn geen door de gebruiker vervangbare onderdelen in dit
toestel. Voor onderhoud of reserveonderdelen, contacteer uw
dealer.
3. Algemene ichtlijnen
Raadpleeg de Velleman
®
se vice- en kwaliteitsga antie achteraan deze
handleiding.
Gebruik het toestel enkel binnenshuis. Bescherm tegen
regen, vochtigheid en opspattende vloeistoffen.
Bescherm tegen stof en extreme hitte.
Bescherm tegen schokken en vermijd brute kracht tijdens de
bediening.
•Leer eerst de functies van het toestel kennen voor u het gaat gebruiken.
•Om veiligheidsredenen mag u geen wijzigingen aanbrengen. Schade door
wijzigingen die de gebruiker heeft aangebracht valt niet onder de
garantie.
•Gebruik het toestel enkel waarvoor het gemaakt is. Bij onoordeelkundig
gebruik vervalt de garantie.
•De garantie geldt niet voor schade door het negeren van bepaalde
richtlijnen in deze handleiding en uw dealer zal de verantwoordelijkheid
afwijzen voor defecten of problemen die hier rechtstreeks verband mee
houden.
4. Kenme ken
•DCF-klok met weergave in 7 talen (Engels - Duits - Frans - Italiaans -
Spaans - Nederlands - Deens)
•100-jarige kalender (2000-2099)
•temperatuurweergave in °C of °F
•weergave van de vochtigheidsgraad
•weersvoorspelling
•alarm met snoozefunctie
•weergave van de maanfase (8 fasen)
5. Omsch ijving
Raadpleeg de figuren op pagina 2 van deze handleiding.
display
1 tijd- en statusweergave
zomertijdregeling (DST) ingeschakeld
snoozefunctie ingeschakeld
zwakke batterij

WC8708 Rev. 01
11.07.2013 Velleman nv
10
alarm ingeschakeld
DCF-signaal OK
2 datum- en maandweergave
3 dag van de week en maanfase (8 fasen)
4 weersvoorspelling (4 aanduidingen)
5 weergave temperatuur (°C of °F), trend en comfort
trendweergave
comfortweergave
6 weergave vochtigheidsgraad
achte aan D ALARM-knop
A
SNOOZE-knop E UP-knop
B
MAX/MIN-knop F DOWN/CF-knop
C
SET-knop G batterijvak
6. Wat is het DCF-signaal
De WC8708 bevat een ontvanger die de radiografische signalen (DCF77)
door de tijdseinzender in Frankfurt uitgezonden kan ontvangen. De
tijdseinzender is gekoppeld aan een atoomklok die de tijd- en
datuminformatie bevat. Uw WC8708 zal bij ontvangst van het DCF-signaal
de wijzers automatisch met de atoomklok synchroniseren.
Het radiosignaal is gemakkelijk binnenshuis te ontvangen. De ontvangst kan
echter verzwakken indien er beton en metaal aanwezig is. Het is daarom
niet aan te raden om de klok te installeren in kelders en binnenin een
metalen kooi. De beste locatie om de klok op kantoor of op een flat te
installeren, is naast een raam.
Vermijd ook installatie in de buurt van magnetische velden of apparaten die
elektrische ruis voortbrengen (bv. een motor).
7. De klok instellen
Raadpleeg de afbeeldingen op pagina 2 van deze handleiding.
•Plaats de batterijen in het batterijvak [G] (zie §10).
Tijdsinstelling
•Kies een locatie voor de klok (raadpleeg §5). U kunt de klok aan de muur
hangen of op een tafel plaatsen met behulp van het meegeleverde statief.
•Wacht tot de klok het signaal van de masterklok ontvangt. De klok zoekt
nu gedurende een 7-tal minuten contact met de masterklok. De
automatische synchronisatie gebeurt dagelijks om 02u00 ’s nachts (het
signaal is doorgaans sterker ‘s nachts).
•Tijdens de synchronisatieprocedure knippert het DCF-symbool . Na de
synchronisatie wordt dit symbool vast op de display weergegeven.
